Dell Latitude 7285 User manual

Latitude 7285 2-in-1
Owner's Manual
Regulatory Model: T02J
Regulatory Type: T02J001

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of your tablet.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
©2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks
may be trademarks of their respective owners.
2017 - 07
Rev. A00

Contents
1 System specications.................................................................................................................................... 6
Processor specications....................................................................................................................................................6
System specications........................................................................................................................................................ 6
Memory specications.......................................................................................................................................................7
Video specications........................................................................................................................................................... 7
Audio specications........................................................................................................................................................... 7
Port and connector specications................................................................................................................................... 7
Communication specications..........................................................................................................................................8
Camera specications........................................................................................................................................................8
Display specications.........................................................................................................................................................8
AC adapter specications................................................................................................................................................. 9
Battery specications........................................................................................................................................................ 9
Physical specications..................................................................................................................................................... 10
Active pen specications................................................................................................................................................. 10
Wireless charging mat specications.............................................................................................................................. 11
Environmental specications............................................................................................................................................11
2 Using your tablet.......................................................................................................................................... 12
Turning o Your Tablet..................................................................................................................................................... 12
Before Working Inside Your Tablet.................................................................................................................................. 13
After working inside your tablet...................................................................................................................................... 14
3 Removing and Installing components............................................................................................................15
microSIM card...................................................................................................................................................................15
microSD card.....................................................................................................................................................................16
Display Panel......................................................................................................................................................................17
Removing the display panel....................................................................................................................................... 17
Installing the display panel.........................................................................................................................................23
Battery...............................................................................................................................................................................23
Removing the battery................................................................................................................................................23
Installing the battery.................................................................................................................................................. 24
Power switch board......................................................................................................................................................... 24
Removing the power button board..........................................................................................................................24
Installing the power button board............................................................................................................................ 25
WLAN card....................................................................................................................................................................... 25
Removing the WLAN card........................................................................................................................................ 25
Installing the WLAN card.......................................................................................................................................... 26
PCIe Solid State Drive (SSD)......................................................................................................................................... 26
Removing the SSD module.......................................................................................................................................26
Installing the SSD module..........................................................................................................................................27
WWAN card......................................................................................................................................................................28
Removing the WWAN card.......................................................................................................................................28
Installing the WWAN card.........................................................................................................................................28
Contents 3

Audio board.......................................................................................................................................................................29
Removing the audio port...........................................................................................................................................29
Installing the audio port.............................................................................................................................................30
Front facing camera.........................................................................................................................................................30
Removing the front camera .....................................................................................................................................30
Installing the front camera.........................................................................................................................................31
Rear facing camera...........................................................................................................................................................31
Removing the rear camera........................................................................................................................................ 31
Installing the rear camera..........................................................................................................................................33
Coin cell battery............................................................................................................................................................... 33
Removing the coin cell battery.................................................................................................................................33
Installing the coin cell battery................................................................................................................................... 34
Docking board.................................................................................................................................................................. 35
Removing the docking board....................................................................................................................................35
Installing the docking board...................................................................................................................................... 35
Thunderbolt over Type-C USB bracket.........................................................................................................................36
Removing the thunderbolt over Type-C bracket................................................................................................... 36
Installing the thunderbolt over Type-C USB bracket.............................................................................................37
System Board................................................................................................................................................................... 37
Removing the system board..................................................................................................................................... 37
Installing the system board....................................................................................................................................... 39
Speaker............................................................................................................................................................................. 39
Removing the speaker...............................................................................................................................................39
Installing the speaker.................................................................................................................................................40
Back cover.........................................................................................................................................................................41
Replacing the back cover.......................................................................................................................................... 41
4 Technology and components........................................................................................................................43
Power adapter..................................................................................................................................................................43
Processors........................................................................................................................................................................ 43
Kaby Lake — 7th Generation Intel Core processors............................................................................................. 43
Chipset.............................................................................................................................................................................. 44
Memory features..............................................................................................................................................................44
Display options..................................................................................................................................................................44
Camera features...............................................................................................................................................................44
Starting the camera...................................................................................................................................................44
Starting the camera application............................................................................................................................... 44
Hard drive options............................................................................................................................................................45
Drivers............................................................................................................................................................................... 46
System drivers............................................................................................................................................................46
Disk driver................................................................................................................................................................... 47
Sound, video and game controller drivers...............................................................................................................48
Storage controller drivers..........................................................................................................................................49
Network drivers......................................................................................................................................................... 50
Graphics driver........................................................................................................................................................... 50
Thunderbolt over Type-C.................................................................................................................................................51
Thunderbolt 3 over Type-C....................................................................................................................................... 51
4Contents

