Set up your Latitude 5401
NOTE: The images in this document may dier from your computer depending on the conguration you ordered.
1 Connect the power adapter and press the power button.
NOTE: To conserve battery power, the battery might enter power saving mode. Connect the power adapter and press
the power button to turn on the computer.
2 Finish Windows setup.
Follow the on-screen instructions to complete the setup. When setting up, Dell recommends that you:
• Connect to a network for Windows updates.
NOTE: If connecting to a secured wireless network, enter the password for the wireless network access when
prompted.
• If connected to the internet, sign-in with or create a Microsoft account. If not connected to the internet, create an oine account.
• On the Support and Protection screen, enter your contact details.
3 Locate and use Dell apps from the Windows Start menu—Recommended
1
Set up your Latitude 5401 5

Table 1. Locate Dell apps
Resources Description
My Dell
Centralized location for key Dell applications, help articles, and other important information about your
computer. It also noties you about the warranty status, recommended accessories, and software updates if
available.
SupportAssist
Pro-actively checks the health of your computer’s hardware and software. The SupportAssist OS Recovery
tool troubleshoots issues with the operating system. For more information, see the SupportAssist
documentation at www.dell.com/support.
NOTE: In SupportAssist, click the warranty expiry date to renew or upgrade your warranty.
Dell Update
Updates your computer with critical xes and latest device drivers as they become available. For more
information about using Dell Update, see the knowledge base article SLN305843 at www.dell.com/support.
Dell Digital Delivery
Download software applications, which are purchased but not pre-installed on your computer. For more
information about using Dell Digital Delivery, see the knowledge base article 153764 at www.dell.com/
support.
4 Create recovery drive for Windows.
NOTE: It is recommended to create a recovery drive to troubleshoot and x problems that may occur with Windows.
For more information, see Create a USB recovery drive for Windows.
6Set up your Latitude 5401

Identifier GUID-2D4FD3BB-D11E-4568-9B46-51EF228459EA
Status Released
Create a USB recovery drive for Windows
Create a recovery drive to troubleshoot and x problems that may occur with Windows. An empty USB ash drive with a minimum capacity
of 16 GB is required to create the recovery drive.
NOTE: This process may take up to an hour to complete.
NOTE: The following steps may vary depending on the version of Windows installed. Refer to the Microsoft support site for
latest instructions.
1 Connect the USB ash drive to your computer.
2 In Windows search, type Recovery.
3 In the search results, click Create a recovery drive.
The User Account Control window is displayed.
4 Click Yes to continue.
The Recovery Drive window is displayed.
5 Select Back up system les to the recovery drive and click Next.
6 Select the USB ash drive and click Next.
A message appears, indicating that all data in the USB ash drive will be deleted.
7 Click Create.
8 Click Finish.
For more information about reinstalling Windows using the USB recovery drive, see the Troubleshooting section of your product's
Service Manual at www.dell.com/support/manuals.
2
Create a USB recovery drive for Windows 7

Identifier GUID-E2915B54-6C0A-41EB-9BAD-A5EE2F68190F
Status Released
Chassis overview
Topics:
• Display view
• Left view
• Right view
• Palmrest view
• Bottom view
Identifier GUID-6EA8D55F-CE6F-47C3-B17E-DFEF46B2B092
Status Released
Display view
3
8 Chassis overview

1 Array microphone
2 Camera shutter
3 Camera
4 Camera status light
5 Array microphone
6 LCD panel
7 LED activity light
Identifier GUID-98DA4F7C-EECF-45EE-B79A-881FFA8ABF9C
Status Released
Left view
1 Power connector port
2 USB 3.1 Gen 2(USB Type-C) port with Thunderbolt
3 USB 3.1 Gen 1 port
4 Smart card reader (optional)
Chassis overview 9

Identifier GUID-BAAE19B3-EA97-46A6-8033-9D1DA79CBF78
Status Released
Right view
1 microSD card reader
2 micro-SIM card slot (optional)
3 Headset/ Microphone port
4 USB 3.1 Gen 1 port
5 USB 3.1 Gen 1 port with PowerShare
6 HDMI port
7 Network port
8 Wedge-shaped lock slot
10 Chassis overview

Identifier GUID-8C870C06-D314-4B02-A718-74F7B8030637
Status Released
Palmrest view
1 Power button with optional ngerprint
2 Keyboard
3 Contactless smart card reader (optional)
4 Touchpad
Chassis overview 11

