Robalo R180 User manual
2013 R180 & R200 Owner’s Manual
OWNER’S/OPERATOR’S MANUAL
P.O. Drawer 928
300 Industrial Park Blvd.
Nashville, GA 31639
Phone: 229-686-7481 Fax: 229-686-3660
This manual has been compiled to help you operate your boat with safety
and pleasure. It contains details of the craft, typical equipment supplied
or fitted, its systems and information on its operation and maintenance.
Please read it carefully and familiarize yourself with your boat before us-
ing it.
If this is your first boat, or you are changing to a new type, for your own
comfort and safety please ensure that you obtain handling and operat-
ing experience before “assuming command” of the boat. Your dealer or
national sailing federation or yacht club will be pleased to advise you of
local sea schools or competent instructors.
Please keep this manual in a secure place and hand it over to the
new owner when you sell the craft.
For a complete list of standard and optional features and equipment, consult your local Robalo dealer. Due to a policy of continual product improvement, specifica-
tions are subject to change without notice. The weights and volumes shown are estimated and can vary from boat to boat because of equipment, etc.
Robalo boats meet or exceed both NMMA and U.S. Coast Guard standards.
Est. 3/12/13
https://www.boat-manuals.com/
ROBALO BOATS OWNER’S MANUAL
HAZARD COMMUNICATION LABELS i
INTRODUCTION 1-1
WELCOME ABOARD! 1-1
ABOUT THIS MANUAL 1-1
CONSTRUCTION & STANDARDS 1-2
RESPONSIBILITIES 1-4
LAWS AND REGULATIONS 1-5
OWNER’S LOGS AND RECORDS 1-6
WARRANTY POLICY TRANFER 1-6
BOAT DATA RECORD 1-7
FUEL USAGE CHART 1-8
TRAVEL PLAN LOG 1-9
OWNERSHIP TRANSFER RECORD 1-15
BOATING SAFETY 2-1
HAZARD COMMUNICATION 2-1
SAFETY RECOMMENDATIONS 2-1
SAFETY EQUIPMENT 2-4
RUNNING AND NAVIGATION LIGHTS 2-5
SAFETY AFLOAT 2-5
WATER SPORTS 2-12
SYSTEMS 3-1
ELECTRICAL SYSTEMS 3-1
FUEL SYSTEM 3-4
MARINE SANITATION DEVICES 3-4
COMPONENTS 4-1
DASHBOARD AND INSTRUMENT PANEL 4-1
HYDRAULIC STEERING SYSTEM 4-2
MULTIFUNCTION NAVIGATION DISPLAY SYSTEM 4-2
THROTTLE 4-2
CONTROLS 4-2
POWER TRIM 4-2
BILGE PUMP 4-3
RUNNING AND NAVIGATIONAL LIGHTS 4-3
STEREO SOUND SYSTEM 4-3
FIRE EXTINGUISHERS 4-3
UNDERWAY 5-1
TRANSPORTING YOUR BOAT 5-1
LAUNCHING AND LOADING 5-2
BOARDING YOUR BOAT 5-3
FUELING 5-4
OPERATING YOUR BOAT 5-6
ANCHORING YOUR BOAT 5-9
MOORING YOUR BOAT 5-10
SHUTTING DOWN THE ENGINE 5-10
PREVENTIVE MAINTENANCE AND REPAIR 6-1
ENGINE 6-1
TUNE-UP 6-2
FUEL SYSTEM 6-2
MONTHLY INSPECTION 6-2
OUTBOARD DRIVE UNIT 6-2
PROPELLERS 6-3
BILGE 6-3
TROUBLESHOOTING 7-1
INTERIOR AND EXTERIOR CARE 8-1
FIBERGLASS AND GELCOAT 8-1
HULL BOTTOM MAINTENANCE 8-2
BOTTOM PAINT (ANTI-FOULING) 8-2
DECK HARDWARE AND FITTINGS 8-2
WINDSHIELD AND PORTHOLE 8-3
CARPET 8-3
SEAT COVERINGS AND VINYL 8-3
CANVAS (WEATHER COVERINGS) 8-4
Table of Contents continued on next page
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com https://www.boat-manuals.com/
WINTERIZING AND STORAGE 9-1
LIFTING THE BOAT 9-1
DRY STORAGE AND PREPARATION 9-1
SYSTEMS AND COMPONENTS 9-2
ENGINE 9-2
FUEL SYSTEM 9-2
BATTERY 9-2
RECOMMISSIONING 9-3
NAUTICAL GLOSSARY 10-1
WARRANTY 11-1
WIRING SCHEMATICS 12-1
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com i
HAZARD COMMUNICATION LABELS
Some or all of the hazard communication labels shown on the following pages can be found in various locations on your boat. If your boat is missing
any of these labels, notify your Robalo dealer for replacement.
Note: Respective labels are determined by the standard and optional equipment actually installed on your boat upon delivery.
No ventilation is provided. Fuel vapors
are a fire and explosion hazard. To avoid
injury or death, do not store fuel or
flammable liquids here.
WARNING
!
056-0864
!
WARNING 056-0864
Avoid serious injury or death from fire
or explosion resulting from leaking fuel.
Inspect system for leaks
at least once a year.
