Inspiron 15-3576
Service Manual
Computer Model: Inspiron 15-3576
Regulatory Model: P63F
Regulatory Type: P63F002

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make
better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or
loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
©2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are
trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their
respective owners.
2018 - 01
Rev. A00

Contents
Before working inside your computer............................ 11
Before you begin ......................................................................................11
Safety instructions....................................................................................11
Recommended tools................................................................................ 12
Screw list................................................................................................. 13
After working inside your computer..............................15
Removing the battery...................................................16
Procedure................................................................................................ 16
Replacing the battery................................................... 18
Procedure................................................................................................ 18
Removing the optical drive........................................... 19
Prerequisites............................................................................................ 19
Procedure................................................................................................ 19
Replacing the optical drive...........................................22
Procedure................................................................................................22
Post-requisites........................................................................................ 22
Removing the keyboard............................................... 23
Prerequisites............................................................................................23
Procedure................................................................................................23
3

Replacing the keyboard................................................26
Procedure............................................................................................... 26
Post-requisites........................................................................................ 26
Removing the base cover............................................. 27
Prerequisites............................................................................................27
Procedure................................................................................................27
Replacing the base cover............................................. 32
Procedure................................................................................................32
Post-requisites........................................................................................ 34
Removing the optical-drive interposer......................... 35
Prerequisites........................................................................................... 35
Procedure............................................................................................... 35
Replacing the optical-drive interposer..........................37
Procedure................................................................................................37
Post-requisites.........................................................................................37
Removing the hard drive.............................................. 38
Prerequisites............................................................................................38
Procedure............................................................................................... 38
Replacing the hard drive...............................................41
Procedure................................................................................................ 41
Post-requisites......................................................................................... 41
Removing the memory modules................................... 42
Prerequisites............................................................................................42
Procedure................................................................................................42
4

Replacing the memory modules................................... 44
Procedure................................................................................................44
Post-requisites........................................................................................ 45
Removing the wireless card......................................... 46
Prerequisites........................................................................................... 46
Procedure............................................................................................... 46
Replacing the wireless card..........................................48
Procedure............................................................................................... 48
Post-requisites........................................................................................ 49
Removing the power-button board............................... 51
Prerequisites............................................................................................ 51
Procedure................................................................................................ 51
Replacing the power-button board...............................54
Procedure............................................................................................... 54
Post-requisites........................................................................................ 54
Removing the speakers................................................55
Prerequisites........................................................................................... 55
Procedure............................................................................................... 55
Replacing the speakers................................................ 57
Procedure................................................................................................57
Post-requisites........................................................................................ 57
Removing the I/O board.............................................. 58
Prerequisites........................................................................................... 58
Procedure............................................................................................... 58
5

Replacing the I/O board...............................................60
Procedure............................................................................................... 60
Post-requisites........................................................................................ 60
Removing the coin-cell battery.....................................61
Prerequisites............................................................................................ 61
Procedure................................................................................................ 61
Replacing the coin-cell battery.................................... 63
Procedure............................................................................................... 63
Post-requisites........................................................................................ 63
Removing the heat sink................................................64
Prerequisites........................................................................................... 64
Procedure............................................................................................... 64
Replacing the heat sink................................................66
Procedure............................................................................................... 66
Post-requisites........................................................................................ 66
Removing the fan.........................................................67
Prerequisites............................................................................................67
Procedure................................................................................................67
Replacing the fan.........................................................69
Procedure............................................................................................... 69
Post-requisites........................................................................................ 69
Removing the status-light lens.....................................70
Prerequisites............................................................................................70
Procedure................................................................................................70
6

Replacing the status-light lens..................................... 72
Post-requisites........................................................................................ 72
Procedure................................................................................................72
Removing the system board......................................... 73
Prerequisites............................................................................................73
Procedure................................................................................................74
Replacing the system board......................................... 78
Procedure................................................................................................78
Post-requisites........................................................................................ 79
Removing the touchpad...............................................80
Prerequisites........................................................................................... 80
Procedure............................................................................................... 80
Replacing the touchpad............................................... 83
Procedure............................................................................................... 83
Post-requisites........................................................................................ 83
Removing the power-adapter port............................... 84
Prerequisites............................................................................................84
Procedure............................................................................................... 84
Replacing the power-adapter port............................... 86
Procedure............................................................................................... 86
Post-requisites........................................................................................ 86
Removing the display assembly....................................87
Prerequisites............................................................................................87
Procedure................................................................................................87
7

