Dell Force10 S60 Series User manual

Dell Force10
S55 and S60 Systems
Quick Start Guide
Regulatory Model: S55/S60

Dell Force10
S55 and S60 Systems
Quick Start Guide
Regulatory Model: S55/S60

Notes, Cautions, and Warnings
NOTE: A NOTE indicates important information that helps you make better use
of your computer.
CAUTION: A CAUTION indicates potential damage to hardware or loss of
data if instructions are not followed.
WARNING: A WARNING indicates a potential for property damage,
personal injury, or death.
If you purchased a Dell n Series computer, any references in this publication to
Microsoft
Windows operating systems are not applicable.
____________________
Information in this publication is subject to change without notice.
© 2011 Dell Inc. All rights reserved.
Reproduction of these materials in anymanner whatsoever without the written permissionof Dell Inc.
is strictly forbidden.
Trademarks used in this text: Dell™, the DELL logo, Dell Precision™, OptiPlex™, Latitude™,
PowerEdge™, PowerVault™, PowerConnect™, OpenManage™, EqualLogic™, KACE™,
FlexAddress™ and Vostro™ are trademarks of Dell Inc. Intel
®
, Pentium
®
, Xeon
®
, Core™ and
Celeron
®
are registered trademarks of Intel Corporation in the U.S. and other countries. AMD
®
is a
registered trademark and AMD Opteron™, AMD Phenom™, and AMD Sempron™ are trademarks
of Advanced Micro Devices, Inc. Microsoft®, Windows®, Windows Server®, MS-DOS®and
WindowsVista®areeithertrademarksorregisteredtrademarksofMicrosoftCorporationintheUnited
States and/or other countries. Red Hat Enterprise Linux®and Enterprise Linux®are registered
trademarks of Red Hat, Inc. in the United States and/or other countries. Novell®is a registered
trademarkand SUSE ™ is atrademarkof NovellInc. in theUnited Statesandothercountries.Oracle®
is a registered trademark of Oracle Corporation and/or its affiliates. Citrix®, Xen®, XenServer®and
XenMotion®areeitherregisteredtrademarksortrademarksofCitrixSystems,Inc.intheUnitedStates
and/or other countries. VMware®, Virtual SMP®, vMotion®, vCenter®, and vSphere®are registered
trademarks or trademarks of VMWare, Inc. in the United States or other countries.
Othertrademarksandtradenamesmaybeusedinthispublicationtorefertoeithertheentitiesclaiming
the marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and
trade names other than its own.
Regulatory Model: S55/S60
2011 - 9 P/N 045FRK Rev. A00

About this Guide 3
About this Guide
This document is intended as a Quick Start Guide to get new systems up and
running and ready for configuration. For complete installation and configuration
information, refer to the following documents:
Documentation S55 S60
Hardware installation and
power-up instructions Installing the S55 System Installing the S60 System
Software configuration FTOS Configuration Guide
for the S55 System FTOS Configuration Guide for the S60 System
Command line interface FTOS Command Reference
for the S55 System FTOS Command Reference for the S60 System
Latest updates Release Notes for the S55
System Release Notes for the S60 System

4About this Guide

Installing the Hardware 5
1
Installing the Hardware
This guide assumes all site preparation has been performed before installing the
chassis.
Installing the Chassis in a Rack or Cabinet
To install the S55 or S60 systems, Dell Force10 recommends that you complete
the installation procedures in the order presented below.
NOTE: Unless stated otherwise, the installation instructions below apply to both
the S55 and S60 chassis.
Always handle the system and its components with care. Avoid dropping the
switch or its field replaceable units.
CAUTION: Always wear an ESD-preventive wrist or heel ground strap when
handling the chassis and its components. As with all electrical devices of this
type, take all necessary safety precautions to prevent injury when installing
this system. Electrostatic discharge (ESD) damage can occur if components
are mishandled.
Attaching Mounting Brackets
The chassis is shipped with mounting brackets (rack ears) and required screws
for rack or cabinet installation. The brackets are enclosed in a package with the
chassis.
NOTE: Dell Force10 recommends attaching the brackets at the PSU side. This
provides the greatest weight support for the chassis in the rack or cabinet.
.
Step Task
1Take the brackets and screws out of their packaging.