WARNING
AVOID SERIOUS INJURY OR
DEATH FROM FIRE OR EXPLOSION
RESULTING FROM LEAKING FUEL.
INSPECT SYSTEMS FOR LEAKS
PRIOR TO USAGE OF BOAT
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com ii
LID MAY CLOSE SUDDENLY AND
MAY CAUSEDAMAGE TO BOAT,
AND/OR PERSONALINJURY
CHECK SURROUNDING AREABEFORE CLOSING UP0
WARNING
AVOID DAMAGE TO YOUR FUEL SYSTEM
DO NOT USE FUEL ORADDITIVES CONTAINING MORE
THAN 10% ALCOHOL BYVOLUME (Methanol or Ethanol)
DAMAGE AND LOSS OF WARRANTY MAY RESULT
WARNING
Carbon monoxide (CO) can cause brain damage or death.
Carbon monoxide can be present in the cabin.
Signs of carbon monoxide poisoning include nausea, headache,
dizziness, drowsiness, and lack of consciousness.
Get fresh air if anyone shows signs of carbon monoxide poisoning.
Get fresh air if carbon monoxide detector alarm sounds.
Carbon monoxide detector must be functioning at all times.
NW-205-05
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com iii
Waste Water Sewage Fresh Water Electrical Hazard
Fuel
!
Blower Warning
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com iv
DANGER
Carbon monoxide (CO) can cause brain damage
or death.
Engine and generator exhaust contains odorless
and colorless carbon monoxide gas.
Carbon monoxide will be around the back of the
boat when engines or generators are running.
Move to fresh air, if you feel nausea, headache,
dizziness, or drowsiness NW-206-06
CARBON MONOXIDE IS PRODUCED BY ALL GASOLINE ENGINES AND
GENERATOR SETS. AVOID BRAIN DAMAGE OR DEATH FROM CARBON
MONOXIDE. KEEP COCKPIT
AND CABIN AREAS WELL VENTILATED. AVOID BLOCKAGE OF EXHAUST
OUTLETS. SIGNS OF EXPOSURE INCLUDE NAUSEA, DIZZINESS, AND
DROWSINESS. SEE BOAT OWNER’S MANUAL FOR MORE DETAILS.
DANGER
DANGER
USING BOARDING LADDER WHILE ENGINE IS RUNNING CAN RESULT
IN SEVERE PERSONAL INJURY. TURN OFF ENGINE BEFORE USING LADDER
THE OPERATOR OF THIS VESSEL IS RESPONSIBLE FOR THE
ACTIONS OF PERSONS IN AND AROUND THIS VESSEL SAFETY IS
THE OPERATORS RESPONSIBILITY
USING SWIM PLATFORM, FORWARD SUN PAD, OR SUN DECK
WHILE BOAT IS UNDERWAY COULD RESULT IN SEVERE
PERSONAL INJURY. STOP BOAT AND TURN
OFF ENGINES BEFORE USING.
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com v
DISCHARGE OF OIL
PROHIBITED
THE FEDERAL WATER POLLUTION CONTROL ACT PROHIBITS THE DIS-
CHARGE OF OIL OR OILY WASTE INTO OR UPON THE NAVIGABLE
WATERS AND CONTIGUOUS ZONE OF THE UNITED STATES IF SUCH
DISCHARGE CAUSES A FILM OR SHEEN UPON, OR DISCOLORATION
OF, THE SURFACE OF THE WATER, OR CAUSES A SLUDGE OR EMUL-
SION BENEATH THE SURFACE OF THE WATER.
VIOLATORS ARE SUBJECT TO A
PENALTY OF $25,000
DANGER
WARNING
BOATMAN’S CHECKLIST
CARBON MONOXIDE IS PRODUCED BY ALL GASOLINE ENGINES
AND GENERATOR SETS. AVOID BRAIN DAMAGE OR DEATH
FROM CARBON MONOXIDE. KEEP COCKPIT AND CABIN AREAS
WELL VENTILATED. AVOID BLOCKAGE OF EXHAUST OUTLETS.
SIGNS OF EXPOSURE INCLUDE NAUSEA, DIZZINESS, AND
DROWSINESS. SEE BOAT OWNER’S MANUAL FOR MORE
DETAILS.
USING BOARDING LADDER WHILE ENGINE IS RUNNING CAN
RESULT IN SEVERE PERSONAL INJURY. TURN OFF ENGINE
BEFORE USING LADDER
THE OPERATOR OF THIS VESSEL IS RESPONSIBLE FOR THE
ACTIONS OF PERSON IN AND AROUND THIS VESSEL. SAFETY
IS THE OPERATOR’S RESPONSIBILITY.
USING SWIM PLATFORM, FORWARD DECK, OR SUN DECK
WHILE BOAT IS UNDERWAY COULD RESULT IN SEVERE
PERSONAL INJURY. STOP BOAT AND TURN
OFF ENGINES BEFORE USING.
AVOID SERIOUS OR FATAL INJURY DUE TO ROTATION OF SEAT.
LOCK SWIVEL WHEN SPEED EXCEEDS 5 M.P.H.
