TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
1
Highlights & Features
•Universal AC input voltage range
•Power will not de-rate for the entire input voltage range
•Power Boost of 150% for 3 seconds
•Rugged and compact design (Vibration 5 G, Shock 30 G)
•Conforms to harmonics current IEC/EN 61000-3-2, Class A
•Wide operating temperature range -20°C to 80°C
•Overvoltage / Overcurrent / Over Temperature / Short Circuit
Protections
•Certified according to IEC/EN/UL 62368-1
Safety Standards
CB Certified for worldwide use
Model Number: DRP024V060W1AZ
Unit Weight:0.33 kg (0.73 lb)
Dimensions (L x W x D): 120.6 x 32 x 113 mm
(4.75 x 1.26 x 4.45 inch)
General Description
The DRP024V060W1AZ is part of the CliQ DIN rail power supply series from one of the world’s leading power supply companies, Delta
Electronics Group, offers state-of-the-art designs made to withstand harsh industrial environments. Its rugged plastic casing has a
compact body at only 32 mm, which is both shock and vibration resistant according to IEC 60068-2 standard. The DRP024V060W1AZ
operates within a wide temperature range from -20°C to +80°C and universal AC input voltage range from 85 Vac to 264 Vac, the power
will not de-rate for the entire input voltage range value. The single phase power supply unit includes overvoltage, overcurrent, over
temperature and short circuit protections. The feature built-in Power Boost of 150% for 3 seconds enables reserve power to be always
available for reliable startup of loads with high inrush current, thus eliminating the need of a more expensive power supply unit at higher
power rating.
Model Information
CliQ DIN Rail Power Supply
Model Number
Input Voltage Range
Rated Output V oltage
Rated Output Curr ent
DRP024V060W1AZ 85-264 Vac (120-375 Vdc) 24 Vdc 2.50 A
Model Numbering
DR P024V060W 1AZ
DIN Rail Power Supply Output Voltage Output Power Single Phase CliQ Series Plastic Case

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
2
Specifications
Input Ratings / Characteristics
Nominal Input Voltage 100-240 Vac
Input Voltage Range 85-264 Vac
Nominal Input Frequency 50-60 Hz
Input Frequency Range 47-63 Hz
DC Input Voltage Range* 120-375 Vdc
Input Current < 1.10 A @ 115 Vac, < 0.70 A @ 230 Vac
Efficiency at 100% Load > 86.0% @ 115 Vac, > 87.0% @ 230 Vac
Max Power Dissipation 0% load < 0.6 W @ 115 Vac & < 1.2 W @ 230 Vac
100% load < 10 W @ 115 Vac & 230 Vac
Max Inrush Current (Cold Start) < 40 A @ 115 Vac, < 80 A @ 230 Vac
Leakage Current < 1 mA @ 240 Vac
*Safety approval according to IEC/EN/UL 60950-1 and IEC/EN/UL 62368-1.
Output Ratings / Characteristics**
Nominal Output Voltage 24 Vdc
Factory Set Point Tolerance 24 Vdc ± 2%
Output Voltage Adjustment Range 22-28 Vdc
Output Current 2.50 A (continuously operating at 24 V)
3.75 A (Power Boost for 3 seconds at 24 V, refer to the details
in the Functions section)
Output Power 60 W (continuously operating at 24 V)
90 W (Power Boost for 3 seconds at 24 V
, refer to the details in
the Functions section)
Line Regulation < 0.5% (@ 85-264 Vac input, 100% load)
Load Regulation < 1.0% (@ 85-264 Vac input, 0-100% load)
PARD*** (20 MHz) < 240 mVpp
Rise Time
< 100 ms @ nominal input (100% load)
Start-up Time < 2,500 ms @ nominal input (100% load)
Hold-up Time > 20 ms @ 115 Vac (100% load)
> 125 ms @ 230 Vac (100% load)
Dynamic Response
(Overshoot & Undershoot O/P Voltage)
± 5% @ 85-264 Vac input, 10-90% load
(Slew Rate: 0.1 A/μs, 50% duty cycle @ 5 Hz to 1 KHz)
Start-up with Capacitive Loads 8,000 µF Max
**For power de-rating from 50°C to 80°C, see power de-rating on page 3.
***PARD is measured with an AC coupling mode, 5 cm wires, and in parallel with 0.1 μF ceramic capacitor.

