Dell External OEMR 2850 User manual

www.dell.com | support.dell.com
Dell™ OpenManage™
Deployment Toolkit
User’s Guide

Notes and Cautions
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if
instructions are not followed.
____________________
Information in this document is subject to change without notice.
© 2009 Dell Inc. All rights reserved.
Reproduction of these materials in any manner whatsoever without the written permission of Dell Inc.
is strictly forbidden.
Trademarks used in this text: Dell, the DELL logo, PowerEdge, PowerVault, and OpenManage are
trademarks of Dell Inc.; Intel386 is a trademark and Intel and Pentium are registered trademarks of
Intel Corporation in the United States and other countries; Microsoft, MS-DOS, Windows, Windows
NT, Active Directory, and Windows Server are either trademarks or registered trademarks of Microsoft
Corporation in the United States and/or other countries; Novell, NetWare, and SUSE are registered
trademarks of Novell, Inc. in the United States and other countries; Red Hat and Red Hat Enterprise
Linux are registered trademarks of Red Hat, Inc. in the United States and other countries.
Other trademarks and trade names may be used in this document to refer to either the entities claiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
ThesamplescriptsprovidedwiththeDellOpenManageDeploymentToolkit are provided"asis."Dell
disclaims any and all warranties, express, implied or statutory, with respect to the sample scripts,
including,butnotlimitedto,theimpliedwarrantiesofmerchantability,fitnessforaparticular purpose,
title and any warranty of non-infringement. Use the sample scripts at your own risk. Dell shall not be
liable for any direct or indirect damages incurred in using the sample scripts. In no event shall Dell or
its suppliers be responsible for any direct or indirect damages whatsoever (including, without
limitation,damagesforlossofprofits,lossofuse,lossofdata,businessinterruption,orotherpecuniary
loss, nor for punitive, incidental, consequential, or special damages of any kind, under any part of this
agreement, even if advised or aware of the possibility of such damage.
April 2009

Contents 3
Contents
1 Introduction . . . . . . . . . . . . . . . . . . . . . . . 11
Introduction tox the DTK User’s Guide . . . . . . . . . 12
What’s New . . . . . . . . . . . . . . . . . . . . . . . 14
Prerequisites and Requirements . . . . . . . . . . . . 14
Supported Operating Systems to
Run DTK Utilities . . . . . . . . . . . . . . . . . . 15
Supported Systems . . . . . . . . . . . . . . . . . 15
Supported BIOS Firmware Versions . . . . . . . . 15
Installation Prerequisites . . . . . . . . . . . . . 15
Deployment Prerequisites . . . . . . . . . . . . . 16
Deploying Operating Systems . . . . . . . . . . . . . . 18
Deployment Methods . . . . . . . . . . . . . . . . . . 18
DTK Deployment Overview . . . . . . . . . . . . . . . 19
Preparing for Deployment . . . . . . . . . . . . . 19
Deploying . . . . . . . . . . . . . . . . . . . . . . 21
Other Dell Documents You Might Need . . . . . . . . . 23
Other Supporting Documents You Might Need . . . . . 24
Obtaining Technical Assistance . . . . . . . . . . . . 25

4Contents
2 Choosing a Microsoft
Windows PE-Based
Deployment Method . . . . . . . . . . . . . . . . 27
Choosing a Deployment Method for
Microsoft Windows PE . . . . . . . . . . . . . . . . . 27
CD-Based Local Deployment . . . . . . . . . . . . 27
CD-Based Local Deployment With
Networking Enabled . . . . . . . . . . . . . . . . 28
Using a Third-Party Deployment
Solution Framework . . . . . . . . . . . . . . . . 29
Deployment Matrix (Windows PE) . . . . . . . . . . . 30
3 Preparing the Directory Structure
for Deployment in
Microsoft Windows PE . . . . . . . . . . . . . . 33
Upgrading Your DTK Version . . . . . . . . . . . . . . 33
Obtaining DTK . . . . . . . . . . . . . . . . . . . . . . 33
DTK Contents . . . . . . . . . . . . . . . . . . . . . . 36
System Utilities and Supporting Files . . . . . . . 36
Sample Configuration Files . . . . . . . . . . . . . 38
Sample Scripts . . . . . . . . . . . . . . . . . . . 39
Documentation . . . . . . . . . . . . . . . . . . . 41
Drivers . . . . . . . . . . . . . . . . . . . . . . . 42
Miscellaneous . . . . . . . . . . . . . . . . . . . 42
Other Supporting Tools and System Files . . . . . . . . 43

