Preface
This manual explains how to install the IP4700, install or replace the
Standby Power Supply (SPS), and how to replace
customer-replaceable units (CRUs). It is intended for technical
personnel and system administrators who will install and maintain
the IP4700 system hardware.
Most rackmount systems are fully assembled, with the storage
systems installed in a cabinet. If you intend to install the IP4700 in a
rackmount cabinet already on site, we assume that you have installed
the appropriate mounting tray and rails as described in the
instructions that accompany the mounting kit.
If you will install and service the IP4700, you should read this
manual. After reading it, you will be able to
• install an IP4700
• upgrade an IP4700 by adding disk modules and disk-array
enclosures (DAEs)
•replace failed CRUs
•install, service, and use the DC Standby Power Supply (DC SPS)

x
IP4700 Installation and Service Guide
Preface
Here is an overview of where information is located in this manual:
Chapter 1 introduces the IP4700’s components.
Chapter 2 explains requirements and describes how to install the
IP4700 and cable it to the LAN and to Disk Array Enclosures (DAEs).
Chapter 3 describes how to replace CRUs such as disk modules.
Chapter 4 introduces the Standby Power Supply (SPS) and explains
how to install and connect cables to them. In addition, it explains how
to replace the SPS.
Appendix A lists the IP4700 and SPS technical specifications.
Glossary defines terms used in the Fibre Channel environment.
Related
Documentation Other related manuals include:
•EMC Fibre Channel Disk Array Enclosure (DAE) Rackmount Model
Hardware Reference (014002591)
•IP4700 Administrator’s Guide (069701169)
•IP4700 Quick Start Guide (069701170)
•IP4700 Release Notes (085600156)
Conventions Used in
This Manual EMC uses the following conventions for notes, cautions, warnings,
and danger notices.
CAUTION
!
A caution contains information essential to avoid damage to the
system or equipment. The caution may apply to hardware or
software.
WARNING
A warning contains information essential to avoid a hazard that can
cause severe personal injury, death, or substantial property damage
if you ignore the warning.
DANGER
A danger notice contains information essential to avoid a hazard
that will cause severe personal injury, death, or substantial property
damage if you ignore the warning.

IP4700 Installation and Service Guide
xi
Preface
EMC uses the following type style conventions in this guide:
Where to Get Help Obtain technical support by calling your local sales office.
For service, call:
and ask for Customer Service.
Your Comments Your suggestions will help us continue to improve the accuracy,
organization, and overall quality of the user publications. Please
e-mail us at [email protected] to let us know your
opinion or any errors concerning this manual.
Boldface •Specific filenames or complete paths.
•Window names and menu items in text.
•Selections you can make from the user
interface, including buttons, icons, options,
and field names.
•Emphasis in cautions and warnings.
Italic •New terms or unique word usage in text.
•Command line arguments when used in text.
Fixed space Examples of specific command entries that you
would type, displayed text, or program listings.
For example:
QUERY [CUU=cuu|VOLSER=volser]
Fixed italic Arguments used in examples of command line
syntax.
United States: [phone] (SVC-4EMC)
Canada: [phone] (543-4SVC)
Worldwide: [phone]

xii
IP4700 Installation and Service Guide
Preface

IP4700 Installation and Service Guide
xiii
The following warnings and cautions pertain throughout this
manual.
WARNING
This unit has two power supply cords. To reduce the risk of electric
shock, disconnect both power supply cords before servicing.
Ground circuit continuity is vital for safe operation of the machine.
Never operate the machine with grounding conductors disconnected.
Remember to reconnect any grounding conductors removed for or
during any installation procedure.
ATTENTION Cet appareil comporte plus d'un cordon d'alimentation. Afin de
prévenir les chocs électriques, débrancher les deux cordons
d'alimentation avant de faire le dépannage.
Un circuit de terre continu est essentiel en vue du fonctionnement
sécuritaire de l'appareil. Ne jamais mettre l'appareil en marche
lorsque le conducteur de mise à la terre est débranché.
Warnings and
Cautions

xiv
IP4700 Installation and Service Guide
Warnings and Cautions
Warnung Das Gerät hat mehr als eine Anschlussleitung. Zur Vermeidung der
Gefahr eines elektrischen Schlages sind vor dem öffnen beide
Anschlussleitungen vom Netz zu trennen.
STROMSTREUVERLUST: Gerät muss geerdet werden, bevor es am
Stromnetz angeschlossen wird.
Additional Warnings
and Cautions Before attempting to service an IP4700 unit, observe the following
additional Warnings and Cautions:
WARNING
Unqualified personnel attempting to remove, install, or service
internal components or options in IP4700 systems risk both personal
injury and damage to the system.
EMC Corporation supports the installation, maintenance, and
expansion of these systems by qualified service providers only.
Service by other personnel may void product warranties. For more
information regarding EMC warranties, refer to your EMC sales and
field engineering contracts.
WARNING
Tout personnel non qualifiéessayant d'enlever, d'installer, ou de
réparer des composants ou des options internes sur les systèmes de la
IP4700 court le risque d'un accident corporel ou matériel.
EMC Corporation supporte l'installation, la maintenance, et
l'extension de ces systèmes uniquement avec des fournisseurs de
services qualifiés. Tout service fourni par tout autre personnel peut
annuler les garanties du produit. Pour en savoir plus sur les garanties
de EMC, reportez-vous aux contrats des services commerciaux et
techniques de EMC.