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
3
Mechanical
Case Cover / Chassis
Plastic
Dimensions (L x W x D) 120.6 x 32 x 113 mm (4.75 x 1.26 x 4.45 inch)
Unit Weight 0.33 kg (0.73 lb)
Indicator Green LED DC OK
Cooling System Convection
Terminal Input 3 Pins (Rated 300 V/20 A)
Output 2 Pins (Rated 300 V/20 A)
Wire AWG 20-14
Mounting Rail Standard TS35 DIN Rail in accordance with EN 60715
Noise (1 Meter from power supply) Sound Pressure Level (SPL) < 40 dBA
Environment
Surrounding Air Temperature Operating -20°C to +80°C
Storage -25°C to +85°C
Power De-rating Vertical Mounting -10°C to -20°C output power is 80% of rated power,
< 0°C de-rate power by 2% / °C,
> 50°C de-rate power by 2.5% / °C
Horizontal Mounting -10°C to -20°C output power is 80% of rated power,
< 0°C de-rate power by 2% / °C,
> 50°C de-rate power by 2.5% / °C,
> 70°C de-rate power by 4% / °C
Operating Humidity 5 to 95% RH (Non-Condensing)
Operating Altitude 0 to 2,000 Meters (6,560 ft)
Shock Test Non-Operating IEC 60068-2-27, 30 G (300 m/S²) for a duration of 18 ms,
1 time per direction, 6 times in total
Vibration Non-Operating IEC 60068-2-6, 10 Hz to 150 Hz @ 50 m/S² (5 G peak);
90 min per axis for all X, Y, Z direction
Over Voltage Category III According to IEC/EN 62477-1 / EN 60204-1
(clearance and creepage distances) and
IEC 62103 (safety part)
Pollution Degree 2
Protections
Overvoltage < 32 V, ±10%, SELV Output, Hiccup Mode,
Non-Latching (Auto-Recovery)
Overload / Overcurrent > 150% of rated load current, Hiccup Mode,
Non-Latching (Auto-Recovery)
Over Temperature < 80°C Surrounding Air Temperature @ 100% load,
Non-Latching (Auto-Recovery)
Short Circuit Hiccup Mode, Non-Latching
(Auto-Recovery when the fault is removed)
Internal Fuse at L pin T3.15AH
Protection Against Shock Class I with PE* connection
*PE: Primary Earth

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
4
Reliability Data
MTBF > 500,000 hrs. as per Telcordia SR-332
I/P: 115Vac, O/P: 100% load, Ta: 25°C
Expected Cap Life Time
10 years (115 Vac & 230 Vac, 50% load @ 40°C)
Safety Standards / Directives
Electrical Equipment of Machines
EN 60204-1 (over voltage category III)
Electrical Equipment for Use in Electrical Power Installations
IEC/EN/BS EN 62477-1 / IEC 62103
Safety Entry Low Voltage
SELV (IEC 60950-1)
Electrical Safety SIQ Bauart EN 62368-1
UL/cUL recognized UL 60950-1 and CSA C22.2 No. 60950-1 (File No. E191395),
UL 62368-1 and CSA C22.2 No. 62368-1 (File No. E191395)
cCSAus
CSA C22.2 No. 60950-1 and UL 60950-1 (File No. 181564)
CB Scheme
IEC 60950-1, IEC 62368-1
BIS
IS 13252-1
UKCA
BS EN 62368-1
Industrial Control Equipment
UL/cUL listed
UL 508 and CSA C22.2 No. 107.1-01 (File No. E315355)
cCSAus
CSA C22.2 No. 107.1-01 (File No. 181564)
CE In conformance with EMC Directive 2014/30/EU and
Low Voltage Directive 2014/35/EU
UKCA In conformance with Electrical Equipment
(Safety) Regulations
2016 No. 1011 and
The Electromagnetic Compatibility Regulations 2016 No. 1091
Galvanic Isolation Input to Output 4.0 KVac
Input to Ground
1.5 KVac
Output to Ground
1.5 KVac

