Dell Latitude 3000 Series User manual

Dell™ Latitude™ 3000 Series
Latitude 14/Model 3440
Latitude 15/Model 3540
Technical Guidebook
August 2013

Table of Contents
Latitude 3000 Product Views and
Technical Specifications
3 -
11
14” Weight, Dimensions, Top/Right View
4
14” Back/Left View
5
15” Weight, Dimensions, Top/Right View
6
15” Back/Left View
7
Latitude 3000 Series Technical
Specifications 8-
11
Marketing System Configurations
12 -
18
Operating Systems
13
Intel Architecture
14
Memory
15
Primary Storage
16
Connectivity Options
17
Security and Keyboard specifications
18
Detailed Engineering Specifications
19
–
45
Primary storage 20-
23
Optical drives
24
Ports and connectors
25
Webcams
26
Wireless 27-
30
Wired communications
31
Integrated Graphics Controller
32
Discrete Graphics 33-
34
Displays 35-
40
Batteries
41
Power Adapters
42
Keyboards
43
Touchpad
44
Operating conditions and MIL-STD-
810G Testing
45
2

Latitude 3000 Series
Product Views and
Technical
Specifications
3

Latitude 14 3000 Series Weight, Dimensions, Top/Right View
4
1. Microphone
2. Camera
3. Camera status light
4. Display
5. Optical drive
6. Optical drive eject button
7. USB 2.0 connector
8. Touchpad
9. Touchpad buttons (2)
10. SD Card Reader
11. Wireless status light
12. Battery status light
13. Hard drive activity light
14. Power status light
15. Keyboard
16. Power button
Starting weight:
4.3lbs (2.0kg) with a 4-cell battery
Dimensions:
Width: 346.0 mm (13.62 inches)
Depth: 245.0 mm (9.65 inches)
Height; 25.0 mm (.98 inches)

Latitude 14 3000 Series Back/Left View
1. Security cable slot
2. Power connector
3. Cooling vents
4. VGA connector
5. Network connector
6. USB 3.0(2) connectors
7. Audio connector
5

Latitude 15 3000 Series Weight, Dimensions, Top/Right View
6
1. Microphone
2. Camera
3. Camera status light
4. Display
5. Security cable slot
6. Optical drive
7. Optical drive eject button
8. USB 2.0 connector
9. Touchpad
10. Touchpad buttons (2)
11. SD card reader
12. Wireless status light
13. Battery status light
14. Hard drive status light
15. Power status light
16. Keyboard
17. Power button
Starting weight:
4.8lbs (2.2kg) with a 4-cell battery
Dimensions:
Width: 376.0 mm (14.8 inches)
Depth: 259.0 mm (10.2 inches)
Height; 25.3 mm (.99 inches)

Latitude 15 3000 Series Back/Left View
7
1. Power connector
2. Cooling vents
3. VGA connector
4. Network connector
5. USB 3.0(2) connectors
6. USB 2.0 connectors
7. Audio connector

Latitude 14 3000 Series Technical Specifications
8
Model Number
Latitude 3440
Processor
Options
4th Generation Intel ® Core i3
–4010U processor
4th Generation Intel ® Core i5
–4200U processor
4th Generation Intel ® Core i5
–4300U processor
4th Generation Intel ® Core i7
–4500U processor (offered only in Brazil)
Operating System
Options
Windows 8, Windows 8 Pro, Window 8 Single Language (Emerging Market), all 64 Bit
Windows 7 Home Premium, Windows 7 Professional, Windows 7 Home Basic (Emerging Market), 32 and
64 Bit
Ubuntu 12.04 Long Term Support (LTS) SP1
Memory
1
2GB DDR3L 1 DIMM
4GB DDR3L 1 DIMM
6GB DDR3L 2 DIMMs
8GB DDR3L 2 DIMMs
Chipset
Intel® HM87
Graphics
Intel® HD 4400 Graphics for 4th Generation Intel® processors
nVidia
GeForce™ GT 740M
Display Options
14.0” HD, (1366 X 768) 16:9, Anti
-Glare
14.0” HD+, (1600 X 900) 16:9. Anti
-Glare
14.0” HD, (1366 X 768) 16:9. Touchscreen with Truelife
Storage Options
1TB
5400 RPM Hard Drive
750GB 5400 RPM Hard Drive
500GB 5400 RPM Hard Drive
320GB 5400 RPM Hard Drive
Optical Drives
Internal / Non
-Swappable Tray Load 8X DVD+/-RW

