Dell™ PowerEdge™
R300 Systems
Getting Started
With Your System
Guide de mise en route
Primeiros passos com o sistema
Procedimientos iniciales con el sistema

Dell™ PowerEdge™
R300 Systems
Getting Started
With Your System

Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data
and tells you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury,
or death.
____________________
Information in this document is subject to change without notice.
© 2007 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly
forbidden.
Trademarks used in this text: Dell, the DELL logo, and PowerEdge are trademarks of Dell Inc.; Intel,
Pentium, Celeron and Xeon are registered trademarks and Core is a trademark of Intel Corporation
in the U.S. and other countries; Microsoft, Windows, and Windows Server are either tradcmarks or
registered trademarks of Microsoft Corporation in the United States and/or other countries; Red Hat
and Enterprise Linux are registered trademarks of Red Hat Inc.; SUSE is a registered trademark
of Novell Inc..
Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Model SMT
December 2007 P/N RW575 Rev. A00

Getting Started With Your System 3
System Features
The major hardware and software features of your system include:
• 1U/1S rack-mountable chassis with support for static rails and sliding rails.
NOTE: Use the System Setup program to view processor information. See
"Using the System Setup Program" in your Hardware Owner’s Manual.
• One of the following processors:
– Single Core Intel
®
Celeron
®
445 Processor
– Dual-Core Intel Core™2 Duo E6305 or E6405 Processor
– Quad-Core Intel Xeon
®
X3323, X3353, or X3363 Processor
• A minimum of 512-MB single or dual-ranked registered 667-MHz DDR2
memory modules with ECC, upgradeable to a maximum of 24-GB by
installing combinations of 512-MB, 1-GB, 2-GB, or 4-GB memory modules
in six memory module sockets on the system board.
• One of the following riser card options:
– Two riser cards (left and center risers), each providing a x8 lane width
PCI-Express expansion slot.
OR
– One riser card (center riser), providing a x8 lane width PCI-Express
expansion slot.
– One riser card (left riser) providing a 3.3 V, 64-bit 133MHz PCI-X
expansion slot.
• One 12.7 mm DVD, or combination CD-RW/DVD in a device drive bay.
• Support for the following internal hard-drive configurations:
– Up to two 3.5-inch, internal, SATA hard drives with the optional SAS
controller card (hot-plug option available).
– Up to two 3.5-inch, internal, Serial-Attached SCSI (SAS) hard drives
with an optional SAS controller card (hot-plug option available).

4Getting Started With Your System
• Optional remote access controller for remote systems management, which
is installed on the dedicated slot on the system board.
• Optional USB flash drive emulates a diskette drive or hard drive.
• One 400-W power supply (optional redundant power supply available).
• Two integrated Gigabit Ethernet network adapters, capable of supporting
10-Mbps, 100-Mbps, and 1000-Mbps data rates with support for Wake-
on-LAN.
• A Dell Remote Access Controller Card (DRAC5), which provides remote
system management, crashed system recovery, and power control functions
for Dell PowerEdge
.
• An integrated VGA-compatible video subsystem with an ATI ES1000,
33-MHz PCI video controller. This video subsystem contains a
minimum of 32MB of graphics memory with support for 2D graphics.
Maximum resolution is 1600 x 1200 with 65,536 colors; true-color
graphics are supported in the following resolutions: 640 x 480, 800 x 600,
1024 x 768, 1280 x 1024. When the optional remote access card is
installed, the maximum video resolution is 1280 x 1024
.
• Fan modules, each of which is comprised of two dual-rotor fans positioned
in front of the processor and memory.
• Fan modules, comprised of two dual-rotor fans positioned in front of the
PSU. These fans are used for the two redundant PSUs (hot-plug hard
drives and redundant PSU configuration).
• Serial connector for console redirection support.
• Security features, including chassis-intrusion detection and keylock
on the optional bezel.
• An integrated Trusted Platform Module (TPM) version 1.2 used for
security applications, capable of generating and storing keys, and storing
passwords and digital certifications. (Not available in China.)