6Installing the Hardware
2Attach the brackets to the sides of the chassis at the PSU end, using four
screws for each bracket. Attach the bracket so that the “ear” faces the
PSU and the outside of the chassis.
S55
S60
Step Task
Power Supply/Fan Module
View from Chassis Rear
View from Chassis Front
Screws
Connect to
Rack/Cabinet
(ears)
Connect to
Rack/Cabinet
(ears)
Screws
Power Supply/Fan Module
Power Supply
Power Supply
Screws
Connect to
rack/cabinet
(ear)
Connect to
rack/cabinet
(ear)
View of chassis front
View from chassis rear

Installing the Hardware 7
Install Chassis into Rack or Cabinet
Ensure that there is adequate clearance surrounding the rack or within the
cabinet to permit access and airflow.
Attach a Ground Cable to the System
The system is shipped with necessary 10-32 screw(s) for attaching a ground
cable to the chassis. The cable itself is not included. Dell Force10 recommends a
6AWG one-hole (for the S55) or two-hole (for the S60) lug, #10 hole size, 63"
spacing (not included in shipping) to properly ground the chassis. The lug must
be a UL recognized, crimp-type lug.
NOTE: The rack installation ears are not suitable for grounding.
CAUTION: Grounding conductors must be made of copper. Do not use
aluminum conductors.
Step Task
1Dell Force10 recommends that one person hold the chassis in place
while a second person attaches the brackets to the posts.
2Attach the bracket "ears" to the rack or cabinet posts, using two screws
for each bracket. Ensure the screws are tightened firmly.
S55
S60
PSU0
PSU1 Rack/Cabinet
Post
Rack Mounting
ears
Rack/Cabinet
Post
Rack Mounting
"ears"
PSU0
PSU1

8Installing the Hardware
NOTE: Coat the one-hole lug with an anti-oxidant compound prior to crimping.
Bring any un-plated mating surfaces to a shiny finish, and coat with an anti-oxidant
prior to mating. Plated mating surfaces must be clean and free from contamination.
The S60 is shipped with 2 10-32 screws for attaching a ground cable to the
chassis. The cable itself is not included. Dell Force10 recommends a 6AWG
two-hole lug, #10 hole size, 63" spacing (not included in shipping) to properly
ground the chassis. The two-hole lug must be a UL recognized, crimp-type lug.
Step Task
1Take the 10-32 screw(s) from the package.
2Cut cable to desired length. Cable length must facilitate the proper
operation of fault interrupt circuits. Dell Force10 recommends using of
the shortest cable route allowable.
3Attach the lug to the chassis as shown, using the supplied 10-32
screw(s) with captive internal tooth lock washer. Each screw should be
torqued to 20 in-lbs.
S55
S60
4Attach the other end of the ground cable to a suitable ground point. The
rack installation ears are not a suitable grounding point.
1
2

Installing the Hardware 9
Install the SFP and SFP+ Optics
The chassis are shipped as follows:
• The S55 has 4 SFP optical ports in the PSU side of the chassis in addition to
the optional SFP+ optical modules.
• The S60 has 4 SFP optical ports in the front of the chassis in addition to the
optional SFP+ optical modules.
CAUTION: Electrostatic discharge (ESD) damage can occur if components
are mishandled. Always wear an ESD-preventive wrist or heel ground strap
when handling the chassis and its components.
WARNING: Follow all warning labels when working with optical fibers.
Always wear eye protection when working with optical fibers. Never look
directly into the end of a terminated or unterminated fiber or connector as it
may cause eye damage.
NOTE: For details on Dell Force10 supported optics, refer to
http://www.force10networks.com/products/specifications.asp
Power Up Sequence
Supply Power and Power Up the System
Dell Force10 recommends re-inspecting your system prior to powering up.
Verify that:
• The equipment is properly secured to the rack and properly grounded.
• The equipment rack is properly mounted and grounded.
• The ambient temperature around the unit (which may be higher than the
room temperature) is within the limits specified for the unit.
• There is sufficient airflow around the unit.
Step Task
1Position the SFP or SFP+ so it is in the correct position. (The optic has a
key that prevents it from being inserted incorrectly.).
2Insert the optic into the port until it gently snaps into place.

10 Installing the Hardware
• The input circuits are correctly sized for the loads and that sufficient over-
current protection devices are used.
• All protective covers are in place.
• Blank panels are installed if optional modules are not installed.
• Blank panels are installed if redundant power supplies are not installed on the
S55.
NOTE: A US AC power cable is included in the shipping container for powering
up an AC power supply. All other power cables must be ordered separately.
CAUTION: Electrostatic discharge (ESD) damage can occur if components
are mishandled. Always wear an ESD-preventive wrist or heel ground strap
when handling the system and its components.
When the chassis powers up, the fans immediately come on at high speed. The
fan speed slows as the system boots up.
The PWR LED blinks until the boot-up sequence is complete. When the boot up
is complete the PWD LED is steadily lit.
The Stack ID LED displays a digit to show the position of the unit in a stacking
chain. For a single chassis, a 0 displays.
AC Power
Connect the plug to each AC receptacle, making sure that the power cord is
secure.
As soon as the cable is connected between the system and the power source, the
chassis is powered-up; there is no on/off switch.
DC Power
To connect the chassis to the DC power source, follow the steps below:
Step Task S55 Task S60
1Connect the plug to each DC
receptacle, making sure that the
power cord is secure.
Remove the small plastic cover from
the DC connectors.