Contents 5
Setting Up a Directory Structure
for Deployment . . . . . . . . . . . . . . . . . . . . . 45
DTK Utilities and Files . . . . . . . . . . . . . . . 45
System-Specific Files . . . . . . . . . . . . . . . 46
Operating System Installation Files . . . . . . . . 48
Configuring a Source System . . . . . . . . . . . . . . 52
RAC Configuration . . . . . . . . . . . . . . . . . 53
4 Preparing the Script Files for
Deployment Using Microsoft
Windows PE . . . . . . . . . . . . . . . . . . . . . . 55
Using the Sample DTK Scripts to Run
a Full Deployment in Windows PE . . . . . . . . . . . 56
The Master Batch File (DEPLOY.BAT) . . . . . . . 56
Editing the Sample Batch Files to Perform
a Complete System Deployment in
Windows PE . . . . . . . . . . . . . . . . . . . . . . . 57
Using the Sample Scripts in
a Scripted Deployment . . . . . . . . . . . . . . . 57
TKENVSET.BAT . . . . . . . . . . . . . . . . . . . 64
Editing DTK Task Scripts . . . . . . . . . . . . . . 68
Using the DTK Sample Scripts to Capture
Configuration Information in Windows PE . . . . . . . 70
Capturing the System BIOS and BMC
Configuration With the SYSCAP.BAT
Sample Script . . . . . . . . . . . . . . . . . . . 70
Capturing the RAC Configuration
With the RACCAP.BAT Sample Script . . . . . . . 71

6Contents
Preparing the Operating System Installation
Scripts for Windows PE . . . . . . . . . . . . . . . . . 73
WININST.BAT . . . . . . . . . . . . . . . . . . . . 73
UNATTEND.TXT . . . . . . . . . . . . . . . . . . 74
UNATTEND.XML . . . . . . . . . . . . . . . . . . 76
5 Running Deployment Scripts
Using DTK and Microsoft
Windows PE . . . . . . . . . . . . . . . . . . . . . . 77
Creating and Customizing Images for
Windows PE 1.0 . . . . . . . . . . . . . . . . . . . . . 77
Obtaining Windows OEM Preinstallation
Kit (OPK) or Windows PE CD . . . . . . . . . . . . 77
Copying Tools From OPK or
Windows PE CD on a Development System . . . . 77
Creating a Standard Windows PE . . . . . . . . . 78
Integration of DTK Directory Structure
in Windows PE Build . . . . . . . . . . . . . . . . 79
Creating a Bootable Windows
PE ISO Image . . . . . . . . . . . . . . . . . . . . 80
CD-Based Local Deployment . . . . . . . . . . . . 81
Running the Windows PE 1.0 Image . . . . . . . . . . 81
CD-Based Local Deployment With
Networking Enabled . . . . . . . . . . . . . . . . 81
Using a Third-Party Deployment
Solution Framework . . . . . . . . . . . . . . . . 82
Creating and Customizing Images for
Windows PE 2.0 . . . . . . . . . . . . . . . . . . . . . 82
Integration of DTK Directory Structure
in Windows PE Build . . . . . . . . . . . . . . . . 82
Creating a Bootable CD . . . . . . . . . . . . . . 83