Getting Started With Your System 5
• Systems management software/circuitry that monitors critical system
voltages and temperatures.
• Back-panel connectors include video, serial, two USB, and two network
adapter connectors.
• Front-panel connectors include one VGA and two USB connectors.
• One internal USB connector is included for a bootable memory key.
• Front-panel 1x5 LCD for system ID and error messaging.
For more information about specific features, see “Technical Specifications”
on page 11.
The following software is included with your system:
• A System Setup program for viewing and changing system configuration
information. For more information, see “Using the System Setup Program”
in the
Hardware Owner’s Manual .
• Enhanced security features, including a system and setup passwords are
available through the System Setup program.
• Video drivers for displaying programs in high-resolution modes.
Systems management software and documentation CDs.
Supported Operating Systems
• Microsoft
®
Windows Server
®
2008 Web, Standard, and Enterprise
(32-bit x86) Editions (
when available )
• Microsoft Windows Server 2008 Web, Standard, Small Business Server
(Premium and Standard), and Enterprise (x64) Editions (
when available )
• Microsoft Windows Server 2003 Web, Standard, Small Business Server
(Premium and Standard), and Enterprise (32-bit x86) Editions
(SP1 and SP2)
• Microsoft Windows Server 2003 Standard and Enterprise (x64) Editions
• Microsoft Windows Server 2003 R2 Standard, Small Business Server
(Premium and Standard), and Enterprise (32-bit x86) Editions

6Getting Started With Your System
• Microsoft Windows Server 2003 R2 Standard and Enterprise (x64)
Editions
•RedHat
®
Enterprise Linux
®
ES (versions 4 and 5) (x86_32)
• Red Hat Enterprise Linux ES (versions 4 and 5) (x86_64)
•SUSE
®
Linux Enterprise Server 9 (SP4 or later) (x86_64)
• SUSE Linux Enterprise Server 10 (x86_64)
NOTE: For the latest information on supported operating systems,
see www.dell.com.
Other Information You May Need
CAUTION: The Product Information Guide provides important safety and
regulatory information. Warranty information may be included within this
document or as a separate document.
•The Rack Installation Guide or Rack Installation Instructions included
with your rack solution describes how to install your system into a rack.
•The
Getting Started Guide provides an overview of system features,
setting up your system, and technical specifications.
•The
Hardware Owner’s Manual provides information about system
features and describes how to troubleshoot the system and install
or replace system components.
• CDs included with your system provide documentation and tools
for configuring and managing your system.
• Systems management software documentation describes the features,
requirements, installation, and basic operation of the software.
• Operating system documentation describes how to install (if necessary),
configure, and use the operating system software.
• Documentation for any components you purchased separately provides
information to configure and install these options.

Getting Started With Your System 7
• Updates are sometimes included with the system to describe changes
to the system, software, and/or documentation.
NOTE: Always check for updates on support.dell.com and read the updates
first because they often supersede information in other documents.
• Release notes or readme files may be included to provide last-minute
updates to the system or documentation or advanced technical reference
material intended for experienced users or technicians.
Obtaining Technical Assistance
If you do not understand a procedure in this guide or if the system does not
perform as expected, see your Hardware Owner’s Manual.
Dell Enterprise Training and Certification is available; see
www.dell.com/training for more information. This service may not be offered
in all locations.
Installation and Configuration
CAUTION: Before performing the following procedure, read and follow the safety
instructions and important regulatory information in your Product Information
Guide.
CAUTION: Whenever you need to lift the system, get others to assist you. To avoid
injury, do not attempt to lift the system by yourself.
This section describes the steps to set up your system for the first time.
Unpacking the System
Unpack your system and identify each item. Keep all shipping materials in
case you need them later.

8Getting Started With Your System
Installing the Rail and System in a Rack
Install the system in the rack once you have read the “Safety Instructions”
located in the rack installation documentation for your system.
See your rack installation documentation for instructions on installing your
system in a rack. For power and cooling guidelines, see the rack capacity
planner tool on www.dell.com.
Connecting the Keyboard, Mouse, and Monitor
Connect the keyboard, mouse, and monitor (optional).
The connectors on the back of your system have icons indicating which cable
to plug into each connector. Be sure to tighten the screws (if any) on the
monitor's cable connector.

Getting Started With Your System 9
Connecting the Power
Connect the system’s power cable(s) to the system (a redundant system is
shown in the illustration). For redundant systems, secure the cables with the
two Velcro straps that ship with your system, as shown. For non-redundant
systems, attach the power cord retention bracket that ships with your system.
Plug the other end of the cable into a grounded electrical outlet or a separate
power source such as an uninterrupted power supply (UPS) or a power
distribution unit (PDU).
Turning on the System
Turn on the system and monitor (optional).

10 Getting Started With Your System
Press the power button on the system and the monitor. The power indicators
should light. Adjust the monitor’s controls until the displayed image is
satisfactory.
Installing the Bezel
Install the bezel (optional).
Complete the 0perating System Setup
If you purchased a preinstalled operating system, see the operating system
documentation that ships with your system. To install an operating system for
the first time, see the Quick Installation Guide. Be sure the operating system
is installed before installing hardware or software not purchased with the
system.

