Dell T05J Instruction Manual

XPS 13 9315 2-in-1
External Display Connection Guide
Regulatory Model: T05J
Regulatory Type: T05J001
July 2022
Rev. A00

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid
the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2022 Dell Inc. or its subsidiaries. All rights reserved. Dell Technologies, Dell, and other trademarks are trademarks of Dell Inc. or its
subsidiaries. Other trademarks may be trademarks of their respective owners.

Chapter 1: Before you begin.......................................................................................................... 4
Check the graphics options on your computer............................................................................................................ 4
Modes of connection.......................................................................................................................................................... 4
Turn off the internal display..............................................................................................................................................5
Chapter 2: Connect external displays............................................................................................ 6
Integrated graphics............................................................................................................................................................. 6
Chapter 3: Troubleshooting......................................................................................................... 10
Chapter 4: Getting help and contacting Dell................................................................................. 11
Contents
Contents 3

Before you begin
You can connect up to two 4K external displays directly, four 4K displays through a USB-C docking station or one 5K and above
display using the Thunderbolt 4 (USB-C) ports available on your XPS 13 9315 2-in-1.
Before you begin, ensure that you:
●Check the graphics options on your computer.
●Check the ports available on your external displays and decide on the modes of connections.
Check the graphics options on your computer
The number of external displays supported depends on the type of graphics processing unit (GPU) available on your computer.
NOTE: On computers with an Intel Iris XeGraphics GPU, you can connect up to two external displays or one 8K display.
The GPU supported by your computer is Intel Iris Xeintegrated graphics, and allows you to connect up to four 4K displays with a
USB-C docking station, or one 5K and above display.
Modes of connection
Depending on the connectors available on your external display, you can connect the displays to the Thunderbolt 4 (USB-C)
ports on your computer using:
●Thunderbolt 4 cables, adapters, or docking stations
●USB-C cables, adapters, or docking stations
NOTE: To experience the full resolution supported by your external displays, use appropriate cables. For example, use
DisplayPort or HDMI cables for 4K and above resolution.
NOTE: USB-C or Thunderbolt docking stations can be used to connect external displays to the computer using a single
USB-C cable, while charging the computer. For more information about the types of docking stations available from Dell,
search in the Knowledge Base Resource at www.dell.com/support.
NOTE: USB-C adapters can also be used to connect external displays to the computer, though these do not allow power
charging at the same time. For more information about the types of USB-C adapters available from Dell, search in the
Knowledge Base Resource at www.dell.com/support.
These are the Thunderbolt 4 (USB-C) ports available on your computer:
NOTE: When connecting a display indirectly using an adapter or docking station, it is recommended that you connect
the display to the docking station first, and then connect the docking station to the Thunderbolt 4 (USB-C) port on your
computer.
1
4 Before you begin

Turn off the internal display
There may be instances where you may want to turn off the computer's internal display to connect more external displays.
You can turn off the display of your computer by using the Intel HD Graphics Command Center.
To turn off the display:
1. In the Windows search bar, type Intel Graphics Command Center and press <Enter>.
2. Accept the Intel Graphics Command Center software licence agreement.
3. On the Intel Graphics Command Center window, click Display. The list of active displays is listed under the Connected
Displays section.
4. Click the ellipsis (...) in the top-right corner of your primary display, then click Extend > Display 2.
5. Click the ellipsis (...) in the top-right corner of display 2, then click Make Display Primary.
6. Click the ellipsis (...) in the top-right corner of your computer's display, then click Disable.
Before you begin 5