IP4700 Installation and Service Guide
xv
Warnings and Cautions
WARNING
Sollten nicht-qualifizierte Mitarbeiter versuchen, in Systemen der
IP4700 interne Komponenten oder Optionen zu entfernen, zu
installieren oder zu warten, laufen sie nicht nur Gefahr sich zu
verletzen, sondern könnten auch das System beschädigen.
EMC unterstützt die Installation, Wartung und Erweiterung dieser
Systeme ausschließlich durch qualifizierte Service-Firmen.
Serviceleistungen anderen Personals könnten zur Aufhebung der
Produktgarantien führen. Weitere Informationen über EMC
Garantieleistungen finden Sie in Ihren EMC Verkaufsverträgen und
den Verträgen für technischen Kundendienst.
WARNING
Il personale non qualificato che tenti di rimuovere, di installare o di
prestare assistenza ai componenti interni o alle opzioni dei sistemi
IP4700 rischia di provocare danni alle persone oltre che ai sistemi.
EMC supporta l'installazione, la manutenzione e l'espansione di
detti sistemi solo da parte di prestatori di servizio qualificati. Il
servizio di assistenza prestato da altro personale puòinvalidare le
garanzie sul prodotto. Per maggiori informazioni sulle garanzie della
EMC, consultare i propri contratti di vendita e di assistenza tecnica.
WARNING
Cualquier persona que trate de remover, instalar o dar servicio a los
componentes internos u opciones de los sistemas IP4700, corre el
riesgo de ocasionarse daño a símismo o de averiar el sistema.

xvi
IP4700 Installation and Service Guide
Warnings and Cautions
WARNING
EMC apoya la instalación, mantenimiento y expansión de estos
sistemas solamente por medio de proveedores de servicio calificados.
El servicio otorgado por otro personal puede cancelar la garantía del
producto. Para obtener más información sobre las garantías que
ofrece EMC, consulte los contratos de venta y de ingeniería de campo
de EMC.
CAUTION
!
Trained personnel are advised to exercise great care at all times
when working on the IP4700 unit. Remember to:
• Remove rings, watches, or other jewelry and neckties before
you begin any procedures.
• Use caution near any moving part and any part that may start
unexpectedly such as a fan, motor, or solenoid.
• Always use the correct tools for the job.
• Always use the correct replacement parts.
• Keep all paperwork, including incident reports, up to date,
complete, and accurate.

IP4700 Installation and Service Guide
xvii
Warnings and Cautions
Static Precautions EMC incorporates state-of-the-art technology in its designs, including
the use of LSI and VLSI components. These chips are very susceptible
to damage caused by static discharge and need to be handled
accordingly.
CAUTION
!
Before handling IP4700 printed-circuit boards or other IP4700 parts
containing LSI and/or VLSI components, observe the following
precautions:
•Store all printed-circuit boards in anti-static bags.
•Use a ground strap whenever you handle a printed-circuit
board.
•Unless specifically designed for non-disruptive replacement,
never plug or unplug printed-circuit boards with the power on.
Severe component damage may result.

xviii
IP4700 Installation and Service Guide
Warnings and Cautions

The IP4700
1-1
1
This chapter describes the IP4700 hardware features. Major topics are
•About the IP4700................................................................................1-2
•IP4700 Components...........................................................................1-4
•Customer-Replaceable Units (CRUs)..............................................1-4
•High-Availability Features................................................................1-5
•Enclosure.............................................................................................1-6
•Storage Processors............................................................................1-10
•Link Control Cards (LCCs).............................................................1-12
•Disk Modules....................................................................................1-13
•Power Supplies.................................................................................1-14
•SPS (Standby Power Supply) .........................................................1-16
•Drive Fan Pack..................................................................................1-17
•Storage Processor Fan Pack ............................................................1-18
The IP4700

1
1-2
IP4700 Installation and Service Guide
The IP4700
About the IP4700
The IP4700 (see Figure 1-1) is an intelligent, highly available,
high-performance, high-capacity, disk-array file server storage
system. It uses multiple LAN connections to communicate with
servers and clients, and a Fibre Channel Arbitrated Loop (FC-AL) as
its disk interconnect. The IP4700 is installed in a rackmount cabinet,
and its modular, scalable design supports additional file storage.
An IP4700 disk-array processor enclosure (DPE) includes two storage
processors (SPs). On some models, four 10/100 Mbps Ethernet ports
on each storage processor provide connection to up to four different
internet protocol (IP) subnetworks. Other models include a single
one-gigabit Ethernet port on each SP. In addition, an integrated
Ethernet device on each SP supports administrative and management
functions. A single low-voltage differential/single-ended (LVD/SE)
small computer system interface (SCSI) port also provides connection
to an optional tape backup device.
Figure 1-1 Rackmount IP4700
EMC144
0
Rackmount
cabinet
File
server
