DELL™ PowerEdge™
Deployment Guide
A Dell Technical White Paper
By Donnie Davis

PowerEdge Deployment Guide
Page ii
THIS WHITE PAPER IS FOR INFORMATIONAL PURPOSES ONLY, AND MAY CONTAIN TYPOGRAPHICAL ERRORS AND
TECHNICAL INACCURACIES. THE CONTENT IS PROVIDED AS IS, WITHOUT EXPRESS OR IMPLIED WARRANTIES OF
ANY KIND.
© 009 Dell Inc. All rights reserved. Reproduction of this material in any manner whatsoever without the express
written permission of Dell Inc. is strictly forbidden. For more information, contact Dell.
Dell, the DELL logo, and the DELL badge, Dell OpenManage, and PowerEdge are trademarks of Dell Inc. Microsoft,
Windows, and Windows Server are either trademarks or registered trademarks of Microsoft Corporation in the
United States and/or other countries. Intel and Xeon are trademarks of Intel Corporation in the United States
and/or other countries.

PowerEdge Deployment Guide
Page 1
Table of Contents
Introduction ..................................................................................................................................................................
Unified Server Configurator (USC) Deployment ...........................................................................................................
Dell Systems Build and Update Utility (SBUU) .............................................................................................................. 3
Dell OpenManage™ Deployment Toolkit (DTK) ............................................................................................................ 3
Manual Installation of Microsoft Operating Systems ................................................................................................... 4
Microsoft WDS (Legacy Images) / RIS ........................................................................................................................... 4
WinPE ........................................................................................................................................................................... 4
Microsoft Automated Deployment Service (ADS) ........................................................................................................ 4

PowerEdge Deployment Guide
Page
Introduction
The purpose of this document is to provide tips on deploying Microsoft® operating systems to Dell PowerEdge
servers. This document will not cover how to setup a deployment infrastructure, but rather the modifications
needed to allow an existing deployment setup to work with the 11th Generation PowerEdge servers.
Many deployment related items changed with the introduction of the Broadcom NetXtreme II (5708 based)
network adapters which were deployed on the 9th and 10th Generation PowerEdge servers. These changes were
needed in order for the network adapters to support iSCSI and TOE. The 11th Generation PowerEdge servers
include 5709-based LOMs (LAN-on-motherboard). This document will briefly cover some of the more commonly
noticed changes. For a comprehensive discussion, see Best Practices for Installation of Microsoft Windows on Dell
Servers wit Broadcom NetXtreme Devices on www.support.dell.com. This document will also cover advanced
procedures such as setting a static IP.
NOTE: Dell recommends installing the latest software updates and security patches for your operating system.
Failing to do so can result in things such as an unstable server or data loss.
Drive Lettering Warning: Since the 11th Generation PowerEdge servers contain an embedded storage device,
Microsoft Windows 003 may see this device as a hard drive. Older versions of the Microsoft operating systems
are not supported on these servers. This can cause drive lettering issues. For example, the embedded device may
get assigned the drive letter C: and the actual hard drive will be assigned drive letter F:. If the hard drive does not
contain a partition when the operating system installation is started, the hard drive will be assigned drive letter F:.
If you observe this issue, follow the steps below to assign the drive letter C: to the hard drive partition:
1. Create the partition on the hard disk as you normally would in the partition selection part of text-mode
setup. You will notice that the drive letter assigned is not C:.
. Delete the partition that you just created.
3. Create the partition again. It should now have drive letter “C” assigned to it.
4. Select the new partition and press <Enter> to install the operating system on the partition.
NOTE: Drive letter changes can only be made during installation.
For more information, see the Microsoft Knowledge Base article 896536 on
http://support.microsoft.com/kb/896536.
NOTE: This same behavior may also be observed if devices such as flash drives or USB drives are attached during
operating system deployment.
Unified Server Configurator (USC) Deployment
The Lifecycle Controller is an embedded system management tool that allows system and storage configuration.
The controller is delivered as a part of iDRAC Express in the 11th Generation PowerEdge servers. The controller
includes 1 GB of managed and persistent storage that embeds systems management features in addition to the
iDRAC features. The Unified Server Configurator is the user interface for local access to the Lifecycle Controller
features prior to operating system installation. USC allows you to configure your operating system, RAID, and to
download drivers and firmware updates. Press the <F10> key within 10 seconds of the Dell logo being displayed
during the system boot process. See the Unified Server Configurator documentation on www.support.dell.com
for complete information.

