Dell 0G8DW Manual

Dell EMC PowerEdge R640
Installation and Service Manual
Regulatory Model: E39S Series
Regulatory Type: E39S001
Questo manuale d’istruzione è fornito da trovaprezzi.it. Scopri tutte le offerte per Dell PowerEdge
R640 0G8DW o cerca il tuo prodotto tra le migliori offerte di Server

Notes, cautions, and warnings
NOTE: A NOTE indicates important information that helps you make better use of your product.
CAUTION: A CAUTION indicates either potential damage to hardware or loss of data and tells you how to avoid the problem.
WARNING: A WARNING indicates a potential for property damage, personal injury, or death.
© 2017 - 2019 Dell Inc. or its subsidiaries. All rights reserved. Dell, EMC, and other trademarks are trademarks of Dell Inc. or its subsidiaries. Other
trademarks may be trademarks of their respective owners.
2019 - 04
Rev. A04

Contents
1 Dell EMC PowerEdge R640 system overview.................................................................................................8
Supported congurations for PowerEdge R640............................................................................................................8
Front view of the system.................................................................................................................................................10
Left control panel view...............................................................................................................................................13
Right control panel view............................................................................................................................................ 16
Back view of the system..................................................................................................................................................18
NIC indicator codes................................................................................................................................................... 22
Power supply unit indicator codes...........................................................................................................................22
Drive indicator codes.......................................................................................................................................................25
LCD panel..........................................................................................................................................................................25
Viewing Home screen................................................................................................................................................26
Setup menu.................................................................................................................................................................27
View menu...................................................................................................................................................................27
Locating the Service Tag of your system......................................................................................................................27
System information label.................................................................................................................................................28
PowerEdge R640 – Front system information label..............................................................................................28
PowerEdge R640 – Service information................................................................................................................ 29
2 Documentation resources............................................................................................................................. 31
3 Technical specications............................................................................................................................... 33
System dimensions.......................................................................................................................................................... 33
Chassis weight................................................................................................................................................................. 34
Processor specications................................................................................................................................................. 34
Supported operating systems.........................................................................................................................................34
Cooling fan specications............................................................................................................................................... 34
PSU specications...........................................................................................................................................................34
System battery specications........................................................................................................................................ 35
Expansion bus specications..........................................................................................................................................35
Memory specications.................................................................................................................................................... 35
Storage controller specications....................................................................................................................................36
Drives.................................................................................................................................................................................36
Hard drive specications...........................................................................................................................................36
Optical drive................................................................................................................................................................36
Ports and connectors specications............................................................................................................................. 36
USB ports................................................................................................................................................................... 36
NIC ports.....................................................................................................................................................................37
Serial port....................................................................................................................................................................37
VGA ports................................................................................................................................................................... 38
IDSDM or vFlash card............................................................................................................................................... 38
Environmental specications..........................................................................................................................................38
Standard operating temperature..............................................................................................................................40
Contents 3

Expanded operating temperature............................................................................................................................ 40
Particulate and gaseous contamination specications..........................................................................................42
4 Initial system setup and conguration.......................................................................................................... 44
Setting up your system................................................................................................................................................... 44
iDRAC conguration........................................................................................................................................................ 44
Options to set up iDRAC IP address........................................................................................................................44
Log in to iDRAC..........................................................................................................................................................45
Options to install the operating system.........................................................................................................................45
Methods to download rmware and drivers...........................................................................................................45
Downloading drivers and rmware.......................................................................................................................... 46
5 Pre-operating system management applications..........................................................................................47
Options to manage the pre-operating system applications........................................................................................ 47
System Setup................................................................................................................................................................... 47
Viewing System Setup...............................................................................................................................................47
System Setup details.................................................................................................................................................48
System BIOS.............................................................................................................................................................. 48
iDRAC Settings utility................................................................................................................................................ 68
Device Settings.......................................................................................................................................................... 68
Dell Lifecycle Controller...................................................................................................................................................68
Embedded system management............................................................................................................................. 68
Boot Manager.................................................................................................................................................................. 68
Viewing Boot Manager..............................................................................................................................................68
Boot Manager main menu........................................................................................................................................ 69
One-shot UEFI boot menu....................................................................................................................................... 69
System Utilities...........................................................................................................................................................69
PXE boot...........................................................................................................................................................................69
6 Installing and removing system components ............................................................................................... 70
Safety instructions...........................................................................................................................................................70
Before working inside your system................................................................................................................................ 70
After working inside your system...................................................................................................................................70
Recommended tools........................................................................................................................................................70
Optional front bezel.......................................................................................................................................................... 71
Removing the front bezel.......................................................................................................................................... 71
Installing the front bezel............................................................................................................................................ 72
System cover....................................................................................................................................................................72
Removing the system cover.....................................................................................................................................72
Installing the system cover........................................................................................................................................73
Backplane cover............................................................................................................................................................... 74
Removing the backplane cover................................................................................................................................ 74
Installing the backplane cover.................................................................................................................................. 75
Inside the system............................................................................................................................................................. 76
Air shroud.......................................................................................................................................................................... 79
Removing the air shroud........................................................................................................................................... 79
4Contents

