DeLonghi ECZ351.GY User manual

COFFEE MAKER

13
1. FUNDAMENTAL SAFETY WARNINGS
• The appliance is not intended for use by persons (including children) with reduced phys-
ical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
• Children should be supervised to ensure that they do not play with the appliance.
• Designated use: this appliance is designed and made to prepare beverages based on
coee, milk and hot water. Use drinking water only in the tank. Never use the accesso-
ries to make beverages other than those described in these instructions. Any other use
is considered improper and thus dangerous. The manufacturer is not liable for damage
deriving from improper use of the appliance.
• The surface of the heating element remains hot after use and the outside of the appli-
ance may retain the heat for several minutes depending on use.
• Clean all the components thoroughly, taking particular care with parts in contact with
the milk.
• Cleaning and user maintenance shall not be made by children without supervision.
• Never clean by immersing the appliance in water.
• IMPORTANT: to prevent damage to the appliance, do not clean with alkaline detergents;
use a soft cloth and, where applicable, neutral detergent.
• This is an household appliance only. It is not intended to be used in: sta kitchen areas in
shops, oces and other working environments; farm houses; by clients in hotels, motels
and other residential type environments; bed and breakfast type environments.
• If the plug or power cord is damaged, it must be replaced by customer services only to
avoid all risk.
• Appliances with removable cord: avoid splashes of water on the power cord connector or
socket at the back of the appliance.
• IMPORTANT: Models with glass surfaces: do not use the appliance if the surface is
cracked.
• The coee maker must not be placed inside a cabinet or kitchen unit during use
FOR EUROPEAN MARKETS ONLY:
• This appliance can be used by children aged from 8 years and above if they have been
given supervision or instruction concerning use of the appliance in a safe way and
understand the hazards involved. Cleaning and user maintenance shall not be made
by children unless they are above 8 years old and supervised. Keep the appliance and
power cord away from children under 8 years of age.

14
• The appliance can be used by persons with reduced physical, sensory or mental capa-
bilities or lack of experience and knowledge if they are supervised or have been given
instruction concerning use of the appliance in a safe way and if they understand the
hazards involved.
• Children shall not play with the appliance.
• Always unplug the appliance when left unattended and before assembly, taking apart
or cleaning.
Surfaces marked with this symbol become hot during use (the symbol is present in
certain models only).
This is an electrical appliance and may cause electric shock.
You should therefore follow these safety warnings:
• Never touch the appliance with damp hands or feet.
• Never touch the plug with damp hands.
• Make sure the socket used is freely accessible at all times,
enabling the appliance to be unplugged when necessary.
• Unplug directly from the plug only. Never pull the cord as
you could damage it.
• To disconnect the appliance completely you must unplug it
from the mains socket.
• If the appliance is faulty, do not attempt to repair. Turn it
o, unplug from the mains socket and contact Customer
Services.
• Before cleaning the appliance, turn it o, unplug from the
mains socket and allow to cool.
Important!
Keep all packaging (plastic bags, polystyrene foam) away from
children.
CHOKING HAZARD. The appliance might contain small parts.
Some of those small parts might be required to get disassem-
bled during cleaning and maintenance operations. Handle with
care and keep small parts out of reach of children.
Danger of burns!
This appliance produces hot water and steam may form while
it is in operation.
During operation (automatic rinsing, hot beverage
delivery, steam delivery, cleaning), avoid contact with
splashes of hot water or steam.
When the appliance is in operation, the cup shelf could become
very hot.
2. GENERAL INFORMATION
2.1 Instruction for Use
Read all the Instruction for Use carefully before using the ap-
pliance. Failure to follow this Instruction for Use may result in
burns or damage to the appliance.
The manufacturer is not liable for damage deriving from failure
to respect this Instruction for Use.
Please note:
These safety warnings are valid for all De’Longhi coee
machines.
Keep this leaet together with the instructions accom-
panying the appliance.
If the appliance is passed to other persons, they must also be
provided with this Instruction for Use.
3. BEFORE USE
3.1 Checking the appliance
After removing the packaging, make sure the product is com-
plete and undamaged and that all accessories are present. Do
not use the appliance if it is visibly damaged. Contact De’Longhi
Customer Services.
