Dell Inspiron 24 5000 Series User manual

Inspiron 24 5000
Service Manual
Computer Model: Inspiron 24–5488
Regulatory Model: W12C
Regulatory Type: W12C007

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make
better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or
loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
Copyright ©2017 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other
trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks may be
trademarks of their respective owners.
2017 - 02
Rev. A00

Contents
Before working inside your computer.............................9
Before you begin ...................................................................................... 9
Safety instructions.................................................................................... 9
Recommended tools................................................................................ 10
Screw list..................................................................................................11
After working inside your computer.............................. 13
Technical overview....................................................... 14
Inside view of your computer................................................................... 14
System-board components......................................................................15
Removing the stand......................................................17
Procedure................................................................................................ 17
Replacing the stand......................................................19
Procedure................................................................................................ 19
Removing the back cover.............................................20
Prerequisites........................................................................................... 20
Procedure............................................................................................... 20
Replacing the back cover.............................................22
Procedure................................................................................................22
Post-requisites........................................................................................ 22
3

Removing the optical drive...........................................23
Prerequisites............................................................................................23
Procedure................................................................................................23
Replacing the optical drive...........................................26
Procedure............................................................................................... 26
Post-requisites........................................................................................ 26
Removing the hard drive.............................................. 27
Prerequisites............................................................................................27
Procedure................................................................................................27
Replacing the hard drive.............................................. 30
Procedure............................................................................................... 30
Post-requisites........................................................................................ 30
Removing the memory modules....................................31
Prerequisites............................................................................................ 31
Procedure................................................................................................ 31
Replacing the memory modules................................... 33
Procedure................................................................................................33
Post-requisites........................................................................................ 34
Removing the wireless card......................................... 35
Prerequisites........................................................................................... 35
Procedure............................................................................................... 35
Replacing the wireless card..........................................37
Procedure................................................................................................37
Post-requisites........................................................................................ 38
4

Removing the heat sink................................................39
Prerequisites........................................................................................... 39
Procedure............................................................................................... 39
Replacing the heat sink................................................ 41
Procedure................................................................................................ 41
Post-requisites......................................................................................... 41
Removing the fan.........................................................42
Prerequisites............................................................................................42
Procedure................................................................................................42
Replacing the fan......................................................... 44
Procedure................................................................................................44
Post-requisites........................................................................................ 44
Removing the coin-cell battery.................................... 45
Prerequisites........................................................................................... 45
Procedure............................................................................................... 45
Replacing the coin-cell battery.....................................47
Procedure................................................................................................47
Post-requisites........................................................................................ 47
Removing the processor.............................................. 48
Prerequisites............................................................................................48
Procedure............................................................................................... 48
Replacing the processor.............................................. 50
Procedure............................................................................................... 50
Post-requisites......................................................................................... 51
5

Removing the microphone........................................... 52
Prerequisites........................................................................................... 52
Procedure............................................................................................... 52
Replacing the microphone........................................... 54
Procedure............................................................................................... 54
Post-requisites........................................................................................ 54
Removing the camera.................................................. 55
Prerequisites........................................................................................... 55
Procedure............................................................................................... 55
Replacing the camera...................................................57
Procedure................................................................................................57
Post-requisites........................................................................................ 57
Removing the VESA-mount bracket.............................58
Prerequisites........................................................................................... 58
Procedure............................................................................................... 58
Replacing the VESA-mount bracket.............................60
Procedure............................................................................................... 60
Post-requisites........................................................................................ 60
Removing the speaker cover........................................ 61
Prerequisites............................................................................................ 61
Procedure................................................................................................ 61
Replacing the speaker cover........................................ 63
Procedure............................................................................................... 63
Post-requisites........................................................................................ 63
6

