Dell SE2422H User manual

Model: SE2422H/SE2422HX
Regulatory model: SE2422Ht/SE2422Hf/SE2422Hb
Dell 24 Monitor
SE2422H/SE2422HX
User’s Guide

NOTE: A NOTE indicates important information that helps you make
better use of your monitor.
CAUTION: A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
Copyright © 2021 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are
trademarks of Dell Inc. or its subsidiaries. Other trademarks may be trademarks of their respective owners.
2021 – 04
Rev. A00

Contents
Safety instructions.......................... 5
About your monitor ......................... 6
Package contents . . . . . . . . . . . . . . . . . . . . . . 6
Product features . . . . . . . . . . . . . . . . . . . . . . .8
Identifying parts and controls . . . . . . . . . . . . . . . .9
Front view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
Back view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Bottom view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Monitor specifications . . . . . . . . . . . . . . . . . . . 12
Resolution specifications . . . . . . . . . . . . . . . . . . . . . . 13
Preset display modes . . . . . . . . . . . . . . . . . . . . . . . . 14
Electrical specifications. . . . . . . . . . . . . . . . . . . . . . . 15
Physical characteristics. . . . . . . . . . . . . . . . . . . . . . . 16
Environmental characteristics . . . . . . . . . . . . . . . . . . . 17
Pin assignments . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Plug-and-Play . . . . . . . . . . . . . . . . . . . . . . . 20
LCD monitor quality and pixel policy . . . . . . . . . . . 20
Ergonomics. . . . . . . . . . . . . . . . . . . . . . . . . 21
Handling and moving your display . . . . . . . . . . . . . 23
Maintenance guidelines . . . . . . . . . . . . . . . . . . 24
Cleaning your monitor. . . . . . . . . . . . . . . . . . . . . . . . 24
Contents | 3

4| Contents
Setting up the monitor...................... 25
Connecting the stand . . . . . . . . . . . . . . . . . . . 25
Using the tilt . . . . . . . . . . . . . . . . . . . . . . . . 28
Connecting your monitor . . . . . . . . . . . . . . . . . 29
Organizing your cables . . . . . . . . . . . . . . . . . . 30
Securing your monitor using Kensington lock (optional) . 31
Removing the monitor stand . . . . . . . . . . . . . . . 32
Wall mounting (optional) . . . . . . . . . . . . . . . . . 33
Operating the monitor ...................... 34
Power on the monitor . . . . . . . . . . . . . . . . . . . 34
Using the front panel controls. . . . . . . . . . . . . . . 34
Using the OSD lock function . . . . . . . . . . . . . . . 36
To unlock the button(s). . . . . . . . . . . . . . . . . . . 38
Front-panel button . . . . . . . . . . . . . . . . . . . . . 39
Using the On-Screen Display (OSD) menu . . . . . . . . 40
Accessing the menu system . . . . . . . . . . . . . . . . . . . . 40
OSD warning messages . . . . . . . . . . . . . . . . . . . . . . . 52
Setting the maximum resolution . . . . . . . . . . . . . . . . . . 56
Troubleshooting ............................57
Self-test . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Built-in diagnostics . . . . . . . . . . . . . . . . . . . . 58
Common problems . . . . . . . . . . . . . . . . . . . . . 59
Product specific problems. . . . . . . . . . . . . . . . . 62
Appendix................................. 63
Contacting Dell. . . . . . . . . . . . . . . . . . . . . . . 63
EU product database for energy label and product
information sheet . . . . . . . . . . . . . . . . . . . . . 63

Safety instructions | 5
Safety instructions
WARNING: Use of controls, adjustments, or procedures other than those
specified in this documentation may result in exposure to shock, electrical
hazards, and/or mechanical hazards.
• Place the monitor on a solid surface and handle it carefully. The screen is fragile
and can be damaged if dropped or hit sharply.
• Always be sure that your monitor is electrically rated to operate with the AC
power available in your location.
• Keep the monitor in room temperature. Excessive cold or hot conditions can have
an adverse effect on the liquid crystal of the display.
• Do not subject the monitor to severe vibration or high impact conditions. For
example, do not place the monitor inside a car trunk.
• Unplug the monitor when it is going to be left unused for an extended period of
time.
• To avoid electric shock, do not attempt to remove any cover or touch the inside
of the monitor.
For information on safety instructions, see the Safety, Environmental, and Regulatory
Information (SERI).

