Delta Electronics Agema Series User manual

Delta Networking – Agema Family
AGC7646V1 Aggregation Switch
Installation Guide
agema.deltaww.com

ii
AGC7646V1 Aggregation Switch
Copyright
All specications and gures are subject to change without prior notice. Actual products may look
different from the photos.
All trademarks and logos mentioned in this guide are the properties of their respective holders.
Copyright © Delta Electronics, Inc. All rights reserved.
Regulatory and Safety Information
This product has been tested in accordance to, and complies with the following safety standards and
electromagnetic compatibility (EMC) inspection standards.
Emissions
Applicable standard
• AS/NZS CISPR 32: Class A
• ICES-003: Class A
• EN55032: Class A
• VCCI Class A
• FCC CFR 47 Part 15, Subpart B Class A
Safety
Applicable standard
• EN 62368-1, Second Edition
• UL 62368-1, Second Edition
• CAN/CSA C22.2 No. 62368-1, Second Edition
• IEC 62368-1, Second Edition Including All National
Immunity
Applicable standard
• EN 55024
• EN 61000-3-2: Harmonic Current Emissions
• EN 61000-3-3: Voltage Fluctuations and Flicker
• EN 61000-4-2: ESD
• EN 61000-4-3: Radiated Immunity
• EN 61000-4-4: EFT
• EN 61000-4-5: Surge
• EN 61000-4-6: Low Frequency Conducted Immunity
• EN61000-4-8: Power Frequency magnetic eld
• EN61000-4-11: Voltage dips and interruption
EU RoHS Compliant
Applicable standard All AG-Series components are EU RoHS compliant

iii
Important!
This product is intended for installation only in the RESTRICTED ACCESS AREA ACCESSIBLE only
to SKILLED PERSONS and INSTRUCTED PERSONS with the proper authorization.
•Access is through the use of a lock or tool and key, or other means of security, and is controlled by
the authority responsible for the location.
•Access can only be gained by service persons or by users who have been instructed about the
reasons for the restrictions applied to the location and about any precautions that shall be taken.
•Never open the equipment and/or switch the plug-in power supplies and fan tray modules. For
safety reasons, the equipment should be opened and maintenance only by qualied service
personnel / SKILL PERSONS.
This product is intended for installation in Information Technology Equipment Rooms (Data Center):
“Suitable for installation in Information Technology Rooms in accordance with Article 645 of the
National Electrical Code and NFPA 75.”
Important!
Ce produit est conçu pour une installation dans un ENDROIT À ACCÈS RESTREINT, ACCESSIBLE
uniquement par des PERSONNES COMPÉTENTES et QUALIFIÉES possédant les autorisations
appropriées.
•L’accès est limité par un cadenas, un outil, une clé ou par un autre moyen et est contrôlé par
l’autorité responsable des lieux.
•L’accès n’est permis que pour le personnel de service ou les utilisateurs qui ont été informés sur
les raisons de la restriction imposée sur l’emplacement et sur les précautions éventuelles qui
doivent être entreprises.
•N’ouvrez jamais l’équipement et ne mettez pas les modules du bloc d’alimentation et du plateau
de ventilation sous tension. Pour des raisons de sécurité, l’ouverture ou l’entretien de l’équipement
doit être effectué par le personnel de service ou des PERSONNES COMPÉTENTES.
Ce produit est conçu pour être installé dans les salles de la technologie de l’information (centre des
données) :
« Il convient à l’installation dans des salles de la technologie de l’information conformément à l’article
645 du National Electrical Code et de NFPA 75 ».
Warning: Fiber Optic Port Safety
When using a ber optic port, never look at the transmit laser while it is powered
on. Also, never look directly at the ber TX port and ber cable ends when they are
powered on.
Avertissement : Consignes de sécurité concernant le port de
fibre optique
Ne regardez jamais le faisceau de laser émis activé lorsque vous utilisez un port de
bre optique. Également, ne regardez jamais le port de bre TX et les extrémités du
câble du bre directement lorsqu’ils sont activés.

