Dell TrueMobile 1300 User manual

www.dell.com | support.dell.com
Dell™ Inspiron™ 1300/B120/B130
Owner’s Manual
Model PP21L
book.book Page 1 Thursday, September 22, 2005 8:08 AM

Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells you how to avoid the
problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury, or death.
Abbreviations and Acronyms
For a complete list of abbreviations and acronyms, see the Glossary.
If you purchased a Dell™ n Series computer, any references in this document to Microsoft
®
Windows
®
operating systems are not applicable.
____________________
Information in this document is subject to change without notice.
© 2005 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, Inspiron, Dell Precision, Dimension, DellNet, OptiPlex, Latitude, PowerEdge, PowerConnect,
PowerVault, PowerApp, and Dell OpenManage are trademarks of Dell Inc.; Intel, Celeron, and Pentium are registered trademarks of Intel
Corporation; Microsoft,Outlook,and Windows are registered trademarks of Microsoft Corporation; EMC is a registered trademark of EMC
Corporation.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products.
Dell Inc. disclaims any proprietary interest in trademarks and trade names other than its own.
Model PP21L
September 2005 P/N WD660 Rev. A01
book.book Page 2 Thursday, September 22, 2005 8:08 AM

Contents 3
Contents
Finding Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
1 A Tour of Your Computer
Front View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Left Side View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Right Side View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Back View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Bottom View . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
2 Setting Up Your Computer
Connecting to the Internet . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Setting Up Your Internet Connection . . . . . . . . . . . . . . . . . . . . 19
Transferring Information to a New Computer . . . . . . . . . . . . . . . . . . 20
Running the Files and Settings Transfer Wizard With the
Operating System CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Running the Files and Settings Transfer Wizard Without the
Operating System CD . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Setting Up a Printer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Printer Cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Connecting a USB Printer. . . . . . . . . . . . . . . . . . . . . . . . . . 23
Power Protection Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Surge Protectors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Line Conditioners . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
Uninterruptible Power Supplies . . . . . . . . . . . . . . . . . . . . . . 24
book.book Page 3 Thursday, September 22, 2005 8:08 AM

4Contents
3 Using the Display
Adjusting Brightness. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Switching the Video Image . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Setting Display Resolution. . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4 Using the Keyboard and Touch Pad
Numeric Keypad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Key Combinations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
System Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
CD or DVD Tray . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Display Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Radios (Including Wireless Networking) . . . . . . . . . . . . . . . . . . 28
Power Management . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Speaker Functions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Microsoft®Windows®Logo Key Functions . . . . . . . . . . . . . . . . 29
Touch Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Customizing the Touch Pad . . . . . . . . . . . . . . . . . . . . . . . . . 30
5 Using a Battery
Battery Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Checking the Battery Charge . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Dell™ QuickSet Battery Meter . . . . . . . . . . . . . . . . . . . . . . . 32
Microsoft®Windows®Power Meter . . . . . . . . . . . . . . . . . . . 32
Low-Battery Warning . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Conserving Battery Power . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Power Management Modes . . . . . . . . . . . . . . . . . . . . . . . . 33
Configuring Power Management Settings . . . . . . . . . . . . . . . . . 34
Charging the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
Replacing the Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
Storing a Battery . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
book.book Page 4 Thursday, September 22, 2005 8:08 AM

Contents 5
6 Using CDs, DVDs, and Other Multimedia
Playing a CD or DVD . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Adjusting the Volume . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Adjusting the Picture . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Copying CDs and DVDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
How to Copy a CD or DVD. . . . . . . . . . . . . . . . . . . . . . . . . . 43
Using Blank CDs and DVDs . . . . . . . . . . . . . . . . . . . . . . . . . 44
Helpful Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
7 Using ExpressCards
ExpressCard Types . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
ExpressCard Blanks . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Installing an ExpressCard . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Removing an ExpressCard or Blank . . . . . . . . . . . . . . . . . . . . . . . 48
8 Setting Up a Home and Office Network
Connecting to a Network Adapter . . . . . . . . . . . . . . . . . . . . . . . . 49
Network Setup Wizard . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Connecting to a Wireless Local Area Network . . . . . . . . . . . . . . . . . 50
Determining Your Network Type . . . . . . . . . . . . . . . . . . . . . . 50
Connecting to a Wireless Network in Microsoft®Windows®XP . . . . . 50
9 Dell™ QuickSet Features
Clicking the QuickSet Icon . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
Double-Clicking the QuickSet Icon . . . . . . . . . . . . . . . . . . . . . . . 53
Right-Clicking the QuickSet Icon . . . . . . . . . . . . . . . . . . . . . . . . 53
book.book Page 5 Thursday, September 22, 2005 8:08 AM

