Dell S2317HWi Monitor
User’s Guide
Model: S2317HWi
Regulatory model: S2317HWib

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better
use of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
____________________
Copyright © 2016 Dell Inc. All rights reserved.
This product is protected by U.S. and international copyright and intellectual property laws.
Dell™ and the Dell logo are trademarks of Dell Inc. in the United States and/or other
jurisdictions. All other marks and names mentioned herein may be trademarks of their
respective companies.
2016 - 02 Rev. X01

Safety Information | 3
Safety Information
WARNING: Safety Instructions
WARNING: Use of controls, adjustments, or procedures other than those
specified in this documentation may result in exposure to shock, electrical
hazards, and/or mechanical hazards.
Please read safety and instructions for use before operating the device.
Please retain this user's guide for future reference.
For information on safety instructions, see the Safety, Environmental, and Regulatory
Information.
Positioning the Monitor
The monitor is equipped with an antenna of the radio transmitter, so we recommend that
you keep a safe distance of 20 cm at least between the monitor and you.
> 20 cm
Power connection - Monitor with external +19.5VDC power
adapter
•Power requirements: The monitor must be powered using the accompanied power
adapter.
•The power adapter must be powered by AC mains power.
•The power adapter is specified as a part of the monitor.

4| Safety Information
Regulatory compliance information
FEDERAL COMMUNICATIONS COMMISSION INTERFERENCE
STATEMENT
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the
user is encouraged to try to correct the interference by one or more of the following
measures:
•Reorient or relocate receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
CAUTION: This equipment complies with FCC radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed and
operated with minimum distance 20cm between the radiator & your body.

About Your Monitor | 5
About Your Monitor
Introduction
The Dell Wireless Monitor enables your laptop computer, Tablet & Mobile Phone devices
to display your screen image via WiFi Direct interface. When you connect the Laptop,
Tablet & Mobile Phone to the Dell Wireless Monitor, you can access the mouse &
keyboard connected to the Monitor to control the Compute device (Laptop, Tablet or
Mobile Phone).
Dell Wireless Monitor also enables your Laptop & Mobile Phone to be connected
simultaneously via WiFi Direct interface. The Laptop displayed in full screen and the
Mobile Phone will be displayed as an overlay (PiP) image.
Package Contents
Your monitor ships with the components shown below. Ensure that you have received all
the components and Contact Dell if something is missing.
Monitor
Stand Arm
NOTE: Some items may be optional and may not ship with your monitor. Some
features or media may not be available in certain countries.
NOTE: To set up with any other stand, please refer to the respective stand setup
guide for setup instructions.

Wireless Charging Base
Power Adapter
Power Cable (Varies by
Countries)
HDMI Cable
•Drivers and
Documentation
Media
•Quick Setup Guide
•Safety,Environmental,
and Regulatory
Information
•Wireless Safety and
Regulatory
Information
6| About Your Monitor

About Your Monitor | 7
Product Features
The Dell S2317HWi flat panel display has an active matrix, Thin-Film Transistor (TFT),
Liquid Crystal Display (LCD) and LED backlight. The monitor features include:
•58.42 cm (23-inch) viewable area display (measured diagonally).
1920 x 1080 resolution, plus full-screen support for lower resolutions.
•Wide viewing angle to allow viewing from a sitting or standing position, or while
moving from side-to-side.
•Wireless charging stand base makes wireless charging possible for your
smartphones or mobile devices.
•Plug and play capability if supported by your system.
•HDMI connectivity makes it simple and easy to connect with legacy and new
systems.
•Build-in Speaker (3 W) x 2.
•On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.
•Software and documentation media includes an Information File (INF), Image Color
Matching File (ICM), and product documentation.
•Dell Display Manager Software included (in the CD shipped with the monitor).
•Energy Saver feature for Energy Star compliance.
•Screenovate drivers/app to support additional/enhanced HID sharing features will
be included for Windows®7/8.x/10.
•Security - lock slot.
•Capability to switch from wide aspect to standard aspect ratio while maintaining
the image quality.
•EPEAT Silver Rating.
•TCO-Certified Displays.
•BFR/PVC- Reduced.
•High Dynamic Contrast Ratio (8,000,000:1).
•0.3 W standby power when in the sleep mode.
•Energy Gauge shows the energy level being consumed by the monitor in real time
(consumption from the wireless charging base is not included).

