Dell DR4000 Restore Manager User manual

Dell DR4000 Systems
Getting Started
With Your System
系统使用入门
Memulai Pengaktifan dengan Sistem Anda
はじめに
시스템 시작 안내서

Dell DR4000 Systems
Getting Started
With Your System
Regulatory Model E13S Series

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use of
your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of data if
instructions are not followed.
WARNING: A WARNING indicates a potential for property damage, personal
injury, or death.
____________________
Information in this publication is subject to change without notice.
© 2011 Dell Inc. All rights reserved.
Reproductionofthesematerialsinanymannerwhatsoever without the written permission of Dell Inc.
is strictly forbidden.
Trademarks used in this text: Dell™ and the DELL logo are trademarks of Dell Inc. Intel
®
and Xeon
®
are registered trademarks or trademarks of Intel Corporation in the United States or other countries.
Othertrademarksandtradenamesmaybeusedinthispublicationtorefertoeithertheentitiesclaiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Regulatory Model E13S Series
2011 - 11 P/N C4521 Rev. A00

Getting Started With Your System 3
Installation and Configuration
WARNING: Before performing the following procedure, review the safety
instructions that came with the system.
Unpacking the System
Unpack your system and identify each item.
Assemble the rails and install the system in the rack following the safety
instructions and the rack installation instructions provided with your system.

4 Getting Started With Your System
Optional – Connecting the Keyboard, Mouse, and Monitor
Connect the keyboard, mouse, and monitor (optional).
The connectors on the back of your system have icons indicating which cable
to plug into each connector. Be sure to tighten the screws (if any) on the
monitor's cable connector.
Connecting the Power Cable(s)
Connect the system’s power cable(s) to the system and, if a monitor is used,
connect the monitor’s power cable to the monitor.

Getting Started With Your System 5
Securing the Power Cable(s)
Bend the system power cable into a loop as shown in the illustration and secure
the cable to the bracket using the provided strap. Plug the other end of the
power cable into a grounded electrical outlet or a separate power source such as
an uninterrupted power supply (UPS) or a power distribution unit (PDU).
Turning On the System
Press the power button on the system and the monitor. The power indicators
should light.

6 Getting Started With Your System
Installing the Optional Bezel
Install the bezel (optional).
Operating System Information
The operating system is preinstalled and configured to support the
preinstalled applications. See the operating system documentation that
shipped with your system for additional information about customizing
the operating system, only if required for your environment.
Other Information You May Need
WARNING: See the safety and regulatory information that shipped with
your system. Warranty information may be included within this document or
as a separate document.
• The rack documentation included with your rack solution describes
how to install your system into a rack.
•The
Administrator’s Guide provides information about what to do on first
boot during initial system setup.

Getting Started With Your System 7
• The Owner’s Manual provides information about system features and
describes how to troubleshoot the system and install or replace system
components. This document is available at
support.dell.com/manuals .
• Any media that ships with your system that provides documentation
and tools for configuring and managing your system, including those
pertaining to the operating system, system management software,
system updates, and system components that you purchased
with your system.
NOTE: Always check for updates on support.dell.com/manuals and read the
updates first because they often supersede information in other documents.
Obtaining Technical Assistance
If you do not understand a procedure in this guide or if the system does
not perform as expected, see your Owner’s Manual. Dell offers comprehensive
hardware training and certification. See dell.com/training for more
information. This service may not be offered in all locations.
NOM Information (Mexico Only)
The following information is provided on the device described in this
document in compliance with the requirements of the official Mexican
standards (NOM):
Importer:
Model number: E13S Series
Supply voltage: 100 V CA to 240 V CA
Frequency: 50/60 Hz
Current consumption: 7.5 A to 4.0 A

