Dell SE2216H User manual

Regulatory Model: SE2216Hf / SE2216HVf
User‘s Guide
Dell SE2216H
Dell SE2216HM
Dell SE2216HV

2
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if
instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal injury,
or death.
© 2015-2020 Dell Inc. All rights reserved.
Information in this document is subject to change without notice. Reproduction of these materials
in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell™ and the DELL logo are trademarks of Dell Inc.; Microsoft®,
Windows, and the Windows start button logo are either trademarks or registered trademarks of
Microsoft Corporation in the United States and/or other countries.
Other trademarks and trade names may be used in this document to refer to either the entities
claiming the marks and names or their products. DellInc. disclaims any proprietary interest in
trademarks and trade names other than its own.
2020 – 12 Rev. A09

3
Contents
About Your Monitor ...................................... 5
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Product Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Identifying Parts and Controls . . . . . . . . . . . . . . . . . . . . . . . . . .7
Monitor Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Plug and Play Capability . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
LCD Monitor Quality & Pixel Policy . . . . . . . . . . . . . . . . . . . . . . 16
Maintenance Guidelines . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Setting Up the Monitor................................... 17
Attaching the Stand . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Connecting Your Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Organizing Your Cables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Removing the Monitor Stand . . . . . . . . . . . . . . . . . . . . . . . . . 20
Operating the Monitor ................................... 21
Power On the Monitor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Using the Front-Panel Controls . . . . . . . . . . . . . . . . . . . . . . . . 21
Using the On-Screen Display (OSD) Menu. . . . . . . . . . . . . . . . . .23
Setting the Maximum Resolution . . . . . . . . . . . . . . . . . . . . . . . 53
Using the Tilt . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55

4
Troubleshooting ........................................56
Self-Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Built-in Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Common Problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 58
Product-Specific Problems. . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Appendix ...............................................62
Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
FCC Notices (U.S. Only) and Other Regulatory Information . . . . . . . 62
Contact Dell. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .62
EU product database for energy label and product information sheet 62

About Your Monitor 5
About Your Monitor
Package Contents
Your monitor ships with all the components shown below. Ensure that you have
received all the components and Contact Dell if anything is missing.
NOTE: Some items may be optional and may not ship with your monitor. Some
features or media may not be available in certain countries.
• Display
• Stand Riser
• Stand Base
• Power Cable (varies with countries)
• VGA Cable
• Quick Start Guide
• Safety and Regulatory Information

6About Your Monitor
Product Features
The Dell SE2216H / SE2216HM / SE2216HV flat-panel display has an active matrix, Thin-
Film Transistor, Liquid Crystal Display and LED backlight.
The monitor’s features include:
• SE2216H / SE2216HM / SE2216HV: 54.61 cm (21.5 in.) diagonal viewable image
size, 1920 x 1080 resolution, plus full-screen support for lower resolutions.
• Wide viewing angle to allow viewing from a sitting or standing position, or while
moving from side-to-side.
• Tilt adjustment capability.
• Plug and play capability if supported by your system.
• On-Screen Display (OSD) adjustments for ease of set-up and screen optimization.
• Security lock slot.
• Capability to switch from wide aspect to standard aspect ratio while maintaining
the image quality.
• Asset Management Capability.
• CECP (for China).
• RoHS compliant.
• BFR/PVC- Reduced.
• SE2216H: TCO Certified Displays.
• High Dynamic Contrast Ratio (8,000,000:1).
• Energy Gauge shows the energy level being consumed by the monitor in real time.
• ≤ 0.3 W in Standby Mode.
• Analog backlight dimming control for flicker free display.

About Your Monitor 7
Identifying Parts and Controls
Front View
1 Function buttons To access the OSD menu and change the settings if required.
For more information, see Operating the Monitor.
2 Power On/Off
button (with LED
indicator)
To turn the monitor On or Off.
Solid white light indicates that the monitor is turned on and
functioning normally. Blinking white light indicates that the
monitor is in Standby Mode.
NOTE: For displays with glossy bezels the user should consider the placement of
the display as the bezel may cause disturbing reflections from surrounding light
and bright surfaces.

