Aqua-Marina BETTA BE-312 User manual

For your own safety and that of your equipment,
make sure to take the following precautions. Failure
to follow warning notices and instruction may result
in property damage, serious injury or death.
WARNING
USER’S GUIDE
INFLATABLE
KAYAK & CANOE
EN

2
GENERAL INFORMATION
SAFETY
Kayak sports can be very dangerous and physically demanding. The users of this
product should understand participating in kayak sports may involve serious injury or
death. Observe all applicable watercraft laws, and use common sense.
PLEASE KEEP THIS MANUAL IN A SECURE PLACE, AND HAND IT OVER TO THE NEW OWNER
WHEN YOU SELL THE CRAFT. RECORD THE “HULL IDENTIFICATION NUMBER” (HIN) WHICH
IS PRINTED ON THE KAYAK’S HULL IN THE FOLLOWING BOX:
MANUFACTURER’S CERTIFICATION
AM kayak products comply with the ISO 6185 standard established by International
Organization for Standardization.
SAFETY CHECK LIST AND SAFETY WARNING
• It is the owner’s responsibility to carefully read the manual and instruct all users in safe
operation of this product.
• Retain owner’s manual for future reference.
• Get kayak instruction specific to this type of craft.
• Follow the instructions in the Owner’s Manual, including the data given on the
capacity plate. Uneven distribution of people or loads in the kayak could result in
danger.
• Use caution when stepping or climbing aboard the kayak. Step into the center of the
kayak for maximum stability.
• Always wear an approved Personal Flotation Device (Life Preserver).
• Wear a helmet when appropriate.
• Do not use in high wind, strong currents, open water or dangerous tides.
• Do not paddle in flood conditions.
• Do not use this product under the influence of alcohol or drugs.
• Do not overload or over inflate
• Do not exceed your paddling ability; be honest with yourself.
• Never tow from another boat or vehicle.
• Know and follow local water safety rules and boating regulations.
• Not a life saving device.
• Not for use by children without adult supervision.
• DO NOT exceed the data given on the capacity plates.
• BEWARE OF OFFSHORE WINDS AND CURRENTS.

3
1
3
2
4
5
6
7
MANUFACTURER’S RECOMMENDATION
The total number of persons and total weight shall not exceed the limits printed on the
kayak. Please refer to the kayak’s hull label for the actual specifications of your product.
KAYAK LABEL FORMAT
1. Standard: EN ISO 6185 PART 1 TYPE III
BS EN ISO 6185 PART1 TYPE III
2. Country of origin
3. Maximum passengers
4. Manufacturer’s recommended maximum load capacity
5. Manufacturer’s recommended working pressure
6. Hull identification number (HIN)
7. Manufacturer’s name and address

4
BETTA
PART LIST
b
j
l
mno
k
b
ac
a
e
d
f
ib
d
g
f
f
h
ib
Safety grab rope
D-rings for the seat and foot brace
Adjustable footrest
(BE-312/BE-412/BE-475 x 1)
a
b
c
d
Integrated drain valve
(BE-312 1+2, BE-412/BE-475 1+4)
e
Valve for I-beam floor
f
High pressure recessed valve for quick
and easy inflation and deflation
g
h
Pressure gauge
i
j
k
l
mSlide-in kayak fin x 2
n
Repair kit (Adaptor for high pressure valve/
Transparent scale/ Repair patch/ Wrench/
Transparent deflation pipe)
o
Inflatable cushion seat
(BE-312 x 1, BE-412 x 2, BE-475 x 3)
Carry bag
pPaddle (BE-312 x 1, BE-412 x 2, BE-475 x 3)
Strong inflatable I-beam floor
Durable rubber carry handle
Max
p
11” foot pump with inflation hose
Extended water splash guard bow design
with hard nose protection

PART LIST
5
LAXO
Extended water splash guard bow design
Zipper of hull covers
D-rings for seat connection
Cargo bungee cord
a
b
c
d
Durable rubber carry handle
Boston valve for the hull
e
11” foot pump with inflation hose
Velcro for removable high-back seat
f
g
h
Slide-in kayak fin x 2
Kayak zip backpack
Pressure gauge
i
j
Durable high-back seat
(LA-285 x 1, LA-320 x 2, LA-380 x 3)
k
Kayak paddle
(LA-285 x 1, LA-320/LA-380 x 2)
l
Repair patch
m
n
o
Strong inflatable I-beam floor
n
a
e
c
c
d
b
b
dg
o
k
j
i
m
l
e
g
a
f
h
b
e