8 Getting Started With Your System
Technical Specifications
Processor
Processor type Two Intel Xeon processors E5645 series
Expansion Bus
Bus type PCI Express Generation 2
Riser card expansion slots Slot 1: PCIe x4, half-length, full-height
Slot 2: PCIe x4, full-length, full-height
Slot 3: PCIe x8, half-length, full-height
Slot 4 : PCIe x4, internal slot for integrated
storage card
Memory
Architecture 1333 MHz DDR3 RDIMMs
Memory module sockets Eight 240-pin
Memory module capacities 4 GB
Maximum RAM 32 GB
Drives
Hard drives Twelve 3.5" hot-swappable SAS or nearline-
SAS drives and two cabled 2.5" SAS drives
NOTE: The operating system is installed on the
internal hard drives in a RAID 1 configuration.
Connectors
Back
NIC Two RJ-45 (for integrated 1 GB NICs)
Serial 9-pin, DTE, 16550-compatible
USB Two 4-pin, USB 2.0-compliant
Video 15-pin VGA
iDRAC Enterprise One RJ-45

Getting Started With Your System 9
Front
Video 15-pin VGA
USB One 4-pin, USB 2.0-compliant
Internal
USB Two 4-pin, USB 2.0-compliant
Video
Video type Matrox G200, integrated in BMC
Video memory 8 MB
Power
AC power supply (per power supply)
Wattage 750 W (redundant power supply)
Voltage 100 VAC to 240 VAC, autoranging, 50 Hz to
60 Hz
Heat dissipation 2450 BTU/hr (maximum)
Maximum inrush current Under typical line conditions and over the
entire system ambient operating range,
the inrush current may reach 55 A per
power supply for 10 ms or less
Batteries
System battery CR 2032 3.0-V Lithium coin cell
Physical
Height 8.67 cm (3.42 inch)
Width 44.52 cm (17.53 inch)
Depth 66.46 cm (26.17 inch)
Weight (maximum configuration) 29.0 kg (63.80 lb)
Weight (empty) 15.85 kg (34.87 lb)
Connectors (continued)

10 Getting Started With Your System
Environmental
NOTE: For additional information about environmental measurements for specific
system configurations, see dell.com/environmental_datasheets.
Temperature
Operating 10 °C to 35 °C (50 °F to 95 °F) with a maximum
temperature gradation of 10 °C per hour
NOTE: For altitudes above 2950 feet, the maximum
operating temperature is derated 1 ºF/550 ft.
Storage –40 °C to 65 °C (–40 °F to 149 °F) with a maximum
temperature gradation of 20 °C per hour
Relative humidity
Operating 20% to 80% (noncondensing) with a maximum
humidity gradation of 10% per hour
Storage 5% to 95% (noncondensing)
Maximum vibration
Operating 0.26 G at 5 Hz to 350 Hz for 15 min
Storage 1.54 G at 10 Hz to 250 Hz for 15 min
Maximum shock
Operating One shock pulse in the positive z axis (one pulse on
each side of the system) of 31 G for 2.6 ms in the
operational orientation
Storage Six consecutively executed shock pulses in the
positive and negative x, y, and z axes (one pulse on
each side of the system) of 71 G for up to 2 ms
Altitude
Operating –16 m to 3048 m (–50 ft to 10,000 ft)
NOTE: For altitudes above 2950 feet, the maximum
operating temperature is derated 1 ºF/550 ft.
Storage –16m to 10,600 m (–50 ft to 35,000 ft)
Airborne Contaminant Level
Class G1 as defined by ISA-S71.04-1985

Dell DR4000 系统
系统使用入门
管制型号 E13S 系列

注、小心和警告
注： “注”表示可以帮助您更好地使用计算机的重要信息。
小心： “小心”表示如果不遵循说明，就有可能损坏硬件或导致数据丢失。
警告： “ 告”表示可能会导致财产损失、人身伤害甚至死亡。
____________________
本出版物中的信息如有更改，恕不另行通知。
©2011 Dell Inc. 版权所有，翻印必究。
未经 Dell Inc. 书面许可，严禁以任何形式复制这些材料。
此文本中使用的商标 Dell™和DELL 徽标是 Dell Inc. 的商标。 Intel
®
和Xeon
®
是
Intel Corporation 在美国或其他国家 /地区的注册商标或商标。
本出版物中述及的其它商标和商品名称是指拥有相应商标和商品名称的公司或其产品。
Dell Inc. 对不属于自己的商标和商品名称不拥有任何所有权。
管制型号 E13S 系列
2011 - 11 P/N C4521 修订版 A00