Installing the air shroud............................................................................................................................................. 80
Cooling fans.......................................................................................................................................................................81
Removing a cooling fan..............................................................................................................................................81
Installing a cooling fan............................................................................................................................................... 82
System memory............................................................................................................................................................... 83
System memory guidelines....................................................................................................................................... 83
General memory module installation guidelines......................................................................................................85
NVDIMM-N memory module installation guidelines .............................................................................................86
Mode-specic guidelines...........................................................................................................................................87
Removing a memory module....................................................................................................................................90
Installing a memory module....................................................................................................................................... 91
NVDIMM-N battery.........................................................................................................................................................92
Removing the NVDIMM-N battery..........................................................................................................................92
Installing the NVDIMM-N battery............................................................................................................................93
Processors and heat sinks.............................................................................................................................................. 93
Removing a processor and heat sink module.........................................................................................................93
Removing the processor from the processor and heat sink module...................................................................95
Installing the processor into a processor and heat sink module...........................................................................97
Installing a processor and heat sink module........................................................................................................... 99
Expansion cards and expansion card risers.................................................................................................................100
Expansion bus specications.................................................................................................................................. 100
Removing an expansion card riser..........................................................................................................................106
Installing an expansion card riser............................................................................................................................108
Removing expansion card from the expansion card riser.....................................................................................110
Installing an expansion card into expansion card riser.......................................................................................... 113
M.2 SSD module..............................................................................................................................................................116
Removing the M.2 SSD module.............................................................................................................................. 116
Installing the M.2 SSD module.................................................................................................................................116
Optional IDSDM or vFlash module................................................................................................................................ 117
Removing the MicroSD card....................................................................................................................................117
Installing the MicroSD card......................................................................................................................................118
Removing the optional IDSDM or vFlash card.......................................................................................................118
Installing optional IDSDM or vFlash card................................................................................................................119
Network daughter card..................................................................................................................................................120
Removing the network daughter card...................................................................................................................120
Installing the network daughter card...................................................................................................................... 121
Integrated storage controller card................................................................................................................................ 122
Removing the integrated storage controller card.................................................................................................122
Installing the integrated storage controller card................................................................................................... 124
Drives............................................................................................................................................................................... 125
Removing a drive blank............................................................................................................................................125
Installing a drive blank.............................................................................................................................................. 126
Removing a drive carrier.......................................................................................................................................... 127
Installing a drive carrier............................................................................................................................................128
Removing the drive from the drive carrier............................................................................................................129
Contents 5

