Delta Electronics NovoConnect B360 User manual

Quick Start Guide
NovoConnect
B360
Wireless Presentation & Collaboration System

1Package Contents
NovoConnect B360
Package Contents
(a) NovoConnect B360 main unit (b) Micro-HDMI-to-HDMI cable (c) Micro-USB-to-USB power cable
(d) USB power adapter (e) NovoConnect mount

2
Your NovoConnect B360
NovoConnect B360
Your NovoConnect B360
Reset
DC 5VMicro HDMI
Micro SD
Connecting Your B360
Video/Audio connection1. : Connect the Micro HDMI port to the TV/projector’s HDMI input port using the
Micro-HDMI-to-HDMI cable (item (b) in “Package Contents”).
Power input2. : Connect the Micro-USB port to the power source using the Micro-USB-to-USB power cable
and the USB power adapter (items (c) and (d) in “Package Contents”).
Note: Throughout this manual, your NovoConnect B360 will be referred to as B360.
Note: You may connect an optional USB mouse, keyboard, or memory drive to the USB port.
Note: The microSD slot supports NTFS and FAT32 format. Do not use other format to avoid data damage.
USB power adapter
HDMI Input Port
Micro HDMI port
(to TV/projector)
Reset Micro-USB port
(5V power input)
USB port (Mouse,
keyboard, memory drive)
microSD slot
Power LED (Green light when power is on)

3Software Download and Installation
NovoConnect B360
Software Download and Installation
Your B360 will power up and show the NovoConnect
home screen (as shown in the gure on this page)
once it is properly connected. Follow the steps below
to download the NovoConnect presentation software
from your B360 onto your PC.
Setup Wi-Fi:
Enable Wi-Fi on your computer. Search for
and connect to the SSID shown on the bottom
right corner of the NovoConnect home screen
(e.g. NVC_DC9AB). Wait a few seconds for the
connection to be established.
A
B
A
B
Software Download:
For Windows/Mac: To download the
presentation software, enter the URL shown
on the NovoConnect home screen into your
browser and follow the instructions on the
next page to download and install.

4
Software Download and Installation (continued)
NovoConnect B360
Software Download and Installation (continued)
For Windows and Mac computers
Once you have opened the webpage from your B360
home screen (for example, http://192.168.43.1:8080 in
the sample home screen), select an OS type and follow
the instructions on the web page to download and
install the NovoConnect software.
For Android and iOS tablets
Download and install the App “NovoPresenter” from
Google Play or iOS App Store. After installation, you
will see the NovoPresenter icon (as shown in the gure
on this page) on your tablet.

5Managing a Presentation
NovoConnect B360
Managing a Presentation
Launching a Presentation After software installation you will be able to access the
appropriate presentation software from your PC, Mac or
tablet.
PC and Mac:
NovoConnect
Desktop Streamer NovoConnect
Desktop Streamer
Android and iPad:
NovoPresenter
Start the application to launch the control panel (shown
on the left). Follow the steps below to start or join a
presentation group:
1. IP address
(Required):
Enter the IP address shown on the
NovoConnect home screen.
2. PIN
(optional):
Check the “PIN required” box and
enter PIN if needed.
3. Your Name
(optional):
Type in your name which will be
displayed to other members of your
presentation group.
4. Click Connect to start or join the presentation
group.

6
Managing a Presentation (continued)
NovoConnect B360
Managing a Presentation (continued)
(A)
12
3
Roles in a Presentation Session
Click on the list tab. This will display all participants in your
presentation group. The role of each participant is indicated by
the graphic symbols shown below.
1. Host
2. Presenter
3. Participant
(B)
21
Assigning Roles
Move the cursor over a participant entry to change the role of a
participant:
1. The host assigns a participant as a presenter.
2. The host assigns a participant as the new host.
(C) 4-Way Split Screen Presentation
Click on a numbered box to assign a presenter’s
on-screen display to the corresponding
presentation screen #1-#4.
Click the center box to assign a presenter’s on-
screen display to full screen.

7Managing a Presentation (continued)
NovoConnect B360
Managing a Presentation (continued)
(D)
1
Screen Preview (participant authorization required)
1. Only the host can preview a participant’s screen.
2. The participant denies or allows screen preview
by toggling the button between and
presentation group.
(E) Click the Connection tab and click Disconnect to leave the
presentation group.
2

8
For More Information
NovoConnect B360
For More Information
Please refer to the B360 user manual for more information on all the features and tools available. Here is a quick
list of topics in the B360 user manual useful in making an effective presentation:
MS, PDF, and Photo document presentations•
Annotation Tools for tablets and PCs•
Browser-based content presentations•
microSD card-based document presentations•
Resetting a presentation session•
Display parameters conguration•
Wi-Fi setup•
Please go to the following site to download the B360 User Manual and to view the most up-to-date product
information:
www.deltaww.com/EduSolution

9Notes
NovoConnect B360
Notes

10
Notes
NovoConnect B360
Notes

Taiwan
Delta Electronics Inc. Education Solutions and Service Department
186, Ruey Kuang Road, Neihu, Taipei
11491, Taiwan R.O.C.
T [phone] / F [phone]
www.deltaww.com
