Dell PowerEdge R210 II User manual

Dell PowerEdge
R210 II Systems
Getting Started
With Your System
系统使用入门
Memulai Dengan Sistem Anda
はじめに
시스템 시작 안내서

Dell PowerEdge
R210 II Systems
Getting Started
With Your System
Regulatory Model: E10S Series

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data
if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury, or death.
___________________
Information in this publication is subject to change without notice.
© 2010 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.
is strictly forbidden.
Trademarks used in this text: Dell™, the DELL logo, and PowerEdge™ are trademarks of Dell Inc.
Intel®is a registered trademark and Core™ is a trademark of Intel Corporation in the U.S. and
other countries. Microsoft®and Windows Server®are either trademarks or registered trademarks
of Microsoft Corporation in the United States and/or other countries. Red Hat®and Red Hat Enterprise
Linux®and are registered trademarks of Red Hat, Inc. in the United States and/or other countries.
SUSE ™ is a trademark of Novell, Inc. in the United States and other countries. Citrix®and
XenServer®are either registered trademarks or trademarks of Citrix Systems, Inc. in the United States
and/or other countries. VMware®is a registered trademarks or trademark of VMWare, Inc. in the
United States or other countries.
Other trademarks and trade names may be used in this publication to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Regulatory Model E10S Series
December 2010 P/N 30G7N Rev. A00

Getting Started With Your System 3
Installation and Configuration
WARNING: Before performing the following procedure, review the safety
instructions that came with the system.
Unpacking the System
Unpack your system and identify each item.
Installing the Rails and System in a Rack
CAUTION: If installed in a closed or multi-unit rack assembly, the operating
ambient temperature of the rack environment may be greater than room ambient.
Therefore, consideration should be given to installing the equipment in an
environment compatible with the maximum ambient temperature (Tma) specified by
the manufacturer.
For more information, see "Technical Specifications" on page 9.
Assemble the rails and install the system in the rack following the safety
instructions and the rack installation instructions provided with your system.

4Getting Started With Your System
Optional—Connecting the Keyboard, Mouse, and Monitor
Connect the keyboard, mouse, and monitor (optional).
The connectors on the back of your system have icons indicating which cable
to plug into each connector. Be sure to tighten the screws (if any) on the
monitor's cable connector.
Connecting the Power Cable
Connect the system’s power cable to the system and, if a monitor is used,
connect the monitor’s power cable to the monitor.

Getting Started With Your System 5
Securing the Power Cable
Bend the system power cable as shown in the illustration and secure the cable
in the retention clip.
Plug the other end of the power cable into a grounded electrical outlet or
a separate power source such as an uninterrupted power supply (UPS) or
a power distribution unit (PDU).
Turning On the System
Press the power button on the system and the monitor. The power indicators
should light.

6Getting Started With Your System
Installing the Optional Bezel
Install the bezel (optional).
Complete the Operating System Setup
If you purchased a preinstalled operating system, see the operating system
documentation that ships with your system. To install an operating system for
the first time, see the installation and configuration documentation for your
operating system. Be sure the operating system is installed before installing
hardware or software not purchased with the system.
Supported Operating Systems
• Microsoft Small Business Server 2011 Standard and Essential Editions
• Microsoft Windows Server 2008 R2 SP1 (x64) Web, Standard,
Foundation, and Enterprise Editions
• Microsoft Windows
Server 2008 R2 (x64) Web, Standard, Foundation,
and Enterprise Editions
• Microsoft Windows Server 2008 SP2 (x86) Web, Standard,
and Enterprise Editions
• Microsoft Windows Server 2008 SP2 (x64) Web, Standard,
and Enterprise Editions
• Microsoft Windows Server 2008 R2 SP1(x64) with Hyper-V for
Standard and Enterprise Editions

Getting Started With Your System 7
• Microsoft Windows Server 2008 R2 (x64) with Hyper-V for Standard and
Enterprise Editions
• Microsoft Windows Server 2008 SP2 (x64) with Hyper-V for Standard and
Enterprise Editions
• VMware ESX 4.1 Update 1 (Classic)
• VMware ESX 4.1 Update 1 (Embedded)
• Citrix XenServer 5.6 Feature Pack 1
• Red Hat Enterprise Linux
6.0 (x86_64)
• SUSE Linux Enterprise Server 11 SP1 (x86_64)
NOTE: For the latest information on supported operating systems,
see support.dell.com.
Dell Software License Agreement
• Before using your system, please read the Dell Software License
Agreement that came with your system.
• You must consider any CD, DVD, or diskette set of Dell installed
software as BACKUP copies of the software installed on your system's
hard-disk drive.
• If you do not accept the terms of the agreement, please call the customer
assistance telephone number. For customers in the United States,
call 800-WWW-DELL (800-999-3355). For customers outside the
United States, visit
support.dell.com and select your country or region
from the top of the page.