3.2 Installing the appliance
When you install the appliance, you should respect the follow-
ing safety warnings:
• The appliance gives o heat. After positioning the appli-
ance on the worktop, leave a space of at least 3 cm be-
tween the surfaces of the appliance and the side and rear
walls and at least 15 cm above the coee maker.
• Water penetrating the appliance could cause damage. Do
not place the appliance near taps or sinks.
• The appliance could be damaged if the water it contains
freezes. Do not install the appliance in a room where the
temperature could drop below freezing point.

15
• Arrange the power cord in such a way that it cannot be
damaged by sharp edges or contact with hot surfaces (e.g.
electric hot plates).
3.3 ìConnecting the appliance
Check that the mains power supply voltage corresponds to that
indicated on the rating plate on the bottom of the appliance.
Connect the appliance to an eciently earthed and correctly
installed socket with a minimum current rating of 10A only.
If the power socket does not match the plug on the appliance,
have the socket replaced with a suitable type by a qualied
professional.
3.4 Setting up the appliance
The rst time you use the machine, the water circuit is empty
and the appliance could be very noisy. The noise becomes less
as the circuit lls.
3.5 Cleaning and maintenance of materials in
contact with food
• The rst time you use the appliance, or if it is not used
for more than 3 or 4 days, rinse all removable accessories
which may come into contact with water or milk with hot
water.
• If the appliance is not used for more than 3 or 4 days, be-
fore making the rst beverage, rinse the water circuit as
described in this Instruction for Use.
• You should carry out automatic cleaning and guided main-
tenance scrupulously when proposed by the appliance
through the display or the lights described in the manual.
3.6 Making cappuccinos and milk-based coees
• The appliance has been tested for use with cow’s milk
and the following products of plant origin: soya, rice and
almond. No other type of milk or product of plant origin
may be used.
• To clean the system, following use with any type of milk,
please follow the standard procedures described in the
instruction manual
• The cleaning methods provided by the manufacturer and
described in the instructions do not guarantee the com-
plete removal of allergens.
• In the case of conrmed or suspected allergies and intoler-
ances, make sure that your machine has not been previous-
ly used with any milk or product of plant origin containing
the allergens you are allergic or the substances you are
intolerant to.
4. DISPOSING OF THE APPLIANCE
The appliance must not be disposed of with house-
hold waste, but taken to an authorised waste separa-
tion and recycling centre.
Readtheseparatesafety instructions beforeusingtheappliance.
5. DESCRIPTION
5.1 Description of the appliance
(page 1 - A )
A1. Steam/hot water dial
A2. Boiler outlet
A3. Water tank
A4. Cup tray
A5. Cappuccino maker
A6. Cappuccino maker nozzle
A7. Spout
A8. Power cord
A9. Cup tray
A10. Drip tray
5.2 Description control panel
(page 1 - B )
B1. Button ON/OFF
B2. Coee/hot water delivery button
B3. Steam button
B4. Power light I
B5. Temperature OK for coee/hot water light
B6. Temperature OK for steam light
5.3 Description of the accessories
(page 1 - C )
C1. Filter holder
C2. 1 coee froth lter
C3. 2 coee froth lter
C4. ESE pod froth lter
C5. Measure/presser
C6. Descaler (*not included, can be purchased from authorised
Customer Services)
6. FILLING THE WATER TANK
1. Open the lid of the appliance (g. 1), then extract the tank
by pulling upwards (g. 2);
2. Fill the tank with fresh clean water, taking care not to ex-
ceed the MAX level indicated (g. 3). Put the tank back in
the appliance, pressing lightly to open the valves located
on the bottom of the tank.
3. More simply, the tank can also be lled without removing
it, pouring the water directly from a jug.
Important: never operate the appliance without water in the tank or without the
tank.
7. SETTING UP THE APPLIANCE
1. Turn the appliance on by pressing the button (B1)
(g. 4): the power light I(B4) comes on ;

16
2. Insert the required coee lter in the lter holder (C1) (g.
5);
3. Attach the lter holder to the machine without lling it
with ground coee (g. 6);
4. Place a 0.5 litre container under the boiler outlet and another 0.5
litre container under the cappuccino maker (g. 7);
5. Wait for the OK light (B5) to come on (g. 8), then immedi-
ately press the button (g. 9) and deliver about half
the tank from the lter holder;
6. Turn the steam dial anti-clockwise (g. 10) and deliver
all the water remaining in the tank from the cappuccino
maker;
7. Close the steam dial and press the button again;
8. Empty the two containers and put back under the boiler
outlet and cappuccino maker, and repeat points 5, 6 and 7.