INTERRUPT SWITCH MUST BE ATTACHED TO OPERATOR WHILE
ENGINE IS RUNNING. QUALIFIED OPERATOR MUST BE IN
CONTROL AT ALL TIMES. READ OWNERS MANUAL BEFORE USE.
For maximum enjoyment and safety, check each of these items
BEFORE you start our engine:
DRAIN PLUG (Securely in place?)
LIFE-SAVING DEVICES (One for every person on board?)
STEERING SYSTEM (Working smoothly and properly?)
FUEL SYSTEM (Adequate fuel? Leaks? Fumes?)
BATTERY (Fully charged? Cable terminals clean and tight?)
ENGINE (In neutral?)
CAPACITY PLATE (Are you overloaded or overpowered?)
WEATHER CONDITIONS (Safe to go out?)
ELECTRICAL EQUIPMENT (Lights, horn, pump, etc.?)
EMERGENCY GEAR (Fire extinguisher, bailer, paddle, anchor
& line, signaling device, tool kit, etc?)
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com 1-1
INTRODUCTION
WELCOME ABOARD!
Congratulations!
on your wise decision to purchase a Robalo boat. We welcome you to
the family of thousands of other Robalo boat owners. Since your boat is a
substantial investment, we are sure you selected your Robalo because of
its value, style, comfort, and performance. This manual contains valuable
information concerning your boat’s operation, maintenance, and care
plus tips on boating safety and seamanship.
ABOUT THIS MANUAL
More and more people are joining the ranks of boat owners. This manual
is written for the first-time boat owner or operator. Even if you are an
experienced boater, you will find much valuable information regarding
the safe operation and maintenance of your new Robalo boat. Keep this
manual on your boat for ready reference.
Due to our policy of continuous product improvement, the illustrations
used in this manual may not be identical to the components, controls,
gauges, etc. on your boat, as they are intended to be representative ref-
erence views. Some controls, indicators, or information may be optional
and not included on your craft.
The precautions in this manual can’t and don’t cover every boating situ-
ation. If a specific method or procedure is not covered, you must make
sure that what you do is safe for you and others. Always use common
sense when boating! Remember, too, that every safe boating excursion
is a happy experience.
This manual is part of your boat’s equipment. Keep it on board the boat at
all times. If you transfer ownership of this boat to someone else, be sure
to give this manual to the new owner.
Your owner’s packet contains the manual for the boat you selected. Also
in this packet are instruction manuals from the suppliers of standard and
optional equipment for your boat. Examples of these manuals include
the engine, electrical equipment, pumps, and cabin amenities. The sup-
pliers of these products maintain their own manufacturer’s warranty and
service facilities. Be sure to fill out each warranty card and mail it to the
manufacturer to validate the warranty. Record all information regarding
these products on the “Boat Data Record.” A copy of this form is near the
end of this chapter under Logs & Records.
Important: Keep the completed Boat Data Record in a safe place at
home. Do not keep it aboard the boat.
Read this manual as well as the manuals for the systems and compo-
nents on your Robalo boat. They provide the information needed for safe
operation and proper maintenance. The information in the manuals pro-
vided by the manufacturers takes precedence over any information in this
manual if there is a conflict.
Following are summaries of each chapter in this manual:
1. Introduction
Included in this chapter is a summary of the manual plus general informa-
tion about construction and standards, dealer and owner responsibilities,
laws and regulations, logs and records, and the warranty for your boat.
2. Boating Safety
This chapter discusses potential hazards associated with boating, safety
recommendations, safety information and practices, and water sports
safety. It also discusses safety equipment needed to provide a safe op-
erating environment.
1
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com 1-2
Note: For your safety, this manual has specific safety warnings
and comments where appropriate. Be sure to read the entire
manual.
3. Systems
Here you will find detailed information about the electrical and fuel sys-
tems needed to operate your boat. This chapter discusses the fresh wa-
ter system and marine sanitation devices which make your boating expe-
rience more comfortable.
4. Components
Standard features and optional equipment for your Robalo boat are dis-
cussed in this chapter. In general, these pertain to equipment and ameni-
ties which make your boat a “home away from home.”
5. Underway
The intent of this chapter is to explain what you need to do before, dur-
ing, and after your boating excursion to make it an enjoyable and safe
experience.
6. Preventive Maintenance & Repairs
Preventive maintenance is the key to troublefree operation and helps
protect your investment. This chapter explains what you should do to
maintain your boat and how to make adjustments and repairs.
7. Troubleshooting
Every boater encounters an operating problem at one time or another.
This chapter provides solutions to problems you can correct.
8. Interior & Exterior Care
This chapter tells you how to inspect, clean, and maintain your boat’s
interior and exterior.
9. Winterizing & Storage
What do you do when you need to winterize or store your boat for extend-
ed periods of time? This chapter provides the necessary information.
10. Nautical Glossary
The Nautical Glossary defines terms associated with your boat and terms
you may encounter during your boating experience.
CONSTRUCTION & STANDARDS
All Robalo boats meet or exceed the construction standards set by
the U.S. Coast Guard, the National Marine Manufacturers Association
(NMMA), and the American Boat and Yacht Council (ABYC) concerning:
• Navigation lights
• Factory installed fuel systems
• Engine and fuel tank compartment ventilation
• Flotation
• Steering systems
• Backfire flame arresters
NMMA certification means that the boat complies with applicable fed-
eral regulations set forth by the U.S. Coast Guard. These regulations
are based on American Boat and Yacht Council (ABYC) standards and
recommended practices.