Installing a drive into the drive carrier....................................................................................................................129
Backplane........................................................................................................................................................................ 130
Backplane details......................................................................................................................................................130
Removing the backplane cover............................................................................................................................... 131
Installing the backplane............................................................................................................................................132
Removing the 2.5 inch drive rear backplane.........................................................................................................133
Installing the 2.5 inch drive rear backplane........................................................................................................... 134
Cable routing...................................................................................................................................................................136
SAS expander card..........................................................................................................................................................141
Removing the SAS expander card.......................................................................................................................... 141
Installing the SAS expander card............................................................................................................................142
Rear drive cage...............................................................................................................................................................143
Removing the rear drive cage.................................................................................................................................143
Installing the rear drive cage................................................................................................................................... 144
System battery............................................................................................................................................................... 145
Replacing the system battery................................................................................................................................. 145
USB module.................................................................................................................................................................... 146
Removing the USB module.....................................................................................................................................146
Installing the USB module........................................................................................................................................147
VGA module.................................................................................................................................................................... 148
Removing the VGA module.....................................................................................................................................148
Installing the VGA module....................................................................................................................................... 149
Optional internal USB memory key.............................................................................................................................. 150
Replacing the optional internal USB memory key................................................................................................ 150
Optical drive (optional)...................................................................................................................................................151
Removing the optical drive...................................................................................................................................... 151
Installing the optical drive........................................................................................................................................ 152
Power supply units......................................................................................................................................................... 152
Hot spare feature..................................................................................................................................................... 153
Removing a power supply unit blank......................................................................................................................153
Installing a power supply unit blank........................................................................................................................154
Removing a power supply unit................................................................................................................................154
Installing a power supply unit..................................................................................................................................155
Removing a DC power supply unit......................................................................................................................... 156
Installing DC power supply unit...............................................................................................................................157
Wiring instructions for a DC power supply unit.................................................................................................... 157
System board..................................................................................................................................................................158
Removing the system board................................................................................................................................... 158
Installing the system board......................................................................................................................................159
Trusted Platform Module...............................................................................................................................................162
Upgrading the Trusted Platform Module...............................................................................................................162
Initializing TPM for BitLocker users........................................................................................................................163
Initializing the TPM 1.2 for TXT users.................................................................................................................... 163
Control panel...................................................................................................................................................................163
Removing the left control panel............................................................................................................................. 163
6Contents

Installing the left control panel................................................................................................................................164
Removing the right control panel...........................................................................................................................165
Installing the right control panel............................................................................................................................. 166
7 Using system diagnostics........................................................................................................................... 168
Dell Embedded System Diagnostics.............................................................................................................................168
Running the Embedded System Diagnostics from Boot Manager.....................................................................168
Running the Embedded System Diagnostics from the Dell Lifecycle Controller..............................................168
System diagnostic controls..................................................................................................................................... 169
8 Jumpers and connectors ........................................................................................................................... 170
System board jumpers and connectors........................................................................................................................ 171
System board jumper settings...................................................................................................................................... 172
Disabling forgotten password........................................................................................................................................173
9 Getting help................................................................................................................................................174
Contacting Dell EMC......................................................................................................................................................174
Documentation feedback...............................................................................................................................................174
Accessing system information by using QRL.............................................................................................................. 174
Quick Resource Locator for R640..........................................................................................................................175
Receiving automated support with SupportAssist ....................................................................................................175
Recycling or End-of-Life service information..............................................................................................................175
Contents 7

Dell EMC PowerEdge R640 system overview
The Dell EMC PowerEdge R640 system is a 1U rack server that supports up to:
• Two Intel Xeon Scalable Processors
• 24 DIMM slots
• 8 x 2.5-inch hard drives or 4 x 3.5-inch hard drives on the front panel, or 10 x 2.5-inch hard drives on the front panel with optional
support for 2 X 2.5-inch hard drives on the back panel
• Two AC or DC redundant power supply units
NOTE: All instances of SAS, SATA hard drives, SSDs, NVMe drives are referred to as drives in this document, unless specied
otherwise.
Topics:
• Supported congurations for PowerEdge R640
• Front view of the system
• Back view of the system
• Drive indicator codes
• LCD panel
• Locating the Service Tag of your system
• System information label
Supported congurations for PowerEdge R640
The PowerEdge R640 system supports the following congurations:
1
8 Dell EMC PowerEdge R640 system overview

Figure 1. Supported congurations for PowerEdge R640
Dell EMC PowerEdge R640 system overview 9