Connect external displays
You can connect up to four external displays to the computer, with the use of a USB-C docking station.
The number of displays supported depends on the following:
●If the internal display is enabled or disabled.
●Your USB-C docking station may also limit the number of supported external displays. Check the documentation that came
with your docking station for details.
The following tables summarize the number of supported external displays:
Table 1. Display support (up to 4K/60 Hz)
Graphics card Direct Graphics Controller
Direct Output Mode
Supported external
displays with computer
internal display on
Supported external
displays with computer
internal display off
Intel Iris Xe Graphics Not applicable 3 4
Table 2. Display support (up to 8K/60 Hz)
Graphics card Direct Graphics Controller
Direct Output Mode
Supported external
displays with computer
internal display on
Supported external
displays with computer
internal display off
Intel Iris Xe Graphics Not applicable Not applicable 1
Integrated graphics
Connecting external displays to XPS 13 9315 2-in-1 with integrated
graphics
NOTE: When connecting a display indirectly using an adapter or a USB-C docking station, it is recommended that you
connect the display to the docking station first, and then connect the docking station to the Thunderbolt 4 (USB-C) port on
your computer.
NOTE: The devices connected to the port on the left side of the computer have priority over the port on the right. While
connecting external displays, it is recommended that you connect the displays to the left port.
With the internal display turned on
You can connect external displays directly to the Thunderbolt 4 (USB-C) ports, or up to three external displays using a USB-C
docking station.
NOTE: The number of external displays that are supported depends on the specifications of the USB-C docking station.
2
6 Connect external displays

●Connect an external display using a direct USB-C or Thunderbolt cable:
●Connect an external display using a USB-C to Thunderbolt/HDMI/DisplayPort adapter:
Connect external displays 7

●Connect up to two external displays using a USB-C docking station:
●Connect up to three external displays using a USB-C docking station:
With the internal display turned off
NOTE: Ensure that you turn off the computer's internal display before connecting the external displays. For more
information, see Turn off the internal display.
8 Connect external displays

You can connect external displays directly to the Thunderbolt 4 (USB-C) ports, or up to four external displays using a USB-C
docking station and a direct connection to the Thunderbolt 4 (USB-C) port with a USB-C or Thunderbolt cable.
NOTE: The connected USB Type-C display provides power to the computer.
●Connect two external displays using direct USB-C or Thunderbolt cables:
●Connect up to four external displays:
NOTE:
○Up to three displays can be connected to the USB-C docking station, and the additional display can be connected to
the right Thunderbolt 4 port with a USB-C or Thunderbolt cable.
○The total number of external displays that is supported depends on the specifications of the USB-C docking station.
○The maximum supported resolutions of the four external displays are as follows:
￭4K UHD (3840 x 2160), at 60 Hz refresh rate (For each of the three external displays that are connected to the
USB-C docking station.)
￭QHD (2560 x 1440), at 60 Hz refresh rate (For the external display that is connected to right Thunderbolt port
with a USB-C or Thunderbolt cable.)
Connect external displays 9

Troubleshooting
8K display not displaying correctly
Question
When I connect an 8K display to the computer using a Thunderbolt docking station, the display output is not correct from the
computer.
Cause
This may be because of a hardware limitation with the Thunderbolt docking station.
Workaround
Connect the 8K display directly to a Thunderbolt port on the computer (not using a docking station). After doing so, power the
display on and off again.
3
10 Troubleshooting

Getting help and contacting Dell
Self-help resources
You can get information and help on Dell products and services using these self-help resources:
Table 3. Self-help resources
Self-help resources Resource location
Information about Dell products and services www.dell.com
My Dell app
Tips
Contact Support In Windows search, type Contact Support, and press
Enter.
Online help for operating system www.dell.com/support/windows
Access top solutions, diagnostics, drivers and downloads, and
learn more about your computer through videos, manuals and
documents.
Your Dell computer is uniquely identified by a Service Tag or
Express Service Code. To view relevant support resources for
your Dell computer, enter the Service Tag or Express Service
Code at www.dell.com/support.
For more information on how to find the Service Tag for your
computer, see Locate the Service Tag on your computer.
Dell knowledge base articles for a variety of computer
concerns
1. Go to www.dell.com/support.
2. On the menu bar at the top of the Support page, select
Support > Knowledge Base.
3. In the Search field on the Knowledge Base page, type the
keyword, topic, or model number, and then click or tap the
search icon to view the related articles.
Contacting Dell
To contact Dell for sales, technical support, or customer service issues, see www.dell.com/contactdell.
NOTE: Availability varies by country/region and product, and some services may not be available in your country/region.
NOTE: If you do not have an active Internet connection, you can find contact information about your purchase invoice,
packing slip, bill, or Dell product catalog.
4
Getting help and contacting Dell 11
