Dell™ Latitude™ 13 7000 Series 2-in-1
Technical Guidebook
January 2015

Table of Contents
Latitude 13
7000 Series 2-in-
1 Product Views
and Technical Specifications
3 -
9
Weight, Dimensions, Top/Right View
4
Back/Left View
5
Undock View
6
Technical Specifications 7-
9
Marketing System Configurations
10 -
16
Operating Systems
11
Intel Architecture
12
Memory
13
Primary Storage and Intel Rapid Start
Technology
14
Connectivity Options
15
Security and Keyboard specifications
16
Detailed Engineering Specifications
17 –
32
Primary storage 18-
20
Ports and connectors
21
Webcam
22
Wireless LAN 23-
24
Mobile Broadband
25
Integrated Graphics Controller
26
Displays
27
Batteries
28
Power Adapters
29
Keyboards
30
Touchpad
31
Operating conditions
32
2

Product Views and
Technical Specifications
3

4
Starting weight:
Tablet: 904.1g (1.99lb),
Docking Base: 764.2g (1.68lb),
Total: 1668.3g (3.67lb) , including ballast.
Dimensions:
Tablet: 320.0mm(X) * 206.0mm(Y) * 10.525mm(Z)
Docking Base: 320.0mm(X) * 227.5mm(Y) * 8.5mm(Z)
Total : 320.0mm(X) * 229.73mm(Y) * 19.925mm(Z)
Latitude 13 7000 Series 2-in-1 : Weight, Dimensions, Top/
Right View
1. Microphone slot
2. ALS
3. Camera status light
4. Camera
5. Power button
6. Power button light
7. Windows key
8. Volume button
9. N-lock slot
10. Keyboard
11. SD slot w/ SD dummy card
12. Touch pad
13. Tablet Display
1234
5
7
8
9
10
11
12
13
6

Latitude 13 7000 Series 2-in-1: Back/Left View
5
1
23
4
5
6
7
8
9
10
1. Finger Printer reader (optional)
2. Tablet smart card reader slot (optional)
3. Tablet rear camera (optional)
4. Audio jack
5. Battery status light
6. DC-in connector
7. USB 3.0 w/ power share connector
8. N-lock slot
9. Mini DP connector
10. USB 3.0 connector

6
Crested Butte 13” Undock View
1. Speaker (left)
2. Tablet hinge pin slot (left)
3. USIM card tray w/ eject hole (optional)
4. Tablet Docking connector-40pin
5. Tablet DC-in connector
6. Tablet hinge pin slot(right)
7. Speaker(right)
8. Undock release button
9. Hinge pin(left)
10. Hinge hook(left)
11. Base docking connector-40pin
12. Hinge stop/ release pin
13. hinge pin(right)
14. Hinge hook(right)
1
2
3
4
956
7
8
10
11
12 13
14

Latitude 13 7000 Series 2-in-1 Technical Specifications
7
Feature
Technical Specification
Model Number
Latitude
13 7000 Series 2-in-1(7350)
Processor Options
Intel® Core
TM M & CoreTM M vPro
Operating System
Microsoft® Windows®
8.1 64-bit
Microsoft® Windows®
8.1 Pro 64-bit
Memory
2,5 Options
DDR3L
-RS SDRAM 1600MHz
Chipset
Integrated with the processor
(Wildcat Point-LP)
Intel Responsiveness Technologies
Optional Intel®
vPro™ technology with Active Management Technology 10.0
Graphics
Intel® Integrated HD Graphics 5300
Display
13.3
“FHD Anti-Glare LCD display with LED backlight display
Storage
5Options
Up to
512GB Solid State Drives
Optical Drive Options
None
Multimedia
High Quality
Stereo Speakers
Stereo global headset jack
Noise reducing
array microphones
2MP FHD
video webcam, optional 8MP FHD Rear webcam
Battery Options
Tablet
- 3cell (30Whr) Lithium Ion battery with ExpressCharge™
Key
board Base - 2cell (20Whr) Lithium Ion battery with ExpressCharge™

