Dell PowerEdge T310 User manual

Dell™ PowerEdge™
T310 Systems
Getting Started
With Your System
系统使用入门
Mengaktifkan Sistem Anda
はじめに
시스템 시작 안내서

Dell™ PowerEdge™
T310 Systems
Getting Started
With Your System
Regulatory Model E09S
Regulatory Type E09S001

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use
of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data
if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury, or death.
____________________
Information in this document is subject to change without notice.
© 2009 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.
is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, and PowerEdge are trademarks of Dell Inc.;
Intel and Xeon are registered trademarks of Intel Corporation in the U. S. and other countries;
Microsoft, Windows, Windows Server, and Hyper-V are either trademarks or registered trademarks
of Microsoft Corporation in the United States and/or other countries; Red Hat and Enterprise Linux
are registered trademarks of Red Hat, Inc. in the United States and other countries; SUSE is a registered
trademark of Novell, Inc. in the United States and other countries.
Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Regulatory Model E09S
Regulatory Type E09S001
May 2009 P/N K087K Rev. A00

Getting Started With Your System 3
Installation and Configuration
WARNING: Before performing the following procedure, review the safety
instructions that came with the system.
Optional – Connecting the Keyboard, Mouse, and Monitor
Connect the keyboard, mouse, and monitor (optional).
The connectors on the back of your system have icons indicating which cable
to plug into each connector. Be sure to tighten the screws (if any) on the
monitor's cable connector.

4Getting Started With Your System
Connecting the Power Cable(s)
Connect the system’s power cable(s) to the system and, if a monitor is used,
connect the monitor’s power cable to the monitor.
Securing the Power Cable(s)
Bend the system power cable(s) into a loop as shown in the illustration and
secure the cable(s) with the provided strap.
Plug the other end of the power cable(s) into a grounded electrical outlet
or a separate power source such as an uninterrupted power supply (UPS)
or a power distribution unit (PDU).

Getting Started With Your System 5
Turning On the System
Press the power button on the system and the optional monitor, if used.
The power indicators should light.
Complete the Operating System Setup
If you purchased a preinstalled operating system, see the operating system
documentation that ships with your system. To install an operating system for
the first time, see the installation and configuration documentation for your
operating system. Be sure the operating system is installed before installing
hardware or software not purchased with the system.
Supported Operating Systems
• Microsoft
®
Windows
®
Server 2008 R2 Standard and Enterprise (x64)
Editions
• Microsoft Windows Server
®
2008 Standard and Enterprise (x86)
Editions with SP2
• Microsoft Windows Server 2008 Standard and Enterprise (x64) Editions
• Microsoft Windows Server 2008 Standard, and Enterprise (x86) Editions
• Microsoft Windows Small Business Server 2008 Standard and
Premium (x64) Editions

6Getting Started With Your System
• Microsoft Windows Essential Business Server 2008 Standard and
Premium (x64) Editions
• Microsoft Windows Server 2003 R2 Standard and Enterprise (x64)
Editions with SP2
• Microsoft Windows Server 2003 R2 Standard and Enterprise (x86)
Editions with SP2
•RedHat
®
Enterprise Linux
®
ES (Version 5.3) (x86)
• Red Hat Enterprise Linux ES (Version 5.3) (x86_64)
•SUSE
®
Linux Enterprise Server 11 (x86_64)
• Microsoft Windows Server 2008 Hyper-V™
NOTE: For the latest information on supported operating systems,
see www.dell.com.
Other Information You May Need
WARNING: See the safety and regulatory information that shipped with your
system. Warranty information may be included within this document or as a
separate document.
•The Hardware Owner’s Manual provides information about system
features and describes how to troubleshoot the system and install or
replace system components. This document is available online at
support.dell.com .
• Any media that ships with your system that provides documentation and
tools for configuring and managing your system, including those
pertaining to the operating system, system management software, system
updates, and system components that you purchased with your system.
NOTE: Always check for updates on support.dell.com and read the updates
first because they often supersede information in other documents.