8| About Your Monitor
Identifying Parts and Controls
Front View
Front panel controls
Description
1Function buttons (For more information, see Operating the Monitor )
2Power On/Off button (with LED indicator)
Label

About Your Monitor | 9
Back View
Back view with monitor stand
Label Description Use
1Stand release latch Releases stand from monitor by using a long
screwdriver to push.
2Security lock slot Secures monitor with security lock (optional
purchase).
3Barcode serial number
label
Refer to this label if you need to contact Dell for
technical support.
4Cable management slot Use to organize cables by placing them through
the slot.
5DC out cable Plugs to the power-adapter port on the monitor,
with a 19.5 V DC power supply.
6Power-adapter port Connect the power cable of the wireless charing
stand, with a 19.5 V DC power supply.

45-degree side view
Description Use
1Wireless charging LED Notifies the charging status of your Qi/PMA device.
(For more information, see Indicator Lights )
2Wireless charging pad •Charge your Qi (WPC) or PMA compliance devices.
•Align your device to the pad to get max charging.
10 | About Your Monitor
Side View
Label

Bottom view without monitor stand
Description Use
1Power-adapter port Connects the DC out cable of the wireless charging
base.
2Line-out port Connect your speakers.
NOTE: This port does not support headphones.
3HDMI port Connect your computer with the HDMI cable.
4Micro-B port This port is for service or debugging only. (NOT for
end-user)
5USB downstream port Connect your USB keyboard and mouse. Other USB
devices are restricted to USB Ethernet, USB
Thumbdrive or USB 2.0 Hubs.
6Regulatory label Lists the regulatory approvals.
About Your Monitor | 11
Bottom View
Label

12 | About Your Monitor
Monitor Specifications
Flat Panel Specifications
Screen type Active matrix - TFT LCD
Panel type Wide view angle
Viewable image
Diagonal
Horizontal, Active Area
Vertical, Active Area
Area
584.2 mm (23 inches)
509.18 mm (20.05 inches)
286.41 mm (11.28 inches)
1458.34 mm2(226.04 inch2)
Pixel pitch 0.265 mm x 0.265 mm
Viewing angle 178° (vertical) typical
178° (horizontal) typical
Luminance output 250 cd/m² (typical)
Contrast ratio 1000 to 1 (typical)
8,000,000 to 1 (typical Dynamic Contrast On)
Faceplate coating Anti-Glare with 3H hardness
Backlight LED edgelight system
Response time 8 ms (typical) for NORMAL mode
6 ms (typical) for FAST mode
Color depth 16.78 million colors
Color gamut 82% (typical)*
* Color gamut (typical) is based on CIE1976 (82%) and CIE1931 (72%) test standards.
Model S2317HWi

Horizontal scan range 30 kHz to 83 kHz(automatic)
Vertical scan range 56 Hz to 76 Hz (automatic)
Maximum preset resolution 1920 x 1080 at 60 Hz
About Your Monitor | 13
Resolution Specifications
Supported Video Modes
Video display capabilities 480p, 480i, 576p, 576i, 720p, 1080i, 1080p
Preset Display Modes
Display Mode Horizontal
Frequency (kHz)
Vertical
Frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/
Vertical)
Model S2317HWi
Model S2317HWi
VESA, 720 x 400 31.5 70.1 28.3 -/+
VESA, 640 x 480 31.5 60.0 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.3 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1152 x 864 67.5 75.0 108.0 +/+
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1600 x 1200 75.0 60.0 162.0 +/+
VESA, 1920 x 1080 67.5 60.0 148.5 +/+