6Contents
10 Solving Problems
Dell Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Drive Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
CD and DVD drive problems . . . . . . . . . . . . . . . . . . . . . . . . 58
Hard drive problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
E-Mail, Modem, and Internet Problems . . . . . . . . . . . . . . . . . . . . . 59
Error Messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Keyboard Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
External Keyboard problems . . . . . . . . . . . . . . . . . . . . . . . . 64
Unexpected characters. . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Lockups and Software Problems . . . . . . . . . . . . . . . . . . . . . . . . 65
The computer does not start up . . . . . . . . . . . . . . . . . . . . . . 65
The computer stops responding . . . . . . . . . . . . . . . . . . . . . . 65
A program stops responding or crashes repeatedly . . . . . . . . . . . . 65
A program is designed for an earlier Microsoft® Windows®
operating system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
A solid blue screen appears . . . . . . . . . . . . . . . . . . . . . . . . 65
Other software problems . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Memory Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 66
Network Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
ExpressCard Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Power Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Ensuring Sufficient Power for Your Computer . . . . . . . . . . . . . . . 68
Printer Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Scanner Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Sound and Speaker Problems . . . . . . . . . . . . . . . . . . . . . . . . . . 69
No sound from integrated speakers . . . . . . . . . . . . . . . . . . . . 69
No sound from external speakers . . . . . . . . . . . . . . . . . . . . . 70
No sound from headphones . . . . . . . . . . . . . . . . . . . . . . . . 70
Touch Pad or Mouse Problems . . . . . . . . . . . . . . . . . . . . . . . . . 70
book.book Page 6 Thursday, September 22, 2005 8:08 AM

Contents 7
Video and Display Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . 71
If the display is blank . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
If the display is difficult to read . . . . . . . . . . . . . . . . . . . . . . . 71
If only part of the display is readable . . . . . . . . . . . . . . . . . . . . 72
Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
What Is a Driver? . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Identifying Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Reinstalling Drivers and Utilities . . . . . . . . . . . . . . . . . . . . . . 73
Resolving Software and Hardware Incompatibilities . . . . . . . . . . . . . 75
Restoring Your Operating System . . . . . . . . . . . . . . . . . . . . . . . . 75
Using Microsoft Windows XP System Restore . . . . . . . . . . . . . . . 76
Using Dell PC Restore by Symantec . . . . . . . . . . . . . . . . . . . . 77
Using the Operating System CD. . . . . . . . . . . . . . . . . . . . . . . 79
11 Adding and Replacing Parts
Before You Begin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Recommended Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Turning Off Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . 81
Before Working Inside Your Computer . . . . . . . . . . . . . . . . . . . 81
Hard Drive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Returning a Hard Drive to Dell . . . . . . . . . . . . . . . . . . . . . . . 85
CD/DVD Drive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Wireless Mini PCI Card . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Hinge Cover . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Keyboard . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 95
12 Appendix
Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
Using the System Setup Program . . . . . . . . . . . . . . . . . . . . . . . 103
Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Viewing the System Setup Screen . . . . . . . . . . . . . . . . . . . . 103
book.book Page 7 Thursday, September 22, 2005 8:08 AM

8Contents
System Setup Screen . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Commonly Used Options . . . . . . . . . . . . . . . . . . . . . . . . . 103
Travelling With Your Computer . . . . . . . . . . . . . . . . . . . . . . . . 105
Identifying Your Computer . . . . . . . . . . . . . . . . . . . . . . . . 105
Packing the Computer . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Travel Tips. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 105
Travelling by Air . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
If Your Computer Is Lost or Stolen . . . . . . . . . . . . . . . . . . . . 106
Cleaning Your Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
Computer, Keyboard, and Display . . . . . . . . . . . . . . . . . . . . 107
Touch Pad . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
CDs and DVDs. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 107
FCC Notices (U.S. Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
FCC Class B . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 108
Macrovision Product Notice. . . . . . . . . . . . . . . . . . . . . . . . . . 109
Dell Technical Support Policy (U.S. Only) . . . . . . . . . . . . . . . . . . . 109
Definition of "Dell-Installed" Software and Peripherals . . . . . . . . . 109
Definition of "Third-Party" Software and Peripherals. . . . . . . . . . . 109
Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 127
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
book.book Page 8 Thursday, September 22, 2005 8:08 AM

