PowerConnect M6220/M6348/8024/8024F/M8024/M8024-k/
7024/7048/7024P/7048P/7024F/7048R/7048R-RA Release Notes
System Firmware Version 4.1.0.6 Page 1
Introduction
This document provides specific information for the Dell PowerConnect 7024/7048/7024P/7048P/7024F/7048R/7048R-
RA/8024/8024F/M6220/M6348/M8024/M8024-k switches firmware version 4.1.0.6.
It is recommended that this release note be thoroughly reviewed prior to installing or upgrading of this product.
Global Support
For information regarding the latest available firmware, release note revisions, or additional assistance, please visit
support.dell.com.
Firmware Specifications
Firmware Version
Firmware Image Name
Version No.
Release Date
PCM6220v4.1.0.6.stk
PC7000_M6348v4.1.0.6.stk
PC8024v4.1.0.6.stk
PCM8024v4.1.0.6.stk
PCM8024kv4.1.0.6.stk
4.1.0.6
4.1.0.6
4.1.0.6
4.1.0.6
4.1.0.6
March 2011
March 2011
March 2011
March 2011
March 2011
Version Numbering Convention
Version number
Description
PowerConnect
Series
4
1
0
6
Four part version number




Denotes the build number.




Denotes an ad hoc release of the product software.




Denotes a scheduled maintenance release of the product software.




Denotes a major version number.
Firmware Version Details
Boot PROM Name
Version No.
Release Date
Not Applicable
4.1.0.6
March 2011
Firmware Upgrade
NOTE: Switches migrating from pre-4.x.x.x versions of code require a
boot code update. Connect to the serial port and follow the procedure
below to update the boot code:
1. Download the new firmware version to the switch
2. After the download completes, activate the new image using the boot system image command
3. Reload the switch using the reload command
4. After the switch boots, select 2 –Start Boot Menu
5. Select 7 –Update Boot Code from the menu
6. After the boot code updates, select 9 –Reset the system.

2 System Firmware Version 4.1.0.6
NOTE: By default, switches in a stack configuration will upgrade or
downgrade stack members with the firmware version installed on the
master switch.
Supported Firmware Functionality
For more details regarding the functionality listed below, please refer to the Dell PowerConnect Series CLI Reference Guide and
the Dell PowerConnect Series Configuration Guide.
Firmware Downgrade
Downgrading from 4.1.0.6 to a previous release is supported on the PowerConnect series switches. It is not recommended to
downgrade the boot code under any circumstances.
Hardware Supported
Dell PowerConnect M6220 Ethernet Switch
Dell PowerConnect M6348 Ethernet Switch
Dell PowerConnect 7024 Ethernet Switch
Dell PowerConnect 7048 Ethernet Switch
Dell PowerConnect 7024P Ethernet Switch
Dell PowerConnect 7048P Ethernet Switch
Dell PowerConnect 7024F Ethernet Switch
Dell PowerConnect 7048R Ethernet Switch
Dell PowerConnect 7048R-RA Ethernet Switch
Dell PowerConnect 8024 Ethernet Switch
Dell PowerConnect 8024F Ethernet Switch
Dell PowerConnect M8024 Ethernet Switch
Dell PowerConnect M8024-k Ethernet Switch

PowerConnect M6220/M6348/8024/8024F/M8024/M8024-k/
7024/7048/7024P/7048P/7024F/7048R/7048R-RA Release Notes
System Firmware Version 4.1.0.6 Page 3
Support Matrix
Since not all functionality is supported on all switches, the following matrix identifies the major differences among the
PowerConnect switch models. A check mark indicates support for the feature. All other features listed in the release notes are
supported on all switches.
Feature/Switch
Priority
Flow
Control
PoE+
iSCSI
Optimization
USB
grEEEn
Ethernet
Hot Swap
Cards
WRED
Dell PowerConnect
M6220 Ethernet
Switch
Dell PowerConnect
M6348 Ethernet
Switch