iv
AGC7646V1 Aggregation Switch
CAUTION
Lithium Battery Caution
Danger of explosion if battery is incorrectly replaced. Replace only with same or equivalent type.
Dispose batteries according to manufacturer’s instructions.
Disposal of a BATTERY into re or a hot oven, or mechanically crushing or cutting of a BATTERY, that
can result in an EXPLOSION.
Leaving a BATTERY in an extremely high temperature surrounding environment that can result in an
EXPLOSION or the leakage of ammable liquid or gas.
A BATTERY subjected to extremely low air pressure that may result in an EXPLOSION or the leakage
of ammable liquid or gas.
Grounding Caution
This equipment must be grounded and the power cord for product should be connected to a socket-
outlet with earthing connection. Note that the grounding screw of chassis should be connected to rack
instead of protective earthing conductor.
If this equipment is installed in the restricted-access location, it should have a separate protective
earthing terminal on the chassis which must be permanently connected to earth ground to adequately
ground the chassis and protect the operator from electrical hazards.
This equipment might provide the hazardous voltage and must be connected by qualied service or
technical person, or be instructed and supervised by qualied service or technical person.
Multiple Power Sources Caution
This symbol indicates the presence of hazardous energy circuits or electric shock hazards. Refer all
servicing to qualied personnel.
WARNING: Do not open the enclosure to reduce the risk of injury from electric shock hazards. Refer
all maintenance, upgrades and service servicing to qualied personnel.
Caution: The power control button on the device and the power switch on the power supply do not turn
off the electrical current supplied to the device. The device also might have more than one power cord.
To remove all electrical current from the device, ensure that all power cords are disconnected from the
power source.

v
MISE EN GARDE
Mise en garde concernant la pile au lithium
Risque d’explosion si la pile est remplacée incorrectement. Remplacez-la avec une pile semblable ou
de même type uniquement. Éliminez les piles selon les directives du fabricant.
L’élimination de la PILE dans un feu, un four chaud ou un broyeur mécanique peut provoquer une
EXPLOSION.
L’exposition de la PILE à une température ambiante extrêmement élevée peut provoquer une
EXPLOSION ou la fuite d’un liquide ou d’un gaz inammable.
L’exposition de la PILE à une pression atmosphérique extrêmement basse peut provoquer une
EXPLOSION ou la fuite d’un liquide ou d’un gaz inammable.
Mise en garde concernant la mise en terre
Cet équipement doit être mis à terre et le cordon d’alimentation du produit doit être branché à une
prise mise à terre. Notez que la vis de mise à la terre du châssis doit être xée sur le bâti plutôt que
sur le conducteur de protection.
Si cet équipement est installé dans un emplacement à accès restreint, l’équipement doit être doté
d’une borne de mise à terre distincte sur le châssis qui doit être branchée adéquatement et en
permanence an de le mettre à terre et protéger les utilisateurs contre les dangers électriques.
Cet équipement peut générer du courant dangereux et doit être branché par du personnel technique
ou de service qualié ou par des personnes informées et supervisées par du personnel technique ou
de service qualié.
Sources multiples d’alimentation
Ce symbole indique la présence de circuits dangereux ou des risques de décharges électriques.
Conez la réparation à du personnel qualié.
AVERTISSEMENT : N’ouvrez pas le boîtier an de réduire les risques de blessures causées par des
décharges électriques. Conez la réparation, les mises à jour et l’entretien à du personnel qualié.
Mise en garde : Le bouton d’alimentation et le commutateur de l’appareil ne coupent pas le courant
électrique qui alimente l’appareil. L’appareil peut également être branché à plusieurs cordons
d’alimentation. An de couper complètement le courant électrique de l’appareil, assurez-vous de
débrancher tous les cordons d’alimentation de la source d’alimentation.

vi
AGC7646V1 Aggregation Switch
Table of Contents
Chapter 1: Introduction -------------------------------------------------------------------1
1.1 Overview ------------------------------------------------------------------------------------ 1
1.2 Package Content ------------------------------------------------------------------------- 1
1.3 Features------------------------------------------------------------------------------------- 2
Chapter 2: Appearance and Mechanism --------------------------------------------3
2.1 Product Overview ------------------------------------------------------------------------- 3
2.2 LED Identication ------------------------------------------------------------------------- 4
2.3 System Requirements ------------------------------------------------------------------- 7
2.4 Data Center Deployment --------------------------------------------------------------- 8
2.5 Power Supply Modules ------------------------------------------------------------------ 9
2.6 Fan Tray Module -------------------------------------------------------------------------10
Chapter 3: Installation ------------------------------------------------------------------- 11
3.1 Mounting -----------------------------------------------------------------------------------11
3.2 Installing an Optional Transceiver and Cable ------------------------------------14
3.3 Connecting to the Console Port ------------------------------------------------------15
3.4 Connecting to a Power Source -------------------------------------------------------16
Chapter 4: Making the Network Connections ----------------------------------- 19
4.1 Twisted-pair Connections --------------------------------------------------------------19
4.2 Fiber Optic Connections ---------------------------------------------------------------20
4.3 Ethernet Cabling -------------------------------------------------------------------------21
Appendix 1 : Technical Specifications--------------------------------------------- 22
Appendix 2 : Warranty------------------------------------------------------------------- 23
Limited and Support Warranty -------------------------------------------------------------23
Technical Support -----------------------------------------------------------------------------23

