Delta Signature 141-WF User manual

COMPLIES WITH:
•
ASME A
1
1
2
.
1
8
.
1
/ CSA B125.1
Indicates ADA compliance to
ICC/ANSI A117.1
•
IAPMO Listed
•
CSA Certified
KITCHEN
FAUCETS
■
Signature
®
Series
■
Single Handle Deck Mount
■
Single and 2 Hole Sink Applications
■
Quick Sna
p
®
Vegetable Sprayer Hose
Installation on Model 441 Series
Submitted Model No.:
_______________________________________________
Specific Features:
__________________________________________________
STANDARD SPECIFICATIONS:
•
Solid brass fabricated body
.
•
9 1/16" (230 mm) long spout swings 360°
.
•
Lever handle shall return to neutral position when
faucet is turned off
.
•
Red and blue button on handle
.
•
Control mechanism shall be of the rotating
stainless steel ball type with replaceable
non-metallic seats operating in stainless steel lined
sockets
.
•
Model 441 series with spray attachment has
anti-siphon device as integral part of valve body.
•
Quick Snap
®
vegetable sprayer hose
with
matching finish sprayhead on model 441 series
- 45" (1143mm) long hose.
•
3/8" O.D. straight, staggered copper supply
tubes - 5 5/8" (143 mm) and 7" (178 mm) long
supplied with 1/2"-14 NPSM adapters
.
441-WF
141-WF
4.D.5
4 1/2"
(114 mm)
1" (25 mm) Max.
1" (25 mm) Max.
Deck Thickness
1" (25 mm) Max.
Deck Thickness
1" (25 mm) Max.
2"
(51 mm)
Dia.
(51 mm)
Dia.
(51 mm)
7/8"
(22 mm) Dia.
1/2"-14 NPSM Adapters
2" (51 mm) Dia. Base
5 5/8"
(143 mm)
7"
(178 mm)
CL 1 3/4"
(45 mm)
9 1/16"
(230 mm)
360° swing spout
(230 mm)
360° swing spout
(230 mm)
5 9/16"
(141 mm)
8 3/8"
(213 mm)
0
1
2
3
4
5
0 10 20 30 40 50 60 70 80 90
Pressure (PSI)
Flow (U.S. Gallons Per Minute)
6
0 69 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flow (Liters Per Minute)
1" (25 mm) Max.
Deck Thickness
1" (25 mm) Max.
Deck Thickness
1" (25 mm) Max.
®
®
UPC
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See full-line price book for finish
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See full-line price book for finish
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
options and product availability.
models, both without notice or obligation. Dimensions are for reference only. See full-line price book for finish
options and product availability.
models, both without notice or obligation. Dimensions are for reference only. See full-line price book for finish
Indianapolis, Indiana 46280
A Division of Masco Corporation of Indiana
© 2006 Masco Corporation of Indiana
WARRANTY
•
Lifetime Faucet and Finish Limited Warranty
to the
original consumer purchaser to be free
from defects in material and workmanship.
•
5 Year Limited Warranty for usage in all industrial,
commercial and bu
siness applications.
DSP-K-141 R
ev
.
E