Dell PowerConnect
7024 Ethernet Switch





Dell PowerConnect
7048 Ethernet Switch





Dell PowerConnect
7024P Ethernet
Switch






Dell PowerConnect
7048P Ethernet
Switch






Dell PowerConnect
7024F Ethernet
Switch





Dell PowerConnect
7048R Ethernet
Switch





Dell PowerConnect
7048R-RA Ethernet
Switch





Dell PowerConnect
8024 Ethernet Switch


Dell PowerConnect
8024F Ethernet
Switch


Dell PowerConnect
M8024 Ethernet
Switch

Dell PowerConnect
M8024-k Ethernet
Switch



4 System Firmware Version 4.1.0.6
Added Functionality in this Release
This section contains a brief introduction to features added in this release that are new for at least one switch listed in the
Hardware Supported section above.
IPv4-Only Mode Optimization
PowerConnect switches allocate the maximum sizes for routing tables (and others, as applicable) for both IPv4 and
IPv6. Switch Performance Optimization allows the operator to optimize the allocation of switch silicon tables for
either IPv4 only or mixed IPv4/IPv6 operation. The template specified limits are enforced by routing components when
routes are being learned. When IPv4 only mode is selected, the following capabilities are disabled:
DHCPv6 relay
DHCPv6 server
IPv6 routing/forwarding
OSPFv3
IPv6 Neighbor Discovery
Configured v6-over-v4 tunnels
Automatic (6to4) tunnels
IPv6 Multicast
A reboot is required when changing to or from IPv4 mode.
Auto-Install
USB based auto-install is an easy way to quickly bring up a switch with a known configuration. Network based auto-
install is useful in rolling out a configuration or firmware update to a group of switches or in maintaining a central
repository of switch configurations and firmware where the switches always obtain their firmware and configuration
from a central server.
The following clarifications are helpful in understanding the processing steps in auto-install:
Always power on the switch that is desired to be the stack master first
Auto-install never proceeds if a startup-config file is present on the (master) switch
USB auto-install is attempted first. Network auto-install only proceeds if USB auto-install fails.
If there are multiple .setup files present on the USB flash device, the powerconnect.setup file is selected
If a valid .setup file is not found on the USB flash device, the single .text file is used
If multiple .text files are present, the powerconnect.text file is used.
Network based auto-install utilizes information obtained from a DHCP server. Refer to the documentation for a
discussion of the DHCP options used by Auto-Install.
When auto-install downloads a firmware image to switch memory, it compares the version to the current switch image.
If different, the image in memory is copied to the switch backup image and activation of the image is attempted. If
activation succeeds, the switch is rebooted and auto-install then attempts configuration file download.
Auto-install configuration files are executed as a script.
For more details on Auto-Install, refer to the User’s Guide.

PowerConnect M6220/M6348/8024/8024F/M8024/M8024-k/
7024/7048/7024P/7048P/7024F/7048R/7048R-RA Release Notes
System Firmware Version 4.1.0.6 Page 5
Link Local Protocol Filtering
Link Local Protocol Filtering blocks Cisco link local protocols from being flooded in the network. By default,
PowerConnect switches process and respond to Cisco CDP packets. However, in networks where this capability is not
desirable or other Cisco proprietary packets are flooded over the network, the administrator can disable flooding of
Cisco link local protocols. The following table identifies the matching criteria for filtering Cisco proprietary packets:
Rule Type
Rule Purpose
Blocked Destination
MAC Address
Ether Type
Blockcdp
Used to block CDP
PDU’s
N/A
0x2000
Blockvtp
Used to block VTP
PDU;s
N/A
0x2003
Blockdtp
Used to block DTP
PDU’s
N/A
0x2004
Blockudld
Used to block UDLD
PDU’s
N/A
0x0111
Blockpagp
Used to block PAGP
PDU’s
N/A
0x0104
Blocksstp
Used to block SSTP
PDU’s
N/A
0x010b
Blockall
Used to block all defined
Protocol Filtering PDU’s
01:00.0C:CC:CC:C0
N/A
DHCP Server
The PowerConnect Series switches support a simple DHCP server capability for domains that do not wish to deploy a
redundant DHCP address assignment solution or who have need of a temporary solution while (re)deploying their
DHCP server solution.
In configuring DHCP scopes, be aware that the DHCP pool address and netmask must exactly match a VLAN address
and netmask assignment for DHCP addresses to be served over that VLAN.
Only a single manual IP address can be assigned to a pool. The address must have a netmask of 32.
GMRP
The GARP Multicast Registration Protocol provides a mechanism that allows networking devices to dynamically
register (and de-register) Group membership information with the MAC networking devices attached to the same
segment, and for that information to be disseminated across all networking devices in the bridged LAN that support
Extended Filtering Services. The PowerConnect Series switches support GMRP as specified in IEEE 802.1Q 1998.
WRED
Weighted random early drop is supported on certain PowerConnect series switches. Refer to the table at the beginning
of this section for further information. CoS queue configuration involves the following hardware port queue
configuration parameters:
scheduler type: strict vs. weighted
minimum guaranteed bandwidth
maximum allowed bandwidth (i.e. shaping)
queue management type: tail drop vs. WRED
tail drop parameters: threshold
WRED parameters: minimum threshold, maximum threshold, drop probability