Most Robalo models can be certified to carry the CE mark. The CE mark
certifies that the boat meets relevant parts of the European Directive for
Recreational Craft 94/25/EC of the European Parliament, including the
International Organization for Standards (ISO) and Recreational Marine
Agreement Group (RMAG) guidelines in effect at the time of manufac-
ture.
We recommend that you see your dealer if you wish to modify factory–in-
stalled equipment or add new equipment. Your dealer is qualified to make
such modifications or additions without placing the safety or design integ-
rity of your boat at risk and without invalidating the warranty.
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com 1-3
Robalo builds exceptionally high quality boats. We offer numerous extras
you won’t see at a boat show. We’ve created a list for your review.
Gelcoat
The advanced technology polyester we use offers superior weathering
resistance to surface yellowing and chalking. It will also help protect and
maintain the original glossy luster of your boat’s finish. Robalo uses a
premium quality gelcoat which offers improved flexibility over other gel-
coats, minimizing the potential for cracking.
Resin
It’s an age-old problem. Water penetrates the gelcoat and blisters the
bottom. The key is the resin. To cut costs, most use a general purpose
resin. Robalo uses a premium quality resin in the hull skin coat of every
boat in our line because of its superior bonding characteristics and ex-
ceptional flex.
Plywood
To protect their wooden components from rot and deterioration, most
boat builders dip their plywood parts in a vat of protective sealant. Un-
fortunately, this only offers very minimal protection for the outside plies.
The plywood Robalo uses throughout our boats is pressure treated with a
wood preservative and fungi inhibiting chemical before it is kiln dried.
Loom Wrap Wiring
Attention to rigging detail is a Robalo hallmark. Instead of routing the
engine wiring harness haphazardly in the bilge in black tape, we rely on
automotive style flexguard loom that not only keeps things neat but also
protects against abrasion.
Through Bolted Stainless Steel Cleats
It’s one of the most often used components on your boat, but most people
think a cleat is a cleat, right? Wrong. Robalo’s cleats are stainless steel
so they won’t corrode and so they won’t twist. Also, ours are big enough
to accept a full-sized looped line.
Heavy Duty Rub Rail
A rub rail is supposed to protect your boat. Most don’t because they’re
the wrong material. Robalo uses a heavy-duty PVC rub rail with stainless
steel insert that absorbs far more impact without denting.
Acrylic Tops
Ours are acrylic because it’s a superior material that won’t crack, peel,
or mildew. Further, our acrylic tops won’t shrink or expand, which means
they look and fit better in all weather conditions.
Stain Resistant Fabrics
Accidents happen. Spilled drinks, wet bathing suits and soggy towels are
a fact of life on a boat. All our cabin fabrics are stain resistant. Buyers can
choose from a wide variety of colors. When it comes to interior fabrics, we
have the one that’s right for you.
Superior Plastics vs. Wood
Robalo prides itself on building seats that are not only comfortable, but
durable. We use plastic seats because they hold their shape and don’t
retain water, reducing the potential for foam deterioration.
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com 1-4
Flotation Requirements
All Robalo boats meet or exceed U.S. Coast Guard requirements for flo-
tation. All Robalo boats also meet or exceed U.S. Coast Guard require-
ments for the following:
• Engine and Fuel Tank Compartment Ventilation
(requirements for flame arresting devices)
• Factory-Installed Fuel Systems
• Navigation Lights
• Steering System
RESPONSIBILITIES
Robalo’s quality service does not end when you buy one of our boats.
Through our dealer network we do everything possible to ensure that you
are satisfied with your purchase. Every Robalo dealer has a responsibility
to you, the boater.
Dealer
Dealer responsibilities include the following:
1. Discuss with you the terms of all warranties and stress the importance
of registering warranties with the appropriate manufacturers.
2. Explain how you can obtain warranty service.
3. Complete new boat and pre-delivery inspection procedures.
Sign the form to certify that all items were completed.
Your Robalo dealer can provide you with thorough instruction in the op-
eration of your boat. Please feel free to ask for assistance.
Boat Owner
Your responsibilities include the following:
1. Read this manual as well as all other manuals and information in-
cluded in your owner’s packet.
2. Schedule an appointment with your dealer to go over all warranties.
After the appointment, complete the Robalo Boat limited warranty reg-
istration card in an envelope inside the Owner’s Manual packet. Keep a
record of the hull number for future reference.
3. Inspect the boat at the time of delivery to make sure all systems and
components are operating properly. Robalo recommends that you refer
to your engine warranty for initial inspection and service requirements.
The new boat and pre-delivery inspection form (found in your owner’s
manual) will help you as you inspect your new boat. After completing your
inspection, sign the form to certify you have inspected the boat with your
dealer.
4. Schedule an appointment with your dealer to go over the pre-delivery
engine service record. Sign this record to indicate your dealer has ex-
plained this record to you.
5. Operate all equipment in accordance with the manufacturer’s instruc-
tions.
6. Become familiar with all federal, state, and local laws affecting your
boat and its operation.