8Getting Started With Your System
Other Information You May Need
WARNING: See the safety and regulatory information that shipped with
your system. Warranty information may be included within this document
or as a separate document.
• The rack documentation included with your rack solution describes how
to install your system into a rack.
•The
Owner’s Manual provides information about system features
and describes how to troubleshoot the system and install or replace
system components. This document is available online at
support.dell.com/manuals .
• Any media that ships with your system that provides documentation and
tools for configuring and managing your system, including those pertaining
to the operating system, system management software, system updates,
and system components that you purchased with your system.
NOTE: Always check for updates on support.dell.com/manuals and read the
updates first because they often supersede information in other documents.
Obtaining Technical Assistance
If you do not understand a procedure in this guide or if the system does
not perform as expected, see your Owner’s Manual. Dell offers
comprehensive hardware training and certification. See dell.com/training
for more information. This service may not be offered in all locations.

Getting Started With Your System 9
Información de la NOM (sólo para México)
La información que se proporciona a continuación aparece en el dispositivo
descrito en este documento, en cumplimiento de los requisitos de la Norma
Oficial Mexicana (NOM):
Technical Specifications
Importador:
Número de modelo: E10S
Voltaje de alimentación: 100 V CA-240 V CA
Frecuencia: 50 – 60 Hz
Consumo eléctrico: 4,0 - 2,0 A
Processor
Processor type One Intel Core processor i3-2100 product family
or
One Intel Xeon processor E3-1200 product family
or
One Intel Pentium processor (when available)
Expansion Bus
Bus type PCI Express Generation 2
Expansion slots One full-height, half-length x16 link
Memory
Architecture 1066 MHz and 1333 MHz DDR3 unbuffered
Error Correcting Code (ECC) DIMMs
Memory module sockets Four 240-pin
Memory module capacities 1 GB, 2 GB, 4 GB, or 8 GB
Minimum RAM 1 GB
Maximum RAM 32 GB

10 Getting Started With Your System
Drives
Hard drives Up to two 3.5-inch cabled SAS or SATA
internal drives
or
Up to two 2.5-inch cabled SAS or SATA
internal drives
Optical drive One optional internal SATA DVD-ROM or
DVD+/-RW drive
NOTE: DVD devices are data only.
Optional external USB DVD-ROM
Connectors
Back
NIC Two RJ-45 (for integrated 1 GB NICs)
Serial 9-pin, DTE, 16550-compatible
USB Two 4-pin, USB 2.0-compliant
Video 15-pin VGA
eSATA One 7-pin connector
Front
Video 15-pin VGA
USB Two 4-pin, USB 2.0-compliant
Internal
USB Two 4-pin, USB 2.0-compliant
Video
Video type Matrox G200, integrated in Winbond WPCM450
Video memory 8 MB

Getting Started With Your System 11
Power
AC power supply (per power supply)
Wattage 250 W
Voltage 100 VAC–240 VAC, 50 Hz/60 Hz, 4.0 A–2.0 A
Heat dissipation 1040 BTU/hr maximum
Maximum inrush current Under typical line conditions and over the entire
system ambient operating range, the inrush
current may reach 25 A
Batteries
System battery CR 2032 3.0-V lithium coin cell
Physical
Height 4.24 cm (1.67 inches)
Width 43.4 cm (17.09 inches)
Depth 39.37 cm (15.5 inches)
Weight
(maximum configuration)
8.058 kg (17.77 lb)
Environmental
NOTE: For additional information about environmental measurements for specific
system configurations, see dell.com/environmental_datasheets.
Temperature
Operating 10 °C to 35 °C (50 °F to 95 °F) with a maximum
temperature gradation of 10 °C per hour
NOTE: For altitudes above 2950 feet, the maximum
operating temperature is derated 1 ºF/550 ft.
Storage –40 °C to 65 °C (–40 °F to 149°F) with a
maximum temperature gradation of 20 °C
per hour
Relative humidity
Operating 20% to 80% (noncondensing) with a maximum
humidity gradation of 10% per hour
Storage 5% to 95% (noncondensing)