6 System Firmware Version 4.1.0.6
Tail drop and WRED parameters are specified individually for each supported drop precedence level.
In addition, the following are specified on a per-interface basis:
queue management type: tail drop vs. WRED (only if per-queue configuration is not supported)
WRED decay exponent
Switch administrators should remember to configure ingress ports as trusted or un-trusted. By default ingress ports trust
dot1p values.
Stack Firmware Synchronization
Stack firmware synchronization updates all stack members to the active firmware version on the master switch. Stack
firmware synchronization is enabled by default. Stack firmware downgrade is enabled by default.
Multicast VLAN Registration
Multicast VLAN Registration provides a method of coalescing multicast traffic requested by users on multiple VLANs
onto a single VLAN when carried over the network.
MVR does not require that either source or receiver ports utilize VLAN tagging.
Network planners are reminded that multicast groups in the 224.0.0.x range are reserved for multicast control plane
traffic. Network planners should select multicast groups in another range for normal multicast traffic, e.g. 239.0.1.x
iSCSI Optimization
iSCSI Optimization automatically configures ports for use with the iSCSI protocol and tracks iSCSI sessions on the
PowerConnect 7000 and 8000 Series switches as well as the PCM6348. Dell EqualLogic arrays are automatically
detected and configuration of Dell EqualLogic connected ports is performed automatically.
Administrators are advised that the configuration performed by enabling iSCSI optimization is not automatically
reversed on disabling the feature. The administrator will need to manually remove the configuration settings when
migrating Dell EqualLogic servers or iSCSI initiator ports to other ports or switches.
Detection of Dell EqualLogic arrays is keyed on receipt of the mandatory System Description TLV in the LLDP
packet. Disabling LLDP will effectively disable Dell EqualLogic array detection.
Dell EqualLogic arrays are required to be upgraded to firmware 5.0.2 or later in order to use the iSCSI Optimization
feature.
LLDP
Administrators should ensure that LLDP-MED is enabled in order to operate EEE. Disabling LLDP or LLDP-MED
will effectively disable EEE, IEEE 802.3at PoE+ high power negotiation and Dell EqualLogic array detection in the
iSCSI Optimization feature.
Connectivity Fault Management
Connectivity Fault Management performs Metro Ethernet maintenance functions. Dell PowerConnect CFM supports
the following functions defined in IEEE 802.1ag Draft 8.1:
Path discovery (link trace messages)
Fault detection (continuity check message)
Fault verification and isolation (loopback and link trace messages)
Fault notification (alarm indication signal or SNMP trap).

PowerConnect M6220/M6348/8024/8024F/M8024/M8024-k/
7024/7048/7024P/7048P/7024F/7048R/7048R-RA Release Notes
System Firmware Version 4.1.0.6 Page 7
Management IP Address Conflict Detection
Management IP address conflict detection actively looks for duplicate IP address assignment and logs conflicts. Only
the last identified IPv4 address conflict is retained for display by a show command. Administrators may examine the
in- memory logs or the output from a SYSLOG server to identify the historical IP address conflicts. If console logging
is enabled for traps, a message will appear on the console indicating that an address conflict has occurred.
Email Alerting
Email alerting allows administrators to be notified regarding system events. Multiple email addresses can be
configured. The system will attempt to resolve mail servers specified with a DNS FQDN immediately and, if
successful, store the mail-server as an IP address. If a new IP address is subsequently assigned to the mail server, the
operator will need to re-assign the email address on the switch.
Only the Mail User Agent functionality of RFC 4409 is implemented. The PowerConnect switch does not implement
SMTP server functionality.
802.1x Monitor Mode
Monitor mode is a special debug mode that assists network administrators in configuring new authentication servers.
Users attempting to authenticate using the authentication server are always granted access when monitor mode is
enabled. All interactions with the supplicant and the authentication server are logged.
Administrators are cautioned against enabling monitor mode in a deployed network where 802.1x users may gain
access to sensitive network resources.
Time Controlled ACLs
Time controlled ACLs allow administrators to apply ACLs based on the time of day. Both periodic and absolute time
periods may be configured.
Administrators are cautioned that invalid (overlapping) periodic entries within a time range will cause the time range to
not be applied. Administrators are advised to test their periodic entries and validate that they become active as expected
before deploying the time ranges in a production network. Administrators can check if a time range is active by using
the show time-range command.
It is recommended to enable ACL logging to ensure notice of ACL activation and de-activation.
SNTP over IPv6
SNTP operates over IPv4 and IPv6 and may be configured using IPv4 or IPv6 addresses or DNS.
Strong Passwords
The strong passwords feature allows administrators to specify that switch administrator passwords meet certain
characteristics considered to enhance network security.
Administrators are advised that the minimum character classes configuration must be enabled (value equal to 1 or
greater) along with enabling the strong password feature before the other minimum character class configurations are
enforced. These character class configuration are:
Minimum number of uppercase letters.
Minimum number of lowercase letters.
Minimum number of numeric characters.
Minimum number of special characters
The password strength restrictions do not apply to users configured for the internal authentication server.

8 System Firmware Version 4.1.0.6
Switch Auditing
Switch auditing enhances network security by logging sensitive administrative actions. Switch auditing logs the
following actions:
Successful login
Unsuccessful attempt to login
Logout out from the switch
Timed out logout from the switch
Download file to the switch
Upload file from the switch
Remove file from the flash
File changes on the flash
Clear configuration
Add or remove user
Change user access level
Use of a SYSLOG server for monitoring network events is highly recommended.
Authentication
The PowerConnect switches support authentication via a number of methods. The methods are specified in named lists.
Lists may be assigned to the enable and login access methods. The supported authentication methods are:
Enable
Line
RADIUS
TACACS
IAS
Local
None
Methods are attempted in the order specified in the authentication list. If the authentication method rejects
authentication, the user login is rejected. If an authentication method fails, e.g. unable to contact the authentication
server, the next method in the list is attempted. Only the RADIUS and TACACS methods can fail and therefore should
be specified first in an authentication list. The other methods will never fail and therefore should be specified after
RADIUS or TACACS in a list.
The 802.1x authentication list cannot be named and only supports the RADIUS, IAS, or none authentication methods.
802.1x authentication supports a single authentication method, not a list of methods.

