Delphi Series Q48DM, 75W Quarter Brick,
Dual Output DC/DC Power Modules:
3.3V/12A and 1.2V/25A
The Delphi Series Q48DM Quarter Brick, 48V input, dual output,
isolated DC/DC converters are the latest offering from a world leade
r
in power system and technology and manufacturing — Delta
Electronics, Inc. This product family provides up to 75 watts of dual
positive regulated outputs with a flexible combination of output current
and in a very cost effective industry standard footprint. Both outpu
t
channels can be used independently. There is a trim function to be
used with the second output voltage (the lower output voltage). With
creative design technology and optimization of component placement,
these converters possess outstanding electrical and thermal
performance, as well as extremely high reliability under highly stressful
operating conditions. All models are fully protected from abnormal
input/output voltage, current, and temperature conditions. The Delphi
Series Q48DM converters meet all safety requirements with basic
insulation.
FEATURES
 High efficiency: 88.5% @ 3.3V/12A &
1.2V/25A
 Size: 57.9mm×36.8mm×9.7 mm
(2.28” ×1.45” ×0.38”)
 Industry standard footprint and pinout
 Flexible current allocation on each output
 Low voltage output (O/P 2) starts up first
 Output 2 can be adjusted (trim)
 Fixed frequency operation
 Input UVLO, Output OCP, OVP, OTP
 No minimum load required
 1500V Isolation and basic insulation
 ISO 9001, TL 9000, ISO 14001, QS9000,
OHSAS18001 certified manufacturing
facility
 UL/cUL 60950-1 (US & Canada), and TUV
(EN60950-1) - pending
OPTIONS
 Positive On/Off logic
 Heatsink available for extended
operation
APPLICATIONS
 Telecom / DataCom
 Wireless networks
 Optical network equipment
 Server and data storage
 Industrial / Test Equipment
PRELIMINARY DATABRIEF 1Delta Electronics, Inc.
DB_Q48DM_02142008

SPECIFICATIONS
GENERAL SPECIFICATIONS OUTPUT SPECIFICATIONS
Input Voltage
2
36~75V Voltage Accuracy Typical ±1.5%
Switching Frequency Line RegulationTypical (3.3V) 350KHz Typical ±0.5%
Isolation Voltage In/Out 1500V Load Regulation Typical ±1.5%
Isolation Capacitance Typical 1500 pF Ripple & Noise Typical 50 mV
Isolation Resistance Minimum 10M Ohms Current Limits Typical 140%
MTBF Over VoltageBellcore (3.3V) TBD Typical 135%
Size Voltage Trim(2.28” ×1.45” ×0.38”) 57.9 x 36.8 x 9.7 mm For Vout2 ±10%
PART NUMBERING SYSTEM
Q 48 D M 3R3 12 N N F A
Product
Type Input Voltage Number of Outputs Product Series Output Voltage 1 Output ON/OFF Logic Pin Length Option Code
Voltage 2
Q - Quarter
Brick 48V D - Dual Output M - 75W Platform 3R3 - 3.3V 12 - 1.2V N - Negative N - 0.150” A - Standard Functions
F - RoHS 6/6
R - 0.170”P - Positive (Lead Free)
MODEL LIST OUTPUT *
MODEL NAME INPUT EFF @ Full Load
Q48DM3R312NN A 36V~75V 2.4A 3.3V/12A 1.2V/25A 88.5%
* Note: Total output power should not exceed 75 watts and maximum output current for high output is 12A, for low output is 25A.
