Delta Electronics Delphi V48SR User manual

FEATURES
 High efficiency: 90.5% @ 3.3V/20A
 Size: 33.0x22.9x9.5mm (1.3”x0.90”x0.37”)
 Input UVLO and OVP
 Industry standard footprint and pinout
 Fixed frequency operation
 SMD and Through-hole versions
 OTP and output OCP, OVP (default is auto-
restart)
 Output voltage trim: -20%, +10%
 Monotonic startup into normal and
pre-biased loads
 2250V isolation and basic insulation
 No minimum load required
 No negative current during power or enable
on/off
 ISO 9001, TL 9000, ISO 14001, QS 9000,
OHSAS 18001 certified manufacturing facility
 UL/cUL 60950 (US & Canada) recognized,
and TUV (EN60950) certified
 CE mark meets 73/23/EEC and 93/68/EEC
directive
Delphi Series V48SR, 1/16
th
Brick 66W
DC/DC Power Modules: 48V in, 1.2V~15V, 25A out
The Delphi Series V48SR, 1/16th Brick, 48V input, single output, isolated
DC/DC converter, is the latest offering from a world leader in powe
r
systems technology and manufacturing ―Delta Electronics, Inc. This
product family provides up to 66 watts of power or 25A of output curren
t
(1.8V and below) in a new 1/16th brick form factor (1.3”x0.90”) and pinout.
With creative design technology and optimization of component placement,
these converters possess outstanding electrical and thermal performance,
as well as extremely high reliability under highly stressful operating
conditions. Typical efficiency of the 3.3V/20A module is greater than
90.5%. All modules are protected from abnormal input/output voltage,
current, and temperature conditions. For lower power needs, but in a
similar small form factor, please check out Delta S48SP (36W or 10A) and
S48SE (17W or 5A) series standard DC/DC modules.
OPTIONS
 SMD module available
 Positive remote On/Off
 OTP and output OVP, OCP mode
(Auto-restart or latch)
APPLICATIONS
 Optical Transport
 Data Networking
 Communications
 Servers
DATABRIEF
DB_V48SR_02022007

2
SPECIFICATIONS
GENERAL SPECIFICATIONS OUTPUT SPECIFICATIONS
Input Voltage 36~75V Voltage Accuracy Typical ± 1.5%
Switching Frequency Typical (3.3V) 415KHz Line Regulation Typical ± 0.1%
Isolation Voltage In/Out 2250V Load Regulation Typical ± 0.1%
Isolation Capacitance Typical 1nF Ripple & Noise Typical 50 mV
Isolation Resistance Minimum 10M ohm Current Limits Typical 120%
MTBF Bellcore (3.3V) 2.4m hours Over Voltage Typical 120%
OTP Typical 135°C Voltage Trim +10%, -20%
Size 33.0x22.9x9.5mm 1.30”x0.90”x0.37”
PART NUMBERING SYSTEM
V 48 S R 1R8 25 N R F A
Product
Type Input Voltage Number of Outputs Product Series Output Voltage Output Current ON/OFF Logic Pin Length/Type Option Code
V - 1/16th
brick
48-
36V~75V
S - Single R - regular 1R2 - 1.2V
1R5 - 1.5V
1R8 - 1.8V
2R5 - 2.5V
3R3 - 3.3V
050 - 5.0V
120 - 12V
150 - 15V
04 - 4.4A
05 - 5.5A
13 - 13A
20 -20A
25 -25A
N - Negative
P - Positive
R - 0.170”
N - 0.145”
K - 0.110”
M - SMD
F- RoHS 6/6
(Lead Free)
A – standard
functions
MODEL LIST
MODEL NAME INPUT OUTPUT EFF @ 100% LOAD
V48SR1R225NRFA 36V~75V 1.2A 1.2V 25A 84.0%
V48SR1R525NRFA 36V~75V 1.4A 1.5V 25A 85.0%
V48SR1R825NRFA 36V~75V 1.6A 1.8V 25A 87.0%
V48SR2R520NRFA 36V~75V 1.8A 2.5V 20A 89.0%
V48SR3R320NRFA 36V~75V 2.4A 3.3V 20A 90.5%
V48SR05013NRFA 36V~75V 2.3A 5.0V 13A 91.0%
V48SR12005NRFA 36V~75V 2.3A 12V 5.5A 91.0%
V48SR15004NRFA 36V~75V 2.3A 15V 4.4A 91.0%
MECHANICAL DRAWING
Surface-mount module Through-hole module