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
5
EMC
Emissions (CE & RE) Generic Standards: CISPR 32, KN 32, EN/BS EN 55032,
CISPR 11, EN/BS EN 55011, FCC Title 47: Class B
Immunity Generic Standards: EN/BS EN 55024, KN 35,
EN/BS EN 61000-6-1
Electrostatic Discharge IEC 61000-4-2 Level 4 Criteria A1)
Air Discharge: 15 kV
Contact Discharge: 8 kV
Radiated Field IEC 61000-4-3 Level 2 Criteria A1)
80 MHz-1GHz, 3 V/M, 80% modulation (1kHz)
Electrical Fast Transient / Burst IEC 61000-4-4 Level 3 Criteria A1)
2 kV
Surge IEC 61000-4-5 Level 3 Criteria A1)
Common Mode2): 2 kV
Differential Mode
3)
: 2 kV
Conducted IEC 61000-4-6 Level 2 Criteria A1)
150 kHz-80 MHz, 3 Vrms
Power Frequency Magnetic Fields IEC 61000-4-8 Criteria A1)
1 A/Meter
Voltage Dips and Interruptions
IEC 61000-4-11
100% dip; 1 cycle (20ms); Self Recoverable
Low Energy Pulse Test (Ring Wave) IEC 61000-4-12 Level 3 Criteria A1)
Common Mode2): 2 kV
Differential Mode
3)
: 1 kV
Voltage Fluctuation and Flicker
IEC/EN/BS EN 61000-3-3
1) Criteria A: Normal performance within the specification limits
2) Asymmetrical: Common mode (Line to earth)
3) Symmetrical: Differential mode (Line to line)

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
6
Block Diagram
Device Description
1) Input terminal block connector
2) Output terminal block connector
3) DC Voltage adjustment potentiometer
4) DC OK control LED (Green)
5) Universal mounting rail system

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
7
Dimensions
L x W x D: 120.6 x 32 x 113 mm (4.75 x 1.26 x 4.45 inch)
Engineering Data
Output Load De-rating VS Surrounding Air Temperature
Note
1. Power supply components may degrade, or
be damaged, when the power supply is
continuously used outside the shaded region,
refer to the graph shown in Fig. 1.
2. If the output capacity is not reduced when the
surrounding air temperature exceeds its
specification as defined on Page 3 under
“Environment”, the device may run into Over
Temperature Protection. When activated, the
output voltage will go into bouncing mode and
will recover when the surrounding air
temperature is lowered or the load is reduced
as far as necessary to keep the device in
working condition.
3. In order for the device to function in the
manner intended, it is also necessary to keep
a safety distance as recommended in the
safety instructions while the device is in
operation.
4. Depending on the surrounding air temperature
and output load
delivered by the power
supply, the device can be very hot!
5. If the device has to be mounted in any other
orientation, please contact [e-mail]
for more details.
Fig. 1 De-rating for Vertical Mounting Orientation
-10°C to -20°C output power is 80% of rated power,
< 0°C de-rate power by 2% / °C,
> 50°C de-rate power by 2.5% / °C
De-rating for Horizontal Mounting Orientation
-10°C to -20°C output power is 80% of rated power,
< 0°C de-rate power by 2% / °C,
> 50°C de-rate power by 2.5% / °C,
> 70°C de-rate power by 4% / °C

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
8
Output Load De-rating VS Input Voltage
Assembly & Installation
The power supply unit (PSU) can be mounted on 35 mm DIN rails in accordance with EN 60715. The device should be installed with
input terminal block at the bottom.
Each device is delivered ready to install.
Mounting
In accordance to EN 60950 / UL 60950 and EN 62368 / UL 62368, flexible cables require ferrules.
Use appropriate copper cables designed to sustain operating temperature of at least 75°C or more to fulfill UL requirements.
Dismounting
Fig. 2.1 Mounting
Snap on the DIN rail as shown in Fig. 2.1:
1. Tilt the unit upwards and insert it onto the DIN rail.
2. Push downwards until stopped.
3. Press against the bottom front side for locking.
4. Shake the unit slightly to ensure that it is secured.
Fig. 2.2 Dismounting
To uninstall, pull or slide down the latch with screw driver as
shown in Fig. 2.2. Then slide the power supply unit (PSU) in the
opposite direction, release the latch and pull out the power
supply unit (PSU) from the rail.
No output power de-rating across the entire
input voltage range