8
Latitude 13 7000 Series 2-in-1 Technical Specifications
Power Options
45
Watt AC Adapter
Connectivity options
Wireless
LAN Options:
Intel® Dual Band Wireless-AC 7265 802.11AC Wi-Fi + BT 4.0 LE Wireless Card
Optional Mobile Broadband & GPS Options:
Dell Wireless
TM DW5810 LTE M2 Card
Ports, Slots & Chassis
Stereo
global headset jack
Memory card
reader
Docking connector
, mDP, USB3.0 (2)
Network
connector, optional SIM card slot
2 M2 slots (WLAN
& WWAN)
Optional
SmartCard Reader and optional Fingerprint Reader , optional NFC
N
-Lock slot
Dimensions & Weight
Width:
13” / 320.0mm
Height:
0.8“ / 19.9mm (Touchscreen)
Depth:
9” / 229.73mm
Starting weight: 3.68lbs / 1.67kg (with 3
-cell battery and no-ODD)
Regulatory and Environmental
Compliance
Regulatory Model:
P58G
Regulatory Type:
P58G001
ENERGY STAR
6.1(Windows OS)
EPEAT Registered. For specific country participation and rating, please see www.epeat.net
BFR/PVC
free
Input
Single
Pointing backlit Keyboard
Precision
Touchpad
Systems Management
Intel®
vPro™ Technology’s advanced management features (optional, requires Intel WiFi
® Link
WLAN
)
Warranty and Service
Limited Hardware Warranty
4; Standard 3-year On Site Service after Remote Diagnosis11 (3-3-
3); Optional 3
-year Dell ProSupport™ for IT12 ; 4 year and 5 year service and support options
12

9
Latitude 13 7000 Series 2-in-1 Technical Specifications
1
Some items will be available post-RTS. Offering may also vary by country and by configuration. For complete details, refer to the
Technical Guidebook available on dell.com.
2
A 64-bit operating system is required to support 4GB or more of system
memory
3
Limited Hardware Warranty: For copy of Limited Hardware Warranty, write Dell USA LP, Attn: Warranties, One Dell Way, Round Rock, TX
78682 or see www.dell.com/warranty
4
GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment a
nd will
be less.
5
Based on Dell lab testing using the following configuration: 3-cell battery, integrated Graphics, 4G DDR3 memory and M.2 SATA drive.
Weights vary depending on configuration and manufacturing variability.
6 Dell defines BFR/PVC Free as set forth in the
Inemi Position Statement on the "definition of Low-Halogen Electronics BFR-/CFR-/PVC-
free". Please see our corporate responsibility page at www.dell.com/environment for more information. Some external adapters,
power
cables and service parts are excluded from this definition unless specifically identified as BFR/PVC free.
7
Mobile Broadband: Available in certain countries only. Subject to wireless provider’s broadband subscription and coverage area;
additional charges apply.
8
Onsite Service after Remote Diagnosis: Remote Diagnosis is determination by online/phone technician of cause of issue; may involve
customer access to inside of system and multiple or extended sessions. If issue is covered by Limited Hardware Warranty
(www.dell.com/warranty) and not resolved remotely, technician and/or part will be dispatched, usually within 1 business day following
completion of Remote Diagnosis. Availability varies. Other conditions apply.
9
Dell Services: Availability and terms of Dell Services vary by region. For more information, visit www.dell.com/servicedescriptions.

Marketing System
Configurations
10

Latitude 13 7000 Series 2-in-1 –Operating
Systems
Windows operating system
Microsoft® Windows® 8.1 64
-bit
Microsoft® Windows® 8.1 Pro 64
-bit
OS Media
Support
None
11

Intel®processor Technology
Broadwell Y Architecture
Latitude 13 Series 2-in-1 (7350) is built with Intel Core M & Core M VPro processor
Technology
•Latest Intel 14nm Process Technology.
•Intel®Integrated HD Graphics 5300
•Optional Intel® vPro™ technology with Active Management Technology 10.0
•Intel® Wireless Display 5.0 driver included in Intel WLAN options
Processors Support List UMA Graphics GSP
Intel® Core X4-5Y71 (Dual Core, 1.2GHz, 4M cache, 4.5W) Intel® HD Graphics 5300 No
Intel® Core X1-5Y10c (Dual Core, 0.8GHz, 4M cache, 4.5W) Intel® HD Graphics 5300 No
12

Memory
•Your computer supports a maximum of 8GB1of memory; however, 32-bit operating systems, such as the 32-bit version of
Microsoft® Windows® 7, can only use a maximum of 4GB of address space. Moreover, certain components within the
computer require address space in the 4GB range. Any address space reserved for these components cannot be used by
computer memory; therefore, the amount of memory available to a 32-bit operating system is less than 4GB.
•Greater than 4GB memory requires a 64-bit operating system
•ONLY MEMORY TYPE SUPPORTED: DDR3-LOW VOLTAGE (“DDR3L”)
•NOT BACKWARD COMPATIBLE WITH DDR3 MEMORY
Memory
7350
DIMM Slots
0
(Memory Down)
Minimum Memory Configuration
4GB
Maximum
Memory Configuration* 8GB
DIMM
Configurations:
8G 1600MHz DDR3L (1x8G) x
4G 1600MHz DDR3L (1x4G) x
11GB means 1 billion bytes
13