8About Your Monitor
Back View
Back View with Monitor Stand
Label Description Use
1 Security lock slot Secures monitor with security lock
(security lock not included).
2 Barcode serial number label Refer to this label if you need to contact
Dell for technical support.
3 Cable management slot Use to organize cables by placing them
through the slot.
Side View

About Your Monitor 9
Bottom View
Label Description Use
1 AC power connector To connect the monitor power cable.
2 HDMI connector Connect your computer with HDMI cable.
3 VGA connector To connect your computer to the monitor using
a VGA cable.
4 Regulatory rating label Lists of regulatory approvals.
Label Description Use
1 AC power connector To connect the monitor power cable.
2 VGA connector To connect your computer to the monitor using
a VGA cable.
3 Regulatory rating label Lists of regulatory approvals.

10 About Your Monitor
Monitor Specifications
The following section give you information about pin assignments for the various
connectors of your monitor.
Pin Assignments
15-pin D-Sub connector
Pin Number Monitor Side of the 15-pin Side Signal Cable
1 Video-Red
2 Video-Green
3 Video-Blue
4 GND
5 Self-test
6 GND-R
7 GND-G
8 GND-B
9 DDC +5 V
10 GND-sync
11 GND
12 DDC data
13 H-sync
14 V-sync
15 DDC clock

About Your Monitor 11
HDMI connector
Pin Number 19-pin Side of the Connected Signal Cable
1 TMDS DATA 2+
2 TMDS DATA 2 SHIELD
3 TMDS DATA 2-
4 TMDS DATA 1+
5 TMDS DATA 1 SHIELD
6 TMDS DATA 1-
7 TMDS DATA 0+
8 TMDS DATA 0 SHIELD
9 TMDS DATA 0-
10 TMDS CLOCK
11 TMDS CLOCK SHIELD
12 TMDS CLOCK-
13 No Connection
14 No Connection
15 DDC CLOCK (SDA)
16 DDC DATA (SDA)
17 GND
18 +5 V POWER
19 HOT PLUG DETECT

12 About Your Monitor
Plug and Play Capability
You can install the monitor in any Plug and Play compatible system. The monitor
automatically provides the computer with its Extended Display Identification Data (EDID)
using Display Data Channel (DDC) protocols so that the computer can configure itself
and optimize the monitor settings. Most monitor installations are automatic. You can
select different settings as required.
Flat-Panel Specifications
Model number SE2216H / SE2216HM /
SE2216HV
Screen type Active matrix - TFT LCD
Panel Type Vertical Alignment
Viewable image
Diagonal 546.1 mm (21.5 in.)
Horizontal Active Area 476.064 mm (18.74 in.)
Vertical Active Area 267.786 mm (10.54 in.)
Area 127483.27 mm2(197.52 in.2)
Pixel pitch 0.24795 x 0.24795 mm
Viewing angle:
Horizontal 178° typical
Vertical 178° typical
Luminance output 250 cd/m² (typical)
Contrast ratio 3000 to 1 (typical)
Dynamic Contrast ratio 8,000,000 to 1 (typical) *
Faceplate coating Antiglare with hard-coating 3H
Backlight LED light bar system
Response Time 12 ms typical (grey to grey)
Color Depth 16.7 mil colors
Color Gamut 84 % (typical) **
* Based on estimation.
** SE2216H / SE2216HM / SE2216HV color gamut (typical) is based on CIE1976 (84 %)
and CIE1931 (72 %) test standards.