Key Features of Thunderbolt 3 over USB Type-C .................................................................................................51
Thunderbolt Icons......................................................................................................................................................52
Dell Active Pen ................................................................................................................................................................ 53
Wireless charging mat..................................................................................................................................................... 54
5 System setup.............................................................................................................................................. 55
Entering BIOS without keyboard................................................................................................................................... 55
System setup options......................................................................................................................................................55
General screen options..............................................................................................................................................55
System Conguration screen options..................................................................................................................... 56
Video screen options................................................................................................................................................. 58
Security screen options.............................................................................................................................................58
Secure Boot screen options..................................................................................................................................... 60
Intel software guard extensions screen options.....................................................................................................60
Performance screen options..................................................................................................................................... 61
Power management screen options.........................................................................................................................61
POST behavior screen options.................................................................................................................................63
Manageability............................................................................................................................................................. 64
Virtualization support screen options......................................................................................................................64
Wireless screen options.............................................................................................................................................64
Maintenance screen options.................................................................................................................................... 65
System logs screen options......................................................................................................................................65
Updating the BIOS ..........................................................................................................................................................65
System and setup password.......................................................................................................................................... 66
Assigning a system password and setup password...............................................................................................66
Deleting or changing an existing system and/or setup password........................................................................67
6 Troubleshooting........................................................................................................................................... 68
Enhanced Pre-boot System Assessment (ePSA)........................................................................................................68
Features:..................................................................................................................................................................... 68
Running the ePSA Diagnostic Utility ...................................................................................................................... 68
Dell wireless charging mat.............................................................................................................................................. 68
Tablet LED.........................................................................................................................................................................69
Diagnostic LED...........................................................................................................................................................69
Real Time Clock (RTC) reset..........................................................................................................................................69
Identifying the AC adapter shipped with your notebooktablet...................................................................................70
7 Contacting Dell............................................................................................................................................. 71
Contents 5

System specications
NOTE: Oerings may vary by region. The following specications are only those required by law to ship with your computer. For
more information about the conguration of your computer, go to Help and Support in your Windows operating system and
select the option to view information about your computer.
Topics:
• Processor specications
• System specications
• Memory specications
• Video specications
• Audio specications
• Port and connector specications
• Communication specications
• Camera specications
• Display specications
• AC adapter specications
• Battery specications
• Physical specications
• Active pen specications
• Wireless charging mat specications
• Environmental specications
Processor specications
Feature Specication
Types • 7th Generation Intel Core i5-7Y54 (4M Cache, up to 3.2 GHz) supports Windows 10 only
• 7th Generation Intel Core i5-7Y57 (4M Cache, up to 3.30 GHz), vPro supports Windows 10 only
• 7th Generation Intel Core i7-7Y75 (4M Cache, up to 3.60 GHz), vPro supports Windows 10 only
System specications
Feature Specication
Chipset Integrated in the processor
DRAM bus width 64-bit; 2 channels
1
6 System specications

Memory specications
Feature Specication
Memory connector Onboard memory
Memory capacity 8 GB and 16 GB (on board)
Memory type LPDDR3—1866 MHz
Video specications
Feature Specication
Type Integrated on system board
UMA controller Intel Integrated HD Graphics 615
External display
support
Optional Dell Adapter - USB Type-C to HDMI/VGA/ Ethernet/USB 3.0/DisplayPort
NOTE: Supports VGA, DisplayPort, HDMI through the docking station.
Audio specications
Feature Specication
Types High-denition audio
Controller Realtek ALC3253
Stereo conversion 24-bit—analog-to-digital and digital-to-analog
Internal interface High-denition audio
External interface Microphone-in, stereo headphones, and speakers universal connector
Speakers Two
Internal speaker
amplier
2 W (RMS) per channel
Volume controls Volume up and Volume down buttons
Port and connector specications
Feature Specication
Audio • Realtek ALC3253-CG Controller
• Microphone-in and stereo headphones/speakers universal connector
Video • Two DisplayPorts over USB Type-C
Memory card reader microSD 3.0
Micro Subscriber
Identity Module
(uSIM) card
Optional
System specications 7