Video input signals HDMI 1.4, 600 mV for each differential line, 100 ohm
input impedance per differential pair
Inrush current 120 V:30 A (Max.) at 0 °C (cold start)
240 V:60 A (Max.) at 0 °C (cold start)
AC/DC
Adapter
Input voltage/
frequency/current
Delta adapter DA65NM111-00: 100 VAC to 240 VAC/50
Hz to 60 Hz ± 3 Hz/1.6 A (Max.)
Chicony adapter HA65NS5-00: 100 VAC to 240 VAC/50
Hz to 60 Hz ± 3 Hz/1.7 A (Max)
Output voltage/
current
Output: 19.5 V DC/3.34 A
14 | About Your Monitor
Electrical Specifications
Physical Characteristics
Model S2317HWi
Model S2317HWi
Signal cable type Digital: HDMI, 19 pins
Dimensions (with stand)
Height 408.1 mm (16.07 inches)
Width 520.7 mm (20.50 inches)
Depth 196.1 mm (7.72 inches)
Dimensions (without stand)
Height 311.6 mm (12.27 inches)
Width 520.7 mm (20.50 inches)
Depth 54.2 mm (2.13 inches)
Stand dimensions
Height 182.5 mm (7.19 inches)
Width 262.4 mm (10.33 inches)
Depth 196.1 mm (7.72 inches)
Weight
Weight with packaging 6.11 kg (13.47 lbs)
Weight with stand assembly and
cables
4.5 kg (9.92 lbs)
Weight without stand assembly 3.2 kg (7.05 lbs)

About Your Monitor | 15
Speaker Specifications
Speaker rated power 2 x 3 W
Frequency Response 200 Hz - 20 kHz
Impedance 8 ohm
Wireless Specifications
Standard 802.11 a/b/g/n/ac
Frequency Band 2.4GHz, 5GHz - Concurrent
Connectivity WiFi Direct, Miracast
Security WPA, WPA2
Content DRM HDCP 2.2
Environmental Characteristics
Operating 0 °C to 40 °C (32 °F to 104 °F)
Non-operating •Storage: -20 °C to 60 °C (-4 °F to 140 °F)
•Shipping: -20 °C to 60 °C (-4 °F to 140 °F)
Operating 10% to 80% (non-condensing)
Non-operating •Storage: 5% to 90% (non-condensing)
•Shipping: 5% to 90% (non-condensing)
Operating 5,000 m (16,404 ft) (maximum)
Non-operating 12,192 m (40,000 ft) (maximum)
•115.94 BTU/hour (maximum)
•78.43 BTU/hour (typical)
Weight of stand assembly 0.82 kg (1.81 lbs)
Front frame gloss Black frame - 85% gloss unit
Model S2317HWi
Model S2317HWi
Model S2317HWi
Temperature
Humidity
Altitude
Thermal dissipation

16 | About Your Monitor
Power Management Modes
If you have VESA's DPM™ compliance display card or software installed in your PC, the
monitor can automatically reduce its power consumption when not in use. This is
referred to as Power Save Mode*. If the computer detects input from the keyboard,
mouse, or other input devices, the monitor automatically resumes functioning. The
following table shows the power consumption and signaling of this automatic power
saving feature.
VESA Modes Horizontal
Sync
Vertical
Sync
Video Power
Indicator
Power
Consumption
Normal
operation
Active Active Active White TBD W (maximum)**
TBD W (typical)
Active-off
mode
Inactive Inactive Blanked White (Glowing) Less than 0.3 W
Switch off - - - Off Less than 0.3 W
Energy Star Power Consumption
On mode 20.9 W ***
* Zero power consumption in OFF mode can only be achieved by disconnecting the
main cable from the monitor.
** Maximum power consumption with max luminance, and USB active.
*** Energy consumption (On Mode) is tested at 230 Volts / 50 Hz. Measurements are
indicative for monitor head only without charging base turned on.
This document is informational only and reflects laboratory performance. Your product
may perform differently, depending on the software, components and peripherals you
ordered and shall have no obligation to update such information. Accordingly, the
customer should not rely upon this information in making decisions about electrical
tolerances or otherwise. No warranty as to accuracy or completeness is expressed or
implied.
NOTE: This monitor is ENERGY STAR®-compliant.