Front view of the system
The front view displays the features available on the front of the system.
Figure 2. Front view of 8 x 2.5-inch drive system
Table 1. Features available on the front of the system
Item Ports, panels, and slots Icon Description
1 Left control panel N/A Contains the system health and
system ID, status LED, and the
iDRAC Quick Sync 2 (wireless)
indicator.
NOTE: The iDRAC Quick
Sync 2 indicator is
available only on certain
congurations.
• Status LED: Enables you to
identify any failed hardware
components. There are up to
ve status LEDs and an
overall system health LED
(Chassis health and system
ID) bar. For more information,
see the Status LED
indicators section.
• Quick Sync 2 (wireless):
Indicates a Quick Sync
enabled system. The Quick
Sync feature is optional. This
feature allows management
of the system by using
mobile devices. This feature
aggregates hardware or
rmware inventory and
various system level
diagnostic and error
information that can be used
in troubleshooting the
system. For more
information, see the
Integrated Dell Remote
Access Controller User’s
Guide at Dell.com/
poweredgemanuals.
2Optical drive (optional) N/A One optional slim SATA DVD-
ROM drive or DVD+/-RW drive.
NOTE: DVD devices are
data only.
10 Dell EMC PowerEdge R640 system overview

Item Ports, panels, and slots Icon Description
3 USB port (optional) The USB port is USB 3.0
compliant.
4 VGA port Enables you to connect a display
device to the system. For more
information, see the Technical
specications section.
5 Right control panel N/A Contains the power button, USB
port, iDRAC Direct micro port,
and the iDRAC Direct status
LED.
6 Drive slots N/A Enable you to install drives that
are supported on your system.
For more information about
drives, see the Technical
specications section.
Figure 3. Front view of 4 x 3.5-inch drive system
Table 2. Features available on the front of the system
Item Ports, panels, and slots Icon Description
1 Left control panel N/A Contains the system health and
system ID, status LED, and the
iDRAC Quick Sync 2 (wireless)
indicator.
NOTE: The iDRAC Quick
Sync 2 indicator is
available only on certain
congurations.
• Status LED: Enables you to
identify any failed hardware
components. There are up to
ve status LEDs and an
overall system health LED
(Chassis health and system
ID) bar. For more information,
see the Status LED
indicators section.
• Quick Sync 2 (wireless):
Indicates a Quick Sync
enabled system. The Quick
Sync feature is optional. This
feature allows management
of the system by using
mobile devices. This feature
Dell EMC PowerEdge R640 system overview 11

Item Ports, panels, and slots Icon Description
aggregates hardware or
rmware inventory and
various system level
diagnostic and error
information that can be used
in troubleshooting the
system. For more
information, see the
Integrated Dell Remote
Access Controller User’s
Guide at Dell.com/
poweredgemanuals.
2 Drive slots N/A Enable you to install drives that
are supported on your system.
For more information about
drives, see the Technical
specications section.
3 Optical drive (optional) N/A One optional slim SATA DVD-
ROM drive or DVD+/-RW drive.
NOTE: DVD devices are
data only.
4 VGA port Enables you to connect a display
device to the system. For more
information, see the Technical
specications section.
5 USB port (optional) The USB port is USB 3.0
compliant.
6 Right control panel N/A Contains the power button, USB
port, iDRAC Direct micro port,
and the iDRAC Direct status
LED.
7 Information tag N/A The Information Tag is a slide-out
label panel that contains system
information such as Service Tag,
NIC, MAC address, and so on. If
you have opted for the secure
default access to iDRAC, the
Information tag also contains the
iDRAC secure default password.
Figure 4. Front view of 10 x 2.5-inch drive system
12 Dell EMC PowerEdge R640 system overview

