Delta T17085 Series User manual

Submitted Model No.:_______________________________________________
Specific Features: __________________________________________________ STANDARD SPECIFICATIONS:
• Monitor
®
17 Series pressure balanced bath
mixing valve with Scald-Guard
®
.
• Maintains a balanced pressure of hot and cold
water even when a valve is turned on or off
elsewhere in the system.
• For use with MultiChoice™ Universal rough
valve body. (R10000 Series)
• Back-to-back installation capability.
• Solid brass forged body.
• Lever volume control handle; temperature
adjustment dial.
• Field adjustable to limit handle rotation into
hot water zone.
• Maximum dial rotation adjustable between 90º
and 180º.
• All parts replaceable from the front of the valve.
T17085 T17285 T17485
0
1
2
3
4
5
0102030405060708090
Pressure (PSI)
Flow (U.S. Gallons Per Minute)
6
069 138 207 276 345 414 483 552 621
0
3.8
7.6
11.4
15.1
18.9
22.7
Pressure (kPa)
Flow (Liters Per Minute)
Showerhead
726.5
Tub Filler
7"
(178 mm)
Face of plasterguard
should be flush with
finish wall line
Supply
Tub AND SHOWER
FAuCET TRIM
■Grail®Bath Collection
■Valve Only (T17085 Series)
■Shower Only (T17285 Series)
■Tub/Shower (T17485 Series)
Delta reserves the right (1) to make changes in specifications and materials, and (2) to change or discontinue
models, both without notice or obligation. Dimensions are for reference only. See current full-line price book or
www.specselect.com for finish options and product availability.
2 3/4"
(70 mm)
5 7/64"
(130 mm)
8" (203 mm)
min.
18" (457 mm)
max.
RP48718▲(Pull-Up Diverter) RP48590▲Showerhead
®
®
UPC
COMPLIES WITH:
• ASME A112.18.1 / CSA B125.1
• ASSE 1016
Indicates compliance to
ICC/ANSI A117.1
WARRANTy
• Lifetime Faucet and Finish Limited Warranty
to the original consumer purchaser to be free
from defects in material and workmanship.
• 5 Year Limited Warranty for usage in all industrial,
commercial and business applications.
DSP-B-T17085 Rev. A
55 E. 111th Street, Indianapolis, Indiana 46280
395 Matheson Blvd. E., Mississauga, ON L4Z 2H2
© 2008 Masco Corporation of Indiana
2 3/4" (70mm)
▲= Designate Proper Finish Suffix
4"
(100 mm)
4 1/2"
(113 mm)
Full Spray