Latitude 14 3000 Series Technical Specifications
9
1 GB means 1 billion bytes and TB equals 1 trillion bytes; significant system memory may be used to support graphics, depending on system memory size and other factors, actual capacity varies with preloaded material and operating environment
and will be less.
2 Weights vary depending on configuration and manufacturing variability.
Multimedia
Integrated 720p HD video webcam and Dell Webcam Central software (Windows 7), Win8 provides native webcam software
High Quality Speakers
Stereo headphone/microphone combo jack
Integrated microphone
Battery Options
4 cell (40 WHr)
6 cell (65 WHr)
Power Options
65W AC adapter
90W AC adapter
Connectivity Options
Wireless LAN Options:
Dell Wireless™ 1705 1X1 802.11bgn + Bluetooth 4.0
Intel® 7260 2X2 802.11bgn + Bluetooth 4.0 + WiDi
*
*Requires an Intel wireless card, a compatible Media Adapter (sold separately) and an HDMI or composite AV-enabled display.
Ports & Slots, Expansion
Gigabit Ethernet (RJ
-45)
USB 3.0 (2), USB 2.0 (1)
VGA
4in 1 memory card reader (SD, SDHC, MS, MS Pro)
Kensington lock slot
Stereo
headphone/microphone combo jack
Optional USB docking
Security
Dell Data Protection|Protected Workspace standard (1 yr free), Dell Data Protection|Security Tools standard, Dell Data Protec
tion|Encryption
(optional)
Dimensions & Weight
2
346 mm x 245 mm x 25.0 mm (w/ 4 cell Non
-Touch), 29.6 mm (w/ 6 cell Non-Touch)
346 mm x 245 mm x 27.9 mm (w/ 4 cell Touch), 32.9 mm (w/ 6 cell Touch)
13.62” x 9.65” x 0.98” (w/ 4 cell Non
-Touch), 1.17” (w 6 cell Non-Touch)
13.62” x 9.65” x 1.1” (w/ 4 cell Touch), 1.3” (w/ 6 cell Touch)
Starting weight: 4.3 lbs./2.0kg with 4 cell battery, 4.6 lbs./2.1 kg with 6 cell battery
Regulatory &
Environmental
Compliance
Regulatory Model: P37G
Regulatory Type: P37G004
Energy Star 5.2 Qualified
EPEAT Bronze Registered
California (CEC) Battery Charger Regulation
NOTE: Optional features listed in this document are suggested offering for US only.
Regional optional features may vary in other countries. EPEAT registration varies by country.
Please see
www.epeat.net for specific country registration and rating.

Latitude 15 3000 Series Technical Specifications
10
Model Number
Latitude 3540
Processor
Options
4th Generation Intel ® Core i3
–4010U processor
4th Generation Intel ® Core i5
–4200U processor
4th Generation Intel ® Core i5
–4300U processor
4th Generation Intel ® Core i7
–4500U processor (offered only in Brazil)
Operating System
Options
Windows 8, Windows 8 Pro, Window 8 Single Language (Emerging Market), all 64 Bit
Windows 7 Home Premium, Windows 7 Professional, Windows 7 Home Basic (Emerging Market), 32 and
64 Bit
Ubuntu 12.04 Long Term Support (LTS) SP1
Memory
1
2GB DDR3L 1 DIMM
4GB DDR3L 1 DIMM
6GB DDR3L 2 DIMMs
8GB DDR3L 2 DIMMs
Chipset
Intel® HM87
Graphics
Intel® HD 4400 Graphics for 4th Generation Intel® processors
AMD Radeon™ HD 8850M
Display Options
15.6” HD, (1366 X 768) 16:9, Anti
-Glare
15.6” Full HD, (1920 X 1080) 16:9. Anti
-Glare
15.6” HD, (1366 X 768) 16:9. Touchscreen with Truelife
Storage Options
1TB
5400 RPM Hard Drive
750GB 5400 RPM Hard Drive
500GB 5400 RPM Hard Drive
320GB 5400 RPM Hard Drive
Optical Drives
Internal / Non
-Swappable Tray Load 8X DVD+/-RW