Removing the speakers................................................64
Prerequisites........................................................................................... 64
Procedure............................................................................................... 64
Replacing the speakers................................................ 66
Procedure............................................................................................... 66
Post-requisites........................................................................................ 66
Removing the control-buttons board............................67
Prerequisites............................................................................................67
Procedure................................................................................................67
Replacing the control-buttons board............................69
Procedure............................................................................................... 69
Post-requisites........................................................................................ 69
Removing the system board.........................................70
Prerequisites............................................................................................70
Procedure................................................................................................ 71
Replacing the system board......................................... 74
Procedure................................................................................................74
Post-requisites........................................................................................ 75
Removing the middle-frame base.................................76
Prerequisites............................................................................................76
Procedure................................................................................................76
Replacing the middle-frame base..................................81
Procedure................................................................................................ 81
Post-requisites......................................................................................... 81
7

Removing the rubber feet............................................ 83
Prerequisites............................................................................................83
Procedure............................................................................................... 83
Replacing the rubber feet............................................ 85
Procedure............................................................................................... 85
Post-requisites........................................................................................ 85
Removing the display assembly....................................86
Prerequisites........................................................................................... 86
Procedure................................................................................................87
Replacing the display assembly....................................88
Procedure............................................................................................... 88
Post-requisites........................................................................................ 88
Clearing forgotten passwords...................................... 90
Procedure............................................................................................... 90
Clearing CMOS settings.............................................. 93
Prerequisites............................................................................................93
Procedure............................................................................................... 93
Post-requisites........................................................................................ 94
Flashing the BIOS........................................................ 95
Diagnostics.................................................................. 96
Getting help and contacting Dell..................................98
Self-help resources..................................................................................98
Contacting Dell........................................................................................98
8

GUID-5D3B1051-9384-409A-8D5B-9B53BD496DE8
Before working inside your
computer
NOTE: The images in this document may dier from your computer
depending on the conguration you ordered.
GUID-D1AE8571-3E47-4D09-AD7C-6AB2F8F0541F
Before you begin
1 Save and close all open les and exit all open applications.
2 Shut down your computer. Click Start → Power → Shut down.
NOTE: If you are using a dierent operating system, see the
documentation of your operating system for shut-down instructions.
3 Disconnect your computer and all attached devices from their electrical outlets.
4 Disconnect all attached network devices and peripherals, such as keyboard,
mouse, and monitor from your computer.
5 Remove any media card and optical disc from your computer, if applicable.
6 After the computer is unplugged, press and hold the power button for 5 seconds
to ground the system board.
GUID-71128823-CE64-4E17-9439-DEE95AF668C4
Safety instructions
Use the following safety guidelines to protect your computer from potential damage
and ensure your personal safety.
WARNING: Before working inside your computer, read the safety
information that shipped with your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
9

WARNING: Disconnect all power sources before opening the computer
cover or panels. After you nish working inside the computer, replace all
covers, panels, and screws before connecting to the electrical outlet.
CAUTION: To avoid damaging the computer, ensure that the work surface is
at and clean.
CAUTION: To avoid damaging the components and cards, handle them by
their edges, and avoid touching pins and contacts.
CAUTION: You should only perform troubleshooting and repairs as
authorized or directed by the Dell technical assistance team. Damage due to
servicing that is not authorized by Dell is not covered by your warranty. See
the safety instructions that shipped with the product or at www.dell.com/
regulatory_compliance.
CAUTION: Before touching anything inside your computer, ground yourself
by touching an unpainted metal surface, such as the metal at the back of
the computer. While you work, periodically touch an unpainted metal surface
to dissipate static electricity, which could harm internal components.
CAUTION: When you disconnect a cable, pull on its connector or on its pull
tab, not on the cable itself. Some cables have connectors with locking tabs
or thumb-screws that you must disengage before disconnecting the cable.
When disconnecting cables, keep them evenly aligned to avoid bending any
connector pins. When connecting cables, ensure that the ports and
connectors are correctly oriented and aligned.
CAUTION: Press and eject any installed card from the media-card reader.
GUID-DEA55279-6FE6-4A1F-A152-21F8A5572B33
Recommended tools
The procedures in this document may require the following tools:
• Phillips screwdriver
• Plastic scribe
10