1 Power button with optional ngerprint
2 Keyboard
3 Touchpad
12 Chassis overview

Identifier GUID-267B22C4-7360-4373-B88A-CF9740CEAB5B
Status Released
Bottom view
1 Service tag label
2 Speakers
Chassis overview 13

Identifier GUID-26CC9B57-795F-4689-8649-667D70D1F3BD
Status Released
Technical specications
NOTE: Oerings may vary by region. The following specications are only those required by law to ship with your computer. For
more information about the conguration of your computer, go to Help and Support in your Windows operating system and
select the option to view information about your computer.
Identifier GUID-9735FCAB-1A62-42BB-A7CD-04A062AEF546
Status Released
Chipset
Table 2. Chipset
Description Values
Chipset CM246
Processor 9th Generation Intel Core i5/i7
DRAM bus width Dual 64 bit
Flash EPROM 24/32 MB(32 MB for Vpro SKU)
PCIe bus PCIe 3.0
Identifier GUID-BFA52F40-8AD1-4DF0-8D0F-942766BC2118
Status Released
Processors
Table 3. Processors
Description Values
Processors 9th Generation Intel Core
i5-9300H
9th Generation Intel Core
i5-9400H
9th Generation Intel Core
i7-9850H
Wattage 35 W 35 W 35 W
Core count 4 4 6
Thread count 8 8 12
4
14 Technical specications

Description Values
Speed 4.1 GHz 4.3 GHz 4.6 GHz
Cache 8M 8M 12M
Integrated graphics Intel UHD Graphics 630 Intel UHD Graphics 630 Intel UHD Graphics 630
Identifier GUID-F07064B8-2EB4-49EC-88A8-43B102E42417
Status Released
Memory
Table 4. Memory specications
Description Values
Slots Two-SODIMM slots
Type Dual-channel DDR4
Speed 2666 MHz
Maximum memory 32 GB
Minimum memory 4 GB
Memory size per slot 16 GB
Congurations supported • 8 GB DDR4 (2 x 4 GB)
• 8 GB DDR4 (1 x 8 GB)
• 16 GB DDR4 (2 x 8 GB)
• 16 GB DDR4 (1 x 16 GB)
• 32 GB DDR4 (2 x 16 GB)
Identifier GUID-29AB3B25-B4D9-4B9A-B1BF-821E8A6A7B8F
Status Released
Ports and connectors
Table 5. External ports and connectors
Description Values
External:
Network One RJ-45, 10/100/1000
USB • Two USB 3.1 Gen 1 port
• One USB 3.1 Gen 1 with PowerShare
• One USB 3.1 Gen 2 (Type-C) with Thunderbolt
Technical specications 15

Description Values
Audio One Universal Jack (headset + mic phone in + line in support) port
Video One HDMI 2.0 port
Media card reader One SD-card slot (Optional), One microSD- card slot
Docking port Supported
Power adapter port One
Security Wedge-shaped lock slot
Table 6. Internal ports and connectors
Description Values
Internal:
M.2 One M.2 2280/2230 slot for solid-state drive
NOTE: To learn more about the features of dierent types
of M.2 cards, see the knowledge base article SLN301626.
Identifier GUID-0ADBC39B-BF43-40EB-BFC0-6F7114D249D1
Status Released
Storage
Your computer supports one of the following congurations:
• 2.5-inch 5400rpm hard-disk drive
• 2.5 inch 7200rpm Hard-drive drive
• M.2 2230 solid-state drive
• M.2 2280 solid-state drive
Table 7. Storage specications
Storage type Interface type Capacity
2.5-inch 5400rpm hard-disk drive SATA up to 6 Gbps Up to 1 TB
2.5 inch 7200rpm Hard-drive drive SATA up to 6 Gbps Up to 1 TB
M.2 2230 solid-state drive PCIe NVMe PCIe Gen3x2 NVMe, up to 16 Gbps Up to 512 GB
M.2 2280 solid-state drive PCIe NVMe PCIe Gen3x4 NVMe, up to 32 Gbps Up to 1 TB
M.2 2280 solid-state drive Class 20 SATA Class 20 Up to 512 GB
16 Technical specications