12 Getting Started With Your System
Maximum vibration
Operating 0.26 Grms at 5 Hz–350 Hz for 15 min
Storage 1.87 Grms at 10 Hz–500 Hz for 15 min
Maximum shock
Operating One shock pulse in the positive z axis (one pulse
on each side of the system) of 31 G for 2.6 ms in
the operational orientation
Storage Six consecutively executed shock pulses in
the positive and negative x, y, and z axes
(one pulse on each side of the system) of 71 G for
up to 2 ms
Six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse
on each side of the system) of 32 G faired
square wave pulse with velocity change at
270 inches/second (686 centimeters/second)
Altitude
Operating –16 m to 3048 m (–50 ft to 10,000 ft)
NOTE: For altitudes above 2950 feet, the maximum
operating temperature is derated 1 ºF/550 ft.
Storage –16 m to 10,600 m (–50 ft to 35,000 ft)
Airborne Contaminant Level
Class G1 as defined by ISA-S71.04-1985
Environmental (continued)

Dell PowerEdge
R210 II 系统
系统使用入门
管制型号：E10S 系列

注、小心和警告
注：“注”表示可以帮助您更好地使用计算机的重要信息。
小心：“小心”表示如果不遵循说明，就有可能损坏硬件或导致数据
丢失。
警告：
“警 ”表示可能会造成财产损失、人身伤害甚至死亡。
___________________
本出版物中的信息如有更改，恕不另行通知。
© 2010 Dell Inc. 版权所有，翻印必究。
未经 Dell Inc. 书面许可，严禁以任何形式复制这些材料。
本文中使用的商标：Dell™、DELL™标和 PowerEdge™是Dell Inc. 的商标。 Intel®和
Core™分别是 Intel Corporation 在美国 和其它国家 /地区的注册商标和商标。
Microsoft®和
Windows Server®是Microsoft Corporation 在美国和 /或其它国家 /地区的商标或注册商标。
Red Hat®和Red Hat Enterprise Linux®是Red Hat, Inc. 在美国和 /或其它国家 /地区的注册
商标。
SUSE™是Novell Inc. 在美国和其它国家 /地区的商标。
Citrix®和XenServer®是Citrix
Systems, Inc. 在美国和 /或其它国家 /地区的注册商标或商标。 VMware®是VMware, Inc.
在美国或其它国家 /地区的注册商标。
本出版物中述及的其它商标和商品名称是指拥有相应商标和商品名称的公司或其产品。
Dell Inc. 对其它公司的商标和产品名称不拥有任何所有权。
管制型号 E10S 系列
2010 年12 月P/N 30G7N Rev. A00

系统使用入门 15
安装和配置
警告：
执行下列步骤之前，请查看系统随附的安全说明。
打开系统包装
打开系统包装并检查各个组件。
在机架中安装滑轨和系统
小心：如果安装在封闭的或多单元机架部件中，机架周围的操作环境温度可
能高于室温。所以，应当考虑将设备安装在与制造商指定的最高环境温度
(TMA) 兼容的环境中。
有关详情，请参阅 第21 页的“技术规格”。
遵循系统随附的安全说明和机架安装说明，在机架中组装滑轨并安装系统。

16 系统使用入门
可选 —连接键盘、鼠标和显示器
接键盘、鼠标和显示器（可选）。
系统背面的 接器附有图标，这些图标指示了要插入每个 接器的电缆。
确保拧紧显示器的电缆 接器上的螺钉（如果有）。
连接电源电缆
将系统电源电缆 接至系统，如果使用显示器，将显示器电源电缆 接至显
示器。

系统使用入门 17
固 电源电缆
如图所示，将系统电源电缆弯曲图中的形状，并使用固定夹固定好电缆。
将电源电缆的另一端插入接地的电源插座或单独的电源，如不间断电源设备
(UPS)
或配电装置
(PDU)
。
开启系统
按下系统和显示器的电源按钮。电源指示灯将会亮起。

18 系统使用入门
安装可选挡板
安装挡板（可选）。
完成操作系统安装
如果购买了预安装的操作系统，请参阅系统随附的操作系统说明文件。第一
次安装操作系统时，请参阅操作系统的安装和配置说明文件。请确保先安装
操作系统，然后再安装未随系统一起购买的硬件或软件。
支持的操作系统
•Microsoft Small Business Server 2011 Standard 版及
Essential
版
•Microsoft Windows Server 2008 R2 SP1 (x64) Web 、
Standard
、
Foundation
版及
Enterprise
版
•Microsoft Windows
Server 2008 R2 (x64) Web
、
Standard
、
Foundation
版及
Enterprise
版
•Microsoft Windows Server 2008 SP2 (x86) Web 、
Standard
版
及
Enterprise
版
•Microsoft Windows Server 2008 SP2 (x64) Web 、
Standard
版
及
Enterprise
版
• 具有
Hyper-V
的
Microsoft Windows Server 2008 R2 SP1 (x64)
Standard
版及
Enterprise
版
• 具有
Hyper-V
的
Microsoft Windows Server 2008 R2 (x64) Standard
版及
Enterprise
版