PART LIST
b
b
c
e
e
e
d
Strong inflatable I-beam floor
h
l
i
k
g
6
RIPPLE
Extended water splash guard bow design
D-rings for seat connection
Cargo bungee cord
Durable rubber carry handle
Boston valve for the hull
11” foot pump with inflation hose
Kayak zip backpack
Pressure gauge
a
b
c
d
e
f
g
h
Slide-in kayak fin x 2i
j
Durable inflatable high-back seat x 3
k
RIPPLE -TECH paddle x 2
l
m
Repair kit (Repair patch/ Transparent deflation pipe)
m
j
a
a
a
f
f

PART LIST
p
c
c
f
b
b
7
MEMBA
Extended water splash guard bow design
Zipper of hull covers
D-rings for seat connection
Cargo bungee cord
a
b
c
d
Velcro paddle holder design
Durable rubber carry handle
e
High pressure recessed valve for quick and
easy inflation and deflation
Kayak paddle
(ME-330 x 1, ME-390 x 2)
7cm drop-stitch air deck floor
f
g
h
16” hand pump with inflation hose & gauge
Velcro for removable high-back seat
i
j
k
l
Slide-in kayak fin x 2
m
Kayak zip backpack
n
o
Repair kit (Adaptor for high pressure
valve/ Repair patch/ Wrench)
p
Durable high-back seat
(ME-330 x 1, ME-390 x 2)
Integrated drain valve
m
n
k
o
a
a
g
g
ed
d
i
i
e
j
e
f
h
ei
l

8
STEAM
PART LIST
lm
n
a
ddej
f
f
k
g
f
c
d
i
i
e
d
c
hhi
Adjustable footrest (ST-312 x1, ST-412 x 2)
High pressure recessed valve for quick
and easy inflation and deflation
D-rings for the seat
b
Extended water splash guard bow design
with hard nose protection
a
c
d
e
Durable rubber carry handlef
Superfast self-bailing drain valves
(ST-312 1+8, ST-412 1+16)
g
Velcro for removable high-back seat
h
i
Stern elastic bungee cord design
j
16” hand pump with inflation hose & gauge
Deck Shield
k
l
m
nSlide-in kayak fin x 2
o
p
Repair kit (Adaptor for high pressure
valve/ Repair patch/ Wrench)
Durable removable high-back seat
(ST-312 x 1, ST-412 x 2)
Kayak zip backpack
10L Dry bag
7cm drop-stitch air deck floor
p
o
i
b
b

9
Model
312cm
(10’3”)
BETTA
BE-312
BETTA
BE-412
STEAM
ST-312
STEAM
ST-412
80cm
(31”)
80cm
(31”)
90cm
(35”)
90cm
(35”)
1
2
1
2
2+1
2+1
2+1
2+1
110kg
(242 lbs)
8.5kg
(18.7lbs)
11.8kg
(26lbs)
11.5kg
(25.4lbs)
15.5kg
(34.2lbs)
Length Width Max.
Passenger Capacity Net Weight
SPECIFICATIONS
412cm
(13’6”)
312cm
(10’3”)
412cm
(13’6”)
180kg
(396 lbs)
BETTA
BE-475
80cm
(31”) 32+1
15kg
(33.1lbs)
475cm
(15’7”)
230kg
(507 lbs)
110kg
(242 lbs)
180kg
(396 lbs)
Air
Chambers
285 cm
(9’4”)
LAXO
LA-285 90cm
(35”) 12+1
110 kg
(242 lbs)
11.5 kg
25.4 lbs
320 cm
(10’6”)
LAXO
LA-320
90cm
(35”) 22+1
180 kg
(396 lbs)
12 kg
26.5 lbs
380 cm
(12’6”)
LAXO
LA-380
90cm
(35”) 2+1 2+1
210 kg
(462 lbs)
17.5 kg
38.6 lbs
370 cm
(12’2”)
RIPPLE
RI-370
85cm
(33”) 32+1
230 kg
(507 lbs)
18.5 kg
40.8 lbs
330 cm
(10’10”)
MEMBA
ME-330
90cm
(35”) 12+1
110 kg
(242 lbs)
13.4 kg
29.5 lbs
390 cm
(12’10”)
MEMBA
ME-390
90cm
(35”) 22+1
180 kg
(396 lbs)
17 kg
37.5 lbs