Contents 7
Running the Windows PE 2.0 Image . . . . . . . . . . 83
CD-Based Local Deployment . . . . . . . . . . . 83
CD-Based Local Deployment With
Networking Enabled . . . . . . . . . . . . . . . . 84
Using a Third-Party Deployment
Solution Framework . . . . . . . . . . . . . . . . 84
6 Choosing an Embedded Linux-Based
Deployment Method . . . . . . . . . . . . . . . . 85
Choosing a Deployment Method for
Embedded Linux . . . . . . . . . . . . . . . . . . . . . 85
Network-Based Deployment . . . . . . . . . . . . 86
Using a Third-Party Deployment
Solution Framework . . . . . . . . . . . . . . . . 87
CD-Based Local Deployment for
Embedded Linux . . . . . . . . . . . . . . . . . . 87
Deployment Matrix (Embedded Linux) . . . . . . . . . 89
7 Preparing the Directory Structure
for Deployment in Embedded Linux . . . . 93
Upgrading Your DTK Version . . . . . . . . . . . . . . 93
Installation for Embedded Linux . . . . . . . . . . . . 93
DTK Contents . . . . . . . . . . . . . . . . . . . . . . 97
System Utilities and Supporting Files . . . . . . . 97
Sample Configuration Files . . . . . . . . . . . . . 99
Sample Scripts . . . . . . . . . . . . . . . . . . . 100
Documentation . . . . . . . . . . . . . . . . . . . 101
Drivers and Dell Real Mode
Kernel (DRMK) . . . . . . . . . . . . . . . . . . . 101
Miscellaneous . . . . . . . . . . . . . . . . . . . 101

8Contents
Other Supporting Tools and System Files . . . . . . . . 101
Setting Up a Directory Structure
for Deployment . . . . . . . . . . . . . . . . . . . . . 103
DTK Utilities and Files . . . . . . . . . . . . . . . 103
System-Specific Files . . . . . . . . . . . . . . . . 103
Creating Operating System Installation
Directories for Supported Linux
Operating Systems . . . . . . . . . . . . . . . . . 105
Configuring a Source System . . . . . . . . . . . . . . 107
How to Obtain Dell Utility Partition Files . . . . . . 108
RAC Configuration . . . . . . . . . . . . . . . . . 108
8 Preparing the Script Files for
Deployment Using Embedded
Linux . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Using the Sample DTK Scripts to Run a
Full Deployment in Embedded Linux . . . . . . . . . . 109
The Master Deployment File . . . . . . . . . . . . 109
Editing the Sample Batch Files to
Perform a Complete System Deployment
in Embedded Linux . . . . . . . . . . . . . . . . . . . 110
Using the Sample Scripts in
a Scripted Deployment . . . . . . . . . . . . . . . 110
tkenvset.sh . . . . . . . . . . . . . . . . . . . . . 116
Editing DTK Task Scripts . . . . . . . . . . . . . . 121

Contents 9
Using the DTK Sample Scripts to
Capture Configuration Information in
Embedded Linux . . . . . . . . . . . . . . . . . . . . . 123
Capturing the System BIOS and BMC
Configuration With the syscap.sh
Sample Script . . . . . . . . . . . . . . . . . . . 123
Capturing the RAC Configuration
With the raccap.sh Sample Script . . . . . . . . . 124
Preparing the Operating System
Installation Scripts . . . . . . . . . . . . . . . . . . . 126
Red Hat Enterprise Linux Server
Operating Systems . . . . . . . . . . . . . . . . . 126
lininst.sh . . . . . . . . . . . . . . . . . . . . . . 126
ks.cfg (for Red Hat Enterprise Linux
Server Version 4) and
ks-rhel5.cfg (for Red Hat Enterprise
Linux Server Version 5) . . . . . . . . . . . . . . . 127
Install Linux Using lininst.sh . . . . . . . . . . . . 127
SUSE Linux Enterprise Server
Operating Systems . . . . . . . . . . . . . . . . . 128
suseinst.sh . . . . . . . . . . . . . . . . . . . . . 128
autoinst.xml (for SUSE Linux
Enterprise Server) . . . . . . . . . . . . . . . . . 129
9 Running Deployment Scripts
Using DTK and Embedded Linux . . . . . . 131
Deployment Using Dell-Provided
Embedded Linux . . . . . . . . . . . . . . . . . . 131
Deployment Using Customized
Embedded Linux . . . . . . . . . . . . . . . . . . 134
Using a Third-Party Deployment
Solution Framework . . . . . . . . . . . . . . . . 134

