| Owner’s Manual
G O R D O N PPHOTO

WELCOME & CONGRATULATIONS
ON YOUR PURCHASE!
To help you get the most out of your paddling experience,
please take some time to read over this owner’s manual and
familiarize yourself with the many features and benefits of
owning a Delta Kayak.
At Delta Kayaks we are not only accomplished manufacturers,
but also passionate paddlers. We have combined our
extensive kayaking experience with innovative designs and
the most advanced materials and methods to create some
of the finest thermoformed kayaks available. Our focus on
detail is evident in both our kayaks’ appearance and perfor-
mance, and we are confident that you will enjoy your Delta
Kayak for many years to come.
|
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 2

| REGISTERING YOUR KAYAK
It’s time to register your new Delta Kayak as you have 30 days to register from
your date of purchase. To activate your 3-year limited warranty, please visit the
registration center on our website at the following address:
www.deltakayaks.com/owners-centre. Fill out the necessary information,
and you will receive a confirmation email once the activation is complete.
Delta Kayaks LTD. provides a limited 3-year warranty against material and
manufacturing defects to the original registered owner. Find out more details
on our warranty further in this document or on our website at
www.deltakayaks.com/owners-centre and click on the warranty tab.
| IMPORTANT INFORMATION ABOUT YOUR DELTA KAYAK
Please fill this out for your records and to help with your online registration:
D e a l e r n a m e w h e r e p u r c h a s e d : _________________________________________________________________________________
P r o v i n c e / S t a t e : _______________________________________ D a t e o f P u r c h a s e : _______________________________
M o d e l : _______________________________________________________ R u d d e r : Skeg:
C o l o u r : _______________________________________________________
S e r i a l # : _______________________________________________________ (12 alphanumeric digits IE:YGD12500A616)
Delta Customer Care: 1-877-888-6544 or [e-mail]
 BKNIGHTPHOTOS
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 3

| THE DELTA DIFFERENCE
Delta makes choosing the right kayak easy. As avid paddlers, we know that t, comfort
and performance are vital to experiencing the best that kayaking has to offer.
• The shape and designs of our kayaks are created using the latest computer modeling
and analysis software and years of paddling and manufacturing experience, ensuring
that each kayak performs at an optimal level for its intended use in varying conditions.
• All Delta Kayaks feature an extended waterline and pronounced keel to aid in tracking
and afford each model with appropriate stability for their intended purpose and target
paddler demographic.
• Optimizing your fit and comfort is quick and easy with our multi-position Contour II seat
system, adjustable SeaDog™ foot braces and integrated padded thigh braces.
• Deck fittings and bungee lines are recessed, hatches are flush-mounted for a sleek look
and no snag Design and carry handles are shock corded so they sit tight on the deck
while not in use.
• Bow and stern Press-Lock hatches are large and provide easy access into full volume dry
storage compartments. These hatches are sealed by curved and flanged watertight bulk-
heads elevating torsional rigidity and ensuring optimal buoyancy in case of capsize.
• Our low-profile Day Pod tucks out of the way yet provides ample storage and easy access
to snacks, binoculars, hydration etc.
• All rudder and skeg cables and lines are tubed and channelled out of sight and out of the
way eliminating the chance to snag them when loading or unloading hatches or when
moving about in the cockpit.
• Deltas’ clean-hull design features large pedal mounts securing the foot pedals inside
the cockpit, spreading the load on a larger surface and doing away with the need to
drill holes through the hull.
 DAVIDBOYLEDESIGN
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 4