10
INSTRUCTION FOR ASSEMBLING AND DISASSEMBLING
Unfold the KAYAK from the packaging box.
Unfold the Aqua Marina kayak on a clean and smooth space and lay it out flat.
PINCH VALVE (For BETTA’s floor)
BOSTON VALVE (For LAXO/ RIPPLE)
HIGH PRESSURE VALVE
(For BETTA/ MEMBA/ STEAM)
11” FOOT PUMP FOR BETTA/ LAXO/ RIPPLE 16” HAND PUMP FOR MEMBA/ STEAM
INFLATE INFLATE
INFLATION
1.
Attach the pump hose to the pump and secure it tightly.
2.
Connect the pump hose to the valve for inflation.
3.
Step 2
Step 1 Upper cap
Main valve
Ring plate
Upper Cap
Open external cap and pull firmly to
extend out.
Unscrew the valve cap, push button in
and turn 90 degrees to make sure that
the valve button pops up to the “UP
position” for inflation.
Step1: Ensure that the main valve is securely
screwed into the ring plate first.
Step2: Open the upper cap of the Boston
valve for inflation.
In this situation, the valve only lets air
in, not out.
UP POSITIONUP POSITION

11
PARTIALLY INFLATE THE SIDE CHAMBERS AND THE KAYAK FLOOR AND CHECK
THAT THE FLOOR IS TUCKED UNDERNEATH THE SIDES.
IMPORTANT! Pleaseusethescale transparency(comewiththe repairkitsbag)tocheckifthe kayakfloorisproperly inflated.Theblacklinein belowshouldNOTbelonger thantheMAX.scale.
IMPORTANT!
Pleaseuse the scale
transparency(come with the
repairkits bag) to check if the
kayakfloor is properly
inflated.The black line in
belowshould NOT be longer
thanthe MAX. scale.
BETTA
Floor
Inflation Sequence Side Chambers
1.45psi / 0.1bar Refer to the transparent scale.*
Floor →Side Chambers
Floor →Side Chambers
Floor →Side Chambers
Side Chambers → Floor
Side Chambers → Floor
1psi / 0.07bar 1psi / 0.07bar
LAXO
1psi / 0.07bar 1psi / 0.07bar RIPPLE
1psi / 0.07bar 4.35psi / 0.3bar MEMBA
1.45psi / 0.1bar 4.35psi / 0.3bar STEAM
11” Foot Pump for BETTA/ LAXO/ RIPPLE 16” Hand Pump for MEMBA/ STEAM
NOTE: For STEAM/MEMBA/RIPPLE, remember to install the air deck floor before inflation.
Start pumping air into the side chambers and the floor of the kayak according to the
inflation sequence as suggested in the below table.
4.
Once inflated, firmly cap each valve.
5.
WARNING: Do not leave your kayak/canoe under direct sunlight as this may cause over-inflation!
Keep inflating until the required air pressure is reached. DO NOT OVERFILL!
TIP: Working pressure of each part should NOT exceed the maximum as below.
NOTE： After multiple times of inflation – deflation, there may be slight displacement of the valve.
Replace it to the correct position when deflated. Then inflate to required air pressure to use.
TIP: If the pump piston starts to squeak, apply some spray silicone on the piston shaft.
*IMPORTANT!
For BETTA, please use the transparent scale (come with the
repair kit bag) to check if the kayak floor is properly inflated.
The black line should NOT be longer than the MAX. scale.

12
BETTA/ RIPPLE
1. Inflate the seat with the foot pump.
2. Once seat position is confirmed, connect the seat straps to the D-rings by using
strap buckles. Attach the upper straps to the D-rings forward of each seat.
LAXO/ MEMBA/ STEAM
1. Attach the seat to the kayak floor with Velcro.
2. Once seat position is confirmed, connect the seat straps to the D-rings by using
strap buckles. Attach the upper straps to the D-rings forward of each seat.
NOTE:
1. It is important to place the seat in the right place to evenly balance the boat
when in the water. A solo paddler should be slightly aft of the boat’s center.
With two paddlers, the heavier one should sit toward the rear.
2. Seat position could be easily adjusted by clipping strap buckles to different
D-rings, and strap buckles may be clipped to the same D-ring if needed.
SEAT INSTALLATION