7. Perform or provide for the appropriate periodic maintenance outlined
in the manuals and service guides.
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com 1-5
LAWS AND REGULATIONS
This section of the manual includes general information about govern-
ment regulations. You, the boater, are responsible for complying with the
requirements of federal, state, and local laws. If you have any questions,
contact the U.S. Coast Guard or other appropriate authority.
Boat Registration
Federal and state laws require that every boat having propulsion ma-
chinery of any type must be registered in the main state of usage. Reg-
istration numbers and validation stickers must be displayed on the boat
according to regulations. The registration certificate must be carried on
board when the boat is in use.
Safety Equipment
The following equipment is required on all boats:
• Fire extinguishers
• Personal flotation devices (PFDs)
• Navigation lights
• Visual distress signals
• Sound signaling device
See Chapter 2 for more information about safety equipment.
Discharge of Oil
The Federal Water Pollution Control Act prohibits the discharge of oil or
oily waste into or upon the navigable waters of the United States or the
waters of the contiguous zone if such discharge causes a film or sheen
upon, or a discoloration of, the surface of the water or causes a sludge
or emulsion beneath the surface of the water. Violators are subject to a
penalty.
Disposal of Plastics & Other Garbage
Plastic refuse dumped in the water can kill fish and marine wildlife and
can foul vessel propellers and cooling water intakes. Other forms of wa-
terborne garbage can litter beaches and cause illness. U.S. Coast Guard
regulations therefore strictly prohibit dumping plastic refuse or other gar-
bage mixed with plastic into the water anywhere. Further, the regulations
restrict the dumping of other forms of garbage within 12 miles from shore
on the east coast, and 9 miles from shore on the west coast.
Within 3 miles of shore and in U.S. lakes, rivers, bays and sounds, it is
illegal to dump plastic, dunnage, lining, and packing materials that float;
and any garbage except dishwater, gray water, and fresh fish parts.
Between 3 and 12 miles it is illegal to dump plastic, dunnage, lining, and
packing materials that float; and any garbage not ground to less than one
square inch.
Between 12 and 25 miles it is illegal to dump plastic, dunnage, and pack-
ing materials that float.
Beyond 25 miles it is illegal to dump plastic.
The U.S. Coast Guard has issued these regulations to implement An-
nex V of the International Convention for the Prevention of Pollution from
Ships, 1973, commonly known as Annex V of the MARPOL (Marine Pol-
lution) Treaty 73/78. They apply to all U.S. vessels wherever they operate
(except waters under the exclusive jurisdiction of a state), and foreign
vessels operating in U.S. waters out to and including the Exclusive Eco-
nomic Zone (200 miles).
If your boat is 26 feet or more in length, the regulations require U.S. rec-
reational boaters attach one or more Coast Guard Trash Dumping Re-
strictions placards to your boat. The placard warns against the discharge
of plastic and other garbage within U.S. navigable waters and specifies
discharge restrictions beyond the territorial sea (generally within 3 or
more nautical miles of shore).
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com 1-6
The placard must also contain the warning that a person violating these
requirements is liable for civil and criminal penalties. The placard must
also state that local regulations may further restrict the discharge of gar-
bage. You may purchase these placards from local marinas, boat deal-
ers, or marine equipment suppliers.
The U.S. Coast Guard has also issued regulations requiring boats to
have a sanitation system on board to control pollution. Wastes are to be
stored in a holding tank or other device, such as a Porta-Potti, until the
device can be pumped out or otherwise disposed of at a shore facility.
Discharging this waste overboard is in most cases prohibited. Check with
the Coast Guard regarding regulations in your area.
OWNER’S LOGS AND RECORDS
At the end of this chapter are three forms which you will find very help-
ful.
Use the Boat Data Record to record all important information about your
boat and the major components installed. After you have entered all the
data, remove this form from your Owner’s Manual and store in a safe
place. Do not keep this form aboard your boat.
The Travel Plan Log provides a record of your destination, departure
and return times, boat description, passenger list, and other information
about the trip you have planned. At the bottom of the form is space for
listing emergency telephone numbers in case your return is delayed past
the expected time. It also has space for indicating information about the
person filing this report. Leave the completed form ashore with a respon-
sible person. We recommend you make several copies of this form each
boating season to ensure an ample supply.
The Fuel Usage Chart is a handy way to record information covering
engine hours, fuel consumption, miles traveled, as well as RPM (revolu-
tions per minute), Average MPH (miles per hour), and GPH (gallons per
hour).
WARRANTY POLICY TRANFER
Your Robalo boat is backed by a Limited Express Warranty. It is important
that you are aware of its terms. If a problem arises with your Robalo boat
as a result of workmanship or materials, contact your dealer as soon as
possible to determine whether correcting the problem may be covered by
the warranty. Please have your hull identification number and necessary
model numbers on hand for the items that may need service or repair.
Your hull identification number is below the rub rail on the starboard aft
corner of your boat.