| FEATURES
Take some time to learn about the
various components of your kayak.
NOTE: Not all models include or come
equipped with all parts shown.
1. Comfort Grab Handles They are dual density polymer with a comfortable rubber skin,
they are easy to grip even when wet and handled in colder weather.
2. Paddle Park Convenient system allows paddlers to secure the blade of their paddle
while rehydrating, taking a picture or having lunch. Makes retrieving your paddle quick
and easy in case of sudden need.
3. Press-Lock Hatch System Innovative, colour matched, hard-shell covers provide a
secure seal with easy on and off convenience. They also offer larger than average dry
storage access to facilitate loading and stowing of gear.
4. Day Pod Accessible and low profile, it’s perfectly placed to storeessentials you may
need to easily access during your paddle. Note: Water sensitive items should always
be stored in a waterproof case or bag.
5. Padded Thigh Braces Built-in and padded for comfort and added grip while bracing.
6 . Contour II Seat System Provides excellent back support in multiple positions.
Its quick and easy adjustment offers every paddler optimal comfort in an ultralight,
user-friendly design.
7. Locking Bar Located behind the cockpit rim on the back deck of the kayak. It allows
for easy and secure cable locking to your roof rack or trailer. Note: Not to be used as
a towing bar.
8. Paddle Float Rescue System Raised lines and scalloped deck make paddle float
re-entry quick and easy with a one-handed operation.
Model shown : Delta 15s
9. SternSpare Paddle Park Raised bungee lines make it easy to secure and access your
spare paddle when you need it.
10. Delta Rudder System Proprietary, lightweight aluminium rudder helps keep you on-
course, facilitating course corrections in wind and current.
11. Easy Rudder Up & Down Haul Static lines and large parrel beads allow you to
effortlessly locate and deploy the rudder even while wearing gloves. Snag free,
under-deck lines allow for a smooth deployment of the rudder in all conditions.
12. Perimeter Lines Our perimeter lines are shock corded and easy to grab with gloved
hands for safe retrieval of your kayak in case of capsize and aid in rescue situations.
13. Delta Skeg System Our skeg system is spring-loaded and easy to deploy. The skeg
aids in tracking and is available on all our performance touring models (in lieu of rudder) *
| NOT PICTURED
Bulkheads (located in cockpit behind seat) All our bulkheads are curved and anged
to enhance the torsional rigidity and strength of our kayaks. They also help to provide
a water-tight seal to the front and rear storage areas so your gear stays dry and add
buoyancy in case of capsize.
Inside Seam Construction Creates a stronger, stiffer, leak-proof seam and doubles as an
innovative cable tray for the rudder control tubes.
Sea-Dog™ Foot Braces Easy to adjust and durable foot braces. On models with rudders,
braces are gas pedal-style, enabling you to stay braced while steering with your feet.
*The Delta 15s does not come with a skeg option; included for reference.
11
21 3 4 5 6 7 8 8 9 10
1312
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 5

| GETTING TO KNOW YOUR KAYAK
Before you get on the water, it is important to take a few moments to
familiarize yourself with the unique features of your new Delta Kayak.
Carefully go over the different components of your kayak and the specifics
on how to properly adjust them before your rst outing. In the next sections,
you will learn about Tracking Sytems, Foot Brace adjustment, Hatch Systems
and our Contour I I Seat System. Each section will provide necessary information
on how to maximize your fit, comfort and performance by adjusting key
components and features. If you have any questions that may not be
answered by this document, please feel free to contact us by email at
[e-mail] or by phone at 1-877-888-6544.
 GREG JONES
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 6

| DELTA KAYAKS’ UNIQUE DESIGN & CONSTRUCTION
Delta Kayaks are moulded from a proprietary blend of highly specialized thermo-
plastic materials. The kayaks’ hull and deck are a multilayered construction featuring
a “Solarkote” exterior layer for the ultimate protection against fading and weathering.
This material gives our boats the high lustre finish, vibrant colors, and excellent
abrasion resistance that will provide many years of virtually maintenance-free
service. The substrate or secondary layer is a very tough high impact ABS thermo-
plastic providing a rugged backup to the Solarkote surface layer.
1. Solarkote™ Exterior Layer
Offers outstanding abrasion and UV resistance for long lasting, vibrant colours
and a high lustre, low friction nish.
2. ABS Secondary Layer
Provides high impact resistance, rigidity and a smooth interior nish.
These materials have a higher impact strength than composite berglass and gel
coats and are also easily polished or repaired if required. Unlike polyethylene kayaks,
our thermoformed kayaks are far less likely to deform in the sun or on your roof rack
due to a higher heat deection threshold. You will also nd our kayaks to be among
the lightest on the market making lifting and transporting easy to manage.
1
2
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 7