PowerConnect M6220/M6348/8024/8024F/M8024/M8024-k/
7024/7048/7024P/7048P/7024F/7048R/7048R-RA Release Notes
System Firmware Version 4.1.0.6 Page 9
Internal Authentication Server
The PowerConnect Series switches support 802.1x authentication of network users from an internal authentication
database. IAS users are given access to network resources. IAS users are not given management access to the switch.
IAS users, once authenticated, can only pass frames across the switch.
The IAS database can be downloaded to the switch using the “ias-users” target in the copy command. The ias-users file
takes the form of a configuration script, as follows:
configure
aaa ias-user username client-1
password my-password1
exit
aaa ias-user username client-2
password aa5c6c251fe374d5e306c62496c3bcf6 encrypted
exit
aaa ias-user username 1f3ccb1157
password 1f3ccb1157
exit
IAS users may also be configured via the web interface.
DNS Client
The PowerConnect Series switches support name resolution via an embedded DNS client. When a DNS name is
specified, it is attempted to be resolved against the configured DNS servers immediately. The PowerConnect switches
will store the resolved IP address. If the IP address of the host resolved via DNS changes, the administrator will need to
update the configured IP address, either via DNS or manually.
If the switch is configured to obtain an address via DHCP, DNS server information received from the DHCP server is
used to populate the DNS client configuration.
Port Profiles (CLI Macros)
The PowerConnect series switches provides a convenient way to save and share common configurations through the
use of CLI macros. A CLI macro is a set of commands having a unique name. When a CLI macro is applied, the CLI
commands contained within the macro are executed and added to the Running Configuration File. When the macro is
applied to an interface, the existing interface configurations are not lost; the new commands are added to the interface
and are saved in the running configuration file.
A CLI macro may have keywords (variables) which are replaced by values provided when the macro is applied (up to 3
keywords per macro). Macros can be applied to specific interfaces, a range of interfaces, or the global configuration.
Administrators may add their own macros or utilize the built-in macros.
Administrators are cautioned to ensure that a sufficient number of exit commands are present in user defined macros to
return the prompt to the level at which it was entered when the macro is invoked.
The software includes 6 built-in macros:
profile-global - the global configuration used to enable RSTP and loop guard.
profile-desktop - the interface configuration for increased network security and reliability when connecting a
desktop device, such as a PC, to a switch port.
profile-phone - the interface configuration used when connecting a desktop device such as a PC with an IP
phone to a switch port.
profile-switch - the interface configuration used when connecting an access switch and a distribution switch
or between access switches.
profile-router - the interface configuration used when connecting the switch and a WAN router.
profile-wireless- the interface configuration used when connecting the switch and a wireless access point.
Built-in macros may not be deleted or altered by the operator.

10 System Firmware Version 4.1.0.6
Changed Functionality in this Release
This section contains commentary on significant differences from previous releases of firmware on PowerConnect
switches, e.g. the PCM6348/PCM6220/PCM8024/PC8024/PC8024F switches. Dell PowerConnect series switches
closely conform to networking industry standard operational capabilities and administrative interfaces. The differences
below should be studied carefully as attempting to configure or operate the PowerConnect switches in the same manner
as for previous releases of firmware for PowerConnect PCM6348/PCM6220/PCM8024/PC8024/PC8024F switches
may lead to unexpected results.
New Web Interface
The Web interface has been enhanced with new navigation feature for ease of use.
CLI Syntax Changes
The CLI has changed significantly to be compatible with the PowerConnect switch standard CLI. Configurations for
previous releases may not be compatible with this release and may need to be updated.
Unit/Slot/Port Naming Conventions
In-band interfaces are named based on stack unit, slot, and port. Units range from 1-12. Slots range from 0-2. Ports
range from 1-48. Rear panel slots are number 1 and 2. Front panel ports belong to slot 0.
The service port is addressed using the out-of-band keyword.
Management VLAN Deprecated
The PowerConnect series switches do not have an in-band management VLAN by default. Administrators can
designate a VLAN for support of in-band management operations.
All Interfaces Default to VLAN 1
By default, all in-band interfaces are members of VLAN 1. The operator may exclude ports from VLAN 1 via
configuration.
Routing Supported on VLANs Only
Routing is only supported on VLAN interfaces. Routing may not be configured on a physical interface.
Assigning IP Address Enables Routing
Assigning an IP address to a VLAN enables routing on the VLAN.
Service/Out-of-band Ethernet Port Defaults to DHCP Addressing
By default, the service/out-of-band Ethernet port will attempt to obtain an address via DHCP.
NOTE: It is recommended that administrators attach the service/out-of-
band Ethernet port to a physically separate network for out-of-band
network management. The service port does not offer routing or
switching capabilities nor does it offer enhanced protection from DOS
attacks. Configure a VLAN on one or more in-band interfaces for
management of PowerConnect switches over the operational network.

