Delta 1313 User manual

®
®
UPC
Submitted Model No.: _______________________________________________
Specific Features: __________________________________________________
STANDARD SPECIFICATIONS:
• Pressure balanced single handle bath
mixing valve.
• Requires 1 1/2" (38 mm) wall cavity.
• Back-to-back installation capability.
• Solid brass fabricated body.
• Lever handle.
• Monitor®with Scald-Guard®valve. Maintains
a balanced pressure of hot and cold water
even when a valve is turned on or off
elsewhere in the system.
• Temperature only controlled with handle.
• Field adjustable to limit handle rotation into
hot water zone.
• 120° maximum handle rotation.
• All parts shall be replaceable from the front
of the valve.
1303 1313 1323 1343 1343-NPS
0
1
2
3
4
5
0 102030405060708090
Pressure (PSI)
Flow (U.S. Gallons Per inute)
6
0 69 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flow (Liters Per inute)
Showerhead
Tub Filler
UL Listed to US and Canadian
Safety Standards

21PL
COMPLIES WITH:
•
ASME A112.18.1M-1996
• ASSE 1016-1996
• CSA B125-93
•
Showerhead GSA A-A-240
Indicates ADA compliance to
CABO/ANSI A117.1-1992
•
ASSE Seal Authorized
• City of L.A. approved
•
CSA Certified
• IAPMO Listed
3 1/2"
(89 mm)
A
7"
(178 mm)
Dimensions
I.P.S. or C. .T. 2 3/8" 5/8"
I.P.S. or C. .T. with stops 5 5/16" 3/8"
B
2"
(51 mm)
1/2"
(13 mm)
Face of plasterguard
should be flush with
finish wall line
Maximum
Allowable Deviation
C/L Supply
Lines
Supply
1303/1313/1343
1343-NPS
AB
3 1/2"
(89 mm)
A
7"
(178 mm)
B
2"
(51 mm)
1/2"
(13 mm)
Face of plasterguard
should be flush with
finish wall line
Maximum
Allowable Deviation
C/L Supply
Lines
Supply
BATH MIXING
VALVES
■Valve Only (1303 Series)
■Tub Only (1313 Series)
■Shower Only (1323 Series)
■Tub/Shower (1343 Series)
■Single Handle
■Monitor®with Scald-Guard®Valve
■Pressure Balance
■Temperature Only Controlled
with Handle
Dimensions
I.P.S. or C. .T. 2 3/8" 5/8"
I.P.S. or C. .T. with stops 5 5/16" 3/8"
AB
8" (203 mm)
min.
18" (457 mm)
max.
8" (203 mm)
min.
18" (457 mm)
max.
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue models, both without notice or obligation. Dimensions are for reference only.
2.D.5

DSP-B-1303 Rev. A
Standard
Features
Washerless ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
Scald-Guard®Valve ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
Back-to-Back Installation ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
1/2" I.P.S. Inlets and Outlets ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
1/2" C.W.T. Sweat Inlets and Outlets ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
Replaceable Cartridge ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
Adjustable Rotational Limit Stop ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
Metal Lever Handle ◆ ◆
Metal Shower Arm and Flange ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
Non-Metallic Push-Clean™
Showerhead/1 Spray Pattern ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
Metal Over-the-Rim Tub Filler ◆◆
Non-Metallic Tub Filler w/Pull-Up Diverter ◆ ◆ ◆ ◆
Non-Metallic Tub Filler w/Pull-Down Diverter ◆ ◆
Screwdriver Stops ◆ ◆ ◆ ◆ ◆ ◆
Chrome Finish ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆ ◆
1303-C
1303-CWS
1303-WS
1313-C
1323-C
1323
1323-CWS
1323-WS
1343
1343-C
1343-CWS
1313
1343-WS
1343-CNPS
1343-NPS
1303
2 1/2"
(64 mm)
2 1/2"
(64 mm)
5 1/4"
(133 mm)
5"
(127 mm)
2 1/2"
(64 mm)
5"
(127 mm)
2 1/2"
(64 mm)
4 3/4"
(121 mm)
RP5836
RP17453
RP17454
RP5834
RP7533
RP5833
RP5835
RP19820
3 7/16"
(87 mm)
3 1/2"
(89 mm)
Full Spray assage
Spray
Soft
Aerated
Spray
2"
(51 mm)
2 1/2"
(64 mm)
3 1/2"
(89 mm)
4 3/8"
(111 mm)
3 7/16"
(87 mm)
4"
(102 mm)
RP28600
Touch-Clean®Showerhead
RP28599
Push-Clean™ Showerhead
RP28602
Ultimate Touch-Clean®
Showerhead
RP28601
Dual Spray Touch-Clean®
Showerhead
Available Options for Field Conversion:
•Screwdriver Stops. Order two RP5876s for I.P.S. or two RP6005s for C.W.T.
•Shower Arm. Order RP6023.
•Shower Flange. Order RP6025.
•Non-metallic Touch-Clean®showerhead/1 spray pattern. Order RP28600.
•Non-metallic Dual Spray Touch-Clean®showerhead/2 spray patterns. Order RP28601.
•Non-metallic Ultimate Touch-Clean®showerhead/3 spray patterns. Order RP28602.
•Brass shower arm diverter for hand shower. Order RP4239.
•Personal hand shower with 24" vertical bar, 60" hose. Order RP7245.
•Personal hand shower with 24" vertical bar, 60" hose, vacuum breaker and wall supply elbow. Order RPW1111HDF.
•Personal hand shower with 60" hose, vacuum breaker and wall supply elbow. Order RPW2222HDF.
•Metallic tub filler with pull-down diverter for 1/2" C.W.T. or 1/2" I.P.S. Order RP17454.
•Non-metallic tub filler with pull-down diverter for 1/2" C.W.T. or 1/2" I.P.S. Order RP17453.
•Non-metallic slip-on tub filler with pull-down diverter for 1/2" C.W.T. Order RP5836.
•Metallic tub filler with pull-up diverter for 1/2" C.W.T or 1/2" I.P.S. Order RP7533.
•Non-metallic tub filler with pull-up diverter for 1/2" C.W.T. or 1/2" I.P.S. Order RP5834.
•Non-metallic slip-on tub filler with pull-up diverter for 1/2" C.W.T. Order RP19820.
•Metallic over-the-rim tub filler for 1/2" I.P.S. Order RP5833.
•Metallic over-the-rim slip-on tub filler for 1/2" C.W.T. Order RP5835.
•Bath waste assemblies and bath accessories also available separately.
Indianapolis, Indiana 46280
A Division of Masco Corporation of Indiana
© 2001 Masco Corporation of Indiana