10 Contents
10 Running Dell Update Packages
in Embedded Linux . . . . . . . . . . . . . . . . 135
Running Update Packages in
Dell-Provided Embedded Linux . . . . . . . . . . . 135
Running Update Packages in
Customized Embedded Linux . . . . . . . . . . . . 135
11 Known Issues and
Frequently Asked Questions . . . . . . . . . 139
Known Issues . . . . . . . . . . . . . . . . . . . . . . 139
General Issues . . . . . . . . . . . . . . . . . . . 139
RAIDCFG Issues . . . . . . . . . . . . . . . . . . 139
RACADM Issues . . . . . . . . . . . . . . . . . . 140
Windows PE Installation Issues . . . . . . . . . . 140
Frequently Asked Questions . . . . . . . . . . . . . . 140
General Deployment Questions . . . . . . . . . . 140
RAIDCFG Questions . . . . . . . . . . . . . . . . 141
SYSCFG Questions . . . . . . . . . . . . . . . . . 145
Embedded Linux Questions . . . . . . . . . . . . 146
Windows PE Questions . . . . . . . . . . . . . . . 147
Glossary . . . . . . . . . . . . . . . . . . . . . . . . . . . 149
Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171

Introduction 11
Introduction
The Dell™ OpenManage™ Deployment Toolkit (DTK) includes a set of
utilities for configuring and deploying Dell systems. The DTK is designed
for customers who need to build scripted installations to deploy large
numbers of systems in a reliable fashion without having to dramatically
change their current deployment processes.
In addition to the command line utilities used to configure various system
features, the DTK also provides sample scripts and configuration files to
perform common deployment tasks and documentation. These files and
scripts describe the use of DTK in Microsoft®Windows® Preinstallation
Environment (Windows PE) and embedded Linux environments.
The benefits of the DTK:
• Provides the tools necessary to automate the pre-operating system
configuration tasks and the unattended operating system installation tasks
when deploying Dell systems.
• Scales to support from one to many system deployment efforts.
• Facilitates consistent system configurations across multiple systems.
• Provides diverse and useful deployment tools that can be utilized in many
different ways.

12 Introduction
Introduction tox the DTK User’s Guide
While the DTK is designed to be flexible and expandable, this guide is
limited to providing general, best practices procedures that focus on the
basic tasks for a successful deployment. Users might find many alternative
solutions to the best practices guidelines described in this guide and many
additional uses for the DTK utilities beyond what is covered in this guide or
in the Dell OpenManage Deployment Toolkit Command Line Interface
Reference Guide.
CAUTION: The best practices guidelines described in this document were
developed and tested on specific systems with specific hardware and software
configurations. As a result, the examples and instructions described in this guide
are not applicable to every environment. The open nature of the DTK utilities and
scripting methodology is designed to allow the flexibility to modify the examples,
procedures, and suggestions to best fit your specific environment. Using the
DTK examples without first making modifications based on your specific
IT environment is likely to result in failed deployments.
Information in this guide is distinctly divided for Windows PE and embedded
Linux. Even though the nature of topics covered for both environments is
similar, the contents are very different, and has been organized into separate
sections. This will enable the user to read only those sections that are
relevant. Content in this User’s Guide is organized as documented in
Tab l e 1- 1 .
Table 1-1. Information Organization in This Guide
Topics Section for
Windows PE
Section for
Embedded Linux
Introduction, that includes
information on:
•DTK
• What’s new for this release
• Prerequisites and requirements
• DTK deployment overview
Introduction Introduction
Planning, that includes best
practices for choosing a deployment
method
"Choosing a Microsoft
Windows PE-Based
Deployment Method"
"Choosing an
Embedded Linux-Based
Deployment Method"