Table 3. Features available on the front of the system
Item Ports, panels, and slots Icon Description
1 Left control panel N/A Contains the system health and system ID, status LED, and the
iDRAC Quick Sync 2 (wireless) indicator.
NOTE: The iDRAC Quick Sync 2 indicator is available only on
certain congurations.
• Status LED: Enables you to identify any failed hardware
components. There are up to ve status LEDs and an overall
system health LED (Chassis health and system ID) bar. For more
information, see the Status LED indicators section.
• Quick Sync 2 (wireless): Indicates a Quick Sync enabled system.
The Quick Sync feature is optional. This feature allows
management of the system by using mobile devices. This feature
aggregates hardware or rmware inventory and various system
level diagnostic and error information that can be used in
troubleshooting the system. For more information, see the
Integrated Dell Remote Access Controller User’s Guide at
Dell.com/poweredgemanuals.
2 Drive slots N/A Enable you to install drives that are supported on your system. For
more information about drives, see the Technical specications
section.
3 VGA port Enables you to connect a display device to the system. For more
information, see the Technical specications section.
4 Right control panel N/A Contains the power button, USB port, iDRAC Direct micro port, and
the iDRAC Direct status LED.
5 Information tag N/A The Information Tag is a slide-out label panel that contains system
information such as Service Tag, NIC, MAC address, and so on. If you
have opted for the secure default access to iDRAC, the Information
tag also contains the iDRAC secure default password.
Left control panel view
Figure 5. Left control panel with optional iDRAC Quick Sync 2.0 indicator
Dell EMC PowerEdge R640 system overview 13

Table 4. Left control panel
Item Indicator or button Icon Description
1 Status LED indicators N/A Indicate the status of the system. For more information, see the
Status LED indicators section.
2 System health and system
ID indicator
Indicates the system health. For more information, see the System
health and system ID indicator codes section.
3 iDRAC Quick Sync 2
wireless indicator (optional)
NOTE: iDRAC Quick
Sync 2 wireless
indicator is available
only on certain
congurations.
Indicates if the iDRAC Quick Sync 2 wireless option is activated. The
Quick Sync 2 feature allows management of the system using mobile
devices. This feature aggregates hardware/rmware inventory and
various system level diagnostic/error information that can be used in
troubleshooting the system. You can access system inventory, Dell
EMC Lifecycle Controller logs or system logs, system health status,
and also congure iDRAC, BIOS, and networking parameters. You can
also launch the virtual Keyboard, Video, and Mouse (KVM) viewer
and virtual Kernel based Virtual Machine (KVM), on a supported
mobile device.Dell.com/poweredgemanuals
Status LED indicators
NOTE: The indicators display solid amber if any error occurs.
Table 5. Status LED indicators and descriptions
Icon Description Condition Corrective action
Drive
indicator
The indicator turns solid amber if
there is a drive error. • Check the System Event Log to determine if the drive has an error.
• Run the appropriate Online Diagnostics test. Restart the system and
run embedded diagnostics (ePSA).
• If the drives are congured in a RAID array, restart the system, and
enter the host adapter conguration utility program.
Temperature
indicator
The indicator turns solid amber if
the system experiences a thermal
error (for example, the ambient
temperature is out of range or
there is a fan failure).
Ensure that none of the following conditions exist:
• A cooling fan has been removed or has failed.
• System cover, air shroud, memory module blank, or back ller bracket is
removed.
• Ambient temperature is too high.
• External airow is obstructed.
If the problem persists, see Getting help.
Electrical
indicator
The indicator turns solid amber if
the system experiences an
electrical error (for example,
voltage out of range, or a failed
power supply unit (PSU) or voltage
regulator).
Check the System Event Log or system messages for the specic issue. If
it is due to a problem with the PSU, check the LED on the PSU. Reseat the
PSU.
If the problem persists, see Getting help.
Memory
indicator
The indicator turns solid amber if a
memory error occurs.
Check the System Event Log or system messages for the location of the
failed memory. Reseat the memory module.
If the problem persists, see Getting help.
14 Dell EMC PowerEdge R640 system overview