Latitude 14 3000 Series Technical Specifications
11
1 GB means 1 billion bytes and TB equals 1 trillion bytes; significant system memory may be used to support graphics, depending on system memory size and other factors, actual capacity varies with preloaded material and operating environment
and will be less.
2 Weights vary depending on configuration and manufacturing variability.
Multimedia
Integrated 720p HD video webcam and Dell Webcam Central software (Windows 7), Win8 provides native webcam software
High Quality Speakers
Stereo headphone/microphone combo jack
Integrated microphone
Battery Options
4 cell (40 WHr)
6 cell (65 WHr)
Power Options
65W AC adapter
90W AC adapter
Connectivity Options
Wireless LAN Options:
Dell Wireless™ 1705 1X1 802.11bgn + Bluetooth 4.0
Intel® 7260 2X2 802.11bgn + Bluetooth 4.0 + WiDi
*
*Requires an Intel wireless card, a compatible Media Adapter (sold separately) and an HDMI or composite AV-enabled display.
Ports & Slots, Expansion
Gigabit Ethernet (RJ
-45)
USB 3.0 (2), USB 2.0 (1)
VGA
4in 1 memory card reader (SD, SDHC, MS, MS Pro)
Kensington lock slot
Stereo
headphone/microphone combo jack
Optional USB docking
Security
Dell Data Protection|Protected Workspace standard (1 yr free), Dell Data Protection|Security Tools standard, Dell Data Protec
tion|Encryption (optional)
Dimensions & Weight
2
376 mm x 259 mm x 25.3 mm (w/ 4 cell Non
-Touch), 31.3 mm (w/ 6 cell Non-Touch)
376 mm x 259 mm x 27.85 mm (w/ 4 cell Touch), 33.85 mm (w/ 6 cell Touch)
14.8” x 10.2” x 0.99” (w/ 4 cell Non
-Touch), 1.23” (w 6 cell Non-Touch)
14.8” x 10.2” x 1.1” (w/ 4 cell Touch), 1.33” (w/ 6 cell Touch)
Starting weight: 4.8 lbs./2.2kg with 4 cell battery, 5.1 lbs./2.3 kg with 6 cell battery
Regulatory &
Environmental Compliance
Regulatory Model: P28F
Regulatory Type: P28F004
Energy Star 5.2 Qualified
EPEAT Bronze Registered
California (CEC) Battery Charger Regulation
NOTE: Optional features listed in this document are suggested offering for US only.
Regional optional features may vary in other countries. EPEAT registration varies by country. Please
see
www.epeat.net for specific country registration and rating.

Marketing System
Configurations
12

Latitude 3000 Series –Operating Systems
Windows operating system
Microsoft® Windows 8® 64 bit
Microsoft® Windows 8® Single Language (Emerging
Market) 64bit
Microsoft® Windows 8® Pro 64 bit
Microsoft
® Windows 7® Home Basic (Emerging Market) SP1 (32
and 64 bit),
Microsoft® Windows 7® Home Premium SP1 (32 and 64 bit),
Microsoft
® Windows 7® Professional SP1 (32 and 64 bit),
(all Win 7 32 bit versions
not available until Oct 2013)
Other
Linux Ubuntu 12.04 Long Term
Support SP1
13