Feature Specication
USIM Optional micro-SIM card slot
Security Lock Noble Wedge Lock slot
Other • Windows Home Button
• Power Button
• I2C for the Dock Pin Keyboard connection
Communication specications
Features Specication
Wireless LAN Intel Dual-Band Wireless-AC 8265 Wi-Fi + BT 4.2 Wireless Card (2x2). Bluetooth Optional
Mobile Broadband
(Optional) • Dell Wireless Qualcomm Snapdragon X7 LTE-A (DW5811e) for AT&T, Verizon, & Sprint (US)
• Dell Wireless Qualcomm Snapdragon X7 LTE-A (DW5811e) (EMEA/ROW)
• Dell Wireless Qualcomm Snapdragon X7 HSPA+ (DW5811e) (China/Indonesia/India)
• Dell Wireless Qualcomm Snapdragon X7 LTE-A (DW5816e for Japan)
WiGig (Optional) Intel Tri-Band Wireless-AC 18265 WiGig + Wi-Fi + BT4.2 Wireless Card WiFi Display (Miracast)
Camera specications
Feature Specication
Type • Front Camera- 720P xed focus
• Rear Camera- 8MP auto focus
• IR Camera- VGA IR camera
Sensor type CMOS sensor technology (Front and Rear camera)
Imaging rate Up to 30 frames per second
Video Resolution • Front Camera- 1280 x 720 pixels
• Rear Camera- 3264 x 2448 pixels
Display specications
Feature Specication
Type 12.3" 3:2 Touch with Corning Gorilla Glass 4 Antireective, and Antismudge
Luminance 400 nits
Height 10.37 inches ( 263.50 mm)
Width 7.28 inches ( 185.06 mm)
Diagonal 12.0 inches (312.42 mm)
Maximum resolution 2880 x 1920
Refresh rate 60 Hz
8 System specications

Feature Specication
Maximum viewing
angles—horizontal
+/-80°
Maximum viewing
angles—vertical
+/-80°
Pixel pitch 0.135 mm
AC adapter specications
Feature Specication
Type 45 W USB Type-C
Input voltage 100 V AC–240 V AC
Input current—
maximum
1.5 A
Input frequency 50 Hz to 60 Hz
Output current 3.34 A (continuous)
Rated output
voltage
20 VDC
Weight 0.64 lbs (0.29 kg)
Dimensions • 1.1 x 1.9 x 4.3 inches
• 28 x 47 x 108 mm
Temperature range
—Operating
0°C to 40°C (32°F to 104°F)
Temperature range
—Non-Operating
–40°C to 70°C (–40°F to 158°F)
Battery specications
Feature Specication
Type • 34 Whr Polymer battery with ExpressCharge
• 34 Whr Long Life Cycle Battery (2-cell)
34 Whr Polymer
battery with
ExpressCharge:
Length 184.00 mm (7.24 inches)
Width 97.00 mm (3.82 inches)
Height 5.9 mm (0.232 inch)
Weight 185.0 g (0.40 lb)
Voltage 11.4 VDC
System specications 9

