Dell Precision 3530 User guide

Precision 3530
Setup and Specications Guide
Regulatory Model: P60F
Regulatory Type: P60F002

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2018 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other trademarks
may be trademarks of their respective owners.
2018 - 05
Rev. A00

Contents
1 Set up your computer.....................................................................................................................................5
2 Chassis view.................................................................................................................................................. 7
Front open view..................................................................................................................................................................7
Back view............................................................................................................................................................................8
Left view..............................................................................................................................................................................8
Right view........................................................................................................................................................................... 9
Rear view...........................................................................................................................................................................10
3 System specications................................................................................................................................... 11
Dimensions and weight.....................................................................................................................................................11
Processor............................................................................................................................................................................11
System information...........................................................................................................................................................12
Operating system..............................................................................................................................................................12
Memory..............................................................................................................................................................................13
Ports and connectors.......................................................................................................................................................13
Communications............................................................................................................................................................... 14
Audio...................................................................................................................................................................................14
Video.................................................................................................................................................................................. 14
Storage...............................................................................................................................................................................15
Media card-reader............................................................................................................................................................ 15
Display................................................................................................................................................................................ 16
Keyboard............................................................................................................................................................................ 16
Camera...............................................................................................................................................................................17
Touchpad............................................................................................................................................................................17
Battery................................................................................................................................................................................17
Input device ......................................................................................................................................................................18
Environmental....................................................................................................................................................................18
Power adapter...................................................................................................................................................................19
4 System setup options.................................................................................................................................. 20
Boot Sequence.................................................................................................................................................................20
Navigation keys.................................................................................................................................................................21
System Setup overview................................................................................................................................................... 21
Accessing System Setup................................................................................................................................................. 21
General screen options.....................................................................................................................................................21
System Conguration screen options............................................................................................................................22
Video screen options....................................................................................................................................................... 25
Security screen options...................................................................................................................................................25
Secure Boot screen options............................................................................................................................................27
Intel Software Guard Extensions....................................................................................................................................27
Performance screen options...........................................................................................................................................28
Power Management screen options..............................................................................................................................28
Contents 3

POST Behavior screen options...................................................................................................................................... 30
Virtualization support screen options.............................................................................................................................31
Wireless screen options................................................................................................................................................... 31
Maintenance screen options...........................................................................................................................................32
System Log screen options.............................................................................................................................................32
Updating the BIOS in Windows .....................................................................................................................................32
System and setup password...........................................................................................................................................33
Assigning a system password and setup password............................................................................................... 33
Deleting or changing an existing system setup password.................................................................................... 34
5 Software......................................................................................................................................................35
Supported operating systems........................................................................................................................................ 35
Downloading drivers........................................................................................................................................................ 35
Downloading the chipset driver..................................................................................................................................... 35
Intel chipset drivers..........................................................................................................................................................36
Intel HD Graphics drivers................................................................................................................................................ 36
6 Getting help................................................................................................................................................. 37
Contacting Dell................................................................................................................................................................. 37
4 Contents

Set up your computer
1 Connect the power adapter.
2 Press the power button.
3 Follow the instructions on the screen to nish Windows setup:
a Connect to a network.
1
Set up your computer 5

b Sign-in to your Microsoft account or create a new account.
4 Locate Dell apps.
Table 1. Locate Dell apps
Register your computer
Dell Help & Support
SupportAssist — Check and update your computer
6Set up your computer

Chassis view
Front open view
1 Array microphone 2 Camera (optional)
3 Camera status light (optional) 4 Array microphone
5 LCD panel 6 Battery charge status light
NOTE: Computer shipped with HD camera module is standard , IR camera is optional.
2
Chassis view 7

Back view
1 Network port 2 HDMI port
3 USB 3.1 Gen 1 port 4 Power connector port
Left view
1Display Port over USB Type-C connector (optional
Thunderbolt™ 3)
2 USB 3.1 Gen 1 port
3 SD Card reader 4 Smart Card reader (optional)
8 Chassis view

Right view
1 Headset port 2 SIM-card slot (optional)
3 USB 3.1 Gen 1 port 4 VGA port
5 Wedge lock slot
Chassis view 9

Rear view
1 Air vent 2 Air vent
3 Service Tag label 4 Speaker
5 Air vent
10 Chassis view