Installing the Hardware 11
Power Supplies
The S55 and S60 chassis are designed to support two hot-swappable power
supplies with integrated fans that provide the cooling for the chassis. There are
two types of power supplies (AC or DC) and there are two air-flow directions
(Normal and Reversed). Two power supplies are required for full redundancy,
but each system will operate with a single power supply.
• In the S55, a blank panel must be attached as redundant power supplies are
not installed.
• In the S60, one of the power supply bays can be equipped with a fan only
module.
WARNING: To prevent electrical shock, make sure the system is grounded
properly. If you do not ground your equipment correctly, excessive emissions
may result. Use a qualified electrician to ensure that the power cables meet
your local electrical requirements.
Fans
The chassis come from the factory with the following:
• The S55 comes with 1 power supply and 2 fan modules installed in the
chassis.
• The S60 comes with 1 power supply and 1 fan module installed in the
chassis.
Both the fan modules and the integrated fan-power supply are hot-swappable if
a second (redundant) power supply is installed and running. With redundant
power supplies, traffic will not be interrupted if a fan module is removed.
2As soon as the cable is connected
between the S55 and the power
source, the chassis is powered-up;
there is no on/off switch.
Attach the connectors to the both DC
power units at the rear of the S60,
making sure that the connection is
secure.
3Replace the plastic cover over the DC
connectors.
4Turn the power switch on.
Step Task S55 Task S60

12 Installing the Hardware
NOTE: Both slots must have operating fan units to run the system. If a module is
not installed in each slot (either as part of the PSU or as an independent fan
module), the system will shut down in 1 minute.
The S55 and the S60 both support two airflow direction options. Only a single
direction can be used in a chassis; do not mix fan flow types in a chassis. The
system will shutdown in 1 minute, if the airflow directions are mismatched.
• Normal is airflow from I/O panel to power supply
• Reversed is airflow from power supply to I/O panel
There are environmental factors that could decrease the amount of time required
between air filter replacements. Check these environmental factors regularly.
Any unusual environmental circumstance at the site that causes an increase in
temperature and/or particulate matter in the air might affect performance (for
example, new equipment installation).
Specifications
Chassis Physical Design
Parameter S55 Specifications S60 Specifications
Height 1.73 inches (4.4 cm) 1.7 inches (4.3 cm)
Width 17.32 inches (44.0 cm) 17.32 inches (44.0 cm)
Depth 18.74 inches (47.6cm) 16.73 inches (42.5cm)
Chassis weight with
factory-installed
components
14.41 pounds (approx.) (6.54
kg) 14.39 pounds (approx.) (6.54 kg)
Rack clearance required Front: 5-inches (12.7 cm)
Rear: 5-inches (12.7 cm) Front: 5-inches (12.7 cm) Rear: 5-inches (12.7 cm)
Thermal dissipation 461 BTU/hr (135W) 597 BTU/hr
Power Consumption 115 Watts (nominal)
135 Watts (maximum)
175 Watts (nominal)
225 Watts (maximum)

Installing the Hardware 13
Environmental Parameters
AC Power Requirements
DC Power Requirements
Power Supplies
The S55 and the S60 are designed to support two hot-swappable power supplies
with integrated fans that provide the cooling for the chassis.
Parameter S55 Specifications S60 Specifications
Temperature 32° to 104°F (0° to 40°C)
-40° to 158°F (-40° to 70°C) 32° to 122°F (0° to 50°C) -40° to 158°F (-40° to 70°C)
non-operating
Maximum altitude No performance degradation
to 10,000 feet (3,048 meters) No performance degradation to 10,000 feet (3,048 meters)
Relative humidity 10 to 85% non-condensing 10 to 85% non-condensing
5 to 95% non-condensing
(non-operating)
Shock MIL-STD-810 MIL-STD-810
Vibration Bellcore GR-63
Parameter S55 Specifications S60 Specifications
Nominal Input Voltage 100 to 240 VAC, 47-63 Hz 100 to 240 VAC, 50/60 Hz
Maximum AC Power
Supply Input Current 5 A 2 A at 100/120 VAC
Maximum System
Power Input 135 W 225W
Parameter S55 Specifications S60 Specifications
Nominal Input Voltage -43 to -72 VDC at startup
-36 to -72 VDC during normal
operation
–40 to – 60 VDC
Maximum Power
Supply Input Current 10 A 3.6 A at -48 VDC
Maximum System
Power Input 135 W 225W