Getting Started With Your System 7
Obtaining Technical Assistance
If you do not understand a procedure in this guide or if the system does not
perform as expected, see your Hardware Owner’s Manual. Dell™ offers
comprehensive hardware training and certification. See
www.dell.com/training for more information. This service may not be offered
in all locations.
NOM Information (Mexico Only)
La información que se proporciona a continuación aparece en el dispositivo
descrito en este documento, en cumplimiento de los requisitos de la Norma
Oficial Mexicana (NOM):
Technical Specifications
Importador:
Número de modelo: E09S
Voltaje de
alimentación:
100-240 V CA
Frecuencia: 50/60 Hz
Consumo eléctrico: 5,8–2,9 A
Processor
Processor type One quad-core Intel®Xeon®processor
Expansion Bus
Bus type PCI Express Generation 2
Expansion slots Slot1: PCIe x8 (x8 routing) half-length
Slot2: PCIe x16 (x8 routing) full-length
Slot3: PCIe x8 (x4 routing) half-length
Slot4: PCIe x1 (x1 routing) half-length
Slot5: PCIe x1 (x1 routing) half-length

8Getting Started With Your System
Memory
Architecture 800-MHz, 1066-MHz, or 1333-MHz DDR3
registered or unbuffered Error Correcting
Code (ECC) DIMMs.
Memory module sockets Six 240-pin
Memory module capacities 1 GB, 2 GB, 4 GB, or 8 GB
Minimum RAM 1 GB
Maximum RAM 32 GB
Drives
Hard drives Up to four 3.5-inch hot-plug SAS or
SATA internal drives
or
Up to four 3.5-inch cabled SAS or
SATA internal drives
or
Up to four 2.5-inch hot-plug SAS or
SSD internal drives in a 3.5-inch carrier.
Optical drive Optional internal SATA DVD-ROM or
DVD+/-RW
Optional external USB DVD-ROM
NOTE: DVD devices are data only.
Tape drive One optional internal half height tape
backup device

Getting Started With Your System 9
Connectors
Back
NIC Two RJ-45 (for integrated 1-GB NICs)
Serial 9-pin, DTE, 16550-compatible
USB Four 4-pin, USB 2.0-compliant
Video 15-pin VGA
Front
USB Two 4-pin, USB 2.0-compliant
Internal
USB Two 4-pin, USB 2.0-compliant
Video
Video type Matrox G200, integrated in iDRAC
Video memory 8 MB
Power
AC power supply (per power supply)
Wattage 375 W (non-redundant power supply)
400 W (redundant power supply)
Voltage 100-240 VAC, 50/60 Hz, 5.8A-2.9A
Heat dissipation 1683 BTU/hr maximum (non-redundant
power supply)
1672 BTU/hr maximum (redundant power
supply)
Maximum inrush current Under typical line conditions and over the
entire system ambient operating range, the
inrush current may reach 25A (redundant
power supply) and 35A (non-redundant
power supply) per power supply for 10 ms
or less.
Batteries
System battery CR 2032 3.0-V lithium ion coin cell

10 Getting Started With Your System
Physical
Height 44 cm (17.3 inch)
Width 21.8 cm (8.6 inch)
Depth 52.1 cm (20.5 inch)
Weight (maximum configuration) 23.5 kg (51.8 lb)
Environmental
NOTE: For additional information about environmental measurements for specific
system configurations, see www.dell.com/environmental_datasheets.
Temperature
Operating 10° to 35°C (50° to 95°F) with a maximum
temperature gradation of 10°C per hour
NOTE: For altitudes above 2950 feet,
the maximum operating temperature is
derated 1ºF/550 ft.
Storage –40° to 65°C (–40° to 149°F) with a
maximum temperature gradation of 20°C
per hour
Relative humidity
Operating 20% to 80% (noncondensing) with a
maximum humidity gradation of 10%
per hour
Storage 20% to 85% (noncondensing)
Maximum vibration
Operating 0.26 G at 5–500 Hz for 15 min
Storage 1.54 G at 10–250 Hz for 15 min

Getting Started With Your System 11
Maximum shock
Operating One shock pulse in the positive z axis
(one pulse on each side of the system) of
31 G for 2.6 ms in the operational orientation
Storage Six consecutively executed shock pulses in
the positive and negative x, y, and z axes
(one pulse on each side of the system) of
71 G for up to 2 ms
Altitude
Operating 0 to 3,048 m (0 to 10,000 ft)
NOTE: For altitudes above 2950 feet,
the maximum operating temperature is
derated 1ºF/550 ft.
Storage 0 to 10,605 m (–50 to 35,000 ft)
Airborne Contaminant Level
Class G2 or lower as defined by ISA-S71.04-1985
Environmental (continued)