System specications
NOTE: Oerings may vary by region. The following specications are only those required by law to ship with your computer. For
more information about the conguration of your computer, go to Help and Support in your Windows operating system and
select the option to view information about your computer.
Topics:
• Dimensions and weight
• Processor
• System information
• Operating system
• Memory
• Ports and connectors
• Communications
• Audio
• Video
• Storage
• Media card-reader
• Display
• Keyboard
• Camera
• Touchpad
• Battery
• Input device
• Environmental
• Power adapter
Dimensions and weight
Table 2. Dimensions and weight
Height • Front height - 0.8 inch (21.65 mm)
• Back height - 0.9 inch (24.3 mm)
Width 14.8 inch (376 mm)
Depth 9.9 inch (250.7 mm)
Weight Starting 4.48 lbs (2.03 kg)
Processor
Global Standard Products (GSP) are a subset of Dell’s relationship products that are managed for availability and synchronized transitions
on a worldwide basis. They ensure the same platform is available for purchase globally. This allows customers to reduce the number of
3
System specications 11

congurations managed on a worldwide basis, thereby reducing their costs. They also enable companies to implement global IT standards
by locking in specic product congurations worldwide. The following GSP processors identied below will be made available to Dell
customers.
NOTE: Processor numbers are not a measure of performance. Processor availability is subject to change and may vary by region/
country.
Table 3. Processor specications
Type UMA Graphics
Intel Core i5-8300H Processor (4 Core, 8M Cache, 2.3GHz, 35W
cTDP)
Intel UHD Graphics 630
Intel Core i5-8400H Processor (4 Core, 8M Cache, 2.5GHz, 35W
cTDP, vPro)
Intel UHD Graphics 630
Intel Core i7-8750H Processor (6 Core, 9M Cache, 2.2GHz, Turbo,
35W cTDP)
Intel UHD Graphics 630
Intel Core i7-8850H Processor (6 Core, 9M Cache, 2.6GHz, 35W
cTDP, vPro)
Intel UHD Graphics 630
Mobile Intel Xeon-E-2176M Processor(6 Core, 12M Cache, 2.7GHz,
4.4GHz Turbo, 35W cTDP, vPro)
Intel UHD Graphics P630
System information
Table 4. System information
Chipset Intel CM246 chipset
DRAM bus width 64-bit
FLASH EPROM {SP1 256 Mbits}
PCIe bus 100 Mhz
External bus frequency {DMI 3.0-8GT/s}
Operating system
Table 5. Operating system
Operating systems supported • Windows 10 Home (64 bit)
• Windows 10 Professional (64 bit)
• Ubuntu 16.04 LTS (64bit)
• Windows 10 Pro for Workstations 64
• Red Hat 7.5
12 System specications

Memory
Table 6. Memory specications
Minimum memory conguration 4 GB
Maximum memory conguration 32 GB
Number of slots 2 SODIMM
Maximum memory supported per slot 16 GB
Memory options • 4 GB - 1 x 4 GB
• 8 GB - 1 x 8 GB
• 8 GB - 2 x 4 GB
• 16 GB - 2 x 8 GB
• 16 GB - 1 x 16 GB
• 32 GB - 2 x 16 GB
Type DDR4 SDRAM Non-ECC memory
Optional ECC memory for Mobile Intel Xeon Processor
Speed 2400/2666 MHz
Ports and connectors
Table 7. Ports and connectors
Memory card reader microSD 4.0 memory card reader
Smart card reader Yes (Optional)
USB Three USB 3.1 Gen 1 (one with PowerShare)
Security Noble wedge lock slot
Docking port DisplayPort over USB Type C (optional Thunderbolt 3)
Audio • Universal audio jack
• Noise reduction array microphones
Video • HDMI 1.4 (UMA)
• One VGA
• HDMI 2.0 (Discrete)
Network adapter One RJ-45 connector
Serial port NA
Parallel port NA
System specications 13

SIM card reader One uSIM card slot (optional)
Communications
Table 8. Communications
Network adapter Intel i219LM Gigabit (10/100/1000 Mbps) Ethernet Controller
(RJ-45 ) with Intel Remote Wake UP, PXE and Manageability
capabilities alerting (AMT 11 / DASH 1.1 )
Wireless • Wi-Fi 802.11 a,b.g,n/ac via M.2
• MU-MIMO RX
• Bluetooth via WLAN
• Mobile Broadband LTE
Audio
Table 9. Audio specications
Controller Realtek ALC3246-CG Controller with Waves MaxxAudio Pro
Type Multi-channel high-denition audio
Stereo conversion Digital audio-out through HDMI — up to 7.1 compressed and
uncompressed audio
Speakers Two (Bi-Directional speakers)
Internal interface High-denition audio codec
Interface
• Universal audio jack
• High quality speakers
• Noise reducing array microphones
• Stereo headset/mic combo
Internal speaker amplier 2 W(RMS) per channel
Volume controls Hot keys
Video
Table 10. Video
Controller Type CPU
Dependency
Graphics
memory type
Capacity External display
support
Maximum
resolution
Intel UHD
Graphics 630
Intel UHD
Graphics P630
UMA • Intel® Core
i5-8300H
• Intel® Core
i5-8400H
• Intel® Core
i7-8850H
Integrated Shared system
memory(Upto 32
GB)
VGA
HDMI 1.4(UMA)
HDMI 2.0(DSC)
eDP(Internal)
HDMI 1.4 (UMA):
4096x2160 @ 30 Hz
HDMI 2.0 (DSC):
4096x2160 @ 60 Hz
14 System specications