Now the appliance is ready for use.
7.1 Auto-o
If the appliance is not used for a certain period of time (depend-
ing on the model), it switches o automatically (and the indica-
tor light goes out).
7.2 Tips for a hotter coee
To make espresso coee at the right temperature, the coee
maker should be preheated as follows:
1. Turn the appliance on by pressing the button (the I
light (B4) comes on) (g. 4) and attach the lter holder to
the appliance without adding pre-ground coee (g. 6);
2. Place a cup under the lter holder. Use the same cup as will
be used to prepare the coee in order to preheat it.
3. Wait until the OK light comes on (g. 8) and immediately
afterwards press the button (g. 9). Continue de-
livering water until the OK light goes o, then interrupt
delivery by pressing the same button again;
4. Empty the cup, wait until the OK light comes on again (B5)
and then repeat the same operation.
(It is normal for a small and harmless pu of steam to be given
o when removing the lter holder).
8. HOW TO MAKE ESPRESSO COFFEE USING PRE
GROUND COFFEE
1. Place the ground coee lter (C2) or (C3) in the lter hold-
er (C1). Use the lter to make one coee or the
lter to make two coees;
2. To make just one coee, place one level measure of pre-
ground coee (about 7 g) in the lter. (g. 11). To make
two coees, place two loosely lled measures (about 6+6 g)
of pre-ground coee in the lter. Fill the lter a little at a time
to prevent the pre-ground coee from overowing.
Important: for correct operation, before lling with pre-ground coee, make sure
there are no coee residues left in the lter from the last time you made coee.
3. Distribute the ground coee evenly and press gently
down with the presser (g. 12). Correct pressing of the
pre-ground coee is essential to obtain a good espresso.
If pressing is excessive, coee delivery will be slow and the
froth will be dark. If pressing is too light, coee delivery
will be too rapid and the froth will be skimpy and light
coloured.
4. Remove any excess coee from the rim of the lter holder
and attach to the appliance. Turn the handle rmly to-
wards the right (g. 6) to avoid water leaking out;
5. Place the cup or cups under the lter holder spouts (g.
13). You are recommended to warm the cups before mak-
ing coee by rinsing them with a little hot water.
6. Make sure the OK light is on (g. 8) (if o, wait until it
comes on), then press the button. Once the re-
quired amount of coee has been delivered, interrupt
delivery by pressing the same button again;
7. To remove the lter holder, turn the handle from right to
left;
Danger of burns! To avoid splashes, never remove the lter holder while the appli-
ance is delivering coee.
8. To eliminate the used coee grounds, hold the lter holder
upside down and tap (g. 14).
9. To turn the appliance o, press the button.
9. HOW TO PREPARE ESPRESSO COFFEE USING
PODS
1. Preheat the appliance as described in section “7.2 TIPS
FOR A HOTTER COFFEE”, making sure the lter holder is
attached.This obtains a hotter coee.
Please note: use pods conforming to the ESE standard, indicated on the pack
by the following symbol. The ESE standard is a system accepted by leading pod pro-
ducers and enables espresso coee to be prepared simply and cleanly.
2. Place the pod coee lter (C4) ( ) in the lter holder;
3. Insert a pod, centring it as far as possible on the lter (g.
15). Always follow the instructions on the pod pack to po-
sition the pod on the lter correctly.
4. Attach the lter holder to the appliance. Always turn as far
as it will go (g. 6);
5. Proceed as in points 5, 6 and 7 in the previous section.
10. HOW TO PREPARE CAPPUCCINO
1. Prepare the espresso coees as described in the previous
sections, using suciently large cups.
2. Press the button (g. 16) and wait for the OK light
(B3)to come on (g. 17);
3. In the meantime, ll a recipient with about 100 grams of
milk for each cappuccino to be prepared.The milk must be
at refrigerator temperature (not hot!). In choosing the size
of the recipient, bear in mind that the milk doubles or tri-
ples in volume (g. 18);

17
Please note: You are recommended to use semi-skimmed milk at refrigerator
temperature.