BOSTON VALVE (For LAXO/ RIPPLE)
13
Turn the kayak over. Slide the kayak fin into the fin box and insert the push-in pin.
NOTE: The kayak fins need to be installed if you use the kayak on flat water.
DO NOT USE KAYAK FINS IN WHITE WATER.
WHEN USING THE KAYAK IN FLAT-WATER, SCREW THE DRAIN CAPS DOWN TIGHTLY. OPEN THE
CAPS BEFORE ENTERING WHITEWATER. THE KAYAK WILL BE PARTIALLY FILLED WITH WATER
WHEN THE DRAIN VALVES ARE OPEN.
TIPS:
WHEN OPENING THE DRAINS, TUCK THE CAPS UNDERNEATH THE INFLATABLE FLOOR SO THEY
DO NOT BLOCK THE OPENING AS WATER DRAINS OUT.
DEFLATION
STEAM
DECK SHIELD SET-UP
KAYAK FIN INSTALLATION
Clear any water or debris out of the valve
areas.
1.
Open valve caps to start deflation.
2.
Open the main valve of the Boston valve for
deflation. In this situation, the valve only lets
air out, not in.

HIGH PRESSURE VALVE
(For BETTA/ MEMBA/ STEAM)
11” FOOT PUMP
FOR BETTA/ LAXO/ RIPPLE
16” HAND PUMP
FOR MEMBA/ STEAM
DEFLATE DEFLATE
NOTE: For STEAM/MEMBA/RIPPLE, remember to remove the air deck floor before folding.
NOTE: For STEAM, remember to remove the Deck Shield before folding the kayak.
Remove all the accessories from the kayak: seats, paddles, kayak fins, etc.
1.
14
PINCH VALVE (For BETTA’s floor)
FOLDING STEPS
Deflate by squeezing out the remaining air. Or by using the pump on “DEFLATE” mode.
3.
Once deflated, firmly cap each valve.
4.
Open external cap and pull firmly to extend out. Start to
deflate by using the transparent deflation pipe (comes
with the repair kit bag), or by simply squeezing the
bottom of the valve.
Slowly press down on the valve button to let air out of
the kayak. There will be an initial burst of air, but will
slow down very quickly.
Once the air flow has slowed down, push valve button
in and turn 90 degrees to make sure that valve button
is locked in “DOWN position” for deflation.
RECOMMENDED
INFLATION
15PSI
1.0BAR
WARNING:KEEPUNDERSHADEWHEN NOT IN USE
WITHAWORKINGPRESSURELESS THAN 10 PSI.
45°
LOCK
L
I
F
E
V
E
S
T
R
E
C
O
M
M
E
N
D
E
D
A
L
W
A
Y
S
W
E
A
R
A
L
E
A
S
H
DOWN POSITIONDOWN POSITION

Refer to the following folding steps for different models.
2.
The kayak bag is designed to allow you to
get your kayak into the bag as easily as
possible with minimal folds. *Side pocket
of the zip backpack is designed to store
kayak pump.
3.
15
STEAM
After deflation, fold the kayak in half the long way. Then, fold the bow to the middle and force out
any remaining air. Repeat this procedure for the stern, and place bow folds on top of stern.
BETTA/RIPPLE/ LAXO/ MEMBA
After deflation, tri-fold the tubes of the kayak. Then, fold the bow to the middle and force out any
remaining air. Repeat this procedure for the stern, and place bow folds on top of stern.
NOTE:
Please avoid bending the fin box.

PADDLE ASSEMBLY
KAYAK PADDLE ASSEMBLY
1. Press and align the push-bottom on the paddle blade with the short shaft hole, ensure the
push-bottom is securely snapped into the short shaft hole.
2. Join the 2 shafts together by pressing and aligning the push-bottom securely snapped into
the hole.
3. To disassemble, reverse the assembly steps.
Note: it is not necessary to detach the paddle blades from the shafts.
Shaft ShaftBlade Blade
Blade Blade
Shaft Shaft
KAYAK PADDLE (* Optional for STEAM )
RIPPLE-TECH PADDLE (Only for RIPPLE )
16
Canoe Paddle
Kayak Paddle
①
②
①
②
NOTE: ALWAYS DRAIN THE WATER LEFT IN THE PADDLE SHAFT AFTER EACH USE.