Getting Started With Your System 11
Technical Specifications
Processor
Processor type Single Core Intel
®
Celeron
®
445 processor
or
Dual-Core Intel Core
™ 2 Duo E6305 or E6405
sequence processor
or
Quad-Core Intel Xeon
®
X3323, X3353, or X3363
serial processor
Expansion Buses
Bus type PCI-X, PCIe
Expansion slots – Two optional riser cards
Riser 1
PCIe Center Riser One full-height, half-length, x8 lane PCIe slot
PCIe Left Riser One full-height, half-length, x8 lane PCIe slot
Riser 2
PCI-X Left Riser One full-height, half-length,
64-bit, 133MHz PCI-X slot
PCIe Center Riser One full-height, half-length, x8 lane PCIe slot
Memory
Architecture Up to six registered DDR2 677 MHz RDRAM
memory modules with ECC
Memory module sockets Six 240-pin
Memory module capacities 512 MB, 1 GB, 2 GB, 4GB
Minimum RAM 512 MB (one 512-MB module)
Maximum RAM 24 GB

12 Getting Started With Your System
Drives
Hard Drives
SATA Up to two 3.5-inch, internal
(optional for hot-plug)
SAS Up to two 3.5-inch, internal with optional SAS
controller card (optional for hot-plug)
CD/DVD drive One optional DVD, or combination
CD-RW/DVD in a device drive bay
NOTE: DVD devices are data only.
USB flash drive One optional drive that emulates a diskette drive
or hard drive
Connectors
Externally accessible
Back
Network adapter Two RJ-45 (for integrated 1-Gigabit network
adapters)
Serial 9 pin
USB Two 4-pin, USB 2.0 compliant
Video 15-pin VGA
Front
Video 15-pin VGA
USB Two 4-pin, USB 2.0 compliant
Internally accessible
SATA channels Three 7-pin
USB key (for memory key) one 4-pin, USB 2.0-compliant

Getting Started With Your System 13
Video
Video type Integrated ATI ES1000 VGA controller
Video memory 32 MB (Min)-64 MB (Max) DDR II
Power
AC power supply
Wattage 400 W redundant PSU for hot-plug hard
drives plus redundant PSU configuration
(maximum configuration)
Voltage 100–240 VAC, 50/60 Hz
Maximum inrush current Under typical line conditions and over
the entire system ambient operating range,
the inrush current may reach 25 A for 10 ms
or less
System battery CR 2032 3.0-V lithium coin cell
Physical
Height 4.2 cm (1.67 in)
Width 42.6 cm (16.78 in)
Depth
With optional bezel 69.3 cm (27.29 in)
Without optional bezel 66 cm (26 in)
Weight (maximum
configuration Kg)
13.45 kg (29.6 lb)

14 Getting Started With Your System
Environmental
NOTE: For additional information about environmental measurements for specific
system configurations, see www.dell.com/environmental_datasheets.
Temperature
Operating 10° to 35°C (50° to 95°F)
Storage –40° to 65°C (–40° to 149°F)
Relative humidity
Operating 20% to 80% (noncondensing) with a maximum
humidity gradation of 10% per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.26 Grms at 5–350 Hz for 15 min
Storage 1.54 Grms at 10–250 Hz for 15 min
Maximum shock
Operating One shock pulse in the positive z axis (one pulse
on each side of the system) of 31 G for up to
2.6 ms
Storage Six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse
on each side of the system) of 71 G for up to 2 ms
Altitude
Operating –16 to 3,048 m (–50 to 10,000 ft)
NOTE: For altitudes above 2,950 feet, the maximum
operating temperature is derated 1°F/550 ft.
Storage –16 to 10,600 m (–50 to 35,000 ft)
Airborne Contaminant Level
Class G2 or lower as defined by ISA-S71.04-1985