4. Place the recipient containing the milk under the cappuc-
cino maker.
5. Wait until the OK light comes on (B3). This indicates that
the boiler has reached the ideal temperature for steam
production.
6. Open the steam by turning the steam dial for a few seconds
to eliminate any water in the circuit. Close the steam.
7. Immerse the cappuccino maker in the milk for about 5
mm and turn the steam dial anticlockwise (g. 19). The
milk now starts to increase in volume and take on a creamy
appearance;
8. When the milk has doubled in volume, immerse the cap-
puccino maker deeply and continue heating the milk.
When the required temperature is reached (60°C is ideal),
interrupt steam delivery by rotating the steam dial clock-
wise and at the same time press the button;
9. Pour the frothed milk into the cups containing the coee
prepared previously. The cappuccino is ready. Sweeten to
taste and if desired, sprinkle the froth with a little cocoa
powder.
Please note: to prepare more than one cappuccino, rst make all the coees
then at the end prepare the frothed milk for all the cappuccinos;
To make coee again after the milk has been frothed, rst cool the
boiler, or the coee will be burnt. To cool, place a container under the boiler outlet,
press the button and deliver water until the OK light goes o. Press the same
button again, then proceed to make coee.
You are recommended to deliver steam for a
maximum of 60 seconds and never to froth
milk more than three times consecutively.
11. CLEANING THE CAPPUCCINO MAKER AFTER
USE
Important! For hygiene reasons, the cappuccino maker should always be cleaned
after use.
Proceed as follows:
1. Turn the steam dial to deliver a little steam for a few sec-
onds (points 2, 6 and 7 of the section "HOW TO PREPARE
CAPPUCCINO COFFEE). This causes the cappuccino maker
to discharge any milk left inside. Press the button
(B1) to turn the appliance o.
2. Wait a few minutes for the cappuccino maker to cool down.
Turn the cappuccino maker downwards to remove it
(g.
20);
3. Remove the cappuccino maker nozzle downwards
(g. 21);
4. Make sure the holes in the cappuccino maker shown in
(g.
22) are not blocked. If necessary, clean with a pin.
5. Reinsert the nozzle and replace the cappuccino maker on
the nozzle, turning it and pushing it upwards until it is
attached.
12. HOT WATER
1. Turn the appliance o by pressing the button (g. 4).
Wait for the OK light to come on ;
2. Place a recipient under the cappuccino maker.
3. When the OK light comes on, press the
button and
at the same time turn the steam dial anticlockwise
(g.
19). Water comes out of the cappuccino maker;
4. To stop hot water delivery, close the dial and press the
button again.
You should not deliver hot water for more
than 60 seconds.
13. CLEANING
13.1 Cleaning
the machine
The following parts of the machine must be cleaned regularly:
- drip tray (A10)
- coee lters
(C2), (C3) and (C4);
- boiler outlet (A2);
- water tank (A3);
- cappuccino maker
(A5) as described in section “11. CLEAN
ING THE CAPPUCCINO MAKER AFTER USE”;
Important!
• Do not use solvents, abrasive detergents or alcohol to clean
the coee machine.
• Do not use metal objects to remove encrustations or coee
deposits as they could scratch metal or plastic surfaces.
Danger! While cleaning, never immerse the coee maker in water. It is an elec-
trical appliance.
Please note: if the appliance is not used for more than 3/4 days, before using
it again, we strongly recommend you perform a rinse cycle as described in section “7.
SETTING UP THE APPLIANCE”
13.2 Cleaning the drip tray
1. Remove the tray;
2.
Remove the cup grille (g. 23), empty the water and clean
the tray with a cloth, then reassemble the drip tray;
3. Put the drip tray back in place.
13.3 Cleaning the coee lters
CLEAN THE COFFEE FILTERS WEEKLY:
1 and 2 cup lters
1. Extract the perforated lter by pulling the tab (g. 24);
2. Rinse the lters under running water (g. 25);
3. Make sure the holes are not blocked. If necessary, clean
with a pin (g. 25) and (g. 26);
4. Place the perforated lter in the lter housing and press
as far as it will go.
Pod lter
Rinse under running water. Make sure the holes are not blocked.
If necessary, clean with a pin (g. 25) and (g. 26).