Introduction 13
NOTE: The best practices examples included in this guide are intended to provide
illustrations for using specific scripts and configurations that have been tested on
specific Dell systems.
This guide also includes a "Known Issues and Frequently Asked Questions" section.
Preparing the deployment directory
structure, that includes best
practices for:
• Installing DTK
• Gathering and organizing
deployment files (DTK, operating
system, drivers, systems
management software, and so on)
• Preparing an optimally configured
source system
"Preparing the
Directory Structure
for Deployment in
Microsoft Windows
PE"
"Preparing the
Directory Structure for
Deployment in
Embedded Linux"
Preparing the deployment script
files, that includes best
practices for:
• Editing and modifying sample
scripts
• Capturing basic input/output
system (BIOS), baseboard
management controller (BMC),
and remote access controller (RAC)
configuration profiles from an
optimally configured source system
"Preparing the Script
Files for Deployment
Using Microsoft
Windows PE"
"Preparing the Script
Files for Deployment
Using Embedded
Linux"
Running a scripted deployment that
includes best practices for:
• Creating deployment media
• Running the deployment
"Running
Deployment Scripts
Using DTK and
Microsoft Windows
PE"
"Running Deployment
Scripts Using DTK and
Embedded Linux"
Running Dell Update Packages in
the embedded Linux environment
on supported Dell systems.
Not applicable "Running Dell Update
Packages in
Embedded Linux"
Table 1-1. Information Organization in This Guide (continued)
Topics Section for
Windows PE
Section for
Embedded Linux

14 Introduction
What’s New
The new features for this release include:
• Support for new Dell systems
NOTE: For the list of Dell systems supported for this version of DTK, see the
readme.txt file in the root folder, or the Dell Systems Software Support Matrix
on the Dell Systems Management Tools and Documentation DVD or on the
Dell Support website at support.dell.com.
• Support for new CLI commands. See Dell OpenManage Deployment
Toolkit Command Line Interface Reference Guide
for more information.
• Support for solid state drives.
Prerequisites and Requirements
The DTK is a collection of Windows PE- and Linux-based utilities and scripts
that assist in performing pre-operating system tasks and deploying Dell systems.
An advanced knowledge of Windows PE and Linux is required for users who
want to use the DTK utilities to perform pre-operating system configuration
tasks or to run a scripted deployment in the respective environments.
A pre-operating system environment is defined as the environment used to
configure system hardware before a major operating system, such as Windows or
Linux, is installed. The DTK utilities and scripts, for example, are executed in a
Windows PE or embedded Linux environment for hardware configuration.
Because of the open nature of the utilities and scripts and the environment in
which they can be used, it is strongly recommended that DTK users have an
advanced understanding of the Windows PE and Linux environment and scripting
knowledge for the respective environments. DTK users with an advanced
understanding of Windows PE and Linux can take full advantage of the utilities
and exploit their capabilities above and beyond what the sample scripts can provide.
CAUTION: Some of the DTK utilities can destroy data if used incorrectly. To avoid
the potential risk of data loss, take all necessary precautions to protect data so that
mission-critical systems are not disrupted in the unlikely event of a failure. See the
Deployment Toolkit Command Line Interface Reference Guide for complete
information about the capabilities of each DTK utility.

Introduction 15
Supported Operating Systems to Run DTK Utilities
For Windows PE, the DTK utilities support Windows PE version 2005 (created
using 32-bit versions of Microsoft Windows Server 2003 family with Service
Pack 1 [SP1]) and Windows PE 2.0 (created using 32-bit version built on the
Windows Vista kernel).
NOTE: DTK utilities do not support Windows PE created with any 64-bit version of
Microsoft Windows Server 2003.
For embedded Linux, the DTK utilities support Red Hat®Enterprise Linux®
Server (version 4, update 4) 32-bit.
Supported Systems
For the list of Dell systems supported for this version of DTK, see the
readme.txt in the root folder, or the Dell Systems Software Support Matrix on
the Dell Systems Management Tools and Documentation DVD or on the
Dell Support website at support.dell.com.
Supported BIOS Firmware Versions
A minimum BIOS version is recommended on some of the platforms for all
the DTK options to work correctly. In general, it is good practice to use the
latest ("n") version of BIOS firmware or the "n-1" version that is available on
the Dell Support website at support.dell.com.
Installation Prerequisites
Before installing the DTK components for Windows PE, ensure that you have
the following:
• The DTK self-extracting zip file ( DTK3.X-WINPE-XX.exe ), which
contains the utilities, sample scripts, sample configuration files, and
documentation you need to deploy your Dell system
• A Windows workstation that has at least 500 MB of free hard-drive space
Before installing the DTK components for embedded Linux, ensure that you
have the following:
• The DTK ISO image, which contains the utilities, sample scripts, sample
configuration files, and documentation you need to deploy your Dell system
• A Linux workstation that has at least 200 MB of free hard-drive space