PowerConnect M6220/M6348/8024/8024F/M8024/M8024-k/
7024/7048/7024P/7048P/7024F/7048R/7048R-RA Release Notes
System Firmware Version 4.1.0.6 Page 11
LACP Ports Inactive Until Attached
Ports in a LAG configured to use LACP (dynamic LAG) remain inactive (discard received traffic) until they become
attached to the LAG. LACP ports that are attached to a LAG will enter the discarding state if they become detached
from the LAG for any reason.
Port level configuration for a port that is configured in a dynamic LAG is disregarded. Remove the port from the LAG
to restore use of the port level configuration.
Ports in a static LAG begin forwarding on link up. Ports in a static LAG disregard port level configuration. Configure
static LAG functions on the static LAG interface.
NOTE: It is recommended that administrators disable portfast and auto-
portfast on physical interfaces configured in a LAG. Portfast and auto-
portfast can interfere with an interface entering into LAG mode on a
reboot and possibly enable a packet storm.
Spanning Tree Changes
Administrators may assign more than 1024 VLANs to MSTP instances. Only VLANs that are configured on the switch
will forward traffic.
The PowerConnect switches implements the 802.1Q-2005 standard which builds on 802.1D-2004. 802.1D-2004
incorporates the the 802.1t, 802.1w and 802.1s revisions. Port path costs are calculated based on the interface speed as
shown below and are dynamically recalculated on interface activation and link speed changes.
External Port Path Cost values (Port Path Cost in 17.14 of 802.1D-2004) are applicable in STP, RSTP, and MST modes
(Ref. Table 17-3 802.1D-2004). Use the spanning-tree cost command in interface mode to set the external port path
cost.
Link Speed Default Value
10 Gb/s 2000
1 Gb/s 20000
100 Mb/s 200000
10 Mb/s 2000000
1 Mb/s 20000000
Internal Port Path Cost values are specific to MST mode only (Ref. Table 13-3 802.1Q-2005). Use the spanning-tree
mst <instance> cost command in interface mode to set the internal port path cost.
Link Speed Default Value
10 Gb/s 2000
1 Gb/s 20000
100 Mb/s 200000
10 Mb/s 2000000
1 Mb/s 20000000

12 System Firmware Version 4.1.0.6
User Configurable CLI Banners
Administrators may configure banners for the following: MOTD, login, and exec. The banners may consist of multiple
lines of text. Each new line will consume an extra two characters (CR/LF) that count against the maximum length
banner that can be configured.
Captive Portal
Captive portal has been extended to support user logout and localization.
802.1Q
The following changes have been made to the operation of VLANs.
VLAN Membership:
By default, all VLANs are members of a trunk port. VLANs created after a trunk port is created are added to all trunk
ports. VLANs deleted by the administrator are removed from all trunk ports. The operator may configure a trunk port
to explicitly disallow certain VLANs.
Native VLAN Configuration on Trunk Ports:
It is now possible to configure the native VLAN on a port in trunk mode. Trunk mode ports will accept untagged
frames but will always transmit tagged frames. It is also possible to configure a trunk port to drop untagged frames by
filtering on the native VLAN, e.g. by using the switchport trunk allowed vlan remove command.
Switchport Mode Configuration Preserved:
When switching between switchport modes (access, trunk, and general), the switchport configuration applicable to the
selected mode is maintained. This means that when switching from one mode to another and back, the port will have
the same configuration as it had in the original mode. Only the configuration applicable to the selected mode is enabled
on the port.
VRRP
The following enhancements have been made to the operation of VRRP to increase usability and robustness of
operation in the network:
Preemption Delay:
Per the VRRP RFC 3768, when preemption is enabled, the backup router discards advertisements until the master
down-timer fires. When the preemption delay timer is set to a non-zero value and the backup switch receives a PDU
with a lower priority from the master, then backup switch waits for the preemption delay value before advertising itself
as the master.
Timer Advertisement Learning:
In VRRP, all participating routers should be configured with coherent advertisement timer interval values. The
operator can now enable timer learning which causes a backup router to learn the master advertisement interval and
change its master down interval accordingly.
Ping-able VRRP Interfaces:
RFC 3768 specifies that a router may only accept IP packets sent to the virtual router’s IP address if the router is the
address owner (master). In practice, this restriction makes it more difficult to troubleshoot network connectivity
problems.