Primary Storage
Latitude 13 7000
Series 2-in-1 (7350)
128GB
1Mobility SSD x
256GB
1Mobility SSD x
512GB
1Mobility SSD x
Primary Storage and Intel Rapid Start Technology
Mobility Solid State Drives offer highly reliable, durable and lightweight storage. SSDs provide improved performance and operate
quieter and cooler than standard hard drives.
Self-Encrypting drives provide hardware encrypted data protection which can be activated within a few seconds centrally and can
be much safer and faster than software based encryption. Note: Encrypted drives require the system be configured in AHCI mode.
11GB means 1 billion bytes
14

Connectivity Options
Connectivity Option
Latitude 13
7000 Series 2-
in-1 (7350)
Regions Carriers
WWAN
M.2
Dell
WirelessTM 5810 LTE (150Mbps) X
APJ/EMEA/ROW,
Except Malaysia,
China, Indonesia
EMEA: generic (no SIM)
APJ: generic (no SIM)
WLAN
M.2
Intel® Dual Band Wireless
-AC 7265
802.11AC
Wi
-Fi + BT 4.0 LE Wireless Card X
WW except ,
Russia, and
Indonesia
NA
Intel® Dual Band Wireless
-AC 7265
802.11AC
Wi
-Fi + BT 4.0 LE Wireless Card IND X Indonesia NA
Intel® Dual Band Wireless
-AN 7265
802.11AGN
Wi-Fi + BT 4.0 LE Wireless Card X Russia NA
15
WWAN Carriers & Countries
•US, Post RTS: VZN, AT&T, Sprint
•Canada: Generic, No SIM
•Brazil: Generic, no SIM
•EMEA: Generic, no SIM
•APJ: Generic, no SIM

Security and Keyboard specifications
Keyboard Specs Latitude 13 7000 Series 2-in-1 (7350)
Number of keys 82 (U.S)
83 (Europe)
84 (Brazil)
86 (Japan)
Layout QWERTY/AZERTY/Kanji
Size Full sized (19.05-mm key pitch)
Backlit keyboard option •Easy enable/disable via hotkey <Fn+right arrow key>
•3 variable brightness levels
16
Security Hardware
Latitude 13 7000 Series
2-in-1 (7350)
Optional FIPS certified Trusted Platform Module (TPM)
X
Optional Swipe Fingerprint Reader
X
Optional
Smartcard Reader X

Detailed Engineering
Specifications
17

128GB SSD
128GB
1SATA SOLID STATE DRIVE
Capacity (GB)
128
Dimensions inches (W x D x H)
Approximately (
0.866x 3.149 x 0.093
inches)
Interface type and Maximum speed
Up to 6Gb/s (SATA 3.0)
MTBF
0.8M hours
Logical Blocks
250,069,680
Power Source
Power Consumption (reference only)
Typical 2mW
Environmental Operating Conditions (Non
-Condensing):
Temperature Range
0°C to 70°C
Relative Humidity Range
5 to 95%
Op Shock (@0.5ms)
1,500G
Environmental Non
-Operating Conditions (Non-Condensing):
Temperature Range
-40°C to 85°C
Relative Humidity Range
5 to 95%
1For hard drives, GB means 1 billion bytes ; actual capacity varies with preloaded material and operating environment and will be less.
18

256GB SSD
256GB
1SATA SOLID STATE DRIVE
Capacity (GB)
256
Dimensions inches (W x D x H)
Approximately (
0.866x 3.149 x 0.093
inches)
Interface type and Maximum speed
Up to 6Gb/s (SATA 3.0)
MTBF
0.8M hours
Logical Blocks
500,118,192
Power Source
Power Consumption (reference only)
Typical 2mW
Environmental Operating Conditions (Non
-Condensing):
Temperature Range
0°C to 70°C
Relative Humidity Range
10 to 90%
Op Shock (@0.5ms)
1,500G
Environmental Non
-Operating Conditions (Non-Condensing):
Temperature Range
-40°C to 85°C
Relative Humidity Range
5 to 95%
1For hard drives, GB means 1 billion bytes ; actual capacity varies with preloaded material and operating environment and will be less.

512GB SSD
512GB
1SATA SOLID STATE DRIVE
Capacity (GB)
512
Dimensions inches (W x D x H)
Approximately (
0.866x 3.149 x 0.093
inches)
Interface type and Maximum speed
Up to 6Gb/s (SATA 3.0)
MTBF
0.8M hours
Logical Blocks
1,000,215, 216
Power Source
Power Consumption (reference only)
Typical 2mW
Environmental Operating Conditions (Non
-Condensing):
Temperature Range
0°C to 70°C
Relative Humidity Range
5 to 95%
Op Shock (@0.5ms)
1,500G
Environmental Non
-Operating Conditions (Non-Condensing):
Temperature Range
-40°C to 85°C
Relative Humidity Range
5 to 95%
1For hard drives, GB means 1 billion bytes ; actual capacity varies with preloaded material and operating environment and will be less.