Icon Description Condition Corrective action
PCIe
indicator
The indicator turns solid amber if a
PCIe card experiences an error.
Restart the system. Update any required drivers for the PCIe card. Reinstall
the card.
If the problem persists, see Getting help.
System health and system ID indicator codes
The system health and system ID indicator is located on the left control panel of your system.
System health and system ID indicators
Table 6. System health and system ID indicator codes
System health and system ID indicator code Condition
Solid blue Indicates that the system is turned on, system is healthy, and system
ID mode is not active. Press the system health and system ID button
to switch to system ID mode.
Blinking blue Indicates that the system ID mode is active. Press the system health
and system ID button to switch to system health mode.
Solid amber Indicates that the system is in fail-safe mode. If the problem persists,
see the Getting help section.
Blinking amber Indicates that the system is experiencing a fault. Check the System
Event Log or the LCD panel, if available on the bezel, for specic error
messages. For information about the event and error messages
generated by the system rmware and agents that monitor system
components, see the Error Code Lookup page at qrl.dell.com.
iDRAC Quick Sync 2 indicator codes
iDRAC Quick Sync 2 module (optional) is located on the left control panel of your system.
iDRAC Quick Sync 2 indicators
Table 7. iDRAC Quick Sync 2 indicators and descriptions
iDRAC Quick Sync 2 indicator
code
Condition Corrective action
O (default state) Indicates that the iDRAC Quick Sync 2
feature is turned o. Press the iDRAC Quick
If the LED fails to turn on, reseat the left control panel
ex cable and check. If the problem persists, see the
Getting help section.
Dell EMC PowerEdge R640 system overview 15

iDRAC Quick Sync 2 indicator
code
Condition Corrective action
Sync 2 button to turn on the iDRAC Quick
Sync 2 feature.
Solid white Indicates that iDRAC Quick Sync 2 is ready
to communicate. Press the iDRAC Quick
Sync 2 button to turn o.
If the LED fails to turn o, restart the system. If the
problem persists, see the Getting help section.
Blinks white rapidly Indicates data transfer activity. If the indicator continues to blink indenitely, see the
Getting help section.
Blinks white slowly Indicates that rmware update is in
progress.
If the indicator continues to blink indenitely, see the
Getting help section.
Blinks white ve times rapidly and
then turns o
Indicates that the iDRAC Quick Sync 2
feature is disabled.
Check if iDRAC Quick Sync 2 feature is congured to
be disabled by iDRAC. If the problem persists, see the
Getting help section. Dell.com/poweredgemanuals
or Dell OpenManage Server Administrator User’s
Guide at www.dell.com/openmanagemanuals.
Solid amber Indicates that the system is in fail-safe
mode.
Restart the system. If the problem persists, see the
Getting help section.
Blinking amber Indicates that the iDRAC Quick Sync 2
hardware is not responding properly.
Restart the system. If the problem persists, see the
Getting help section.
Right control panel view
Figure 6. Right control panel
Table 8. Right control panel
Item Indicator or button Icon Description
1 Power button Indicates if the system is turned
on or o. Press the power
button to manually turn on or o
the system.
16 Dell EMC PowerEdge R640 system overview

Item Indicator or button Icon Description
NOTE: Press the power
button to gracefully shut
down an ACPI-compliant
operating system.
2 USB port The USB ports are 4-pin, 2.0-
compliant. This port enables you
to connect USB devices to the
system.
3 iDRAC Direct LED N/A The iDRAC Direct LED indicator
lights up to indicate that the
iDRAC Direct port is actively
connected to a device. For more
information, see the iDRAC
Quick Sync 2 indicator codes
section.
4 iDRAC Direct port (Micro-AB
USB)
The iDRAC Direct (Micro-AB
USB) port enables you to access
the iDRAC Direct (Micro-AB)
features. For more information,
see the Integrated Dell Remote
Access Controller User’s Guide
at Dell.com/
poweredgemanuals.
iDRAC Direct LED indicator codes
The iDRAC Direct LED indicator lights up to indicate that the port is connected and is being used as a part of the iDRAC subsystem.
You can congure iDRAC Direct by using a USB to micro USB (type AB) cable, which you can connect to your laptop or tablet. The
following table describes iDRAC Direct activity when the iDRAC Direct port is active:
Table 9. iDRAC Direct LED indicator codes
iDRAC Direct LED
indicator code
Condition
Solid green for two seconds Indicates that the laptop or tablet is connected.
Flashing green (on for two
seconds and o for two
seconds)
Indicates that the laptop or tablet connected is recognized.
Turns o Indicates that the laptop or tablet is unplugged.
Dell EMC PowerEdge R640 system overview 17