PowerConnect M6220/M6348/8024/8024F/M8024/M8024-k/
7024/7048/7024P/7048P/7024F/7048R/7048R-RA Release Notes
System Firmware Version 4.1.0.6 Page 13
This capability adds support for responding to pings by the VRRP master, but does not allow the VRRP Master to
accept other types of packets. A configuration option controls whether the router responds to Echo Requests sent to a
VRRP IP address. When enabled, the VRRP master responds to both fragmented and un-fragmented ICMP Echo
Request packets. The VRRP master responds to Echo Requests sent to the virtual router’s primary address or any of its
secondary addresses. When the VRRP master responds with an Echo Reply, the source IPv4 address is the VRRP
address and source MAC address is the virtual router’s MAC address. The VRRP master does not respond to pings sent
from the master.
Members of the virtual router who are in backup state discard ping packets destined to VRRP addresses, just as they
discard any Ethernet frame sent to a VRRP MAC address.
Fragmentation and Reassembly:
Fragmentation and reassembly of VRRP packets is not supported.
DHCP Relay
The following enhancements have been made to the operation of DHCP Relay to bring the implementation into
conformance with RFC 4649:
DHCPv6 Relay Circuit Id/Remote Id Types
RFC 4649 specifies the IANA assignment of the Relay Circuit Id sub-option and Remote Id option. The
implementation has been changed so that the administrator can no longer assign a numerical value to these TLVs as the
IANA assigned number is now used. The administrator can still enable or disable the insertion of these TLVs in
messages sent to the DHCP server.
Relay Information Option:
The operator has the ability to enable DHCP Relay Information Options both globally and on a physical interface. The
interface configuration overrides the global configuration for the selected interface.
Relay Information Option Check:
When DHCP Option-82 insertion is enabled for a relay agent, the server should echo received Option 82 unaltered back
toward the client. The relay agent is required to strip Option 82 information before relaying the BOOTPREPLY to the
DHCP client. When enabled, the Relay Information Option Check will cause the BOOTPREPLY packet to be dropped
if invalid sub-options are echoed by the DHCP server.
L2 Address Table
The administrator can disable MAC address table aging.
The administrator can configure static forwarding of a MAC address on a specific VLAN.
NOTE: By default, multicast frames are flooded by the switch. Utilize the
mac address-table multicast filtering command to disable flooding of
multicast frames.

14 System Firmware Version 4.1.0.6
LLDP Enhancements
Multiple Neighbor Support:
Multiple neighbors are supported on a single LLDP interface. The number of recognized neighbors is limited to two per
port or 834 LLDP neighbors on a fully stacked set of switches. There is no restriction on the number of neighbors
connected to an LLDP port. If more LLDP neighbors are present than are supported, then only the last two neighbors
that communicate with the local LLDP interface are recognized and any additional neighbors are ignored.
EEE Support:
Support is added to process/communicate the EEE TLV to partner devices. The EEE TLV is an 802.3 organizationally
specific TLV used to report on the EEE Data Link Layer capabilities.
LLDP-MED Support:
LLDP-MED uses LLDP’s organizationally specific TLV extensions and defines new TLVs which make it easier to
deploy VoIP in a wired or wireless LAN/MAN environment. The LLDP implementation supports the following TLVs:
Mandatory 802.1AB TLVs
Chassis ID TLV (subtype shall default to MAC Address)
Port ID TLV (subtype shall default to MAC address
TTL TLV
MAC/PHY configuration/status TLV
End of LLDP PDU
Optional 802.1AB TLV
Systems Capabilities TLV
Power via MDI TLV
NOT recommended for transmission in order to conserve LLDPDU space.
Mandatory LLDP-MED TLVs
LLDP-MED Capabilities TLV
This TLV allows the network connectivity device to definitively determine whether particular connected
devices do support LLDP-MED and to discover which specific LLDP-MED TLVs the particular end point
devices are capable of supporting as well as what specific device class they belong to.
Network Policy TLV
This TLV allows the device to advertise its VLAN and associated Layer 2 priority and Layer 3 DSCP
attributes which apply for a set of specific protocol applications on this port.
Location Identification TLV
This TLV provides the advertisement of location identifier information Class II endpoint Devices. This is
expected to be related to wire map or similar network topology data, such that the configuration of the
network Connectivity device is able to uniquely identify the physical location of the connected MED
endpoint.
Extended Power-via-MDI TLV
This TLV allows for advanced power management between endpoints and network connectivity devices. It
transmits fine grained power requirement details. This TLV provides significantly more value than the
802.1AB Power via MDI TLV.
EEE TLV
The EEE TLV is used to exchange information about the EEE Data Link Layer capabilities. Devices that
require longer wake up times prior to being able to accept data on their receive paths may use the Data Link
Layer capabilities to negotiate for extended system wake up times from the transmitting link partner. This
mechanism may allow for more or less aggressive energy saving modes.

PowerConnect M6220/M6348/8024/8024F/M8024/M8024-k/
7024/7048/7024P/7048P/7024F/7048R/7048R-RA Release Notes
System Firmware Version 4.1.0.6 Page 15
Dynamic VLAN Assignment
Dynamic VLAN assignment is intended to support the connection of hosts to a router with enhanced levels of service,
typically either security or QoS. This release supports dynamic VLAN assignment as assigned from the RADIUS
server as part of port authentication. The following additional checks are performed in support of dynamic VLAN
assignment:
Before assigning the port to RADIUS assigned VLAN, dot1x checks if the given VLAN is in the VLAN database or
not. If the assigned VLAN is not in the VLAN database and dynamic VLAN assignment is enabled, a VLAN is created
on the port over which the client is authenticated. Each time a client is de-authenticated on an interface with a particular
VLAN, a check verifies if there any other interface which is a VLAN member. If there is no interface as a member, the
VLAN is deleted. This behavior is same for MAC based authentication as well.
Usability Enhancements
In the output of the show running-config command, the slot and member configuration is commented with the
switch/slot type in human comprehensible form.
When in interface config mode, CLI users can navigate to a different interface by entering the appropriate interface
command without leaving interface config mode.
CLI users can log out of the switch using the exit command (exit is an alias for quit).
The CLI Reference Guide is updated with acceptable character sets and maximum lengths for string parameters to
commands.
Management ACLs permit specification of service any as shorthand for enabling all services access for in-band
management.
VLANs may be administratively assigned to MSTIs in excess of the switch physical limits and without regard to
whether the VLAN is actually configured. Frames are only forwarded on VLANs assigned to interfaces.
Administrators can re-enter SYSLOG server config mode for a particular SYSLOG server entry without requiring the
deletion and re-creation of the entry.
Administrators can configure the web timeout by navigating to: System -> Management Security -> Telnet Server ->
Telnet Session Timeout.
User configured banners (login, exec, MOTD) appear in the running config.
By default, auto-install supports image downgrade for network installs, specific version USB installs (using a .setup
file), and stack firmware synchronization.
A comprehensible message and recommendation is issued when configuring multiple services (telnet, http,…) to listen
on the same TCP port.
The terminal length command allows user control over terminal paging.
Simple Mode
The PowerConnect M8024-k is the only modular switch that defaults to the simple mode of operation. Simple mode
contains a restricted set of commands suitable for control of a port aggregation device that can be deployed in a
network without requiring updates to the network by a network administrator. Users needing switch capabilities which
require the network administrator to modify the network configuration can exit simple mode using the no mode simple
command.
AAA Authentication
In prior releases, more than one method could be specified for dot1x authentication even though only the first method
was attempted. The CLI and Web now only accept a single method for dot1x authentication.