| HATCH SYSTEMS
When paddling you often want to bring a snack, extra clothing or camping gear if you are
heading out on an overnight or extended trip. We have outtted our kayaks with appropriately
sized hatches to t the gear we think you may need while using each particular model. These
hatches are sealed with rigid covers to ensure your gear is safe and secure during your outings.
It is important to note that all valuables should be inserted into waterproof containers or
bags before placing them in any compartment as there is always the possibility of water
inltrating into the hatches.
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 8

2
| HATCH SYSTEMS
Press-Lock Hatches
Our proprietary hard-shelled Press-Lock hatch covers are colour matched to the deck of your
kayak and are designed to provide a secure seal with easy on and off convenience. The hard-
shelled cover helps to increase the structural integrity of the deck and will not implode when
extra pressure is applied on the hatch during re-entry. It also guarantees the same UV protection
as the rest of the kayak. The Santoprene® rubber seal offers a superior seal plus UV, moisture
and mold resistance and has been designed to easily be replaced if an issue should arise.
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 9

| HATCH SYSTEMS
Press-Lock Hatches: How to use them
Due to the positive seal that these hatches offer, you will need a little leverage
to get them open.
Figure 1 – Locate the tab that tethers the hatch to the deck.
Figure 2 – Simply pull the tab down, then towards you to unhook.
Figure 3 – Pull with an upward motion until the hatch cover is unsealead.
Figure 4 – Once opened, load your gear and rmly place the hatch cover back
on the hatch rim.
Figure 5 – To close with a complete seal, place the hatch cover in place and
place both hands on top. Apply a little downward pressure, and use
a gentle twist or ‘wiggle’ to re-seal the cover.
If your Press-Lock hatches seem to be harder to get on and off over time,
we recommend the use of Armor All™ Original spray or wipes to clean and
lubricate the hatch seals for easy on and off operation.
1
2
3
4
4
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 10

| HATCH SYSTEMS
Quarter-Turn Hatch Covers
These hatch styles are found on our Delta 10AR and Cat 10.5 SOT (Sit-On-Top)
models (Figure 1). They are easy to operate and flush mounted so they are out
of the way. SEA-LECT Designs Quarter-Turn Hatch Covers are UV stabilized and
feature a new locking system that prevents over tightening, jamming and cross
threading. A specially engineered lubricated gasket is used in conjunction with a
knife edge for a leak tested seal. They are also tethered to the inside of the hatch
so there is little risk of losing them. (Figure 2) On the Delta Cat 10.5 SOT there is
also a removable nylon storage bag incorporated in the hatch for cleaning purposes.
Model shown: Delta Cat 10.5 SOT
2
1
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 11

| CONTOUR SEAT SYSTEM
Personalizing your t and comfort is simple with our feature rich,
multi-position Contour II Seat System. Its ergonomic design provides
optimum support with channel-vented foam cushioning for excellent
drainage and air ow.
Key features of the Contour II Seat System are:
1. Hi-Low Backrest Adjustment
2. Channel Venting
3. Contour Fit Kit Ready
4. Core Drainage
5. Multi-Position Seat Adjustment
The seat-pan and backrest are designed to conform to your body
and offer excellent ergonomic support. Self locking, hardware free
backrest adjustment allows for easy backrest height positioning
while in or out of your kayak. The Contour II Indexing System
makes it easy to slide the seat forward or back in 5 positions for
a personalized fit.
1
2
5
3
4
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 12