1
Chapter 1: Introduction
1.1 Overview
AGC7646V1 is a ToR/Leaf and EoR switch with deep buffers for data center deployment
or as mobile access/aggregation switching and edge routing in service provider network.
AGC7646V1 is not only offering 100GbE uplink ports but also supporting virtualization
features. AGC7646V1 is SDN capable, compatible with choices of third party NOS and as
well as ONIE, openow for today’s open network ecosystem. It also provides comprehensive
capability on layer 2 and layer 3 features, including SNMP, Spanning Tree, VLAN, QinQ,
Trunk, QoS, RIP, OSPF, IGMP, DVMRP, PIM-DM, PIM-SM, Access Control, etc. This product
which aims for Data Center and Carrier Networks also supports advance features such as
MPLS, TRILL, PFC, VEPA, QCN, VxLAN and NVGRE to meet Data Center high performance
and virtualization requirement.
1.2 Package Content
After unpacking this switch, check the contents to be sure you have received all the
components. Then, before beginning the installation, be sure you have all other necessary
installation equipment.
•AGC7646V1
•Rack-mounting kits
•Installation guide
If any item is missing or damaged, contact the vendor immediately, see “Technical Support”.

2
AGC7646V1 Aggregation Switch
1.3 Features
The following lists the key main features of AGC7646V1 switch:
•46 x 10GbE SFP+ and 6 x 100GbE QSFP28 ports, support splitter cable
•1 x RJ45 OOB management port
•1 x RJ45 Console port
•1 x USB port
•System / Fan / Power status LED indication and per port LEDs
•On board high performance CPU system with large memory
•Hot-swappable PSUs and 1+1 redundancy support
•Hot-swappable FANs and 3+1 redundancy support
•Standard 1RU chassis high
•800Gbps interface bandwidth
•Low pin-to-pin latency: Cut-Through and Store & Forward Mode
•4GB GDDR5 of packet buffer memory
•External TCAM for extending classication database
•Support Jumbo Frame up to 9Kbyte
•Supports port speeds of 10G, 25G, 40G, 100G

3
Chapter 2: Appearance and Mechanism
2.1 Product Overview
2.1.1 Front View
Management port x 1
Console port x 1
QSFP28 port x 6
SFP+ port x 46
(Figure 2-1: Front View)
2.1.2 Rear View
PSU x 1
4 Fan tray slots
Secondary PSU
slot x 1 (optional)
(Figure 2-2: Rear View)
NOTE:
The switch supports up to two PSUs. However, it might be shipped with one power supply
pre-installed in the rear panel of the switch. You may purchase an additional PSU for
redundancy.

4
AGC7646V1 Aggregation Switch
2.2 LED Identification
This section provides an overview of the front and rear LEDs.
2.2.1 Front LEDs
Upper SFP+ Port LED
Lower SFP+ Port LED
Upper QSFP28 Port LED
Lower QSFP28 Port LED
Power LED
System LED
Fan LED
(Figure 2-3: Front LED Identification)
LED Description
System LED
• Solid Green – Normal operation
• Blinking Green – Booting progress or System in diagnostic mode
• Solid Amber – System failure
• Off – No power
Power LED
• Solid Green – Power supply units are supplied to the switch & operating normally
• Solid Amber – Power supply unit failure
• Off – Power is disconnected
Fan LED • Solid Green – All fans are operating normally
• Solid Amber – One or more fans failure
10G SFP+
slots
LED (Solid Lighting –Linkup; Blinking –Activity)
• Solid Green – A valid 10G link
• Solid Amber – A valid 1G link
• Blinking –Packet transmission or reception in progress
• Off – No link

