Dell OptiPlex Powered USB HUB Installation and operation manual

www.dell.com | support.dell.com
DellTM Powered USB Hub
Product Information Guide

www.dell.com | support.dell.com
DellTM Powered USB Hub
Product Information Guide
Model TF661
PLEASE READ THIS DOCUMENT CAREFULLY!
IT CONTAINS THE TERMS AND CONDITIONS OF SALE THAT
GOVERN YOUR PURCHASE, UNLESS YOU HAVE A SEPARATE
AGREEMENT WITH DELL. THIS DOCUMENT CONTAINS VERY
IMPORTANT INFORMATION ABOUT YOUR RIGHTS AND
OBLIGATIONS, AS WELL AS LIMITATIONS AND EXLCUSIONS
THAT MAY APPL
Y TO YOU. THIS DOCUMENT ALSO CONTAINS
A DISPUTE RESOLUTION CLAUSE.

Notes, Notices, and Cautions
NOTE: A NOTE indicates important information that helps you make better use of your
Powered USB Hub
NOTICE: A NOTICE indicates either potential damage to hardware or loss of data and tells
you how to avoid the problem.
CAUTION: A CAUTION indicates a potential for property damage, personal injury,
or death
Information in this document is subject to change without notice.
© 2006 Dell Inc. All rights reserved.
Reproduction in any manner whatsoever without the written permission of Dell Inc. is strictly forbidden.
Trademarks used in this text: Dell, the Dell logo, Dell OptiPlex, are trademarks of Dell Inc.
Other trademarks and trade names may be used in this document to refer to either the entities claiming the
marks and names or their products. Dell Inc. disclaims any proprietary interest in trademarks and trade names
other than its own.
February 2006 TF662 (A00)

Contents | 5
Contents
Safety 7
Overview 8
Unpacking 8
Component Identification 9
Installation 10
Remove Integrator cover and slide tray out 10
Install retainers 11
Install Powered USB Hub 11
Connect AC power cord to hub and power outlet 12
Connect AC pass-through power cords to hub 12
Connect USB Host cable 13
Connect peripherals 14
Turn hub power switch on 15
Allow Windows to install hub driver 15
Allow Windows in install peripheral driver(s) 16
Slide Integrator tray in 16
Replace Integrator cover 17
Specifications 18
U.S Terms and Conditions of Sale 20
Limited Warranties and Return Policy 23
Limited Warrant for Dell-Branded Hardware Products (U.S. Only) 23
Total Satisfaction Return Policy (U.S. Only) 26

6| Contents
Export Regulations 28
Dell Software License Agreement 28
Regulatory Notices 30
WEEE Statement 31

Product Information Guide | 7
Safety
CAUTION: Use of procedures other than those specified in this documentation
may result in exposure to shock, electrical hazards, and/or mechanical hazards.
•Read and understand all instructions before using the DellTM Powered USB Hub.
•To reduce the risk of electric shock, do not immerse the DellTM Powered USB Hub in water or
any other liquid.
•Never disassemble or touch the inside of the DellTM Powered USB Hub. This action could result in
electrical shock.
•Service or repair work should be done by a qualified service person. Incorrect reassembly can
cause electric shock.
•To keep from damaging your DellTM Powered USB Hub, avoid exposing it to moisture and
extreme temperatures.
•To help protect your product from sudden, transient increases and decreases in electrical power,
use a surge suppressor, line conditioner, or uninterruptible power supply (UPS).
•Do not use your Powered USB Hub in a wet environment, for example, near a bath tub, sink, or
swimming pool or in a wet basement.
•Ensure that nothing rests on your product’s cables and that the cables are not located where
they can be stepped on or tripped over.
•Use only the power cable provided with this product or the manufacturer’s authorized
replacement power cable.
•Connect the power cable to an electrical outlet that is near the product and easily accessible.
•To completely turn off the product, the power cable must be removed from the power source.
•Refer service or repairs, other than those described in the user documentation, to a professional
service person.
•Do not set up this product or make any electrical or cabling connections, such as the power
cable or telephone, during an electrical storm.
•The Dell™ Powered USB Hub is for use with UL Listed products only (USA and Canada).

Product Information Guide | 8
www.dell.com | support.dell.com
Overview
The DellTM Powered USB Hub is designed to connect up to six Powered USB peripherals. While
designed for POS applications, the DellTM Powered USB Hub is ideal for any circumstance requiring
Powered USB peripherals.
Unpacking
Unpack your DellTM Powered USB Hub. Confirm contents of box:
•DellTM Powered USB Hub
•Product Information Guide (this manual)
•Placemat
•USB Host Cable
•AC Power Cable
•AC Pass-Through Cables (2)

Product Information Guide | 9
Component Identification
Inspect your DellTM Powered USB Hub and become familiar with its external components.

Product Information Guide | 10
www.dell.com | support.dell.com
Installation
Note: Installation instructions assume that the DellTM Powered USB Hub is installed into an
Integrator. If an Integrator is not used, place the Powered USB Hub in a secure location and
follow the below instructions; skipping the steps that mention the Integrator.
Remove Integrator cover and slide tray out
Remove the front cover from the Integrator1by gently sliding it up (a). Once the cover is removed,
depress the retaining button and slide the Integrator’s PC tray out (b).
1Consult the Integrator’s Product Information Guide for additional details