Feature Specication
34 Whr Long Life
Cycle Battery (2-
cell):
Length 233.06 mm (9.170 inches)
Width 90.73 mm (3.572 inches)
Height 5.9 mm (0.232 inch)
Weight 250.00 g (0.55 lb)
Voltage 11.4 VDC
Temperature range
Operating • Charge: 0°C to 50°C (32°F to 122°F)
• Discharge: 0°C to 70°C (32°F to 158°F)
Non-operating - 20°C to 85°C (- 4°F to 185°F)
Life span 300 discharge per charge cycles
Physical specications
Feature Specication
Weight - Tablet only 1.5 lb (0.7kg)
Weight - Tablet
+Keyboard
3.01 lb (1.36 kg)
Width 10.8 inches (274.8 mm)
Height 0.3 inch (7.9 mm)
Depth 8.2 inches (209.2 mm)
Active pen specications
Feature Specication
Model number PN557W
Length 6.33 inches (160.6 mm)
Diameter 0.37 inch (9.5 mm)
Pressure Resolution 2048 levels
Accuracy/Resolution • Pen contact accuracy is 0.2 mm at 0° tilt; < 0.4 mm at up to 60° tilt in either stationary or in motion state
• Pen hover accuracy is less than 2 mm within hovering height of more or equal to 10 mm in either stationary or
in motion state
Weight (including
battery)
20.4 g with batteries
Battery • Stylus: Primary non- rechargeable AAAA alkaline (1x)
• End cap: 319 lithium coin cell (2x)
10 System specications

Feature Specication
Battery life • Primary AAAA: 12 months for 3 hours/day, 5 days/week
• 319 coin cell (2x): 12 months or more
Stylus Tip • Tip — 0.11 inch (2.8 mm)
• Diameter —0.07 inch (1.8 mm)
Wireless charging mat specications
Feature Specication
Model Number PM30W17
PTU Rated Power 20W (AirFuel mode)
30W (Dell on Dell mode)
Weight 645 g (Charging Mat only)
Dimension:
Legnth 12.28 inch (312.00 mm)
Width 11.17 inch (283.82 mm)
Height 0.69 inch (17.73 mm)
DC Cable length 2.0 m
AC Cable length 1.0 m
Environmental specications
Temperature Specications
Operating 0°C to 35°C (32°F to 95°F)
Storage –40°C to 65°C (–40°F to 149°F)
Relative humidity
—maximum
Specications
Operating 10% to 90% (non-condensing)
Storage 10% to 95% (non-condensing)
Altitude—
maximum
Specications
Operating 0 m to 3048 m (0 to 10,000 ft)
Non-operating 0 m to 10,668 m (0 ft to 35,000 ft)
Airborne
contaminant level
G2 or lower as dened by ISA S71.04–1985
System specications 11

Using your tablet
This section covers how to power on and turn o your tablet including how to install the micro SD and micro SIM cards.
Topics:
• Turning o Your Tablet
• Before Working Inside Your Tablet
• After working inside your tablet
Turning o Your Tablet
Turning o your tablet completely shuts down your tablet. You can turn o your tablet by two ways:
• Using power button
• Using charms menu
1 To turn o your tablet using power button:
a Press and hold the Power button until you see “Slide to shut down your PC” on the screen.
NOTE: After you press and hold the Power button, by default, the tablet enters sleep mode. However, if you
change the power button setting to shut down, the tablet shuts down. To change the power button setting,
go to Control Panel > Power Options > Change Plan Setting > Change Advanced Power Settings. To access
Control Panel, swipe at the right edge of the screen, tap Search, enter Control Panel in the search box, and
then click Control Panel.
b Slide to shut down your tablet.
2
12 Using your tablet

NOTE: You can also turn o your tablet without sliding down the screen. Press and hold the Power button for
>10 seconds to turn o your tablet. You can perform this force shutdown, if your tablet is not responding / behaving
unexpectedly or touch is not working.
2 To turn o your tablet using the charms menu:
a Swipe from the right edge of the display to access the Charms menu.
b Touch Settings —> Power —> Shut down to turn o the tablet.
Before Working Inside Your Tablet
Use the following safety guidelines to help protect your tablet from potential damage and to help to ensure your personal safety. Unless
otherwise noted, each procedure included in this document assumes that the following condition exists:
• You have read the safety information that shipped with your tablet.
WARNING: Before working inside your tablet, read the safety information that shipped with your tablet. For additional safety
best practices information, see the Regulatory Compliance Homepage at www.dell.com/regulatory_compliance
CAUTION: Many repairs may only be done by a certied service technician. You should only perform troubleshooting and simple
repairs as authorized in your product documentation, or as directed by the online or telephone service and support team. Damage
due to servicing that is not authorized by Dell is not covered by your warranty. Read and follow the safety instructions that came
with the product.
CAUTION: To avoid electrostatic discharge, ground yourself by using a wrist grounding strap or by periodically touching an
unpainted metal surface, such as a connector on the back of the tablet.
CAUTION: Handle components and cards with care. Do not touch the components or contacts on a card. Hold a card by its
edges or by its metal mounting bracket.
CAUTION: When you disconnect a cable, pull on its connector or on its pull-tab, not on the cable itself. Some cables have
connectors with locking tabs; if you are disconnecting this type of cable, press in on the locking tabs before you disconnect the
cable. As you pull connectors apart, keep them evenly aligned to avoid bending any connector pins. Also, before you connect a
cable, ensure that both connectors are correctly oriented and aligned.
NOTE: The color of your tablet and certain components may appear dierently than shown in this document.
To avoid damaging your tablet, perform the following steps before you begin working inside the tablet.
1 Ensure that your work surface is at and clean to prevent the tablet cover from being scratched.
2 Turn o your tablet (see Turning O Your Tablet).
Using your tablet 13

