Delta DVPPS01 User manual

5011679805-S005
2014-04-30

Warning
EN aDVPPS01/02/05 is an OPEN-TYPE device. It should be installed in a control cabinet free of airborne dust, humidity,
electric shock and vibration. To prevent non-maintenance staff from operating DVPPS01/02/05, or to prevent an
accident from damaging DVPPS01/02/05, the control cabinet in which DVPPS01/02/05 is installed should be
equipped with a safeguard. For example, the control cabinet in which DVPPS01/02/05 is installed can be unlocked
with a special tool or key.
EN aDO NOT connect AC power to any of I/O terminals, otherwise serious damage may occur. Please check all wiring
again before DVPPS01/02/05 is powered up. After DVPPS01/02/05 is disconnected, Do NOT touch any terminals in
a minute. Make sure that the ground terminal on DVPPS01/02/05 is correctly grounded in order to prevent
electromagnetic interference.
FR aDVPPS01/02/05 est un module OUVERT. Il doit être installé que dans une enceinte protectrice (boitier, armoire, etc.)
saine, dépourvue de poussière, d’humidité, de vibrations et hors d’atteinte des chocs électriques. La protection doit
éviter que les personnes non habilitées à la maintenance puissent accéder à l’appareil (par exemple, une clé ou un
outil doivent être nécessaire pour ouvrir a protection).
FR aNe pas appliquer la tension secteur sur les bornes d’entrées/Sorties, ou l’appareil DVPPS01/02/05 pourra être
endommagé. Merci de vérifier encore une fois le câblage avant la mise sous tension du DVPPS01/02/05. Lors de la
déconnection de l’appareil, ne pas toucher les connecteurs dans la minute suivante. Vérifier que la terre est bien
reliée au connecteur de terre afin d’éviter toute interférence électromagnétique.
XIntroduction
Thank you for choosing DELTA DVP series. DVPPS series is a power module with 3 types that sorted by
output circuit. 1. DVPPS01 provides 24V DC and 1A current for output power. 2. DVPPS02 provides 24V DC
and 2A current for output power. 3. DVPPS05 provides 24 V DC and 5 A current for output power. DVPPS
series is only used for Delta DVP series. DVPPS series is separated from the PLC MPU for better space
utilization and easier installation.
Product Profile & Outline
DVPPS01 (Unit: mm) DVPPS02 (Unit: mm)
390
13.3 60
36.5
DVPPS01
1
2
33
4
5
6
13.3 60
100
32.5
90
55
33
DVPPS02
1
2
33
4
5
6
7
7
DVPPS05 (Unit: mm)
MPower LED NOutput/input terminal (fixed terminal) ODIN rail clip
PDIN rail track (35mm) QI/O terminal label RNameplate
SMounting holes
ENGLISH

YElectrical Specifications
Model
Item DVPPS01 DVPPS02 DVPPS05
Power input 100 ~ 240VAC (-15% ~ +10%), 50/60Hz
Output power 24VDC (±3%)
Maximum output current 1 A 2 A 5 A
Ripple & noise Under 100mVp-p Typical at
full load Under 240mVp-p Typical at full load
Efficiency 78% ~ 87% Typical at full load Above 88% Typical at full load
Overcurrent/short circuit
protection Auto Recovery
Overvoltage/
overtemperature
protection
--
Overvoltage protection: The
power supply is cut off for 5
seconds. DVPPS05 operates
normally after power is
supplied.
Overtemperature protection:
The power supply is cut off for
5 seconds, and the
temperature inside DVPPS05
falls to the temperature below
85oC. DVPPS05 operates
normally after power is
supplied.
Grounding The diameter of grounding wire cannot be smaller than the wire diameter of terminals L and
N (All PLC units should be grounded directly to the ground pole).
Operation environment 0°C~55°C (temperature), 50~95% (humidity), Pollution
degree 2
-20°C~55°C (temperature),
50~95% (humidity),
Pollution degree 2
Storage environment -25°C~70°C (temperature), 5~95% (humidity)
UL UL508 Listed (Industrial Control Equipment)
Agency
approvals CE
European Community EMC
Directive 89/336/EEC and
Low Voltage Directive
73/23/EEC
EMC Directive 2004/108/EC and Low Voltage Directive
2006/95/EC
Weight (g) 158 250 488
ZInstallation and Wiring
Mounting Arrangements and Wiring
DIN Rail Installation:
The DVPPS can be secured to a cabinet by using the DIN rail
that is 35mm high with a depth of 7.5mm. When mounting the
DVPPS on the DIN rail, be sure to use the end bracket to stop
any side-to-side motion of the DVPPS, thus to reduce the
chance of the wires being pulled loose. On the bottom of the
DVPPS is a small retaining clip. To secure the DVPPS to the
DIN rail, place it onto the rail and gently push up on the clip. To
remove it, pull down on the retaining clip and gently pull the
DVPPS away from the DIN rail. Please see the figure on the
right:
For heat dissipation. Make
sure to provide a minimum
clearance of 50mm between
the unit and all sides of the
cabinet. (as shown below)
Direct mounting: Tighten M4 screws into direct mount hole.

Wiring:
To suit M3.5 screw terminals
Below 6.2
Below 6.2
1. Please use O-type or Y-type terminals for I/O wiring terminals. The
specification for the terminals is as shown on the left. Tighten PLC terminal
screws to a torque of 5 ~ 8kg-cm (4.3 ~ 6.9 in-lbs).
2. Please avoid tiny metal material enter DVPPS01/02/05 when screwing and
wiring. After finishing wire, remove the affix that pasted on the heat sink for
heat dissipation.
3. Use Copper Conductors Only, 60°C.
Wiring Notes
Environment
1. DO NOT store the DVPPS01/02/05 in a dusty, smoky, or corrosive atmosphere.
2. DO NOT store the DVPPS01/02/05 in an environment with high temperature or high humidity.
3. DO NOT install PLC on a shelf or on an unstable surface.
Power Input Wiring
Power input of DVPPS01/02/05 is AC input; following items should be noticed:
1. Connect the AC input (100VAC ~ 240VAC) to terminals L and N. Any 110VAC or 220VAC connected to the
+24V terminal will permanently damage the DVPPS01/02/05.
2. Please use wires of 1.6mm and above for the grounding.
3. If the power-cut time is less than 10ms, the DVPPS01/02/05 still operates unaffectedly. If the power-cut
time is too long, the DVPPS01/02/05 will stop operating and all the outputs will be Off.
[Trial Run
Power indicator, Running and Test
The “POWER” LED at the front of DVPPS01/02/05 will be lit (in green) if the power is on. If the indicator is not
ON, it indicates that the power supply is not enough or short circuit. Please check your power wiring.
\Troubleshooting
Judge the errors by the indicators on the front panel. When errors occurred on DVPPS01/02/05, please check:
“POWER” LED
The “POWER” LED at the front of the MPU will be lit (in green) if the power is on. If the indicator is not on
when the MPU is powered up, please check if power supply is normal. If the indicator is not on when the MPU
is powered up and with the input power being normal, it is an indication that the PLC is malfunction. Please
have this machine replaced or have it repaired at a dealer near you.