The Robalo Limited Warranty Policy may be transferred to subsequent
owner(s) providing the Ownership Transfer Record (OTR) is completed
and returned to the Robalo Customer Service Office. The OTR is located
at the end of this chapter. Subsequent owner(s) will receive the balance
of warranty available subject to a $100.00 deductible per occurrence for
claims filed in accordance with the Robalo Limited Warranty Policy. The
Ownership Transfer fee is $500.00 for boats with hull lengths less than 26
feet and $1,000 for boats with hull lengths of 26 feet or more.
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com 1-7
BOAT DATA RECORD
Purchase Dealership Service Dea
l
e
r
s
h
i
p
Name
S
ales Manager
Name
S
ervice Manager
A
ddress
P
hone
A
ddress
P
hone
F
ax
F
ax
G
e
n
e
r
a
l
Fuel
S
ys
t
e
m
Ra
d
i
o
Model Name State of Registration
Hull Identification Number
Tank Capacity Filter Type
Fresh
W
a
t
e
r
Manufacturer Type
Model Number
Boat Name
Hull Color(s)
Tank Capaci
t
y
P
r
op
e
ll
e
r
Serial Number
Key N
u
m
b
e
r
s
Length Beam Weight Manufacturer Pitch Cabin
Draft (Drive Down) Draft (Drive Up)
Freeboard (Fore) Freeboard (Aft)
E
ng
i
n
e
Manufacturer Model Name/Number
Oil Type/SAE Quarts Filter Type
Model Number
B
a
tt
e
r
y
Manufacturer
Model Number
Glove Box
Ignition
• Design Category: A B C D
(circle one)
• Maximum Rated Engine Power — kilowatts (horsepower)
• Unladen
W
eigh
t
— kilograms (pounds)
• Maximum Load:
W
eigh
t
— kilograms (pounds)
Serial Number
Number o
fP
eople
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com 1-8
Date
RunTime
(
I
n
Hours)
Fuel
Used
(In
Gallons
)
Distance
Traveled
(In Miles)
RPM
Average Miles
Per hour
Gallons
per Hour
Date
RunTime
(In Hours)
Fuel
Used
(In
Gallons)
Distance
Traveled
(In Miles)
RPM
Average Miles
Per hour
Gallons
per Hour
FUEL USAGE CHART
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com 1-9
Full Name
Age/Se
x
Phone Numbe
r
Complete Address
Full Name
Phone NumberAge/Se
x
Complete Address
The boat listed below
should
return
b
y
:
at the
latest.
P
o
li
c
e
C
o
a
s
t
G
u
a
r
d
Da
t
eTime
If it has not, please call the
emergency
nu
m
b
e
r
s
listed at the
r
i
gh
t
.
O
t
h
e
r
Au
t
ho
r
i
t
y
P
e
r
s
on
a
l
Trip
I
n
f
o
r
m
a
t
i
on
E
ng
i
n
e Passenger List
(Use Another Sheet
If
N
e
c
e
ss
a
r
y
)
Departure Date/Time Departure Location Type HP
Return Date/Time Return Location Fuel Type Fuel Capacity
Boat De
sc
r
i
p
t
i
on
Safety &
Emergency
E
qu
i
p
m
e
n
t
(YES/NO & NUMBER)
Full Name
Boat Name Type Life Jackets Cushions Distress Light Age/Sex Phone Number
Registration Number Manufacturer
Complete
A
ddress
F
lares
S
moke
S
ignals
F
lash Ligh
t
Length Mirror Paddles Anchor
Hull Color Deck (Color)
Cabin (Color) Trim (Color)
Food Water Life Raft
Ra
d
i
o
Other Physical Characteristics
Onboard (Yes/No) Type
Full Name
Age/Sex Phone Number
Complete Address
Frequencies usually used or moni
t
ored
ALWAYS
FILL THIS SHEET OUT COMPLETELY—IN AN EMERGENCY ALL INFORMATION MAY BE HELPFUL
TRAVEL PLAN LOG
https://www.boat-manuals.com/
Boat ID Number
Boat Model: Date of Sale:
Dealer Name: City State
Owner Name: Delivery Promise Date/Time Sales Person
CHECK BOXES BELOW AS NEEDED CHECK BOXES BELOW AS NEEDED
OK OK
NEEDS CORRECTION NEEDS CORRECTION
COMPLETED COMPLETED
Boat: After Starting Engine (in water or tank test):
B
oa
t
ge
l
coa
t
an
d
s
t
r
i
p
i
ng
T
r
i
m gauge sync
U
p
h
o
l
s
t
ery c
l
ean an
d
f
ree o
f
d
e
f
ec
t
s
Ch
ec
k
f
ue
l
li
ne connec
t
ors
f
or
l
ea
k
s
Wi
n
d
s
hi
e
ld
a
li
gnmen
t
Idli
ng spee
d
se
t
w
ithi
n proper range
f
or eng
i
ne
C
anvas
Fit
G
ear s
hift
wor
k
s proper
l
y
f
orwar
d
, reverse, neu
t
ra
l
Cl
earcoa
t
remova
l
f
rom
t
ape s
t
r
i
pes
I
ns
t
rumen
t
s reg
i
s
t
er proper
ly
Ch
ec
k
ca
bi
n
/
conso
l
e
d
oors,
h
a
t
c
h
es, ca
bi
ne
t
s an
d
h
ea
d
d
oors,
l
a
t
c
h
es
E
ng
i
ne emergency s
h
u
t
o
ff
, eng
i
ne s
t
ops w
h
en
di
sconnec
t
e
d
wor
k
smoo
thl
y,
H
-
t
op an
d
T
-
t
op
d
oors
&
l
a
t
c
h
es wor
k
proper
l
y.