Finding Information 9
Finding Information
NOTE: Some features or media may be optional and may not ship with your computer. Some features or media may
not be available in certain countries.
NOTE: Additional information may ship with your computer.
What Are You Looking For? Find It Here
• How to set up my computer
• Basic troubleshooting information
• How to run the Dell Diagnostics
• How to set up a printer
• Additional information about setting up my computer
• How to troubleshoot and solve problems
• How to remove and install parts
• Specifications
• How to contact Dell
Owner’s Manual
NOTE: This document is available as a PDF at
support.dell.com.
• Warranty information
• Terms and Conditions (U.S. only)
• Safety instructions
• Regulatory information
• Ergonomics information
• End User License Agreement
Dell™ Product Information Guide
• Service Tag and Express Service Code
• Microsoft Windows License Label
Service Tag and Microsoft
®
Windows
®
License
These labels are located on
the bottom of your computer.
• Use the Service Tag to
identify your computer
when you use
support.dell.com or
contact technical
support.
• Enter the Express Service Code to direct your call when
contacting technical support.
book.book Page 9 Thursday, September 22, 2005 8:08 AM

10 Finding Information
• Solutions — Troubleshooting hints and tips, articles
from technicians, and online courses, frequently asked
questions
• Community — Online discussion with other Dell
customers
• Upgrades — Upgrade information for components, such
as memory, the hard drive, and the operating system
• Customer Care — Contact information, service call and
order status, warranty, and repair information
• Service and support — Service call status and support
history, service contract, online discussions with
technical support
• Reference — Computer documentation, details on my
computer configuration, product specifications, and
white papers
• Downloads — Certified drivers, patches, and software
updates
Dell Support Website — support.dell.com
NOTE: Select your region to view the appropriate support
site.
NOTE: Corporate, government, and education customers
can also use the customized Dell Premier Support website at
premier.support.dell.com.
• Notebook System Software (NSS)— If you reinstall the
operating system for your computer, you should also
reinstall the NSS utility. NSS provides critical updates
for your operating system and support for Dell™
3.5-inch USB floppy drives, Intel
®
Pentium
®
M
processors, optical drives, and USB devices. NSS is
necessary for correct operation of your Dell computer.
The software automatically detects your computer and
operating system and installs the updates appropriate
for your configuration.
To download Notebook System Software:
1 Go to support.dell.com and click Downloads .
2 Enter your Service Tag or product model.
3 In the Download Category drop-down menu, click All .
4 Select the operating system and operating system
language for your computer, and click
Submit.
5 Under Select a Device , scroll to System and
Configuration Utilities
, and click Dell Notebook System
Software
.
• How to use Windows XP
• How to work with programs and files
• How to personalize my desktop
Windows Help and Support Center
1 Click the Start button and click Help and Support .
2 Type a word or phrase that describes your problem and
click the arrow icon.
3 Click the topic that describes your problem.
4 Follow the instructions on the screen.
What Are You Looking For? Find It Here
book.book Page 10 Thursday, September 22, 2005 8:08 AM

A Tour of Your Computer 11
A Tour of Your Computer
Front View
1display latch release 5touch pad 9keyboard
2display latches (2) 6touch pad buttons 10 power button
3display 7speakers
4keyboard status lights 8device status lights
1
9
2
8
3
7
10
4
5
6
book.book Page 11 Thursday, September 22, 2005 8:08 AM

12 A Tour of Your Computer
DISPLAY LATCH RELEASE —Slide to release the display latches and open the display.
DISPLAY LATCHES —Keeps the display closed.
DISPLAY —For more information about your display, see “ Using the Display .”
KEYBOARD STATUS LIGHTS
The green lights located above the keyboard indicate the following:
TOUCH PAD/TOUCH PAD BUTTONS —Provides the functionality of a mouse.
SPEAKERS —To adjust the volume of the integrated speakers, press the speaker-volume keyboard shortcuts. For
more information, see “
Speaker Functions .”
Turns on when the numeric keypad is enabled.
Turns on when the uppercase letter function is enabled.
Turns on when the scroll lock function is enabled.
9
A
book.book Page 12 Thursday, September 22, 2005 8:08 AM