16 Introduction
Deployment Prerequisites
Before beginning the deployment process for Windows PE, ensure that you have
all of the following tools, software, and information ready to use or consult:
• Advanced knowledge of Windows
• OEM Preinstallation Kit (OPK) or Windows PE CD and
Windows Server 2003 (with SP1) to build Windows PE 1.0
• Windows Automated Installation Kit (Windows AIK) CD version 936330
or later to customize Windows PE 2.0
• An unzip utility
• Working knowledge to build Windows PE 1.0 and Windows PE 2.0
(See the Microsoft documentation to customize Windows PE 1.0 and
Windows PE 2.0)
• Working knowledge of Microsoft Remote Installation Services (RIS) and
Automated Deployment Services (ADS) (including setting up of RIS and
ADS environments) or any other third party deployment system or tool for
Windows PE 1.0
• Working knowledge of Windows Deployment Services (WDS) or any
other third party deployment system or tool for Windows PE 2.0
• A workstation with the following capabilities:
– A writable CD drive and CD-writing software (optional)
– Network access
• A target system with a CD drive, if performing a local deployment
• A target system with a CD drive and network access, if performing a
network deployment
• All DTK utilities, sample scripts, and sample configuration files
• All other utilities and files necessary to perform the deployment, including all
required Windows PE drivers, operating system drivers, and the Dell utility
partition image file
• DTK documentation:
–
Dell OpenManage Deployment Toolkit Version Command Line
Interface Reference Guide
– Dell OpenManage Deployment Toolkit Version User’s Guide

Introduction 17
•The Dell Systems Management Tools and Documentation DVD
NOTE: You can also obtain the latest drivers from the Dell Support website at
support.dell.com.
• Your operating system software and documentation
• An optimally configured source system with network access
For embedded Linux, ensure that you have all of the following tools, software,
and information ready to use or consult:
• Advanced knowledge of Linux and Linux scripting (Bash), Linux
networking, installing and working with RPM Package Managers (RPMs),
and creating and modifying loop file systems
• Any third party deployment system or tool
• A workstation with the following capabilities:
– A writable CD drive and CD-writing software (optional)
– Network access
• A target system with a CD drive, if performing a local deployment
• A target system with a CD drive and network access, if performing a
network deployment
• All DTK utilities, sample scripts, and sample configuration files
• All other utilities and files necessary to perform the deployment, including
all required Linux drivers, operating system drivers, and the Dell utility
partition file
• DTK documentation:
–
Deployment Toolkit Version Command Line Interface Reference Guide
– Deployment Toolkit Version User’s Guide
•The Dell Systems Management Tools and Documentation DVD
NOTE: You can also obtain the latest drivers from the Dell Support website at
support.dell.com.
• Your operating system software and documentation
• An optimally configured source system with network access