W
a
t
er
i
s com
i
ng ou
t
o
f
p
it
o
t
t
u
b
e proper
l
y
Ch
ec
k
a
ll
th
ru
h
u
ll
fitti
ngs, van
it
y
d
ra
i
n, ga
ll
ey
d
ra
i
n,
anc
h
or we
ll
d
ra
i
n,
d
ra
i
n p
l
ug-
h
u
ll
,
t
o
il
e
t
h
oses,
li
vewe
ll
E
ng
i
ne c
h
arg
i
ng
b
a
tt
er
i
es proper
ly
Equipment: Running Water Test:
TV/DVD VHF Radio Horn
B
oa
t
per
f
ormance
Filler Cushion Fit Bilge Pumps Wipers
P
or
t
eng
i
ne per
f
ormance
Running Light Auto bilge floats Bilge Blowe
r
St
ar
b
oar
d
eng
i
ne per
f
ormance
Cabin Light Stove operates Dockside Power
St
eer
i
ng opera
t
es
f
ree
ly
Mast Light Generator Refrigerator
F
ue
l
fl
ow wor
ki
ng correc
tly
Cockpit Lights Air Conditioner Steering oil level
P
ower s
t
eer
i
ng opera
t
es correc
tl
y
(if
equ
i
ppe
d)
Spreader Lights Tables & Legs CO Detector
T
r
i
m
t
a
b
s opera
t
e correc
tl
y
Stereo Microwave Toilet Operates
E
ng
i
ne
t
r
i
ms correc
tly
Stereo Remote Trim Tabs Bow Thruste
r
I
ns
t
rumen
t
s reg
i
s
t
er proper
ly
Anchor/Rode Windlass VHF Radio
Li
vewe
ll
sys
t
ems opera
t
e correc
tly
Overhead Lights Livewell Pumps Fishbox Pumps
R
ev
i
ew gauge opera
ti
on
Check water heater system Water & waste winterized
Water pressure system operates (Let pressure stand 15 minutes to see if pump goes on)
All
accessory equ
i
pmen
t
opera
t
es an
d
on
b
oar
d
En
g
ine: Carpets installed
Ch
ec
k
f
ue
l
sys
t
em
f
or
l
ea
k
s
All
b
oa
t
, eng
i
ne, an
d
accessory
lit
era
t
ure an
d
manua
l
s rea
dy
P
r
i
mary s
t
eer
i
ng sys
t
em comp
l
e
t
e opera
ti
ona
l
c
h
ec
k
O
wner
f
am
ili
ar
i
ze
d
w
ith
opera
ti
on an
d
warran
t
y po
li
c
y
St
eer
i
ng sys
t
em purge
d
correc
tly
W
arran
t
y car
d
s comp
l
e
t
e
d
an
d
ma
il
e
d
f
or owne
r
Th
ro
ttl
e con
t
ro
l
ca
bl
e,
t
rave
l
, an
d
a
tt
ac
h
e
d
f
as
t
eners
B
oa
t
proper
l
y c
l
eane
d
,
i
n
t
er
i
or an
d
ex
t
er
i
o
r
Shift
er con
t
ro
l
ca
bl
e,
t
rave
l
, an
d
a
tt
ac
hi
ng
f
as
t
eners
P
rop
i
ns
t
a
ll
e
d
proper
l
y w
ith
nu
t
,
k
eys, co
tt
er p
i
ns Above services
performed by
P
rop
Si
ze:
P
or
t
_
_______________
_
Stbd
_
_______________
_
Technician Date
P
rop ro
t
a
ti
on
D
ea
l
er commen
t
s
(
re
f
er
t
o c
h
ec
kli
s
t
b
y
it
em
)
S
a
f
e
t
y neu
t
ra
l
sw
it
c
h
, eng
i
ne w
ill
no
t
s
t
ar
t
i
n gea
r
E
ng
i
ne emergency s
h
u
t
o
ff
, eng
i
ne w
ill
no
t
s
t
ar
t
w
h
en
di
sconnec
t
e
d
Ri
gg
i
ng
h
oses an
d
f
ue
l
pr
i
mer
b
u
lb
s proper
l
y rou
t
e
d
C
us
t
omer
Si
gna
t
ure
B
a
tt
ery ca
bl
es an
d
groun
d
w
i
res connec
t
e
d
proper
ly
C
ommen
t
s
DEALER COPY (WHITE) / CUSTOMER COPY (YELLOW)
CUSTOMER SATISFACTION
CHECK, INSPECT AND PERFORM THE FOLLOWING OPERATIONS
PRE-DELIVERY FINAL CHECK
OPERATION RECORD (PDOR)
NEW BOAT AND PRE-DELIVER
Y
https://www.boat-manuals.com/
+A:6H:8DBEA:I:I=:;DAADL>C<>C;DGB6I>DC6C9G:IJGCID-D76ADL>I=I=:8DGG:8IIG6CH;:G;::6BDJCI6C9
68DEND;I=:7>AAD;H6A: DGDI=:G:K>9:C8:D;EJG8=6H:L>I=>C96NH6;I:GEJG8=6H:;GDBI=:DG><>C6A
G:I6>AEJG8=6H:G:GI>;>:9=:8@HDGBDC:NDG9:GHH=DJA97:B69:E6N67A:ID-D76ADD6IH
55555555555555555555555555555555 55555555555555555555555555555555555
)&&#(+#& &#'&$
&'' &''
(,(( % (,(( %
)!!#( ( $#)"& ($!