A Tour of Your Computer 13
DEVICE STATUS LIGHTS
If the computer is connected to an electrical outlet, the light operates as follows:
• Solid green: The battery is charging.
• Flashing green: The battery is almost fully charged.
If the computer is running on a battery, the light operates as follows:
• Off: The battery is adequately charged (or the computer is turned off).
• Flashing orange: The battery charge is low.
• Solid orange: The battery charge is critically low.
KEYBOARD —The keyboard includes a numeric keypad as well as the Microsoft Windows logo key. For information
on supported keyboard shortcuts, see “
Key Combinations .”
POWER BUTTON —Press the power button to turn on the computer or to enter or exit a power management mode.
NOTICE: To avoid losing data when you turn off your computer, shut down your computer through the Start menu
instead of pressing the power button.
Turns on when you turn on the computer, and blinks when the computer is in a power
management mode.
Turns on when the computer reads or writes data.
NOTICE: To avoid loss of data, never turn off the computer while the light is flashing.
Turns on steadily or blinks to indicate battery charge status.
Turns on when wireless networking is enabled. To enable or disable wireless networking, press
<Fn><F2>.
NOTE: Wireless networking is optional and may not be available on your computer.
book.book Page 13 Thursday, September 22, 2005 8:08 AM

14 A Tour of Your Computer
Left Side View
MODEM CONNECTOR (RJ-11)
NOTICE: The network connector is slightly larger than the modem connector. To avoid damaging the computer, do
not plug a telephone line into the network connector.
1modem connector 4USB connectors (3) 7ExpressCard slot
2network connector 5microphone connector 8ExpressCard slot release
button
3video connector 6headphone connector
To use the internal modem, connect the telephone line to
the modem connector.
For additional information on using the modem, see the
online modem documentation supplied with your computer.
453 7 81 2 6
book.book Page 14 Thursday, September 22, 2005 8:08 AM

A Tour of Your Computer 15
NETWORK CONNECTOR (RJ-45)
VIDEO CONNECTOR
USB CONNECTORS
AUDIO CONNECTORS
EXPRESSCARD SLOT —Supports one ExpressCard. The computer ships with a plastic blank installed in the slot.
For more information, see “
Using ExpressCards .”
Connects the computer to a network. The green and yellow
lights next to the connector indicate activity for wired
network communications.
For information on using the network adapter, see the
online network adapter documentation supplied with
your computer.
Connects an external VGA-compatible monitor.
Connect USB devices, such as a mouse, keyboard, or printer.
You can also connect the optional floppy drive directly to a
USB connector using the optional floppy-drive cable.
Attach headphones or speakers to the connector.
Attach a microphone to the connector.
book.book Page 15 Thursday, September 22, 2005 8:08 AM

16 A Tour of Your Computer
Right Side View
OPTICAL DRIVE —You can install devices such as a DVD drive or other optical drive in the optical drive
bay. For more information, see “
CD/DVD Drive .”
OPTICAL-DRIVE-TRAY EJECT BUTTON —Press this button to eject a CD or DVD from the optical drive.
SECURITY CABLE SLOT —Lets you attach a commercially available antitheft device to the computer. For more
information, see the instructions included with the device.
NOTICE: Before you buy an antitheft device, ensure that it will work with the security cable slot.
1optical drive bay 2optical drive-tray eject button 3security cable slot
3
2
1
book.book Page 16 Thursday, September 22, 2005 8:08 AM

A Tour of Your Computer 17
Back View
AC ADAPTER CONNECTOR —ATTACHES AN AC ADAPTER TO THE COMPUTER.
The AC adapter converts AC power to the DC power required by the computer. You can connect the
AC adapter with your computer turned either on or off.
CAUTION: The AC adapter works with electrical outlets worldwide. However, power connectors and power
strips vary among countries. Using an incompatible cable or improperly connecting the cable to the power strip
or electrical outlet may cause fire or equipment damage.
NOTICE: When you disconnect the AC adapter cable from the computer, grasp the connector, not the cable itself,
and pull firmly but gently to avoid damaging the cable.
CAUTION: Do not block or push objects into the air vents. Do not store your computer in a low-airflow
environment, such as a closed briefcase, while it is running. Restricting the airflow can damage the computer or
cause a fire.
AIR VENT —The computer uses fans to create airflow through the vents, which prevents the computer from
overheating.
1AC adapter connector 2air vent
21
book.book Page 17 Thursday, September 22, 2005 8:08 AM