| CONTOUR SEAT SYSTEM
Seat Pan Adjustment
The Delta Contour II seat pan is designed to slide forward and back into 5 different positions.
This feature adjusts the distance to the foot braces, adjust the position of your thighs under
the thigh braces for maximum control, and adjust the trim of your kayak in cases where
you have distributed the weight of your load unevenly. By adjusting the seat pan to its
furthest rear position, entering and exiting your cockpit is made easier.
Backrest Adjustment
For back support, the backrest incline can be adjusted with the seat cord located on the
right side of the cockpit coaming. This cord runs through the backrest and adjusts with
a cleat. To adjust the backrest incline, release the cord from the cleat by pulling the cord
inward towards the centre of the cockpit. When a comfortable incline position is found,
lock the adjustment cord back into the cleat. To adjust the backrest height, simply pull
up or push down on the backrest and it will slide into the next position on the seat post.
You can also pull up or down on the tube located on the backside of the backrest and
move it up or down on the ladder. Once pressure is applied on the backrest, this tube
will seat itself into one of the positions on the seat post and secure in that position.
The adjustment of your backrest incline and height can be done while on shore or seated
in the cockpit while on the water.
TOP VIEW
BACK VIEW
1
1
1
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 13

| TRACKING SYSTEMS
Rudder
If your Delta Kayak is 14 feet or longer it may be equipped with our rudder system.
It is designed to help navigate your kayak through waterways and help keep your
kayak tracking straight in wind and currents. To lower the rudder blade into the
water, rst you must ensure the Rudder Locking clip has been lifted off the top of
the blade (Figure 1). The Up-haul and Down-haul are located directly underneath
your left elbow (Figure 2) Locate and grasp the ball furthest to the back of your
kayak and slide it forward (Figure 3). To bring the rudder blade back to its holder
on the deck, once again grab the ball that is furthest back and pull it forward.
When beaching your kayak, or pulling into shore, retract the rudder blade to
avoid damage.
Regularly ush out the track and pedal system with a hose to eliminate sand
and gravel to keep the pedal sliding freely.
To avoid damaging your kayak, DO NOT carry your kayak by the rudder.
For ruddered models we use a gas pedal-style foot brace system which allows
a constant brace and the ability to steer the kayak with only a slight push of the
balls of your feet.
1
2
3
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 14

| TRACKING SYSTEMS
Skeg
Our performance touring kayak models come with the option of a skeg system
instead of a rudder system. A skeg is located under the hull near the stern of your
kayak. It is deployed by a cord on the left side of the cockpit and secured by a
cleat. Simply release the cord from the cleat to deploy fully or in increments for
partial deployment as needed. The skeg is used to increase tracking but unlike
a rudder, does not help steer the kayak. Our skeg system is spring loaded so if
you do happen to go over a submerged object, it will retract into the skeg box and
spring back out when no longer obstructed. Our skeg uses a static cord instead
of a cable to eliminate any possibility of kinking.
For best practice, retract the skeg into the skeg box before beaching or when
launching to avoid potential damage to the skeg blade and box.
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 15

| FOOT BRACES
Foot Brace Adjustment
The balls of your feet should rest evenly against the foot braces (Figure 1)
Your knees should be slightly bent and resting on the padding that is positioned
under the thigh braces and the underside of the deck. Your legs should be in
a comfortable, relaxed and supported position.
Adjusting the distance between the seat and pedal is a simple procedure. Turn up
the ag in front of the foot pedal track to a 90° angle so it points to the middle of
the cockpit (Figure 2). This frees the locking lugs from the actual pedal. To move
the pedal forward or backward simply push or pull the pedal on its track until it is
in the desired position (Figure 3). This adjustment can be made using your foot or
your hand. Once in place, simply ip the ag lever to the down position to lock.
2
1
3
2
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 16