6| About your monitor
About your monitor
Package contents
NOTE: Some components may be optional and may not ship with your
monitor.
Your monitor ships with the components shown in the table below. If any component
is missing, contact Dell technical support for assistance. For more information on
contacting Dell, See Contacting Dell.
Display
Stand riser
Stand base
VESA cover
Power cable (varies by country)

About your monitor | 7
HDMI cable
VGA cable (SE2422HX only)
• Quick Setup Guide
• Safety, Environmental, and
Regulatory Information

8| About your monitor
Product features
The Dell SE2422H/SE2422HX monitor has an active matrix, Thin-Film Transistor
(TFT), Liquid Crystal Display (LCD), and LED backlight. The monitor features include:
• 60.45 cm (23.8 in.) viewable area monitor (measured diagonally) 1920 x 1080
(16:9) resolution, plus full-screen support for lower resolutions.
• Color gamut of 72% NTSC (typical),CIE 1931.
• Digital connectivity with HDMI.
• Tilt adjustment capability.
• Removable pedestal stand and Video Electronics Standards Association (VESA™)
100 mm mounting holes for flexible mounting solutions.
• Plug and play capability, if supported by your computer.
• On-Screen Display (OSD) adjustments for ease of set-up and screen
optimization.
• Power and OSD buttons lock.
• Security lock slot.
• Stand lock.
• ≤ 0.3 W in Standby mode.
• The monitor adopts Flicker-Free technology, which clears the eye visible flicker,
brings comfort viewing experience and preventing users suffer from eye strain
and fatigue.
• Supports 48 Hz to 75 Hz (HDMI) in FreeSync Mode.
• Supports AMD FreeSync™ technology
• Optimize eye comfort with a TÜV-certified flicker-free screen.
WARNING: The possible long-term effects of blue light emission from the
monitor may cause damage to the eyes, including eye fatigue, digital eye
strain, and so on.

About your monitor | 9
Identifying parts and controls
Front view
21
Label Description Use
1Function buttons For more information, see
Operating the monitor.
2Power LED indicator Solid white light indicates
the monitor is turned on and
functioning normally. Blinking
white light indicates the monitor
is in Standby mode.

10 | About your monitor
Back view
2
4
6
1
2
3
45
6
Label Description Use
1VESA mounting holes (100 mm x
100 mm-behind the VESA cover)
Wall mount the monitor using VESA-
compatible wall mount kit (100 mm x 100
mm).
NOTE: Wall mount kit is not shipped with
your monitor and is sold separately.
2Regulatory label Lists the regulatory approvals.
3Stand release button Releases stand from the monitor.
4Barcode, serial number, and Service
Tag label
The Service Tag is a unique alphanumeric
identifier that enables Dell service
technicians to identify the hardware
components in your monitor and access
warranty information. Refer to this label
if you need to contact Dell for technical
support.
5Cable-management slot Connect the cables by inserting them
through the slot.
6VESA cover The two endpoints on the front of the
VESA cover are aligned with the VESA
mounting holes and the VESA cover is
gently pressed.