3 If the tablet is connected to a docking device (docked) such as the optional docking station or keyboard dock, un-dock it.
4 Disconnect the power adapter from the tablet.
5 Press and hold the power button for a few seconds to remove the ea power from the system board.
CAUTION: To guard against electrical shock, always unplug your tablet from the electrical outlet.
CAUTION: Before touching anything inside your tablet, ground yourself by touching an unpainted metal surface, such as
the metal at the back of the tablet. While you work, periodically touch an unpainted metal surface to dissipate static
electricity, which could harm internal components.
6 Remove the storage SD card from the tablet.
After working inside your tablet
NOTE: Leaving stray loose screws inside your table may severely damage your tablet.
1 Replace all screws and ensure that no stray screws remain inside your tablet.
2 Connect any external devices, peripherals, and cables that you removed before working on your tablet.
3 Replace any media card, SIM card, and any other parts that you removed before working on your tablet.
4 Connect your tablet and all attached devices to their electrical outlets.
5 Turn on your tablet.
14 Using your tablet

Removing and Installing components
This section provides detailed information on how to remove or install the components from your tablet.
Topics:
• microSIM card
• microSD card
• Display Panel
• Battery
• Power switch board
• WLAN card
• PCIe Solid State Drive (SSD)
• WWAN card
• Audio board
• Front facing camera
• Rear facing camera
• Coin cell battery
• Docking board
• Thunderbolt over Type-C USB bracket
• System Board
• Speaker
• Back cover
microSIM card
1 Insert a paperclip or a microSIM card removal tool into the pinhole on the microSIM card tray [1].
2 Insert the microSIM card into the slots indicated on the slot [2].
3 Align the cover with the groove on the tablet and slide it inside to secure the microSIM [3].
3
Removing and Installing components 15

4 You can perform the same steps to remove the microSIM.
microSD card
1 Insert a paperclip or a microSD card removal tool into the pinhole on the microSD card tray [1].
2 Insert the microSD card into the slots indicated on the slot [2].
3 Align the cover with the groove on the tablet and slide it inside to secure the microSD [3].
16 Removing and Installing components

4 You can perform the same steps to remove the microSD.
Display Panel
Removing the display panel
1 Follow the procedure in Before working inside your tablet.
2 Remove the microSIM card and microSD card.
3 To release the display panel (with plastic scribe):
a Remove the M2x4 (4) screws that secure the display panel to the tablet [1].
b Use a plastic scribe to remove the microSIM/microSD cover [2].
Removing and Installing components 17

4 Insert a plastic scribe into the microSIM/microSD slot.
5 Pry the edges starting from microSIM/microSD slot [1, 2].
18 Removing and Installing components

6 To release the display panel (with suction cup):
a Remove the M2x4 (4) screws that secure the display panel to the tablet [1].
b Attach a suction cup to the display panel above the left docking slot, located at the bottom of the system, while inserting a
plastic scribe into the left docking slot to stabilize the system, and then carefully pull open the display panel using the suction
cup.
Removing and Installing components 19

7 Lift the display panel from the tablet.
8 Slide the display panel [1], and ip the display panel [2].
20 Removing and Installing components