• Appearance and MechanismChapter 2
5
LED Description
100G QSFP28
slots
LED1 (Solid Lighting –Linkup; Blinking –Activity)
• Solid Green – 100G operation
• Solid Amber – 40G operation
• Solid Blue – 25G operation
• Solid Purple – 10G operation
• Off – No Link
LED2 (Solid Lighting –Linkup; Blinking –Activity)*
• Solid Blue – 25G operation
• Solid Purple – 10G operation
• Off – No Link
LED3 (Solid Lighting –Linkup; Blinking –Activity)*
• Solid Blue – 25G Operation
• Solid Purple – 10G Operation
• Off – No Link
LED4 (Solid Lighting –Linkup; Blinking –Activity)*
• Solid Blue – 25G Operation
• Solid Purple – 10G Operation
• Off – No Link
*LED2 to LED4 support through breakout cable.
Management
port
Link LED
• Off – No link is established on the port
• Solid Yellow – A valid link at 10/100Mbps is established on the port
• Solid Green – A valid link at 1000Mbps is established on the port
Act LED
• Off – No link is established on the port
• Blinking Green – Activity, transmitting or receiving packet at this port

6
AGC7646V1 Aggregation Switch
2.2.2 Rear LEDs
Fan tray LED Power Supply LED
(Figure 2-4: Rear LED Identification)
LED Description
Fan tray LED • Solid Green – FAN is operating normally
• Solid Red – Fan failure
Power Supply
LED
• Solid Green – PSU is operating normally
• Solid Red – Unplugged or power lost; with a second PSU in parallel still with
input power

• Appearance and MechanismChapter 2
7
2.3 System Requirements
Component Requirement
System requirements
Switch fabric capacity Non-blocking full wire speed on all packet sizes
Forwarding architecture Store and forward or cut-through
Port packet forwarding rate
(at 64 Bytes)
• 148,000,000 pps (100GbE)
• 59,520,000 pps (40GbE)
• 14,880,000 pps (10GbE)
Memory type • 4GB GDDR5 of packet buffer memory
• External TCAM for extending classication database
Console port Serial RS232 console ports (RJ45)
Management port 10/100/1000Mbps, auto sensing, auto negotiation
Port requirements
Speed Capability per Port
• 1G/10Gbps (SFP+ port)
• 40G/100Gbps (QSFP28 port)
• 10G/25G (QSFP28 port, working in breakout cable)
Full-Duplex Flow Control Support the IEEE 802.3x PAUSE frame

8
AGC7646V1 Aggregation Switch
2.4 Data Center Deployment
The following gure illustrates the converged Ethernet data center deployment.
Spine
Leaf
Rack 1 Rack N End of Row
10GbE Fabric
100GbE Fabric
Data Center
VPN/MPLS
VPN/MPLS
VPN/MPLS
Data Center
Internet
Internet
(Figure 2-5: Data Center: Spine and Leaf Deployment)
BBU
BBU
BBU
Mobile Access
Network
AGC7646V1
Access Switch
10GbE
10GbE
10 GbE
Service
Provider
Core
Access Packet
Switch Network
AGC7646V1
Aggregaon Switch Provide Edge Router
Provide Edge Router
AGC7646V1
Aggregaon Switch
(Figure 2-6: Mobile Access Network Deployment)

• Appearance and MechanismChapter 2
9
2.5 Power Supply Modules
The power supply modules are hot-swappable power supply units (PSUs) for the switch.
You can install up to two PSUs. The PSUs operate in a load-sharing mode and provides 1+1
redundancy.
(Figure 2-7: Power Supply Unit)
NOTE:
1+1 redundancy is a system where a switch power supply is backed up by
another switch power supply in a load-sharing mode. If one power supply fails,
the other power supply takes over the full load of the switch.
WARNING:
• The switch includes plug-in power supply and fan tray modules that are
installed into its chassis. All modules have a front-to-back airow direction.
• Risk of explosion if battery is replaced by an incorrect type. Dispose of used
batteries according to the instructions.
• Remove the power cable from the module prior to removing the module
itself. Power cable must not be connected prior to insertion in the chassis or
equivalent.
AVERTISSEMENT:
• Le commutateur comporte des modules de bloc d’alimentation enchable
et de cassette de ventilation dans son châssis. La circulation d’air se fait de
l’avant vers l’arrière dans tous les modules.
• Risque d’explosion si la pile est remplacée par une de type différent. Suivez
les instructions pour éliminer les piles usées.
• Débranchez le câble d’alimentation du module avant de retirer ce dernier. Le
câble d’alimentation ne doit pas être branché avant l’insertion des modules
dans le châssis ou ailleurs.