About your monitor | 11
Bottom view
1 2 3 4
Label Description Use
1Security lock slot Secures monitor with security cable lock (sold separately).
2Power connector Connect the power cable (shipped with your monitor).
3HDMI port Connect the HDMI cable (shipped with your monitor).
4VGA port Connect the VGA cable (SE2422HX only)

12 | About your monitor
Monitor specifications
Description Values
Screen type Active matrix - TFT LCD
Panel type Vertical Alignment (VA)
Aspect ratio 16:9
Viewable image dimensions
Diagonal 604.50 mm (23.80 in.)
Active Area
Horizontal 527.04 mm (20.75 in.)
Vertical 296.46 mm (11.67 in.)
Area 156246.28 mm2(242.18 in.2)
Pixel pitch 0.2745 mm x 0.2745 mm
Pixel per inch (PPI) 92.56
Viewing angle
Horizontal 178° (typical)
Vertical 178° (typical)
Brightness 250 cd/m² (typical)
Contrast ratio 3000 to 1 (typical)
Display screen coating Anti-glare with 3H hardness
Backlight LED edgelight system
Response Time (Gray to
Gray)
12 ms (Normal mode)
8 ms (Fast mode)
5 ms (Extreme mode)
NOTE: In Extreme mode, slight artifacts may be
encountered due to overdriving for fast speed and
responsiveness. Use Normal/Fast/Extreme mode
for optimal front of screen experience and game
play.
Color depth 16.70 million colors
Color gamut* 72% NTSC, CIE 1931
Connectivity • 1 x HDMI 1.4 port
• 1 x VGA
Border width (edge of monitor to active area)
Top 12.80 mm

About your monitor | 13
Left/Right 12.80 mm
Bottom 16.92 mm
Adjustability
Height adjustable stand NA
Tilt -5° to 21°
Cable management Yes
Dell Display Manager (DDM)
Compatibility Easy Arrange and other key features
Security Security lock slot (cable lock sold separately)
* At panel native only, under Custom Mode preset.
Resolution specifications
Model SE2422H SE2422HX
Description HDMI VGA HDMI VGA
Horizontal scan range 30 to 83 kHz 31 to 84 kHz 31 to 80 kHz
Vertical scan range 48 to 75 Hz
Maximum preset
resolution
1920x1080 @ 75Hz(HDMI)
1920x1080 @ 60Hz(VGA)
Video display
capabilities (HDMI
mode)
480p, 576p, 720p, 1080i, 1080p, FHD

14 | About your monitor
Preset display modes
Display Mode Horizontal
Frequency
(kHz)
Vertical
frequency
(Hz)
Pixel Clock
(MHz)
Sync Polarity
(Horizontal/
Vertical)
720 x 400
31.47
70.08
28.32
-/+
640 x 480 31.47 59.94 25.18 -/-
640 x 480 37.50 75 31.50 -/-
800 x 600 37.88 60.317 40 +/+
800 x 600 46.88 75 49.50 +/+
1024 x 768 48.36 60 65 -/-
1024 x 768
60.02
75.029
78.75
+/+
1152 x 864 67.50 75 108 +/+
1280 x 1024 64 60.02 108 +/+
1280 x 1024 80 75.02 135 +/+
1600 x 900 60 60 108 +/+
1920 x 1080 67.50 60 148.50 +/+
1920 x 1080
83.89
75
174.50
+/-

About your monitor | 15
Electrical specifications
Description Values
Video input signals • HDMI 1.4 , 600mV for each dierential line, 100
ohm input impedance per dierential pair
• Analog RGB, 0.7 Volts +/- 5%, positive polarity at
75 Ω input impedance
Input voltage/ frequency/
current
100-240 VAC / 50 or 60 Hz ± 3 Hz / 1.5 A
(maximum)
Inrush current 120 V: 30 A (max.) at 0°C (cold start)
240 V: 60 A (max.) at 0°C (cold start)
Power Consumption 0.3 W (Off Mode)1
0.3 W (Standby mode)1
15.7 W (On Mode)1
24 W (Max)2
15.9 W (Pon)3
49.7 kWh (TEC)3
1As defined in EU 2019/2021 and EU 2019/2013.
2Max brightness and contrast setting.
3Pon: Power consumption of On Mode measured with reference to Energy Star test
method.
TEC: Total energy consumption in kWh measured with reference to Energy Star test
method.
CAUTION: This document is informational only and reflects laboratory
performance. Your product may perform differently, depending on the
software, components and peripherals you ordered and shall have no
obligation to update such information. Accordingly, the customer should
not rely upon this information in making decisions about electrical
tolerances or otherwise. No warranty as to accuracy or completeness is
expressed or implied.