PowerEdge Deployment Guide
Page 3
Dell Systems Build and Update Utility (SBUU)
The SBUU is on the Systems Management Tools and Documentation DVD that ships with your system. Using SBUU,
you can configure RAID, install an operating system, and update firmware. Boot from the DVD and you will see all
of the options in the user interface.
To install an operating system using SBUU:
1) Turn on the server.
) At POST, press < F11> when prompted for BIOS Boot anager.
3) Highlight the optical drive containing the Dell Systems Build and Update Utility and press <Enter>.
4) Click Configure in the Server OS Installation.
SBUU will now ask questions about the installation you wish to perform. The answers to these questions
will be used to configure RAID, as well as to customize and to automate the operating system installation
process. Click Continue after answering each question.
5) Select any options you want on the Operating System Installation Summary page and click Apply Now.
SBUU will now prepare for the installation. Remember that you can place your mouse pointer over the “I”
balloons in the SBUU to receive more information about that item.
6) When prompted, remove the SBUU DVD and insert the operating system DVD. The installation will
continue automatically.
NOTE: Windows® Server 008 will not prompt for the operating system media at this time. The server will
reboot, start the operating system installation, and then ask for the operating system DVD.
7) The system will reboot when the SBUU completes the initial setup for the installation. The server should
boot to the hard drive at this time to start the operating system installation.
8) Depending on the operating system you chose to install, other reboots may occur at different times as a
part of the operating system installation process.
9) The operating system and required drivers should now be installed.
NOTE: For additional information on SBUU and the features of the program, www.support.dell.com for the SBUU
documentation.
Dell OpenManage™ Deployment oolkit (D K)
The Dell OpenManage Deployment Toolkit (DTK) is a collection of utilities that can be built into pre-installation
environments, such as WinPE and embedded Linux. The DTK also contains sample scripts and help files to aid you
in understanding how to use this tool. The DTK not only provides the ability to install an operating system, but also
allows you to configure hardware settings such as RAID levels and BIOS settings. For additional information and
features, download the DTK from www.support.dell.com (look in the Systems anagement section, if searching
for a particular server model).
NOTE: The DTK does not support 64-bit WinPE at this time; however, Dell plans to add this support in the future.

PowerEdge Deployment Guide
Page 4
Manual Installation of Microsoft Operating Systems
This installation method involves booting to the operating system installation DVD to complete the installation.
Depending on the operating system you are installing, the mass storage drivers may not be included, and
therefore, the installation will fail since no hard drives will be seen. Operating systems released prior to Microsoft
Windows Server 008 will look for a floppy disk for the mass storage drivers. Since many servers ship without a
floppy drive, this may cause a problem. To assist, Dell developed the Dell USB Key F6 Driver Utility. This utility can
be downloaded from www.support.dell.com. The utility allows you to provide the mass storage drivers from a
USB key by making the USB key appear to the operating system as a floppy drive. Press <F6> when prompted at
the beginning of the operating system installation. Please keep in mind that there will likely be other drivers that
will need to be installed after the operating system installation is complete. You can determine what devices do
not have drivers installed by looking in Device anager. For the 11th Generation PowerEdge servers, you will also
need to install the chipset, Broadcom NetXtreme II, and Matrox G 00 video drivers. You may also use the Unified
Server Configurator to update drivers and firmware.
Microsoft WDS (Legacy Images) / RIS
For this deployment service, you will need to ensure that the mass storage driver for the controller in your server,
such as the PERC 6, is added per the Microsoft WDS / RIS documentation. See http://technet.microsoft.com/en-
us/library/cc7 0099.aspx for more information. You will also need to add the network adapter driver. See
Microsoft Knowledge Base article 315 79 on http://support.microsoft.com/kb/315 79. Remember that starting
with the Broadcom NetXtreme II 5709-based adapters, a separate WDS / RIS driver must be used for the text mode
portion of the installation due to technology changes needed to support iSCSI and TOE. Dell recommends that the
Broadcom drivers be installed using the drivers setup.exe and a cmdlines.txt file. See the Microsoft
documentation for a detailed explanation. This will ensure that the network driver version as well as the
Broadcom Advanced Control Suite is in sync. For more information see Best Practices for Installation of Microsoft
Windows on Dell Servers wit Broadcom NetXtreme Devices. Additional information is also available in the
Microsoft Knowledge Base article 54078 on http://support.microsoft.com/kb/ 54078/en.
WinPE
You will need to add the mass storage driver and network driver based on the Microsoft WinPE documentation.
Remember that you must use the latest RIS network driver for the Broadcom NetXtreme 5708 and 5709 adapters.
See Best Practices for Installation of Microsoft Windows on Dell Servers wit Broadcom NetXtreme Devices for
more information.
Microsoft Automated Deployment Service (ADS)
Dell has observed a problem with ADS when two Intel™ Xeon™ processors are installed. When booting to the
Deployment Agent, ADS gives the following error:
Windows could not start due to an error while booting the RAMDISK. Windows
failed to build a bootable RAMDISK image. System will reboot in 5 seconds.

PowerEdge Deployment Guide
Page 5
This error continues even after ensuring that all needed drivers are added to the PreSystem directory. The solution
for this issue is to use WinPE instead of the default deployment agent. See the following Microsoft knowledge
base article: http://support.microsoft.com/?id=9707 1
Using UEFI
For additional information about using UEFI, see Deploying UEFI-Aware Operating Systems on Elevent Generation
Dell TM PowerEdgeTM Servers.