Pin
Number
19-pin Side of the
Connected Signal Cable
TMDS DATA 2+
TMDS DATA 2 SHIELD
TMDS DATA 2-
TMDS DATA 1+
TMDS DATA 1 SHIELD
TMDS DATA 1-
TMDS DATA 0+
TMDS DATA 0 SHIELD
TMDS DATA 0-
TMDS CLOCK+
TMDS CLOCK SHIELD
TMDS CLOCK-
CEC
Reserved (N.C. on device)
DDC CLOCK (SCL)
DDC DATA (SDA)
DDC/CEC Ground
+5V POWER
HOT PLUG DETECT
About Your Monitor | 17
Pin Assignments
HDMI Connector
Plug and Play Capability
You can install the monitor in any Plug and Play-compatible system. The monitor
automatically provides the computer system with its Extended Display Identification Data
(EDID) using Display Data Channel (DDC) protocols so the system can configure itself
and optimize the monitor settings. Most monitor installations are automatic; you can
select different settings if desired. For more information about changing the monitor
settings, see
Operating the Monitor .
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19

18 | About Your Monitor
Universal Serial Bus (USB) Interface
This section gives you information about the USB ports that are available on the monitor.
Transfer Speed Data Rate Power Consumption*
High speed 480 Mbps 2.5 W (Max, each port)
Full speed 12 Mbps 2.5 W (Max, each port)
Low speed 1.5 Mbps 2.5 W (Max, each port)
NOTE: This monitor is High-Speed USB 2.0 compatible.
USB Downstream Connector
Pin Number 4-pin Side of the Connector
1VCC
2DMD
3DPD
4GND
USB Ports
•2 downstream - bottom
NOTE: USB 2.0 functionality requires a USB 2.0-capable computer.
NOTE: The monitor's USB interface works only when the monitor is On or in the
power save mode. If you turn Off the monitor and then turn it On, the attached
peripherals may take a few seconds to resume normal functionality.
LCD Monitor Quality and Pixel Policy
During the LCD Monitor manufacturing process, it is not uncommon for one or more
pixels to become fixed in an unchanging state which are hard to see and do not affect
the display quality or usability. For more information on Dell Monitor Quality and Pixel
Policy, see Dell Support site at: http://www.dell.com/support/monitors.

About Your Monitor | 19
Maintenance Guidelines
Cleaning Your Monitor
CAUTION: Read and follow the Safety Instructions before cleaning the monitor.
WARNING: Before cleaning the monitor, unplug the monitor power cable from
the electrical outlet.
For best practices, follow the instructions in the list below while unpacking, cleaning, or
handling your monitor:
•To clean your anti-static screen, lightly dampen a soft, clean cloth with water. If
possible, use a special screen-cleaning tissue or solution suitable for the anti-
static coating. Do not use benzene, thinner, ammonia, abrasive cleaners, or
compressed air.
•Use a lightly-dampened, warm cloth to clean the monitor. Avoid using
detergent of any kind as some detergents leave a milky film on the monitor.
•If you notice white powder when you unpack your monitor, wipe it off with a
cloth.
•Handle your monitor with care as a darker-colored monitor may get scratched
and show white scuff marks more than a lighter-colored monitor.
•To help maintain the best image quality on your monitor, use a dynamically
changing screen saver and turn Off your monitor when not in use.

20 | Operating the Monitor
Operating the Monitor
Setting up the Miracast
Miracast is a wireless display standard that is supported by Windows®7, Windows®8,
Windows®8.1, Windows®10, Android 4.2 or newer version operating systems. The
monitor can connect to a computer or an Android device wirelessly via Miracast.
Connect the monitor to a computer with Miracast
NOTE: The environment surrounding the monitor and the computer may affect
transmission signal and compromise signal strength. Remove all objects between
the monitor and the computer to ensure maximum signal transmittion and
reception.
In Windows®8.1:
1Select Devices from the Charms bar.
2Select Project from the Devices menu.
3Select monitor name as displayed on your monitor.
4Select your Projection Mode.