INSTRUCTION FOR CARE AND STORAGE
The kayak is made of the highest quality materials and complies with ISO 6185 standards.
Altering the construction of the kayak will endanger your own safety, safety of the
occupants and void the limited warranty!
There is very little that you have to do to keep your kayak in good condition for many years.
• Clean your kayak after a trip to prevent damage from sand, salt water or sun exposure.
Most dirt can be removed with a garden hose, a sponge and mild soap. Make sure the
kayak is completely dry before being stored . Use as few cleaning agents as possible, do
not discharge waste agents into water, and clean your kayak preferably on land.
• The products may be stored inflated, but do not place any heavy or sharp objects on it.
Hanging the kayak is not recommended.
• Store your kayak in a dry room.
• Take protection method to keep your kayak away from rodents or other vermin, as they
may bite the product.
• The room temperature shall be maintained between 0°C (32°F) and 40°C (104°F).
17

18
• BETTA kayaks have a limited SIX (6) months warranty.
• LAXO/ RIPPLE/ MEMBA/ STEAM kayaks have a limited TWELVE (12) months warranty.
1. The warranty is valid only when this product is used for normal recreational activities and does
not cover products used in rental or school operations
2. AM will make the final warranty determination, which may require inspection and/or photos of
the equipment, which clearly show the defect(s). If necessary, this information must be sent to
the AM distributor in your country with prepaid postage. Product can be returned only if a
return authorization number is given in advance by the AM distributor. The return authorization
number must be clearly labeled on the outside of the package, or it will be refused
3. If a product is deemed to be defective by AM, the warranty covers the repair or replacement of
the defective product only. AM will not be responsible for any costs, losses, or damages
incurred as a result of loss or misuse of this product
4. This warranty does not cover damage caused by misuse, abuse, neglect, normal wear and tear
including, but not limited to, punctures, damage due to excessive heat exposure, damage
caused by improper handling and storage, damage caused by use in waves or shore break,
board breakage caused by filling or crashing in surf conditions, or damage caused by anything
other than defects in material and workmanship
5. This product must not be modified and/or fitted with a motor except AM BlueDrive power fin
6. This product must not be used in excess of the manufacturers recommended maximum load
capacity
7. This warranty is void if any unauthorized repair, change or modification has been made to any
part of the equipment
8. The warranty for any repaired or replacement equipment is good from the date of the original
purchase only
9. The original purchase receipt must accompany all warranty claims. The name of the retailer and
date of purchase must be clear and legible
10. There are no warranties that extend beyond the warranty specified here in
THIS PRODUCT IS DESIGNED IN ACCORDANCE WITH
STANDARDS FOR A SPECIFIC USE. ANY MODIFICATIONS OR
TRANSFORMATIONS HIGHER THAN THAT INDICATED BY THE
MANUFACTURER COULD RESULT IN SERIOUS RISKS FOR THE
USER AND WILL VOID THE WARRANTY.
WARNING
WARRANTY
AM warrants this product to be free from major defects in material or
workmanship to the original purchaser for below specified period from the date
of purchase. This warranty is subject to the following limitations:

19
JOIN AQUA MARINA
COMMUNITY
Sign up to receive communications from Aqua Marina to
keep updated with our latest products and news.
Check out our social media sites to get involved and find
out more.
KEEP UPDATED
FIND YOUR WONDERLAND
https://www.facebook.com/aquamarinaglobal
https://www.instagram.com/aquamarinaglobal
https://twitter.com/aquamarinasup
https://www.youtube.com/c/AquaMarinaGlobal
I would like to receive communications from Aqua Marina.
You can unsubscribe from these communications at any time. We take the
protection of your data seriously. For more information on our privacy
practices, please review our Privacy Policy.
AM Official Site AM HOW-TO Guide AM Service Center List

Pour votre propre sécurité et celle de votre
équipement, assurez-vous de prendre les précautions
notifiées dans ce manuel. Le non-respect des
avertissements et des instructions peut entraîner des
dommages matériels, des blessures graves ou la mort.
ATTENTION
MANUEL DE L’UTILISATEUR
GONFLABLE
KAYAK & CANOE
FR