Identifier GUID-7DF32F47-45CF-4A08-AD99-B01EEC4F3CE6
Status Released
Dimensions and weight
Table 8. Dimensions and weight
Description Values
Height:
Front 20.4 mm (0.8 in.)
Rear 22.85 mm (0.9 in.)
Width 323.05 mm (12.72 in.)
Depth 216 mm (8.5 in.)
Weight 1.53 kg (3.37 lb)
NOTE: The weight of your computer depends on the conguration
ordered and the manufacturing variability.
Identifier GUID-2959A596-4E1F-4C1B-9E6C-857583B2F398
Status Released
Operating system
• Windows 10 Home (64-bit)
• Windows 10 Professional (64-bit)
• Windows 10 Pro for Workstations (64-bit)
• Red Hat 7.5
Identifier GUID-25120817-DDDF-4AED-BAF6-CD32F9074C86
Status Released
Communications
Ethernet
Table 9. Ethernet specications
Description Values
Model number Integrated Connection I219-LM/I219-V Ethernet (RJ-45)
Transfer rate 10/100/1000
Technical specications 17

Wireless module
Table 10. Wireless module specications
Description Values
Model number Intel Dual Band Wireless AC
9560 (802.11ac) 2x2 + Bluetooth
5.0
Qualcomm QCA61x4A (DW1820)
802.11ac Dual Band (2x2)
Wireless Adapter + Bluetooth 4.2
Intel AX200 + Bluetooth 5.0
Transfer rate 1.73 Gbps • 802.11ac - Up to 867 Mbps
• 802.11n - Up to 450 Mbps
• 802.11a/g - Up to 54 Mbps
• 802.11b - Up to 11 Mbps
2400 Mbps
Frequency bands supported 2.4/ 5 GHz (160 MHz) 2.4 GHz (802.11b/g/n) and 5
GHz (802.11a/n/ac)
2.4/ 5 GHz
Wireless standards WiFi 802.11b/g/a/n/ac, • 802.11a, 802.11b, 802.11g,
802.11n and 802.11ac
• Dual-mode Bluetooth 4.2,
BLE (HW ready, SW depends
on OS)
• WiFi 802.11a/b/g
• Wi-Fi 4 (WiFi 802.11n)
• Wi-Fi 5 (WiFi 802.11ac)
• Wi-Fi 6 (WiFi 802.11ax)
Encryption 64/128-bit encryption 128-bit encryption • 64-bit/128-bit WEP
• AES-CCMP
• TKIP
Bluetooth Bluetooth 5.0 Bluetooth 4.2 Bluetooth 5.0
Identifier GUID-B1CB5EA4-1B5D-4E85-8719-A570DFA599F9
Status Released
Mobile broadband
Table 11. Intel XMM 7360 Global LTE-Advanced
Description Values
Model number Intel XMM 7360 Global LTE-Advanced
18 Technical specications

Identifier GUID-AD5B9ABA-9B9B-44A5-8988-23AEA8D10DF6
Status Released
Audio
Table 12. Audio specications
Description Values
Controller Realtek ALC3204
Stereo conversion Supported
Internal interface Intel HDA
External interface Universal Audio Jack
Speakers 2
Internal speaker amplier Supported (Audio codec built-in amplier)
External volume controls Keyboard shortcut controls
Speaker output:
Average 2 W
Peak 2.5 W
Subwoofer output Not supported
Microphone Dual-array microphones
Identifier GUID-5A030285-DC52-439D-9856-7809E3B2E340
Status Released
Media-card reader
Table 13. Media-card reader specications
Description Values
Type • One microSD-card slot
• One SD-card slot (Optional)
Cards supported • MicroSD
• SD-card (optional)
Technical specications 19

Identifier GUID-A15BD78F-A4E0-4BCD-8B25-353A630A4965
Status Released
Keyboard
Table 14. Keyboard specications
Description Values
Type Standard keyboard
Layout QWERTY
Number of keys • United States and Canada: 81 keys
• United Kingdom: 82 keys
• Japan: 85 keys
Size X=19.05 mm (0.75 in.) key pitch
Y=19.05 mm (0.75 in.) key pitch
Shortcut keys Some keys on your keyboard have two symbols on them. These
keys can be used to type alternate characters or to perform
secondary functions. To type the alternate character, press Shift
and the desired key. To perform secondary functions, press Fn and
the desired key.
NOTE: You can dene the primary behavior of the
function keys (F1–F12) changing Function Key Behavior in
BIOS setup program.
Keyboard shortcuts
Identifier GUID-7CA8D522-5417-4454-AD1B-C66FCD5E923B
Status Released
Camera
Table 15. Camera specications
Description Values
Number of cameras One
Type • Optional RGB HD 720p camera
• Optional IR camera
Location Front camera
Sensor type CMOS sensor technology
Resolution
Camera
20 Technical specications