GUID-BCDC42DB-8C8B-4ED4-B188-110DADCC06A7
Screw list
Table 1. Screw list
Component Secured to Screw type Quantity Screw image
Stand Back cover M4x6 4
Optical-drive assembly Middle-frame
base
M3x5 1
Optical-drive bracket Optical drive M2x2.5 1
Hard-drive assembly Middle-frame
base
M3x5 1
Hard-drive bracket Hard drive M3x3.5 3
Wireless-card bracket Wireless card M2x2.5 1
Heat sink Middle-frame
base
M3x5 1
Fan Middle-frame
base
M3x5 2
VESA-mount bracket Middle-frame
base
M3x5 4
System board Middle-frame
base
M3x5 5
Speaker cover Middle-frame
base
M3x3 4
Middle-frame base Display
assembly
M3x5 16
11

Component Secured to Screw type Quantity Screw image
Middle-frame base Display panel M3x3 4
Rubber feet Display
assembly
M3x5 2
12

GUID-06588814-2678-4667-9FF9-C009F4BCE185
After working inside your
computer
CAUTION: Leaving stray or loose screws inside your computer may severely
damage your computer.
1 Replace all screws and ensure that no stray screws remain inside your computer.
2 Connect any external devices, peripherals, or cables you removed before working
on your computer.
3 Replace any media cards, discs, or any other parts that you removed before
working on your computer.
4 Connect your computer and all attached devices to their electrical outlets.
5 Turn on your computer.
13

GUID-93575C2B-9DA3-42EF-B01E-9C841B3CE7F5
Technical overview
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
GUID-147AC8D0-F246-4849-B0E4-1685403CABF0
Inside view of your computer
1 speaker cover 2 VESA-mount bracket
3 control-buttons board 4 hard-drive assembly
5 optical-drive assembly 6 middle-frame base
14

7 right microphone (touch-screen
models only)
8 camera
9 fan 10 left microphone (touch-screen
models only)
11 heat sink 12 wireless card
13 memory modules 14 coin-cell battery
15 system board
GUID-10780793-CEA7-4C74-9763-8F42F335BD8B
System-board components
1 display-backlight cable connector 2 control-buttons board cable
connector
3 display-cable connector 4 hard-drive data cable connector
15

5 optical-drive data cable connector 6 hard-drive and optical-drive power
cable connector
7 touch-screen board cable connector 8 fan-cable connector
9 processor socket 10 wireless-card slot
11 memory-module slots (2) 12 camera and microphone-cable
connector
13 CMOS jumper 14 password jumper
15 speaker-cable connector
16

GUID-4BBD3587-8BDA-47F1-ACEB-3CE6AB50FBB3
Removing the stand
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
GUID-65C00A99-7280-4E08-9A59-743A8B81763A
Procedure
1 Using a plastic scribe, pry the stand cover o the back cover.
2 Slide and remove the stand cover from the back cover.
1 back cover 2 stand cover
3 stand
17

3 Remove the four screws (M4x6) that secure the stand to the back cover.
4 Lift the stand o the back cover.
1 back cover 2 M4x6 screws (4)
3 stand
18

GUID-A1A7E0D7-52BF-4F80-84FE-DF5301AE97BA
Replacing the stand
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
GUID-0120D3E9-7648-47E6-A44B-75EF2CF30854
Procedure
1 Align the screw holes on the stand bracket with the screw holes on the back
cover.
2 Replace the four screws (M4x6) that secure the stand bracket to the back
cover.
3 Slide and replace the stand cover on the stand bracket.
19

GUID-AE7F608F-4CAF-464A-B977-4C4D9BB3963A
Removing the back cover
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
GUID-22F48CCD-4C2A-4D29-9089-89A6B3CFA736
Prerequisites
Remove the stand.
GUID-EF8166AC-F5F0-4FAF-8D88-0D70CA4A4132
Procedure
CAUTION: Do not remove the back cover unless you need to install internal
accessories for your computer.
1 Using your ngertips, pry the back cover from the display assembly.
20