Controller Type CPU
Dependency
Graphics
memory type
Capacity External display
support
Maximum
resolution
• Intel Xeon
Processor
E-2176M
Via Optional Type-C
Port: DisplayPort
Analog: (VGA)
system 1920x1200
@ 60Hz
Max Digital: (DP 1.2
over Type-C Port)
4096x2304 @ 60Hz
Nvidia Quadro
P600
Discrete NA GDDR5 4GB DisplayPort
HDMI 2.0
HDMI 1.4 (UMA):
4096x2160 @ 30 Hz
HDMI 2.0 (DSC):
4096x2160 @ 60 Hz
Analog: (VGA)
system 1920x1200
@ 60Hz
Max Digital: (DP 1.2
over Type-C Port)
4096x2304 @ 60Hz
Storage
Table 11. Storage specications
Primary/Boot drive Primary interface Secondary drive Secondary interface Security option
SSD M.2 2280 SATA: up to 512GB,
OPAL SED options
SATA AHCI, Up to 6
Gbps
M.2 2230 (WWAN
slot)
PCIe 3 x2 NVME, Up to 16
Gbps
YES
SSD M.2 2280 PCIe/NVMe: up to 2TB,
OPAL SED options
PCIe 3 x4 NVME, Up to
32 Gbps
M.2 2230 (WWAN
slot)
PCIe 3 x2 NVME, Up to 16
Gbps
YES
One 2.5 " HDD: up to 2TB, OPAL SED
options
SATA AHCI, Up to 6
Gbps
M.2 2230 (WWAN
slot)
PCIe 3 x2 NVME, Up to 16
Gbps
YES
SSD M.2 2230 PCIe/NVMe : up to
256GB (in WWAN slot only)
PCIe 3 x2 NVME, Up to
16 Gbps
M.2 2280 SATA SATA AHCI, Up to 6 Gbps NO
SSD M.2 2230 PCIe/NVMe : up to
256GB (in WWAN slot only)
PCIe 3 x2 NVME, Up to
16 Gbps
2.5" HDD SATA AHCI, Up to 6 Gbps NO
Media card-reader
Table 12. Media-card reader specications
Type One SD 4.0 card slot
Supported cards • SD 4.0
• Memory Stick, Pro, HG, Duo and XC
• SDHC
• Secure Digitale Xtended Capacity(SDXC) and Multi-Media Card
• SD UHS-I (Ultra High Speed-I) and SD UHS-II (Ultra High
Speed-II) FD/HD mode
System specications 15

Display
Table 13. Display specications
Type • 15.6" HD (1366 x 768) Anti-glare (16:9) WLED, 220 nits, 45%
color gamut, non-touch, Carbon Fiber Reinforced Polymer LCD
Back
• 15.6" FHD WVA (1920 x 1080) Anti-glare (16:9) WLED, 300 nits,
non-touch, 72% color gamut w/ PremierColor, Carbon Fiber
Reinforced Polymer LCD Back
• 15.6" FHD WVA (1920 x 1080) Embedded Touch Display with
Truelife, 220 nits, 45% color gamut, Carbon Fiber Reinforced
Polymer LCD Back
Height (Active area) 7.62 inch (193.5 mm)
Width (Active area) 13.55 inch (344.2 mm)
Diagonal 15.6 inch(396.25 mm)
Touch panel specication 10 nger touch support is supported on the embedded 15.6" touch
panel.
Luminance/Brightness (typical) 220/300 nits
Refresh rate 60 Hz
Horizontal viewing angle (min) +/- 40 degrees(HD)
+85/-85 degrees(FHD)
Vertical viewing angle (min) +10/- 30 degrees(HD)
+85/-85 degrees(FHD)
Keyboard
Table 14. Keyboard specications
Number of keys • 82 (U.S. and Canada)
• 83 (Europe)
• 84(Brazil)
• 86 (Japan)
Size Full sized
• X= 19.05 mm key pitch
• Y= 19.05 mm key pitch
Backlit keyboard Yes(Optional)
Layout QWERTY/AZERTY/Kanji
16 System specications