14 Installing the Hardware
WARNING: To prevent electrical shock, make sure the systems are grounded
properly. If you do not ground your equipment correctly, excessive emissions
may result. Use a qualified electrician to ensure that the power cables meet
your local electrical requirements.
WARNING: Electrostatic discharge (ESD) damage can occur if components
are mishandled. Always wear an ESD-preventive wrist or heel ground strap
when handling the systems and their components.
CAUTION: Remove the power cable from the modules prior to
removing the module itself. Power must not be connected prior to
insertion in the chassis.
WARNING: Prevent exposure and contact with hazardous voltages.
Do not attempt to operate this system with the safety cover removed.
CAUTION: The DC power supply comes with a 6-8inch cord with a
snap-in plug that attaches to the DC power supply and screw
terminals that attach to the main power. Dell Force10 recommends
using a longer cable, to ensure sufficient room.
CAUTION: The power supply is marked + 48V - . Connect the + (plus
sign) to the red cable on the 6-8 inch cord; the - (minus sign) connects
to the black cable. BE SURE TO connect the RED to RETURN and
connect the BLACK to -48V.
NOTE: For a NEBS compliant installation, the AC power connections
must use a surge protection device (SPD) to protect the AC power supplies
from damage to excessive power line surges.
NOTE: To comply with the GR-1089 Lightning Criteria for Equipment
Interfacing with AC Power Ports, an external surge protection device
(SPD) is intended to be used at the AC input of the router.
NOTE: The DC power return conductor must be isolated from the chassis
or frame when connections to the power supply are made.

Installing the Hardware 15
Install a DC Power Supply
The power supply modules should slide into the slots smoothly. Do not force a
module into a slot. This may damage the power supply or the chassis.
S55 S60
Step Task
1Take the power supply unit out of the shipping box.
2Remove the small plastic cover over the DC connectors. Do not
throw the cover away; you will replace it when installation is
complete.
3Using the grab handle, slide the unit in to the power supply bay.
4Tighten the securing screw at the top of the unit.
5Attach power cables.
6Replace the small plastic cover over the DC connectors.
7Turn on power if installing a DC unit.
Grab Handle
PSU0
PSU1
Fan Module
Optional Module
Cable
Connector
Grab Handle
Securing Screw
DC Power Connector
Fans and Filters
PSU0
PSU1
Power Switch

16 Installing the Hardware

Installing the Software 17
2
Installing the Software
Navigating CLI Modes
The FTOS prompt changes to indicate the CLI mode. You must move linearly
through the command modes, with the exception of the end command which
takes you directly to EXEC Privilege mode; the exit command moves you up
one command mode level.
Console Access
NOTE: You must have a password configured on a virtual terminal line before you
can Telnet into the system. Therefore, you must use a console connection when
connecting to the system for the first time.
The S55/S60 has 2 management ports available for system access: a serial
console port and a USB-B port. The USB-B ports acts exactly as the console
port.
By default, the S55/S60 sends system messages to the serial console port.
However, only one console connection can be active at a time. When both the
serial console port and the USB-B port are connected, the system defaults to the
USB-B port. The console connection is considered inactive if the USB-B port is
also connected.
You can switch between console connections by physically connecting or
disconnecting the cables. A system message is displayed on the serial console
prior to switching to the USB-B console. When the USB-B cable is detached,
the system returns to the serial console default.

18 Installing the Software
Serial Console
The RS-232 console port is labeled on the chassis. It is in the upper right-hand
side, as you face the rear of the chassis.
Accessing the RJ-45 console port with a DB-9 adapter
You can connect to the console using an RJ-45 to RJ-45 rollover cable and an
RJ-45 to DB-9 female DTE adapter to a terminal server (for example, PC).
Table 2-1 lists the pin assignments.
S55 S60
Step Task
1Install an RJ-45 copper cable into the console port.Use a rollover (crossover)
cable to connect the S55 or S60 console port to a terminal server.
2Connect the other end of the cable to the DTE terminal server.
3Terminal settings on the console port cannot be changed in the software and are
set as follows:
9600 baud rate
No parity
8 data bits
1 stop bit
No flow control
Table 2-1. Pin Assignments Between the Console and a DTE Terminal Server
S55/S60
Console Port RJ-45 to RJ-45 Rollover Cable RJ-45 to DB-9 Adapter Terminal Server Device
Signal RJ-45 pinout RJ-45 Pinout DB-9 Pin Signal
RTS 1 8 8 CTS
RJ-45
Console Port
Console
Port