About Your Monitor 13
Resolution Specifications
Model number SE2216H / SE2216HM /
SE2216HV
Scan range
• Horizontal 30 kHz to 83 kHz (automatic)
• Vertical 56 Hz to 76 Hz (automatic)
Maximum preset
resolution
1920 x 1080 at 60 Hz
Electrical Specifications
Model number SE2216H / SE2216HM SE2216HV
Video input signals • Analog RGB: 0.7 Volts
± 5 %, 75 ohm input
impedance
• HDMI, 600mV for each
differential line, 100 ohm
input impedance per
differential pair
• Analog RGB: 0.7 Volts
± 5 %, 75 ohm input
impedance
Synchronization input
signals
Separate horizontal and vertical synchronizations, polarity-free
TTL level, SOG (Composite SYNC on green)
AC input voltage /
frequency / current
100 VAC to 240 VAC / 50 Hz or 60 Hz ± 3 Hz / 1.0 A (typical)
Inrush current 120 V: 30 A (Max.)
240 V: 60 A (Max.)
Power Consumption 0.2 W (Off Mode)1
0.3 W (Standby Mode)1
15.5 W (On Mode)1
24 W (Max)2
15.1 W (Pon)3
48.6 kWh (TEC)3
1As defined in EU 2019/2021 and EU 2019/2013.
2Max brightness and contrast setting.
3Pon : Power consumption of On Mode measured with reference to Energy Star test method.
TEC: Total energy consumption in kWh measured with reference to Energy Star test method.
This document is informational only and reflects laboratory performance. Your product
may perform differently, depending on the software, components, and peripherals you
ordered, and shall have no obligation to update such information. Accordingly, the
customer should not rely upon this information in making decisions about electrical
tolerances or otherwise. No warranty as to accuracy or completeness is expressed or
implied.

14 About Your Monitor
Preset Display Modes
The following table lists the preset modes for which Dell guarantees image size and
centering:
Display mode
Horizontal
frequency
(kHz)
Vertical
frequency
(Hz)
Pixel clock
(MHz)
Sync polarity
(Horizontal/
Vertical)
VESA, 720 x 400 31.5 70.1 28.3 -/+
VESA, 640 x 480 31.5 59.9 25.2 -/-
VESA, 640 x 480 37.5 75.0 31.5 -/-
VESA, 800 x 600 37.9 60.3 40.0 +/+
VESA, 800 x 600 46.9 75.0 49.5 +/+
VESA, 1024 x 768 48.4 60.0 65.0 -/-
VESA, 1024 x 768 60.0 75.0 78.8 +/+
VESA, 1152 x 864 67.5 75.0 108.0 +/+
VESA, 1280 x 1024 64.0 60.0 108.0 +/+
VESA, 1280 x 1024 80.0 75.0 135.0 +/+
VESA, 1600 x 900 60.0 60.0 108.0 +/+
VESA, 1920 x 1080 67.5 60.0 148.5 +/+
Physical Characteristics
The following table lists the monitor's physical characteristics:
Model number SE2216H / SE2216HM SE2216HV
Connector type • 15-pin D-subminiature
(Black connector);
• HDMI
• 15-pin D-subminiature
(Black connector)
Signal cable type • Analog: D-Sub, 15 pins;
• Digital: HDMI, 19 pins
(cable not included)
• Analog: D-Sub, 15 pins
Dimensions: (with stand)
Height 395.7 mm (15.58 in.) 395.7 mm (15.58 in.)
Width 506.2 mm (19.93 in.) 506.2 mm (19.93 in.)
Depth 179.9 mm (7.08 in.) 179.9 mm (7.08 in.)

About Your Monitor 15
Dimensions:
(without stand)
Height 302.7 mm (11.92 in.) 302.7 mm (11.92 in.)
Width 506.2 mm (19.93 in.) 506.2 mm (19.93 in.)
Depth 54.7 mm (2.15 in.) 54.7 mm (2.15 in.)
Stand dimensions:
Height 174.7 mm (6.8 in.) 174.7 mm (6.8 in.)
Width 250.0 mm (9.84 in.) 250.0 mm (9.84 in.)
Depth 179.9 mm (7.08 in.) 179.9 mm (7.08 in.)
Weight:
Weight with packaging 4.80 kg (10.58 lb) 4.80 kg (10.58 lb)
Weight with stand
assembly and cables
3.61 kg (7.96 lb) 3.61 kg (7.96 lb)
Weight without stand
assembly (no cables)
2.78 kg (6.13 lb) 2.78 kg (6.13 lb)
Weight of stand assembly 0.54 kg (1.19 lb) 0.54 kg (1.19 lb)
Environmental Characteristics
The following table lists the environmental conditions for your monitor:
Model number SE2216H / SE2216HM / SE2216HV
Temperature
• Operating 0 °C to 40 °C (32 °F to 104 °F)
• Non-operating Storage: -20 °C to 60 °C (-4 °F to 140 °F)
Shipping: -20 °C to 60 °C (-4 °F to 140 °F)
Humidity
• Operating 10 % to 80 % (non-condensing)
• Non-operating Storage: 5 % to 90 % (non-condensing)
Shipping: 5 % to 90 % (non-condensing)
Altitude
• Operating 5,000 m (16,404 ft) max
• Non-operating 12,191 m (40,000 ft) max
Thermal dissipation 81.9 BTU/hour (maximum)
61.4 BTU/hour (typical)