Camera
Table 15. Camera specications
Resolution Camera:
• Still image: 0.92 megapixels
• Video: 1280x720 at 30 fps
Infrared camera (optional):
• Still image: 0.92 megapixels
• Video: 1280x720 at 30 fps
Diagonal viewing angle • Camera : 74 degrees
• Infrared camera : 74 degrees
Touchpad
Table 16. Touchpad specications
Resolution • Horizontal: 1221
• Vertical: 661
Dimensions • Width: 4.0 inch (101.7 mm )
• Height: 2.17 inch (55.2mm)
Multi-touch Supports up to 5 ngers. Gesture support is dependent on
operating system.
Battery
Table 17. Battery Specications
Type • 68 WHr,4 Cell, Li-ion/Polymer, ExpressCharge Capable Battery
• 68 WHr,4 Cell, Li-polymer, Long Cycle Life Battery
• 92 Whr, 6 Cell ExpressCharge Capable Li-ion/polymer Battery
Dimension 1 68 WHr,4 Cell,Li-ion/Polymer
• Length: 233mm (9.17 inch)
• Width: 95.9mm ( 3.78 inch)
• Height: 7.05mm (0.28 inch)
• Weight: 340.00 g
2 68 WHr,4 cell, Li-polymer Battery
• Length: 233mm (9.17 inch)
• Width: 95.9mm ( 3.78 inch)
• Height: 7.05mm (0.28 inch)
System specications 17

• Weight: 340.00 g
3 92 WHr,6 cell,Li-polymer
• Length: 332mm (13.07 inch)
• Width: 96mm (3.78 inch)
• Height: 7.7mm (0.303 inch)
• Weight: 450.00 g
Weight (maximum) 0.045 kg (0.99 lb )
Voltage • 68 WHr - 7.6 VDC
• 68 WHr - 7.6 VDC
• 92 WHr - 11.4 VDC
Life span 300 discharge/recharge cycles(Standard) and 1000discharge/
recharge cycles(Long cycle)
Charging time when the computer is o (approximate) 2-4 hours
Operating time Varies depending on operating conditions and can signicantly
reduce under certain power-intensive conditions
Temperature range: Operating • Charge: 0 °C to 50 °C (32 °F to 122 °F)
• Discharge: 0 °C to 70 °C (32 °F to 158 °F)
Temperature range: Storage -20 °C to 65 °C (-4 °F to 149 °F)
Coin-cell battery ML1220
Input device
• Single Point non-backlit Keyboard
• Dual Pointing backlit Keyboard
• Microsoft Precision Touchpad
Environmental
NOTE: For more details on Dell environmental features, please go to the environmental attributes section. See your specic
region for availability.
Table 18. Environmental
Energy ecient power supply Internal
80 plus bronze certication 155W EPA bronze
80 plus platinum certication 240W EPA platinum
Customer replaceable unit No
Recyclable packaging Optional, US only
MultiPack packaging No
18 System specications

Power adapter
Table 19. Power adapter specications
Type • 130 W adapter
Input Voltage 100 to 240 VAC
Input current (maximum) • 130 W - 1.8 A
Adapter size 7.4 mm Barrel Type
Input frequency 50 Hz to 60 Hz
Output current • 130 W - 6.7 A (continuous)
Rated output voltage 19.5 VDC
Temperature range (Operating) -40º to 70º C (-40º to 158º F)
Temperature range (Non-Operating) -40º to 70º C (-40º to 158º F)
System specications 19

System setup options
NOTE: Depending on the computer and its installed devices, the items listed in this section may or may not appear.
Topics:
• Boot Sequence
• Navigation keys
• System Setup overview
• Accessing System Setup
• General screen options
• System Conguration screen options
• Video screen options
• Security screen options
• Secure Boot screen options
• Intel Software Guard Extensions
• Performance screen options
• Power Management screen options
• POST Behavior screen options
• Virtualization support screen options
• Wireless screen options
• Maintenance screen options
• System Log screen options
• Updating the BIOS in Windows
• System and setup password
Boot Sequence
Boot Sequence allows you to bypass the System Setup–dened boot device order and boot directly to a specic device (for example:
optical drive or hard drive). During the Power-on Self Test (POST), when the Dell logo appears, you can:
• Access System Setup by pressing F2 key
• Bring up the one-time boot menu by pressing F12 key
The one-time boot menu displays the devices that you can boot from including the diagnostic option. The boot menu options are:
• Removable Drive (if available)
• STXXXX Drive
NOTE: XXX denotes the SATA drive number.
• Optical Drive (if available)
• SATA Hard Drive (if available)
• Diagnostics
NOTE: Choosing Diagnostics, will display the ePSA diagnostics screen.
4
20 System setup options
