DeLonghi KBP3010 User manual

instructions
CORDLESS KETTLE
KBP3010
Please retain these instructions for future reference
KBP3010 15-06-2004 12:02 Pagina 1

2
Kettle KBP3010
Description of Appliance
The following terms are used throughout the instruction manual
Lid
Handle
Latch
ON/OFF switch and
indicator light
Water level indicator
Body
FiIter
(Inside the Spout)
Spout
360°base with
cord storage
Plug
Filter
KBP3010 15-06-2004 12:02 Pagina 2

Thank you for choosing this De’Longhi kettle.To get the
best results from your new kettle it is advisable to read
these instructions carefully before using the appliance.
This is the only way to ensure optimum results and maxi-
mum safety.
Using for the first time
•Before use, check that the appliance has not been damaged dur-
ing transport.
•Remove all packaging from the kettle and power base.
•Remove any labels from the outer surfaces.
•Remove the filter by pushing as shown in fig. 1 and wash with
water (fig. 2). Refer to page 5.“Removing the scale filter”
•Fill the kettle and boil.
•The boiled water should be discarded and the kettle rinsed out
with cold water.This procedure should be carried out three
times, to remove any manufacturing dust, etc.
•After the kettle has been rinsed out, re-fit the filter (fig. 3).
Using the kettle
With the specially designed power base and central connector,
you can now set the kettle on the base at any angle, from any
position.
•Release cord from storage base and adjust length by winding
around the base to give the correct cord length to reach the
plug socket to be used (fig. 4).
•Do not leave loose cord hanging over the edge of work sur-
faces.
Filling
•Remove the kettle from the base unit before filling.
•Open lid and fill kettle to desired level.
Do not fill with less than 0,8 litre of water to prevent the kettle
running dry while operating; misuse of this kind will shorten the
life of the element.
Do not fill with more than 1,5 litres of water (up to the MAX
indication located inside the kettle) (fig. 5).
If the kettle is overfilled, there is a risk that boiling water may
be ejected causing burns.
A handy water level viewer enables you to see the quantity of
water in the kettle.
ac
b
1
2
CORD EXIT
0,8 l
M
ax
M
in
1,5 l
Fig.1
fig.2
Fig.3
Fig.4
Fig.5
Kettle KBP3010
3
KBP3010 15-06-2004 12:02 Pagina 3

4
Switching on
•Plug the power base into the mains socket.
•Place kettle on power base.
•Press the ON/OFF switch down (fig. 6) to switch the kettle on.
•The indicator light around the ON/OFF switch will come on.
•The kettle will automatically switch off once the water is boiled
(the ON/OFF switch will click upwards and the light will go
out).
•To turn the kettle off before the water boils, you may move the
ON/OFF switch up to the OFF position, or simply lift the kettle
from its base - it will switch off and the switch will return to
the OFF position automatically.
Pouring
•Remove the kettle from the power base and carefully pour out
the water. Do not tilt the kettle suddenly or pour water out at
too sharp an angle.
•When you lift the kettle from the base, you may see moisture
on the top surface of the base.This is condensation from the
steam that causes the kettle to turn off automatically after boil-
ing. Steam is allowed to escape via vents in the underside of the
kettle. Condensation on the base is perfectly normal, and should
not be a cause for alarm.
Safety devices
1) Automatic ON/OFF switch
Your kettle is fitted with an ON/OFF switch which automatical-
ly switches off once the water has boiled. If the kettle has just
boiled, wait a minute or so before re-boiling the kettle. Do not
attempt to hold the ON/OFF switch in the ON position or
adjust the switch mechanism.
2) Safety cut-out
If the kettle is switched ON with too little or no water, it is
protected against damage by a safety cut-out which will switch
off the power.
If this cut-out operates, disconnect the kettle from the mains
supply and leave to cool down before refilling with cold water
(otherwise the element could be damaged).
3) If the kettle is lifted from base while operating (ON), it will
automatically switch off.
I
Fig.6
Kettle KBP3010
KBP3010 15-06-2004 12:02 Pagina 4

5Kettle KBP3010
Cleaning and maintenance
Cleaning the kettle
•Allow the kettle to cool down fully and disconnect the appli-
ance from the mains before cleaning.
•Do not immerse the kettle or base in water.
•Use a soft dampened cloth to wipe the outside of the kettle
and dry with a soft, dry cloth.
•DO NOT use harsh scouring agents.
•Ensure that all connectors and sockets are kept dry.
Scale
Scale is mainly calcium carbonate (chalk), a harmless, naturally
occurring mineral found in most water supplies.“Hard” water con-
tains more of this mineral than “soft” water.
When the water is heated, the minerals in the water solidify, mak-
ing the water appear cloudy. These minerals form a thin film on the
walls, element and on the surface of the water.The water may look
like it has white coloured pieces of plastic floating on the surface.
On traditional kettle elements, scale forms a hard white “crust”
which adversely affects performance and reduces the life of the
element.
As soon as you notice a film forming on the water, or, when clean-
ing the filter, if you notice a film on the walls or the element, simply
rinse the kettle and wipe it out.
Scale filter
Your kettle is fitted with a scale filter to prevent loose particles of
scale being poured into your beverage.This filter is both removable
and washable.
The frequency with which you will need to clean any scale deposits
from your filter will depend on the hardness of water in your area
and how often you use the kettle.
You should remove and clean the water filter when you notice any
deposits being left on the filter or if the pouring efficiency is
impaired.
Removing the scale filter
•Allow the kettle to cool down fully.
•Disconnect the appliance from the mains electrical supply.
•Make sure that your hands are clean and free from soap, cream
or anything which might taint the water.
•Empty the kettle and remove the filter by pushing as shown in fig. 1.
•Rinse under a tap whilst brushing with a soft brush (fig. 2).
•Replace the filter (fig. 3).
KBP3010 15-06-2004 12:02 Pagina 5