16 | About your monitor
Physical characteristics
Description SE2422H SE2422HX
Connector type • One HDMI 1.4 port
• One VGA port
Signal cable type • HDMI 1.8 m cable
• VGA 1.8 m cable (SE2422HX only)
Dimensions (with stand)
Height (extended) 420.25 mm (16.55 in.)
Width 552.64 mm (21.76 in.)
Depth 178.81 mm (7.04 in.)
Dimensions (without stand)
Height 331.61 mm (13.06 in.)
Width 552.64 mm (21.76 in.)
Depth 49.69 mm (1.96 in.)
Stand dimensions
Height (extended) 173.93 mm (6.85 in.)
Width 240.42 mm (9.47 in.)
Depth 178.81 mm (7.04 in.)
Weight
Weight with packaging 5.23 kg (11.53 lb) 5.33 kg (11.75 lb)
Weight with stand assembly and
cables 3.77 kg (8.31 lb) 3.87 kg (8.53 lb)
Weight without stand assembly
(For wall mount or VESA mount
considerations - no cables)
3.18 kg (7.01 lb) 3.18 kg (7.01 lb)
Weight of stand assembly 0.33kg (0.73 lb) 0.33kg (0.73 lb)

About your monitor | 17
Environmental characteristics
Description Values
Compliant Standards
• RoHS Compliant
• BFR/PVC reduced monitor (excluding external cables)
• Arsenic-Free glass and Mercury-Free for the panel only
Temperature
Operating 0°C to 40°C (32°F to 104°F)
Non-operating Storage:–20°C to 60°C (–4°F to 140°F)
Shipping:–20°C to 60°C (–4°F to 140°F)
Humidity
Operating
(non-condensing)
20% to 90%
Non-operating
(non-condensing) •Storage: 5 % to 90 %
•Shipping: 5 % to 90 %
Altitude
Operating
(maximum)
5000 m (16,404 ft)
Non-operating
(maximum)
12.192 m (40,000 ft)
Thermal dissipation 81.89 BTU/hour (maximum)
53.57 BTU/hour (on mode)

18 | About your monitor
Pin assignments
VGA connector
Pin number 15-pin side of theconnected signal cable
1Video-Red
2Video-Green
3Video-Blue
4GND
5Self-test
6GND-R
7GND-G
8GND-B
9Computer 5 V / 3.3 V
10 GND-sync
11 GND
12 DDC data
13 H-sync
14 V-sync
15 DDC clock

About your monitor | 19
HDMI port
Pin number 19-pin side of
theconnected signal
cable
Pin
number
19-pin side of
theconnected signal
cable
1TMDS DATA 2+ 11 TMDS CLOCK SHIELD
2TMDS DATA 2 SHIELD 12 TMDS CLOCK-
3TMDS DATA 2- 13 CEC
4TMDS DATA 1+ 14 Reserved (N.C. on device)
5TMDS DATA 1 SHIELD 15 DDC CLOCK (SCL)
6TMDS DATA 1- 16 DDC DATA (SDA)
7TMDS DATA 0+ 17 DDC/CEC Ground
8TMDS DATA 0 SHIELD 18 +5 V POWER
9TMDS DATA 0- 19 HOT PLUG DETECT
10 TMDS CLOCK+

20 | About your monitor
Plug-and-Play
You can install the monitor in any Plug-and-Play-compatible system. The monitor
automatically provides the computer system with its extended display identification
data (EDID) using display data channel (DDC) protocols so the computer can configure
itself and optimize the monitor settings. Most monitor installations are automatic;
you can select different settings if desired. For more information about changing the
monitor settings, see Operating the monitor.
LCD monitor quality and pixel policy
During the LCD monitor manufacturing process, it is common for one or more pixels
to become fixed in an unchanging state.This is hard to notice and will not affect the
display quality or usability. For more information on LCD Monitor Pixel Policy, see:
https://www.dell.com/pixelguidelines.