Back view of the system
The back view displays the features available on the back of the system.
Figure 7. Back view of 2 x 2.5-inch drives with 1 PCIe expansion slot
Table 10. 2 X 2.5-inch drive system with 1 PCIe expansion slot
Item Ports, panels, or slots Icon Description
1 PCIe expansion card slot N/A The expansion slot(s) enable you
to connect PCI Express
expansion cards. For more
information on the expansion
cards that are supported on your
system, see the Expansion card
guidelines.
2 Drive slot (2) N/A Enable you to install drives that
are supported on your system.
For more information about
drives, see the Technical
specications section.
3 Power supply unit (2) N/A For more information about the
PSU congurations, see the
Technical specications section
4 NIC port (4) The NIC ports that are
integrated on the network
daughter card (NDC) provide
network connectivity. For more
information about the supported
congurations, see the Technical
specications section.
5 USB 3.0 port (2) The USB ports are 9-pin and
3.0-compliant. These ports
enable you to connect USB
devices to the system.
6 VGA port Enables you to connect a display
device to the system. For more
information, see the Technical
specications section.
7 Serial port Enables you to connect a serial
device to the system. For more
18 Dell EMC PowerEdge R640 system overview

Item Ports, panels, or slots Icon Description
information, see the Technical
specications section.
8 iDRAC9 dedicated network port Use the iDRAC9 dedicated
network port to securely access
the embedded iDRAC on a
separate management network,
see the Integrated Dell Remote
Access Controller User’s Guide
at Dell.com/poweredgemanuals
9 System status indicator cable
port
N/A Enables you to connect the
status indicator cable and view
system status when the CMA is
installed.
10 System identication button The System Identication (ID)
button is available on the front
and back of the systems. Press
the button to identify a system in
a rack by turning on the system
ID button. You can also use the
system ID button to reset iDRAC
and to access BIOS using the
step through mode.
Figure 8. Back view of system with 3 PCIe expansion slots
Table 11. 2 X 2.5-inch drive system with 3 PCIe expansion slot
Item Ports, panels, or slots Icon Description
1 PCIe expansion card slot(3) N/A The expansion slot(s) enable you
to connect PCI Express
expansion cards. For more
information on the expansion
cards that are supported on your
system, see the Expansion card
guidelines.
2 Power supply unit (2) N/A For more information about the
PSU congurations, see the
Technical specications section
3 NIC port (4) The NIC ports that are
integrated on the network
daughter card (NDC) provide
network connectivity. For more
information about the supported
Dell EMC PowerEdge R640 system overview 19

Item Ports, panels, or slots Icon Description
congurations, see the Technical
specications section.
4 USB 3.0 port (2) The USB ports are 9-pin and
3.0-compliant. These ports
enable you to connect USB
devices to the system.
5 VGA port Enables you to connect a display
device to the system. For more
information, see the Technical
specications section.
6 Serial port Enables you to connect a serial
device to the system. For more
information, see the Technical
specications section.
7 iDRAC9 dedicated network port Use the iDRAC9 dedicated
network port to securely access
the embedded iDRAC on a
separate management network,
see the Dell.com/
poweredgemanuals
8 System status indicator cable
port
N/A Enables you to connect the
status indicator cable and view
system status when the CMA is
installed.
9 System identication button The System Identication (ID)
button is available on the front
and back of the systems. Press
the button to identify a system in
a rack by turning on the system
ID button. You can also use the
system ID button to reset iDRAC
and to access BIOS using the
step through mode.
Figure 9. Back view of system with 2 PCIe expansion slots
Table 12. 2 X 2.5-inch drive system with 2 PCIe expansion slot
Item Ports, panels, or slots Icon Description
1 PCIe expansion card slot (2) N/A The expansion slot(s) enable you
to connect PCI Express
expansion cards. For more
20 Dell EMC PowerEdge R640 system overview