Replacing the display assembly.................................... 91
Procedure................................................................................................ 91
Post-requisites......................................................................................... 91
Removing the display bezel.......................................... 92
Prerequisites............................................................................................92
Procedure............................................................................................... 93
Replacing the display bezel.......................................... 94
Procedure............................................................................................... 94
Post-requisites........................................................................................ 94
Removing the display panel..........................................95
Prerequisites........................................................................................... 95
Procedure............................................................................................... 95
Replacing the display panel..........................................98
Post-requisites........................................................................................ 98
Procedure............................................................................................... 98
Removing the camera.................................................. 99
Prerequisites........................................................................................... 99
Procedure............................................................................................... 99
Replacing the camera..................................................101
Procedure...............................................................................................101
Post-requisites....................................................................................... 101
Removing the display hinges...................................... 102
Prerequisites.......................................................................................... 102
Procedure.............................................................................................. 102
8

Replacing the display hinges.......................................104
Post-requisites.......................................................................................104
Procedure..............................................................................................104
Removing the display back-cover and antenna
assembly.................................................................... 105
Prerequisites..........................................................................................105
Procedure..............................................................................................105
Replacing the display back-cover and antenna
assembly.....................................................................107
Procedure.............................................................................................. 107
Post-requisites....................................................................................... 107
Removing the palm rest..............................................108
Prerequisites.......................................................................................... 108
Procedure..............................................................................................108
Replacing the palm rest...............................................110
Post-requisites....................................................................................... 110
Procedure...............................................................................................110
Downloading drivers.................................................... 111
Downloading the audio driver.................................................................. 111
Downloading the graphics driver............................................................. 111
Downloading the USB 3.0 driver.............................................................112
Downloading the Wi-Fi driver................................................................. 112
Downloading the media-card reader driver............................................. 112
Downloading the chipset driver.............................................................. 113
Downloading the network driver.............................................................113
9

System setup.............................................................. 115
Boot Sequence.......................................................................................115
Navigation keys...................................................................................... 115
BIOS overview........................................................................................116
Entering BIOS setup program.................................................................116
System setup options............................................................................. 117
System setup options............................................................................ 124
Troubleshooting..........................................................130
Flashing the BIOS.................................................................................. 130
Flashing BIOS (USB key)....................................................................... 130
Enhanced Pre-Boot System Assessment (ePSA) diagnostics.................131
Running the ePSA diagnostics..........................................................131
Diagnostics............................................................................................ 132
Flea power release................................................................................. 133
Wi-Fi power cycle.................................................................................. 134
Getting help and contacting Dell.................................135
Self-help resources................................................................................ 135
Contacting Dell...................................................................................... 136
10

Before working inside your
computer
NOTE: The images in this document may dier from your computer
depending on the conguration you ordered.
Before you begin
1 Save and close all open les and exit all open applications.
2 Shut down your computer. Click Start → Power → Shut down.
NOTE: If you are using a dierent operating system, see the
documentation of your operating system for shut-down instructions.
3 Disconnect your computer and all attached devices from their electrical outlets.
4 Disconnect all attached network devices and peripherals, such as keyboard,
mouse, and monitor from your computer.
5 Remove any media card and optical disc from your computer, if applicable.
Safety instructions
Use the following safety guidelines to protect your computer from potential damage
and ensure your personal safety.
WARNING: Before working inside your computer, read the safety
information that shipped with your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
WARNING: Disconnect all power sources before opening the computer
cover or panels. After you nish working inside the computer, replace all
covers, panels, and screws before connecting to the electrical outlet.
CAUTION: To avoid damaging the computer, ensure that the work surface is
at and clean.
11