6
Kettle KBP3010
To clean the scale filter
It is vital to clean and descale regularly in order to maintain good
working order
•Use a proprietary descaling product e.g. citric acid crystals.
We recommend using citric acid crystals as follows:
• Pour into kettle about 50 gr. or 2 oz. of citric acid crystal and
then fill with water up to the max level indicated and then boil.
Allow the contents to cool, and then rinse thoroughly.
•Do not use a more concentrated solution. If the filter requires
descaling, remove the filter and place into the citric acid solu-
tion.
•Ensure that the electrical connections are completely dry
before using the kettle.
•Citric acid crystals are available from most pharmacies.
Safety Warnings
Please read these instructions before operating and retain for
future reference.
•Ensure that your mains supply voltage is the same as that
marked on the underside of your kettle.
•To protect against electrical hazards do not immerse the mains
lead, plug power base or kettle in water or any other liquid. Do
not use in the bathroom or near any source of water. Do not
use outdoors.
•Do not touch hot surfaces i.e. body or lid. Use handles or
knobs.
•Do not remove the lid while the kettle is boiling.
•Take care when pouring - do not over-tilt the kettle as water
may enter into the switch mechanism.
•Water can remain hot for a long time after boiling, and can
present a scald hazard. Keep the kettle and the mains lead away
from the edge of the work surface and out of the reach of chil-
dren.
•Do not allow the mains lead to hang over the edge of the table
or work surface, or anywhere it may be accidentally caught or
tripped over.
•Close supervision is necessary when any appliance is used near
children.
•Remove the plug from the mains socket when not in use and
before cleaning.Allow the kettle to cool before cleaning.
•Remove the kettle from its power base before filling.
•Never move the kettle whilst it is in use.
•Do not use the kettle if you have wet hands.
•Keep the kettle, the power base, and the mains lead away from
hotplates, hobs or burners.
KBP3010 15-06-2004 12:02 Pagina 6

7Kettle KBP3010
•Do not use the kettle for any purpose other than heating water.
Do not place any utensils into the kettle.The use of accessory
attachments not recommended by the appliance manufacturer
may result in fire, electric shock or personal injury.
•Never use the kettle without its lid.
•Position the kettle properly on the power base before switching
on.
•Use the kettle only with the power base supplied (and vice
versa).
•Do not operate this kettle if the mains lead or plug is damaged,
if the kettle malfunctions, or has been damaged in any manner. It
must be returned to a service agent for repair or replacement
in order to avoid hazard.
•The power cable must not be replaced by the user as this
requires the use of special tools. If the power cable is damaged,
contact an authorized Service Centre.
•If the kettle is overfilled, boiling water may overflow.
KBP3010 15-06-2004 12:02 Pagina 7

8
Kettle KBP3010
Electrical Requirements
The flexible mains lead is supplied connected to a B.S. 1363 fused
plug having a fuse of 13 amp capacity.Should this plug not fit the
socket outlets in your home, it should be cut off and replaced with
a suitable plug, following the procedure outlined below.
Note: Such a plug cannot be used for any other appliance and
should therefore be properly disposed of, (having removed the
fuse) and not left where children might find it and plug it into a
supply socket - with the obvious consequent danger.
If the plug is a moulded-on type the fuse cover must be refitted. If
the fuse cover is lost, the plug must not be used until a replace-
ment cover is obtained.The colour of the correct replacement
fuse cover is that of the coloured insert in the base of the fuse
recess or elsewhere on the plug.Always state this colour when
ordering a replacement fuse cover.
N.B.We recommend the use of good quality plugs and wall sockets
that can be switched off when the machine is not in use.
important: the wires in the mains lead fitted to this appliance are
coloured in accordance with the following code:
As the colours of the wires in the mains lead of this appliance may not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The wire which is coloured green and yellow must be connected to
the terminal in the plug which is marked with the letter E or by the
earth symbol or coloured green or green and yellow.
The wire which is coloured blue must be connected to the terminal
which is marked with the letter Nor coloured black.
The wire which is coloured brown must be connected to the terminal
which is marked with the letter Lor coloured red.
When wiring the plug, ensure that all strands of wire are securely
retained in each terminal. Do not forget to tighten the mains lead
clamp on the plug. If your electricity supply point has only two pin
socket outlets, or if you are in doubt, consult a qualified electrician.
Should the mains lead ever require replacement, it is essential
that this operation be carried out by a qualified electrician and
should only be replaced with a flexible cord of the same size.
Only 13amp replacement fuses which are ASTA approved to B.S.
1362 should be fitted.
This appliance conforms to the Norms EN 55014 regarding
the suppression of radio interference.
GREEN AND YELLOW
BLUE
BROWN
EARTH
NEUTRAL
LIVE
Green and Yellow to
Earth
Blue to
Neutral
13 amp
Fuse
Brown to
Live
Cord Clamp
Warning
this appliance must be earthed
KBP3010 15-06-2004 12:02 Pagina 8

KBP3010 15-06-2004 12:02 Pagina 9