12 Getting Started With Your System

Dell™ PowerEdge™
T310 系统
系统使用入门
管制型号 E09S
管制类型 E09S001

注、小心和警告
注：“注”表示可以帮助您更好地使用计算机的重要信息。
小心：“小心”表示如果不遵循说明，就有可能损坏硬件或导致数据
丢失。
警告：
“警 ”表示可能会造成财产损失、人身伤害甚至死亡。
____________________
本说明文件中的信息如有更改，恕不另行通知。
© 2009 Dell Inc. 版权所有，翻印必究。
未经 Dell Inc. 书面许可，严禁以任何形式复制这些材料。
本文中使用的商标：Dell、DELL 标和 PowerEdge 是Dell Inc. 的商标； Intel 和Xeon 是
Intel Corporation 在美 国和其它国家或地区的注册商标； Microsoft、Windows、Windows
Server 和Hyper-V 是Microsoft Corporation 在美国和 /或其它国家或地区的商标或注册
商标； Red Hat 和Enterprise Linux 是Red Hat, Inc. 在美国和 /或其它国家或地区的注册
商标； SUSE 是Novell, Inc. 在美国和 /或其它国家或地区的注册商标。
本说明文件中述及的其它商标和产品名称是指拥有相应商标和产品名称的公司或其制造的
产品。 Dell Inc. 对本公司的商标和产品名称之外的其它商标和产品名称不拥有任何专有权。
管制型号 E09S
管制类型 E09S001
2009 年5 月P/N K087K Rev. A00

系统使用入门 15
安装和配置
警告：
执行下列步骤之前，请阅读系统随附的安全说明。
可选 –连接键盘、鼠标和显示器
连接键盘、鼠标和显示器（可选）。
系统背面的连接器附有图标，这些图标指示了要插 每个连接器的电缆。
确保拧紧显示器的电缆连接器上的螺钉（如果有）。

16 系统使用入门
连接电源电缆
将系统电源电缆连接至系统，如果使用显示器，将显示器电源电缆连接至显
示器。
固定电源电缆
如图所示，将系统电源电缆弯曲成一个环路，并使用所提供的腕带固定该
电缆。
将电源电缆的另一端插 接地的电源插座或单独的电源，如不间断电源设备
(UPS)
或配电装置
(PDU)
。

系统使用入门 17
开启系统
按下系统和显示器（如有使用）上的电源按钮。电源指示灯将会亮起。
完成操作系统安装
如果购买了预 装的操作系统，请参阅随系统提供的操作系统说明文件。
第一次 装操作系统时，请参阅操作系统的 装和配置说明文件。请确保先
装操作系统，然后再 装未预装的硬件或软件。
支持的操作系统
•Microsoft
®
Windows
®
Server 2008 R2 Standard
版和
Enterprise (x64)
版
•Microsoft Windows Server
®
2008 Standard
版和
Enterprise (x86)
版
（含
SP2
）
•Microsoft Windows Server 2008 Standard 版和
Enterprise (x64)
版
•Microsoft Windows Server 2008 Standard 版和
Enterprise (x86)
版
•Microsoft Windows Small Business Server 2008 Standard
版和
Premium (x64)
版
•Microsoft Windows Essential Business Server 2008 Standard 版和
Premium (x64)
版
•Microsoft Windows Server 2003 R2 Standard 版和
Enterprise (x64)
版
（含
SP2
）

18 系统使用入门
•Microsoft Windows Server 2003 R2 Standard 版和
Enterprise (x86)
版
（含
SP2
）
•Red Hat
®
Enterprise Linux
®
ES
（第
5.3
版）
(x86)
•Red Hat Enterprise Linux ES
（第
5.3
版）
(x86_64)
•SUSE
®
Linux Enterprise Server 11 (x86_64)
•Microsoft Windows Server 2008 Hyper-V
™
注：有关支持的操作系统的最新信息，请参阅 www.dell.com。
可能需要的其它信息
警告：
请查看系统附带的安全和管制信息。保修信息可能包括在该说明文
件中，也可能 为单独的说明文件提供。
• 《硬件用户手册》提供了有关系统功能的信息，并说明了如何排除系
统故障以及安 或更换系统组件。可在
support.dell.com
在线获取该说
明文件。
• 系统随附的任何介质，它提供了用于配置和管理系统的文件和工具，
包括与随系统购买的操作系统、系统管理软件、系统更新软件以及系
统组件相关的文件和工具。
注：请经常访问 support.dell.com 查看是否有更新， 先阅读更新
信息，因为这些更新通常会取代其它说明文件中的信息。
获得技术帮助
如果您对本指南中的步骤有疑问，或系统运行无法达到预期效果，请参阅
《硬件用户手册》。
Dell™
提供全面的硬件培训和认证。有关详情，请参阅
www.dell.com/training
。此服务可能并非在所有地区都提供。