#()& #()&
/DG:<>HI:GI=:IG6CH;:GI=:H:8DC9EJG8=6H:GBJHIB6>AI=:;DAADL>C<ID-D76AD 26GG6CIN/G6CH;:G
+*G6L:G)6H=K>AA:"CDA6I:GI=6CI=>GIN96NH6;I:GI=:EJG8=6H:;GDBI=:
,/'%'+) EJG8=6H:GC*LC:GH=>E/G6CH;:G-:8DG98DBEA:I:97NI=: ,/'%'+)-2/!&0#/ 6C9I=:
HJ7H:FJ:CIDLC:G8DEND;I=:7>AAD;H6A:DGDI=:G:K>9:C8:D;EJG8=6H:D;I=:7D6I;GDBI=:
,/'%'+) EJG8=6H:G>C8AJ9>C<I=:BD9:A6C9=JAA>9:CI>;>86I>DCCJB7:G6C9I=:L6GG6CINIG6CH;:G;::
6H;DAADLH
;DG6CN=JAAA:C<I=A:HHI=6C ;::I
;DG6CN=JAAA:C<I= ;::IDG<G:6I:G
)DI:IG6CH;:G;::H6G:L6>K:9;DG:6A:G:BDCHIG6IDGD6IH
0EDCG:8:>EID;I=>HIG6CH;:GG:8DG9I=:C:LDLC:GH=6AAG:8:>K:I=:DJIHI6C9>C<76A6C8:D;I=:*)
4 -/-).! -' '$($/ 2--)/46C9I=:!$1 4 -/-).! -'
'$($/ ./-0/0-'#0''2--)/4>C>I>6I:97NI=:DG><>C6AEJG8=6H:G 2 0#.2#+1
,4+#/01,1&#,/'%'+)-2/!&0#/0&)) #/#0-,+0' )#$,/"#"2!1' )#-#/,!!2//#+!#$,/+5
!)'*$')#"'+!!,/"+!#4'1&1&#, ),'*'1#"//+15,)'!5
+A:6H:G:;:GIDI=:-D76AD*LC:GH(6CJ6A;DG9:I6>A:9EGDK>H>DCH8DC8:GC>C<I=:-D76AD'>B>I:96C9
.IGJ8IJG6A26GG6CIN+DA>8>:H-D76ADD6IH''G:H:GK:HI=:G><=IID9:CNIG6CH;:GD;L6GG6CINID
HJ7H:FJ:CIDLC:GH
,J:HI>DCH8DC8:GC>C<I=:-D76AD26GG6CIN+DA>8NH=DJA97:HJ7B>II:9>CLG>I>C<IDI=:-D76AD
JHIDB:G.:GK>8:*;;>8:+*DM)6H=K>AA:"
https://www.boat-manuals.com/
2013 Robalo R180 & R200 Owner’s Manual
Robalo Boats, LLC
Nashville, GA
robalo.com 2-1
BOATING SAFETY
YOU are responsible for your safety and your boat, as well as the safety
of passengers and other boaters.
HAZARD COMMUNICATION
As you read this manual, please note the hazard warnings which alert
you to safety precautions related to unsafe conditions or operating pro-
cedures. We have included these warnings because we are concerned
about your safety and the safety of your passengers. Hazard statements
generally have five parts:
1. The hazard symbol
2. A signal word which indicates the severity of the hazard
3. A concise description of the hazard
4. The results of ignoring the hazard
5. Steps for avoiding the hazard
The three signal words indicating the severity of the hazard are danger,
warning, and caution. The meanings they convey are as follows:
DANGER: calls attention to immediate hazards that WILL
result in severe personal injury or death.
WARNING: identifies hazards or unsafe practices that
COULD result in severe personal injury or death.
CAUTION: indicates hazards or unsafe practices that COULD
result in minor personal injury or product or property damage.
Note: This is a general advisory statement relating to equipment opera-
tion and maintenance procedures. Its intent is to call attention to informa-
tion more important than normal text.
SAFETY RECOMMENDATIONS
The popularity of boating and other water sports has grown tremendously
in the past few years. Boating safety and the safety of your passengers
are your responsibilities. You should fully understand and become famil-
iar with the operating procedures and safety precautions in this manual
and the other manuals in the owner’s packet before you launch your
Robalo boat.
Remember that along with the freedom and exhilaration of boating comes
the responsibility that you have for the safety of your passengers and the
other boaters who share the water with you. Throughout this manual spe-
cific precautions and symbols identify safety-related information. Be sure
to pay close attention to them.
2
https://www.boat-manuals.com/
This manual suits for next models
1
Table of contents
Other Robalo Boat manuals