16 About Your Monitor
LCD Monitor Quality & Pixel Policy
During the LCD Monitor manufacturing process, it is not uncommon for one or more
pixels to become fixed in an unchanging state. The visible result is a fixed pixel that
appears as an extremely tiny dark or bright discolored spot. When the pixel remains
permanently lit, it is known as a “bright dot.” When the pixel remains black, it is known
as a “dark dot.”
In almost every case, these fixed pixels are hard to see and do not detract from display
quality or usability. A display with 1 to 5 fixed pixels is considered normal and within
competitive standards. For more information, see Dell Support site at:
http://www.dell.com/support/monitors.
Maintenance Guidelines
Caring for Your Monitor
CAUTION: Read and follow the safety instructions before cleaning the
monitor.
CAUTION: Before cleaning the monitor, unplug the monitor power
cable from the electrical outlet.
For best practices, follow these instructions while unpacking, cleaning, or handling your
monitor:
• To clean your antistatic screen, slightly dampen a soft and clean cloth with water. If
possible, use a special screen-cleaning tissue or solution suitable for the antistatic
coating. Do not use benzene, thinner, ammonia, abrasive cleaners, or compressed
air.
• Use a slightly dampened, warm cloth to clean the plastics. Avoid using detergent of
any kind as some detergents leave a milky film on the plastics.
• If you notice a white powder when you unpack your monitor, wipe it off with a
cloth. This white powder occurs during the shipping of the monitor.
• Handle your monitor with care as a darker-colored monitor may scratch and show
white scuff marks more than a lighter-colored monitor.
• To help maintain the best image quality on your monitor, use a dynamically
changing screen saver and power off your monitor when not in use.

Setting Up the Monitor 17
Setting Up the Monitor
Attaching the Stand
NOTE: The stand base is detached when the monitor is shipped from the factory.
1. Assemble the stand riser to stand base.
a. Place the monitor stand base on a stable table top.
b. Slide the monitor stand body in the correct direction down onto the
stand base until it clicks into place.
2. Attach the stand assembly to the monitor:
a. Place the monitor on a soft cloth or cushion near the edge of desk.
b. Align the stand assembly bracket to the monitor groove.
c. Insert the bracket towards monitor until it locks in place.

18 Setting Up the Monitor
Connecting Your Monitor
WARNING: Before you begin any of the procedures in this section, follow
the Safety Instruction.
To connect your monitor to the computer:
1. Turn o your computer and disconnect the power cable.
2. Connect the black VGA or HDMI cable to the corresponding video port
on the back of your computer. Do not use all cables at the same time.
Use the all cables only when they are connected to dierent computers
with appropriate video systems.
Connecting VGA Cable
SE2216H / SE2216HM:
SE2216HV:

Setting Up the Monitor 19
Connecting HDMI cable (Optional Purchase) (for
SE2216H / SE2216HM)
NOTE: The graphics are used for the purpose of illustration only. Appearance on the
computer may vary.
Organizing Your Cables
After attaching all necessary cables to your monitor and computer, (See Connecting
Your Monitor for cable attachment), organize all cables as shown above.

20 Setting Up the Monitor
Removing the Monitor Stand
NOTE: This is applicable for a monitor with a stand. When any other stand is bought,
please refer to the respective stand setup guide for the removal instructions.
1. Place the monitor on a soft cloth or cushion near the edge of desk.
2. Use a long and thin screwdriver to push the release latch located in a
hole just above the stand.
3. Once the latch is released, remove the base away from the monitor.