CAUTION: To avoid damaging the components and cards, handle them by
their edges, and avoid touching pins and contacts.
CAUTION: You should only perform troubleshooting and repairs as
authorized or directed by the Dell technical assistance team. Damage due to
servicing that is not authorized by Dell is not covered by your warranty. See
the safety instructions that shipped with the product or at www.dell.com/
regulatory_compliance.
CAUTION: Before touching anything inside your computer, ground yourself
by touching an unpainted metal surface, such as the metal at the back of
the computer. While you work, periodically touch an unpainted metal surface
to dissipate static electricity, which could harm internal components.
CAUTION: When you disconnect a cable, pull on its connector or on its pull
tab, not on the cable itself. Some cables have connectors with locking tabs
or thumb-screws that you must disengage before disconnecting the cable.
When disconnecting cables, keep them evenly aligned to avoid bending any
connector pins. When connecting cables, ensure that the ports and
connectors are correctly oriented and aligned.
CAUTION: Press and eject any installed card from the media-card reader.
Recommended tools
The procedures in this document may require the following tools:
• Phillips screwdriver #1
• Plastic scribe
12

Screw list
The following table provides the list of screws that are used for securing dierent
components to the palm-rest assembly.
Table 1. Screw list
Component Secured to Screw type Quantity Screw image
Optical-drive
assembly
Base cover M2x5 1
Optical-drive
bracket
Optical drive M2x3 1
Base cover Palm-rest
assembly
M2.5x8 8
Base cover Palm-rest
assembly
M2x5 2
Base cover Palm-rest
assembly
M2x2 3
Base cover Palm-rest
assembly
M2x5 5
Hard-drive
assembly
Palm-rest
assembly
M2x3 4
Hard-drive
bracket
Hard drive M3x3 4
Wireless-card
bracket
System board M2x3 1
Display hinge Palm-rest
assembly
M2.5x8 3
Power-button
board
Palm-rest
assembly
M2x2 1
13

Component Secured to Screw type Quantity Screw image
I/O board Palm-rest
assembly
M2x3 1
Fan System board M2x5 2
System board Palm-rest
assembly
M2x3 2
Touch-pad
bracket
Touch pad M2x3 6
Power-adapter
port
Palm-rest
assembly
M2x3 1
Display panel Display back-
cover and
antenna
assembly
M2x3 4
Display hinges Display back-
cover and
antenna
assembly
M2.5xM2.5 big
head
6
14

After working inside your
computer
CAUTION: Leaving stray or loose screws inside your computer may severely
damage your computer.
1 Replace all screws and ensure that no stray screws remain inside your computer.
2 Connect any external devices, peripherals, or cables you removed before working
on your computer.
3 Replace any media cards, discs, or any other parts that you removed before
working on your computer.
4 Connect your computer and all attached devices to their electrical outlets.
5 Turn on your computer.
15

Removing the battery
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Slide the battery-release latch to the unlocked position.
You hear a click sound when the battery is unlocked.
2 Using your ngertips, lift the battery at an angle and remove it from the battery
bay.
16

3 Turn the computer over, open the display, and press the power button for ve
seconds to ground the system board.
17

Replacing the battery
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Procedure
1 Close the display and turn the computer over.
2 Place the battery in the battery bay and snap the battery into place.
18

Removing the optical drive
WARNING: Before working inside your computer, read the safety
information that shipped with your computer and follow the steps in Before
working inside your computer. After working inside your computer, follow
the instructions in After working inside your computer. For more safety best
practices, see the Regulatory Compliance home page at www.dell.com/
regulatory_compliance.
Prerequisites
Remove the battery.
Procedure
1 Remove the screw (M2x5) that secures the optical-drive assembly to the base
cover.
2 Using a plastic scribe, push to release the optical-drive assembly from the
optical-drive bay.
19

3 Pull the optical-drive assembly out of the optical-drive bay.
4 Remove the screw (M2x3) that secures the optical-drive bracket to the optical
drive.
NOTE: Note the orientation of the optical-drive bracket so that you can
replace it correctly.
20