16 System Firmware Version 4.1.0.6
Issues Resolved
The following issues from previous releases have been corrected in this release. The issues listed here may have been discovered
on any of the switches listed on the title page.
Summary
User Impact
Workaround
SSH crash - memPartAlloc: block too big
Reduced switch functionality.
Memory allocation issue is corrected and
checked for memory leaks
PC M8024 switch reset out-of-band
address to none when switchports were
changed
Inability to access switch via OOB
port.
The out-of-band address is maintained
over switchport changes.
Web page shows IP address as '0.0.0.0'
for '1.1.1.1' routing interface.
Operator confusion over switch
operations
The web page output has been corrected.
Read-Only Web page is populating all
configured IP and IPv6 ACL names when
we select the ACL Name.
Operator confusion regarding web
page operations.
The web page has been corrected to only
populate the selected entry.
FAN LED graphic on web page needs to
glow in RED when FANs are not
operational (stopped).
Inability to determine switch
status.
Web page has been corrected
Incorrect command is being displayed in
running-config, when disabled the boot
host dhcp
Operator confusion regarding web
page operations.
The running config now shows the correct
configuration
DUT crashes while configuring max
dynamic vlans.
Network outage possible.
The PowerConnect does not crash when
using maximum dynamic VLANs
Manager of the stack is changing when
trying to learn maximum number of
VLANs using GVRP.
Operator confusion regarding
switch operations.
The stack manager does not change during
learning with GVRP
Switch prompts to save config data when
no changes have been made
Operator confusion regarding
switch operation.
The switch no longer prompts to save
config data if no changes have been made
Crash while RFC3918 Group Capacity
test is running
Network outage possible.
The PowerConnect switch runs the
RFC3918 test without crashing
'no' version of 'key' command is not
implemented
Operator frustration with switch
management.
The no key command is implemented to
return the key configuration to the default.
Password is not accepting quotation ( " )
character
Operator confusion regarding
switch configuration.
Passwords can be enclosed in quotes
(contain embedded blanks). A password
may not contain a quote. The accepted
character set and length is documented in
the CLI reference manual.
Incorrect warning message displayed
while executing the command "boot
system <unit> image1"
Operator confusion regarding
switch operation.
The error message has been corrected to
indicate that the unit selected for reboot
does not exist.
IPV6 command displays wrong output
Operator confusion regarding
switch operation.
The IPv6 output has been corrected to
remove the duplicate display lines in show
ipv6 help.
LLDP-MED log messages showing 5 sec
difference in entry age out information
Operator confusion regarding
switch operation.
The LLDP timer has been updated to
account for processing skew.
Dhcpv6 web issues
Operator confusion regarding
switch configuration.
The acceptable character sets are
documented in the CLI Reference guide.
LLDP MED application should not allow
configuration of location and inventory
transmit TLV's as underlying application
not present
Operator confusion regarding
switch configuration.
Location and inventory TLVs cannot be
enabled for transmission in LLDP MED.