10
AGC7646V1 Aggregation Switch
2.6 Fan Tray Module
The fan tray module is part of the switch air cooling system that provides cooling for the
switch. You must install the fan tray module in the switch that matches the airow direction
of the installed power supply unit.
(Figure 2-8: Fan Tray Module)

11
Chapter 3: Installation
3.1 Mounting
This switch can be mounted in a standard 19-inch equipment rack. Prior rack mounting the
switch, pay particular attention to the following factors:
•Mechanical Loading: Do not place any equipment on top of a rack-mounted unit.
•Circuit Overloading: Be sure that the supply circuit to the rack assembly is not overloaded.
•Grounding: Rack-mounted equipment should be properly grounded. Particular attention
should be given to supply connections other than direct connections to the mains.
To rack-mount devices with sliding rail:
1. Install the front mounting bracket to the device using the six M3 screws provided in the rack
mounting kit.
(Figure 3-1: Installing the Front Mounting Bracket)
2. Pull the inner rail out until it is fully extended, and then push the tab forward to release the
inner rail from the middle rail. Remove the inner rail.
NOTE:
Repeat the similar steps to extend another inner rail.
(Figure 3-2: Removing the Inner Rail)

12
AGC7646V1 Aggregation Switch
3. Align the hooks on the switch and the holes in the inner rail, and then slide the inner rail
backward until it is locked into place.
NOTE:
Repeat the similar steps to install another inner rail.
(Figure 3-3: Installing the Inner Rail on the Switch)
4. Push the middle rail back into the outer rail. Then repeat the similar step to assemble
another middle rail into the outer rail.
5. Making sure the L-shaped of the rear bracket is facing inward, align and push the rail rmly
into the rear rack until it clicks into place. Then pull the latch of the front bracket and align
the hooks with the front rack holes. Release the latch to lock the hooks into place.
NOTE:
Repeat the similar steps to install another outer rail.
(Figure 3-4: Installing the Outer Rail to the Rack)

• InstallationChapter 3
13
6. Once the mounting brackets are installed properly, pull the middle rails out until they are
fully extended, ensuring the ball retainer is securely locked. Then slide the inner rails on
the switch into the middle rails and push the switch all the way to the rear of the rack.
CAUTION:
Due to the switch’s weight, it should be installed by at least two people.
MISE EN GARDE:
À cause du poids du commutateur, au moins deux personnes doivent
l’installer.
(Figure 3-5: Installing the Front Mounting Bracket)
7. If installing a single switch only, go to “Connecting to a Power Source”.
8. If installing multiple switches, mount them in the rack, one below the other, in any order.

14
AGC7646V1 Aggregation Switch
3.2 Installing an Optional Transceiver and Cable
The SFP+ slots support the following optional transceivers and cables:
•10GBASE-SR
•10GBASE-LR
•10GBASE AOC
•10GBASE DAC
The QSFP28 slots support the following optional transceivers and cables:
•100G BASE-SR4
•100G BASE-LR4
•100G AOC (Active Optical Cable)
•100G DAC (Direct Attached Cable)
•100G to 4x25G AOC
•100G to 4x25G DAC
•40G BASE-SR
•40G BASE-LR4
•40G AOC (Active Optical Cable)
•40 DAC (Direct Attached Cable)
(Figure 3-6: Inserting an SFP+ Transceiver into a Slot)
(Figure 3-7: Inserting a QSFP28 or QSFP Transceiver into a Slot)
To install the SFP+, QSFP, or QSFP28 transceiver, follow these steps:
1. Consider network and cabling requirements to select an appropriate SFP+, QSFP, or
QSFP28 transceiver type.
2. Insert the transceiver with the optical connector facing outward and the slot connector
facing down. Note that SFP+, QSFP, or QSFP28 transceivers are keyed so they can only
be installed in one orientation.