系统使用入门 13
安装和配置
警告： 执行下列步骤之前，请查看系统随附的安全说明。
打开系统包装
打开系统包装并检查各个组件。
遵循系统随附的安全说明和机架安装说明，在机架中组装滑 并安装系
统。

14 系统使用入门
可选 — 连接键盘、鼠标和显示器
连接键盘、鼠标和显示器 （可选）。
系统背面的连接器附有图标，指示要插入每个连接器的电缆。请确保拧紧
显示器电缆连接器上的螺钉 （如果有）。
连接电源电缆
将系统电源电缆连接至系统，如果使用显示器，则将显示器电源电缆连接
至显示器。

系统使用入门 15
固定电源电缆
如图所示，将系统电源电缆弯曲成一个环状，并使用所提供的扣带将其固
定到支架。将电源电缆的另一端插入接地的电源插座或单独的电源，如不
间断电源设备 (UPS) 或配电装置 (PDU)。
开启系统
按下系统和显示器的电源按钮。电源指示灯将会亮起。

16 系统使用入门
安装可选挡板
安装挡板 （可选）。
操作系统信息
操作系统已预安装并被配置为支持已预安装的应用程序。请参阅随附系统
的操作系统说明文件，以获得有关自定义操作系统的更多信息 （仅当您
的环境有此要求时）。
可能需要的其它信息
警告： 请参阅系统附带的安全与管制信息。保修信息可能包括在该说明文
件中，也可能作为单独的说明文件提供。
• 机架解决方案随附的机架说明文件介绍了如何将系统安装到机架中。
• 《管理员 南》提供初始系统设置时首次引导的相关信息。
• 《用户手册》提供了有关系统功能的信息，并说明了如何排除系统故障
以及安装或更换系统组件。该说明文件可从
support.dell.com/manuals
在线获取。
• 系统随附的任何介质，其中提供了用于配置和管理系统的说明文件和
工具，包括与系统预装的操作系统、系统管理软件、系统更新以及系
统组件相关的说明文件和工具。
注： 请经 访问 support.dell.com/manuals 以获得更新，并首先阅读这些
更新，因为这些更新通 会取代其他说明文件中的信息。

系统使用入门 17
获得技术帮助
如果您对本指南中的步骤有疑问，或系统运行无法达到预期效果，请参阅
《用户手册》。 Dell 提供全面的硬件培训和认证。有关详情，请参阅
dell.com/training。此项服务可能并非在所有地区都提供。
NOM 信息 仅限于墨西哥）
本说明文件中述及的符合墨西哥官方标准 (NOM) 要求的设备上均具有以
下信息：
进口商：
型号： E13S 系列
电源电压： 100 V 至240 V 交流
频率： 50/60 Hz
电流消耗： 7.5 A 至4.0 A

18 系统使用入门
技术规格
处理器
处理器类型 双 Intel Xeon 处理器 E5645 系列
扩充总线
总线类型 PCI Express 第2 代
扩充卡扩 槽 插槽 1：PCIe x4，半长，全高
插槽 2：PCIe x4，全长，全高
插槽 3：PCIe x8，半长，全高
插槽 4：PCIe x4，用于集成存储卡的内部插
槽
内存
体系结构 1333 MHz DDR3 RDIMM
内存模块插槽 八个 240 针
内存模块容量 4 GB
最大 RAM 32 GB
驱动器
硬盘驱动器 12 个3.5" 热插拔 SAS 或近线存储 SAS 驱动
器，以及 2 个已布好线的 2.5" SAS 驱动器
注： 操作系统安装在按 RAID 1 配置的内部
硬盘驱动器上。
连接器
背面
NIC
两个 RJ-45 （用于集成的 1 GB NIC）
串行 9 针、 DTE、16550 兼容
USB
两个 4 针、 USB 2.0 兼容
视频 15 针VGA
iDRAC Enterprise
1 个RJ-45