Systèmes Dell™
PowerEdge™ R300
Guide de mise en route

Remarques, avis et précautions
REMARQUE : Une REMARQUE indique des informations importantes qui peuvent
vous aider à mieux utiliser votre ordinateur.
AVIS : Un AVIS vous avertit d'un risque de dommage matériel ou de perte
de données et vous indique comment éviter le problème.
PRÉCAUTION : Une PRÉCAUTION indique un risque potentiel d'endommagement
du matériel, de blessure corporelle ou de mort.
____________________
Les informations contenues dans ce document peuvent être modifiées sans préavis.
© 2007 Dell Inc. Tous droits réservés.
La reproduction de ce document de quelque manière que ce soit sans l'autorisation écrite de Dell Inc.
est strictement interdite.
Marques utilisées dans ce document : Dell, le logo DELL et PowerEdge sont des marques de Dell Inc. ;
Intel, Pentium,Celeron et Xeon sont des marques déposées de Intel Corporation aux États-Unis
et dans d'autres pays ; Core est une marque de Intel Corporation aux États-Unis et dans d'autres pays ;
Microsoft, Windows et Windows Server sont des marques ou des marques déposées de Microsoft
Corporation aux États-Unis et/ou dans d'autres pays ; Red Hat et Enterprise Linux sont des marques
déposées de Red Hat Inc. ; SUSE est une marque déposée de Novell Inc.
D'autres marques et noms de marques peuvent être utilisés dans ce document pour faire référence
aux entités se réclamant de ces marques et de ces noms ou à leurs produits. Dell Inc. dénie tout intérêt
propriétaire vis-à-vis des marques et des noms de marque autres que les siens.
Modèle SMT
Décembre 2007 N/P RW575 Rév. A00

Guide de mise en route 17
Caractéristiques du système
Les principales caractéristiques du système sur le plan matériel et logiciel
sont les suivantes :
• Châssis 1U/1S montable en rack avec support pour rails statiques
et rails coulissants.
REMARQUE : Utilisez le programme de configuration du système
pour visualiser les informations concernant les processeurs.
Voir “Using the System Setup Program” (Utilisation du programme
de configuration du système) dans le document Hardware Owner's
Manual (Manuel du propriétaire).
• L'un des deux processeurs suivants est installé :
– Processeur à coeur unique Intel
®
Celeron
®
445
– Processeur double coeur Intel Core™2 Duo E6305 ou E6405
– Processeur quadruple coeur Intel Xeon
®
X3323, X3353 ou X3363
• Un minimum de 512 Mo de mémoire, sous forme de barrettes DDR2
à une seule ou deux rangées de connexion, à registres et avec ECC,
cadencées à 667 MHz. Extension possible (jusqu'à 24 Go maximum)
via l'installation de combinaisons de barrettes de 512 Mo, 1 Go, 2 Go
ou 4 Go dans les six emplacements mémoire de la carte système.
• L'une des options suivantes pour la carte de montage :
– Deux cartes de montage (gauche et centrale) offrant chacune
un logement d'extension PCI-Express x8.
-ou-
– Une carte de montage (installée au centre) comprenant un logement
d'extension PCI-Express x8.
– Une carte de montage (installée à gauche) comprenant un logement
d'extension PCI-X 64 bits à 3,3 V (133 MHz).
• Un lecteur de DVD de 12,7 mm ou un lecteur combo CD-RW/DVD,
installé dans une baie de périphérique.

18 Guide de mise en route
• Prise en charge des configurations suivantes pour les disques durs
internes :
– Jusqu'à deux disques durs SATA internes de 3,5 pouces, avec
la carte contrôleur SAS en option (version enfichable à chaud
disponible en option).
– Jusqu'à deux disques durs SAS (Serial-Attached SCSI) internes
de 3,5 pouces, avec une carte contrôleur SAS en option
(version enfichable à chaud disponible en option).
• Un contrôleur d'accès distant en option (pour la gestion de systèmes
à distance), installé dans le logement dédié de la carte système.
• Un lecteur flash USB (en option) émulant un lecteur de disquette
ou un disque dur.
• Un bloc d'alimentation de 400 W (bloc d'alimentation redondant
disponible en option).
• Deux cartes réseau Ethernet Gigabit intégrées prenant en charge
des débits de 10, 100 ou 1000 Mbps avec prise en charge de la fonction
Wake-on-LAN.
• Un contrôleur DRAC5 (Dell Remote Access Controller Card 5)
fournissant des fonctions de gestion de systèmes à distance, de
récupération d'urgence et de contrôle de l'alimentation pour Dell
PowerEdge
.
• Un sous-système vidéo compatible VGA intégré avec contrôleur vidéo
PCI ATI ES1000 (33 MHz). Ce sous-système dispose d'un minimum
de
32 Mo de mémoire graphique avec prise en charge des graphiques
en 2D. La résolution maximale prise en charge est de 1600 x 1200
avec 65536 couleurs. Les graphiques True-color sont pris en charge
dans les résolutions suivantes : 640 x 480, 800 x 600, 1024 x 768 et
1280 x 1024. Lorsque la carte RAC en option est installée, la résolution
vidéo maximale est de 1280 x 1024
.
• Quatre modules de ventilation, chacun comprenant deux ventilateurs
à double rotor, positionnés devant le processeur et la mémoire.