18 Introduction
Deploying Operating Systems
After the system hardware is versioned and configured, an operating system
can be installed using unattended setup files, samples of which are provided
as part of the DTK. While these sample configuration files are operating
system specific, they have been enhanced for Dell systems. See your operating
system documentation for more information about how to modify these
unattended installation files.
For Windows PE, the sample configuration files contain examples to deploy
the following operating systems:
• Windows Server 2003 with SP1 (32-bit)
• Windows Server 2003 with SP2 (32-bit)
• Windows Server 2008 (32-bit)
NOTE: For the latest supported operating systems, see the Windows PE
documentation.
For embedded Linux, the sample configuration files contain examples to
deploy the following operating systems:
• Red Hat Enterprise Linux Server version 4 (32- and 64-bit)
• Red Hat Enterprise Linux Server version 5 (32- and 64-bit)
•SUSE
®
Linux Enterprise Server version 10 (64-bit)
Deployment Methods
Dell systems can be deployed using several different methods. The most
common method is using the Systems Build and Update Utility
on the
Dell Systems Management Tools and Documentation DVD that is shipped
with your system. Currently, this method is used to deploy a single system at
a time with the installation wizard.
The DTK, on the other hand, offers a complete set of utilities and sample
scripts that can be used to automate deployment of large numbers of
Dell systems. This guide is designed to help guide you through some of the
most basic planning considerations, logistical preparations, and deployment
procedures to get you started using the DTK to deploy Dell systems.

Introduction 19
DTK Deployment Overview
Preparing for Deployment
The deployment process can be separated into two main tasks: preparation
and the actual deployment.
To prepare for using the DTK utilities and scripts to deploy to a target system
in the Windows PE environment:
1
Copy or extract the DTK utilities, sample scripts, sample configuration
files, and drivers provided (in the zip file) into the Windows PE image.
2 Organize the DTK utilities, scripts, and configuration files, the operating
system installation files, and the requisite system files and drivers on a
network share or local media.
3 Set up an optimally configured source system by using the Dell Systems
Build and Update Utility to install your operating system; and the Systems
Service and Diagnostics Tools to load drivers. (This source system will be
the master server that will be used to replicate settings onto target servers.)
NOTE: You can also obtain the latest drivers from the Dell Support website at
support.dell.com.
4 Edit the DTK sample script files that read the system configuration files to
set up the system BIOS, BMC, RAID, and RAC and then install an
operating system on a target system.
5 Generate a system BIOS, BMC, RAID, and/or RAC configuration profile
from the optimally configured source system. (This source system will be the
master server that will be used to replicate settings onto target servers.)
You can obtain the system BIOS, BMC, RAID, and/or RAC configuration
files by booting from the DTK Windows PE ISO image and running the
SYSCAP.BAT , RAIDCAP.BAT , and RACCAP.BAT scripts. Then, copy the
generated configuration files to a read/write share onto the workstation.
NOTE: In previous releases, you could use a system profile generated on a
specific Dell system to deploy only that same system model. From DTK version
2.4 and later, you can use a system BIOS configuration profile generated for all
systems belonging to the same generation. For example, syscfg_x8xx.ini for
x8xx systems, syscfg_x9xx.ini for x9xx systems, and so on.
6 Create an operating system answer file that contains unattended operating
system software installation information.

20 Introduction
To prepare for using the DTK utilities and scripts to deploy to a target system
in the embedded Linux environment:
1
Obtain the DTK Linux ISO image, which is a self-contained bootable
ISO image.
2 Use and customize the sample scripts per your requirements.
3 Set up an optimally configured source system by using the Systems Build
and Update Utility on the
Dell Systems Management Tools and
Documentation
DVD to install your operating system. Use the Systems
Service and Diagnostics Tools on the
Dell Systems Management Tools and
Documentation
DVD to load drivers.
NOTE: You can also obtain the latest drivers from the Dell Support website at
support.dell.com.
4 Install an operating system on a target system.
5 Generate a system BIOS, BMC, RAID, and/or RAC configuration profile
from the optimally configured source system. (This source system will be
the master server that will be used to replicate settings onto target servers.)
You can obtain the system BIOS, BMC, RAID, and/or RAC configuration
files by booting from the DTK Linux ISO image and running the
syscap.sh , raidcap.sh , and raccap.sh scripts. Then, copy the generated
configuration files to a read/write share onto the workstation.
NOTE: In previous releases, you could use a system profile generated on a
specific Dell system to deploy only that same system model. From DTK version
2.4 and later, you can use a system BIOS configuration profile generated for all
systems belonging to the same generation. For example, syscfg_x8xx.ini for
x8xx systems, syscfg_x9xx.ini for x9xx systems, and so on.
6 Create an operating system answer file that contains unattended operating
system software installation information.