Intel®processor Technology
Haswell Architecture
Latitude 3000 Series is built with Intel 4th Generation Core Processor Technology
•4th generation ULT (2-chip) Processor and Chipset
•Intel®Integrated HD Graphics 4400
•Intel® Wireless Display 4.1 driver included in Intel WLAN options
Processors Support List UMA Graphics
Intel® Core™ i5
-4200U
Intel® HD Graphics 4400
Intel® Core™ i3
-4010U
Intel® HD Graphics 4400
Intel® Core™ i7
-4500U (only available in Brazil)
Intel® HD Graphics 4400
Intel® Core™ i5
-4300U (available Oct ‘13)
Intel® HD Graphics 4400
14

Memory
•Your computer supports a maximum of 8GB1of memory when you use two 4GB DIMMs; however, 32-bit
operating systems, such as the 32-bit version of Microsoft® Windows® 7, can only use a maximum of 4GB of
address space. Moreover, certain components within the computer require address space in the 4GB range. Any
address space reserved for these components cannot be used by computer memory; therefore, the amount of
memory available to a 32-bit operating system is less than 4GB.
•Greater than 4GB memory requires a 64-bit operating system.
•ONLY MEMORY TYPE SUPPORTED: DDR3-LOW VOLTAGE (“DDR3L”)
•NOT BACKWARD COMPATIBLE WITH DDR3 MEMORY
Memory
14/15 3000 Series
DIMM Slots
2
Minimum Memory Configuration
2GB
Maximum
Memory Configuration* 8GB
DIMM
Configurations:
8G 1600MHz DDR3L (2x4G) x
6G 1600MHz DDR3L (1x4G+1x2G) x
4G 1600MHz DDR3L (1x4G) x
2G 1600MHz DDR3L (1x2G) x
11GB means 1 billion bytes
15

Primary Storage
14/15 3000 Series
320GB
15400rpm x
500GB
15400rpm x
750GB
15400rpm x
1TB
5400rpm x
Primary Storage
11GB means 1 billion bytes
16

Connectivity Options
Connectivity Option 14/15 3000 Series
WLAN
Intel®Centrino® 7260 Wireless + WiDi
(802.11a/b/g/n 2x2 + Bluetooth 4.0) x
Dell WirelessTM DW1705 Wi-Fi
(802.11b/g/n 1x1 + Bluetooth 4.0) x
WWAN –Not supported on Latitude 14/15 3000 Series
17
NOTE : Standalone Bluetooth 4.0 module is no longer available. Bluetooth 4.0 is only
available via WLAN+BT combo cards, such as the Intel®Centrino®7260 as indicated above.

Security and Keyboard specifications
Keyboard Specs
Number of keys 104 (U.S. and Canada)
105 (Europe)
107 (Brazil)
108 (Japan)
Layout QWERTY/AZERTY/Kanji
Size full sized (19-mm key pitch)
Backlit keyboard option •None
18
Security Software
14/15 3000 Series
Dell Data
Protection|Security Tools (standard) X
Dell Data
Protection|Protected Workspace (standard) (1 yr free) X
Dell Data
Protection|Encryption (optional) X
NOT FIPS certified Trusted Platform Module (TPM)
X

Detailed Engineering
Specifications
19

320GB HDD 5400 RPM
320GB HDD 5400 RPM
Capacity (GB) 320GB
Dimensions inches (W x D x H) Approximately (2.760 x 3.959 x 0.276 inches)
Interface type and Maximum speed Up to 6Gb/s (SATA 3.0)
MTBF 550,000 hours
Logical Blocks 625142448
Power Source
Power Consumption (reference only) Idle 0.7W, Active 3.25 W
Environmental Operating Conditions (Non
-Condensing):
Temperature Range 5°C to 60°C
Relative Humidity Range 5 to 90%
Op Shock (@2ms) 350G
Environmental Non
-Operating Conditions (Non-Condensing):
Temperature Range -40°C to 65°C
Relative Humidity Range 5 to 95%
1For hard drives, GB means 1 billion bytes ; actual capacity varies with preloaded material and operating environment and will be less.
20