PowerConnect M6220/M6348/8024/8024F/M8024/M8024-k/
7024/7048/7024P/7048P/7024F/7048R/7048R-RA Release Notes
System Firmware Version 4.1.0.6 Page 17
Summary
User Impact
Workaround
SysUpTime is not being shown correctly
during an SNMP walk (Poll interval 1sec)
Operator confusion regarding
switch operation.
The correct variable is used to write
SysUpTime
Log messages need to be corrected on ip
dhcp snooping rate limit scenario.
Operator confusion regarding
switch configuration. Inability to
diagnose network issues.
Interface representations in log messages
use unit-slot-port format.
The show ip vlan command output is not
proper after more-quit prompt is
encountered, i.e. after around 16 routing
interfaces
Operator confusion regarding
switch configuration.
The paging has been corrected.
Invalid error port number displayed on
log message when vlan is changed to
forbidden mode from access mode
Operator confusion regarding
switch configuration.
The error message is no longer issued.
The banner motd XXXXX does not
appear in show running-config
Operator confusion regarding
switch configuration.
All banner configuration appear in the
running-config
Web page mac-vlan table too slow to
load.
Operator frustration with switch
management.
For certain browsers, paging has been
implemented to speed up load times.
Confused between ip default gateway
and ip default route (update manual with
how to set a default route).
Operator confusion regarding
switch configuration.
The ip default route command is
deprecated. Use the ip default route
command to set a default route.
Auto Install show boot retry count line
needs to be left aligned by one space.
None.
The retry count alignment is corrected
Cannot Access Optical Transceiver
Diagnostics Page if Multiple Submits
done prior to initial refresh completing
Operator frustration with switch
management.
This is a browser dependant issue (IE 6)
that is not seen in later versions. The web
session recovers after doing a refresh.
Error messages for non-existent stack
members non-informative
Operator confusion regarding
switch configuration.
The user can pre-configure stack units. If
the stack unit does not exist for a switch
configuration operation, an error message
indicating same is issued.
Traffic is forwarding when IPv6
forwarding is disabled
Incorrect operational state in
network.
The ipv6 forwarding command is deprecated.
To disable traffic forwarding, use the no ipv6
unicast-routing in place of no ipv6
forwarding command.
A LAG member comes UP if configured
individually as no shutdown, even though
the port-channel's state is down
Incorrect operational state in
network.
LAG members are placed in the blocking
state for dynamic LAGs and only come up
when the LAG link comes up.
Re-authenticate Now check box is not
highlighted when edit check box is
selected
Inability to configure switch.
The Re-authenticate Now check box is
highlighted when the edit check box is
selected
Block command is not seen in show
running config through web and cli
User confusion over switch
operations.
The block command is a temporary
administrative assignment and is not
maintained persistently in the saved or
running configs.
FDB entries are getting aged out before
default age-out time, when both FDB and
MFDB tables are full.
User confusion over switch
operations.
On the PCM6220, the MFDB and FDB
tables are a shared resource. The user is
continually sending new MFDB entries,
which causes old FDB entries to be
removed to make a place for the new
MFDB entries.
DHCP packets forwarding is not proper
to/from the trusted and un-trusted ports
Incorrect operational state in
network.
The frame flooding routing in DHCP
snooping now takes into account trust
status.
Configuring all ports in all VLANs takes
a long time
Operator frustration with switch
management.
VLAN configuration has been optimized.

18 System Firmware Version 4.1.0.6
Summary
User Impact
Workaround
Max number of OSPF neighbors not
supported
User confusion over switch
operations.
The maximum number of neighbors is
supported.
Cable fault distance not getting displayed
in WEB in case of cable with one or more
pairs cut or short.
User confusion over switch
operations.
The fault distance is displayed in the web
page.
Ports representation need to be changed
in debug messages
User confusion over switch
operations. Inability to diagnose
network issues.
Ports are now displayed in C/S/P standard
format
No error message for illegal characters in
various command parameters
User confusion over switch
configuration.
The accepted character set and length is
documented in the CLI reference manual.
The ARP entry is not seen in the ARP
table when an ARP reply is sent to DUT.
User confusion over switch
operations. Inability to diagnose
network issues.
ARP entries are stored properly
Mapping Table configuration is not being
displayed on Read-Only mode user web
page.
User confusion over switch
configuration.
The mapping table is displayed for a read-
only user.
ACL is getting deleted when trying to
create max+1 rule.
User confusion over switch
operations. Possible security
issues.
Corrected error checking logic.
LLDP-Med TLV information not
registered for jumbo frame sizes greater
than 8000
User confusion over switch
operations.
Jumbo LLDP frames are now processed
properly
VLAN binding entries are not being
displayed on Read-Only mode user web
page.
User confusion over switch
operations.
VLAN binding entries are available to
read only users
Unable to execute the command dot1x
timeout tx-period 1
User confusion over switch
operations.
This command is accepted with a timeout
period of 1 second. Corrected range check
on input.
In switching> network security >dot1x
authentication web page in read-only user
mode, the Re-Authenticate Now check
box can be checked
User confusion over switch
operations. Possible security issue.
Read-only properties are set for the check
box
System Device information web page
LED information not in sync with front
panel LED information.
No user impact expected.
This issue was regarding various stylistic
aspects of the system device web page.
The system device web page conforms to
the requirements as it exists and does
necessarily match the CLI with regarding
to capitalization or naming conventions
DHCP snooping static binding thru
DHCP request is denied as this is a
expected behavior.
User confusion over switch
operations.
Removed the log message indicating that a
bound DHCP client with an existing
binding sent a DISCOVER. Added a
counter for this condition to the DHCP
debug statistics.
Mode of transfer is displaying
“unknown,” while downloading the code
from ftp
User confusion over switch
operations.
ftp transfer mode is displayed
Allow disabling and enabling of terminal
paging
User frustration over switch
configuration.
The terminal length command is now
implemented.
Web does not allow to configure image
descriptor to its max length i.e. 255
characters.
User confusion over switch
operations.
Images descriptors up to 255 characters
are allowed