| SAFETY
There are always risks involved in watersports and kayaking is no exception.
It is very important to be aware of these risks before you go paddling. Although
kayaking can be a very safe and fun-lled activity, paddlers at the beginner stage
should note that they may be particularly at risk in unfavourable conditions, such
as bad weather or rough waters. It is important to learn how these conditions
affect kayaks and their operation. In addition, it is crucial to know how to re-enter
your kayak in the event of capsize, particularly if this happens in cold water.
It is also advised that you always paddle with a partner so that there is someone
available to assist you in the event of capsize or other emergencies. Wearing
a coastguard approved PFD (Personal Floatation Device) is vital to your safety
while paddling, as well as, the proper clothing for the appropriate conditions.
These are only preliminary guidelines and Delta Kayaks strongly recommends
that you take a course from a certied instructor and learn as much as you can
about kayaking to ensure your experience is as safe as possible.
Any person using kayaks built and/or sold by Delta Kayaks is personally responsible
for determining that their abilities are equal or superior to the conditions that they
may encounter during their outing and that exercising proper judgment in choice
of where and when to paddle is crucial to a safe paddling trip. Any paddler using
a Delta Kayak assumes all risks and takes complete responsibility for any and
all damages or injuries, including death, which may result from use of a Delta
Kayak.
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 17

| SAFETY EQUIPMENT
US and Canadian Coast Guard regulations require the following:
One Coastguard approved personal flotation device or life
jacket of appropriate size for each paddler
One buoyant heaving line of not less than 15m in length
A watertight ashlight or 3 approved ares of Type A, B or C
A sound signalling device (whistle or air horn)
A bailer or bilge pump
In addition, it is also recommended to carry the following
as supplemental safety gear:
Change of clothing in case of capsize
Water bottle
Energy bar
Sunscreen
First aid kit including safety blanket
Matches and fire starters
Float or Trip Plan
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 18

| CARE AND MAINTENANCE
Your Delta Kayak is designed to be as durable and maintenance-free as possible.
However, there are some simple measures you can take to ensure that your
kayak stays in the best condition possible giving you many years of use and
enjoyment. The built-in Solarkote nish resists against abrasion and harmful UV
rays. All that is required is washing with a soft cloth or sponge and warm soapy
water. Whenever possible, avoid dragging your kayak on rough or rocky surfaces.
If minor scuffs and abrasions do occur, we recommend the use of Novus Polish or
similar polishing products.
NEVER USE STRONG SOLVENTS, SUCH AS ACETONE OR LACQUER
THINNERS ON YOUR KAYAK AS THESE CAN SERIOUSLY DAMAGE THE FINISH
AND INTEGRITY OF THE POLYMER YOUR KAYAK IS CONSTRUCTED FROM.
After use in saltwater it is very important to thoroughly rinse your kayak with clean
freshwater to prevent salt and grime buildup. Pay particular attention to the rudder
system as this is where there are the most moving part. It is a good idea to flush
out the holes where the rudder cables enter the deck of the kayak.
Routinely check all deck lines and rudder cables for abrasion or wear. Replace
these as required. Contact the retailer where you purchased your kayak for infor-
mation on replacement parts.
WE DO NOT RECOMMEND THE USE OF 303 PROTECTANT ON OUR
BOATS AS IT IS KNOWN TO DEGRADE POLYMERS SUCH AS ABS. WE ARE
AWARE THAT MANY OF OUR DEALERS SELL 303 BUT WE ADVISE AGAINST
ITS USE.
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.CO M 20

| S T OR A GE
General Storage
Your kayak can be stored either right-side-up or upside-down. Ensure that you
have supports on or near the bulkheads. We recommend using padded supports
or straps that are a minimum of 1” in diameter to support your kayak on racks or
hanging from a suspended point. Before you store your kayak, it is important that
you have inspected and cleaned out sand and gravel underneath the seat and in
the side seat tracks. Make sure all salt water is thoroughly rinsed off. It is good
practice to use a Delta Kayaks cockpit cover during storage. It is best to store
your kayak out of direct sunlight whenever possible to further prolong the life of
your kayaks outfitting, seat padding and internal cockpit surfaces.
Do not cover cockpit or dry storage areas with hatches or seals until the in-
side of the kayak is completely dry as this may result in the formation of mold or
mildew
Do not suspend your kayak using the bow and stern grab loops. They are not
designed for this purpose.
EXPERIENCE THE DELTA DIFFERENCE | DELTAKAYAKS.COM 20