18 A Tour of Your Computer
Bottom View
MEMORY MODULE/MINI PCI COVER —Covers the compartment that contains the memory module(s) and Mini
PCI card. For more information on replacing memory, see “
Memory .” For more information on replacing the Mini
PCI card, see “
Wireless Mini PCI Card .”
OPTICAL DRIVE LOCKING SCREW —Secures the optical drive in the optical drive bay. For more information, see
“
CD/DVD Drive .”
HARD DRIVE —Stores software and data. For more information, see “ Hard Drive .”
BATTERY —When a battery is installed, you can use the computer without connecting the computer to an
electrical outlet. For more information, see “
Using a Battery .”
BATTERY-BAY LATCH LOCK —Unlocks the battery so that it can be released from the battery bay.
BATTERY-BAY LATCH RELEASE —Releases the battery from the battery bay. See “ Replacing the Battery .”
PROCESSOR AND THERMAL MODULE COVER —Covers the processor and thermal module.
FAN —The computer uses fans to create airflow through the vents, which prevents the computer from overheating.
1memory module/Mini PCI
cover
4battery 7thermal module cover
2optical drive locking screw 5battery-bay latch lock 8fan
3hard drive cover 6battery-bay latch release
4
3
5
12
7
8
6
book.book Page 18 Thursday, September 22, 2005 8:08 AM

Setting Up Your Computer 19
Setting Up Your Computer
Connecting to the Internet
NOTE: ISPs and ISP offerings vary by country.
To connect to the Internet, you need a modem or network connection and an Internet service
provider (ISP). Your ISP will offer one or more of the following Internet connection options:
• Dial-up connections that provide Internet access through a telephone line. Dial-up connections
are considerably slower than DSL and cable modem connections.
• DSL connections that provide high-speed Internet access through your existing telephone line.
With a DSL connection, you can access the Internet and use your telephone on the same line
simultaneously.
• Cable modem connections that provide high-speed Internet access through your local cable TV
line.
If you are using a dial-up connection, connect a telephone line to the modem connector on your
computer and to the telephone wall jack before you set up your Internet connection. If you are using
a DSL or cable modem connection, contact your ISP for setup instructions.
Setting Up Your Internet Connection
To set up an Internet connection with a provided ISP desktop shortcut:
1
Save and close any open files, and exit any open programs.
2 Double-click the ISP icon on the Microsoft
®
Windows
®
desktop.
3 Follow the instructions on the screen to complete the setup.
If you do not have an ISP icon on your desktop or if you want to set up an Internet connection with
a different ISP:
1
Save and close any open files, and exit any open programs.
2 Click the Start button and click Internet Explorer .
The
New Connection Wizard appears.
3 Click Connect to the Internet .
4 In the next window, click the appropriate option:
• If you do not have an ISP and want to select one, click
Choose from a list of Internet service
providers (ISPs)
.
book.book Page 19 Thursday, September 22, 2005 8:08 AM

20 Setting Up Your Computer
• If you have already obtained setup information from your ISP but you did not receive a setup CD,
click
Set up my connection manually .
• If you have a CD, click
Use the CD I got from an ISP .
5 Click Next .
If you selected
Set up my connection manually , continue to step 6. Otherwise, follow the instructions
on the screen to complete the setup.
NOTE: If you do not know which type of connection to select, contact your ISP.
6 Click the appropriate option under How do you want to connect to the Internet? , and then click Next .
7 Use the setup information provided by your ISP to complete the setup.
If you are having problems connecting to the Internet, see " E-Mail, Modem, and Internet Problems ." If
you cannot connect to the Internet but have successfully connected in the past, the ISP might have a
service outage. Contact your ISP to check the service status, or try connecting again later.
Transferring Information to a New Computer
The Microsoft® Windows®XP operating system provides a Files and Settings Transfer Wizard to move
data from a source computer to a new computer. You can transfer data, such as:
• E-mail messages
• Toolbar settings
• Window sizes
• Internet bookmarks
You can transfer the data to the new computer over a network or USB connection, or you can store it on
a removable medium, such as a writable CD or floppy, for transfer to the new computer.
NOTE: You can transfer information from the old computer to the new computer by directly connecting the two
computers with a USB cable. To transfer data over a USB connection, you must access the Network Connections
utility from the Control Panel and perform additional configuration steps, such as setting up an advanced
connection and designating the host computer and the guest computer.
For instructions on setting up a direct cable connection between two computers, see Microsoft Knowledge Base
Article #305621, titled How to Set Up a Direct Cable Connection Between Two Computers in Windows XP. This
information may not be available in some countries.
For transferring information to a new computer, you must run the Files and Settings Transfer Wizard.
You can use the optional Operating System CD for this process or you can create a wizard disk with the
Files and Settings Transfer Wizard utility.
Running the Files and Settings Transfer Wizard With the Operating System CD
NOTE: This procedure requires the Operating System CD. This CD is optional and may not be included with all
computers.
book.book Page 20 Thursday, September 22, 2005 8:08 AM