18
13.4 Cleaning the boiler outlet
About every 300 coees, the espresso boiler outlet must be
cleaned as follows:
• Make sure the appliance is not hot and that it is unplugged
from the mains;
• Using a screwdriver, unscrew the screw xing the espresso
boiler outlet (g. 27);
• Remove the boiler outlet;
• Clean the boiler with a damp cloth (g. 28);
• Clean the outlet thoroughly in hot water using a brush.
Make sure the holes are not blocked. If necessary, clean
with a pin.
• Rinse under running water, rubbing all the time.
• Replace the boiler outlet, making sure it is correctly posi-
tioned on its gasket.
Failure to clean as described above invalidates the guarantee.
14. DESCALING
We recommend descaling the coee maker about every 200
coees.We recommend using commercially available De’Longhi
descaler (C6). Proceed as follows:
1. Fill the tank with the descaler solution, obtained by dilut-
ing the descaler with water following the instructions on
the pack;
2. Press the
button;
3. Make sure the lter holder is not attached and position a
container under the boiler outlet and cappuccino maker;
4. Wait until the OK light comes on ;
5. Press the button and deliver about 1/4 of the solu-
tion in the tank. At intervals, turn the steam dial to deliver
water from the cappuccino maker. Then interrupt water
delivery by pressing the
button and leave the
solution to work for about 5 minutes;
6. Repeat point 5 another 3 times, until the tank is empty;
7. To eliminate residues of descaler solution, rinse the tank
well and ll it with clean water (without descaler);
8. Press the button and deliver water until the tank
is empty. At intervals, turn the steam dial to deliver water
from the cappuccino maker;
9. Repeat points 7 and 8.
15. TECHNICAL DATA
Mains voltage: See rating label
Absorbed power: “
Size LxDxH:
185x244(329)x305 mm
Pressure: 15 bars
Water tank capacity: 1.1 l
Power cord length: 1300 mm
Weight: 3.8 kg

19
PROBLEM POSSIBLE CAUSE SOLUTION
No espresso coee is delivered No water in the tank Fill the tank with water
The holes in the lter holder are blocked Clean the lter holder spout holes
The lter and removable perforated lter
are blocked
Clean as described in section “13.3 CLEANING THE
COFFEE FILTERS”
The espresso boiler outlet is blocked Clean as described in section“13. CLEANING”
Scale in the water circuit Descale as described in section “14. DESCALING”
The espresso coee drips from
the edges of the lter holder
rather than the holes
The lter holder has been inserted incor-
rectly or is dirty
Attach the lter holder correctly and rotate rmly
as far as it will go
The espresso boiler gasket has lost elas-
ticity or is dirty
Have the espresso boiler gasket replaced by Cus-
tomer Services
The holes in the lter holder spouts are
blocked
Clean the lter holder spout holes
The lter and removable perforated lter
are blocked
Clean as described in section “13.3 CLEANING THE
COFFEE FILTERS”
The espresso coee is cold The OK light is not on when you deliver
coee
Wait until the OK light comes on
No preheating was done Preheat as described in section”7.2 TIPS FOR A
HOTTER COFFEE”
The cups were not preheated Pre-heat the cups with hot water
Scale in the water circuit Descale as described in section “14. DESCALING”
The pump is excessively noisy The water tank is empty Fill the tank
The tank is not correctly in place and the
valve on the bottom is not open
Press the tank down lightly to open the valve on
the bottom
There are air bubbles in the tank
connector
Follow the instructions in section“12. HOT WATER”
until water is delivered
The coee froth is too dark
(delivered from the spout too
slowly)
The ground coee is pressed down too
rmly
Press the coee down less rmly
The quantity of ground coee is too high Reduce the quantity of ground coee
The espresso boiler outlet is blocked Clean as described in section “13.4 CLEANING THE
BOILER OUTLET”
The lter and removable perforated lter
are blocked
Clean as described in section “13.3 CLEANING THE
COFFEE FILTERS”
The ground coee is too ne or damp Use only ground coee for espresso coee makers
and make sure it is not damp
The wrong type of ground coee is being
used
Use a dierent type of ground coee
16. TROUBLESHOOTING
Below is a list of some of the possible malfunctions.
If the problem cannot be resolved as described, contact Customer Services.