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
9
Safety Instructions
Vertical Mounting
•ALWAYS switch mains of input power OFF before connecting and disconnecting the input voltage to the unit. If mains are not turned
OFF, there is risk of explosion / severe damage.
•To guarantee sufficient convection cooling, please refer to the following instructions to ensure sufficient clearance around
the device.
Vertical Mounting: 50 mm (1.97 inch) above and below the device as well as a lateral distance of 20 mm (0.79 inch) to other
units.
Horizontal Mounting: 50 mm (1.97 inch) above and below the device as well as a lateral distance of 50 mm (1.97 inch) to
other units.
•Note that the enclosure of the device can become very hot depending on the surrounding air temperature and load of the power
supply. Risk of burns!
•Only plug in and unplug connectors when power is turned off!
•DO NOT insert any objects into the unit.
•Hazardous voltages may be present for up to 5 minutes after the input mains voltage is disconnected. Do not touch the unit during
this time.
Horizontal Mounting

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
10
Functions
Graph illustrating the Start-up Time, Rise Time, and Hold-up Time
Start-up Time
The time required for the output voltage to reach 90% of its final steady state set value, after the input voltage is applied.
Rise Time
The time required for the output voltage to change from 10% to 90% of its final steady state set value.
Hold-up Time
Time between the collapse of the AC input voltage, and the output falling to 95% of its steady state set value.
Inrush Current
Inrush current is the peak, instantaneous, input current measured
and, occurs when the input voltage is first applied. For AC input
voltages, the maximum peak value of inrush current will occur
during the first half cycle of the applied AC voltage. This peak value
decreases exponentially during subsequent cycles of AC voltage.
Dynamic Response
The power supply output voltage will remains within ±5% of its
steady state value, when subjected to a dynamic load from 10% to
90% of its rated current.
50% duty cycle / 5 Hz to 1 KHz

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
11
Power Boost
  (%)= 
 
   (
) = (  × ) + (-  ×)
 
OR
-  =
 ×   (  × )

An example of Power Boost and Average Output Power
Power Boost Peak Power
(WP)
Power Boost
Duration (TP) Duty Cycle Non-Peak Power (WN)
Non-Peak Power
Duration (TN)
Total Time
(T)
150% 90 3 sec 10% 57 W 27 sec 30 sec
150% 90 3 sec 35% 44 W 5.5 sec 8.5 sec
120% 72 6 sec 20% 57 W 24 sec 30 sec
120% 72 6 sec 35% 53 W 11 sec 17 sec
It is not recommended to prolong the duration of Power Boost to be longer than the specified duty cycle calculation, this may cause
damage to the PSU.
External Input Protection Device
The unit is protected at the L pin, with an internal fuse that cannot be replaced. The power supply has been tested and approved on
20 A (UL) and 16 A (IEC) branch circuits without additional protection device. An external protection device is only required if the supplying
branch has an ampacity greater than above. Thus, if an external protective device is necessary, or, utilized, please refer a minimum value
of 20 A B- or 13 A C- characteristic breaker.
Power Boost is the reserve power available
constantly that allows reliable startup to support
sudden and short spike of loads with high inrush
current typically during turn on to remove the need
of more expensive higher rated power supply unit.
After the output has reached its steady state set
value, the power supply can support surge loads
with a higher short-term power demand up to 150%
of maximum rated load (IOMax), for a maximum
duration of 3 seconds. The Power Boost is also
available to repeatedly basis with according to the
condition of an average (R.M.S) output power shall
not exceed continuous operating condition or refer
to duty cycle calculation below.
Fig. 3 Duty Cycle Calculation

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
12
Overload & Overcurrent Protections (Auto-Recovery)
The power supply’s Overload (OLP) and Overcurrent (OCP)
Protections will be activated when output current (IO) exceeds its
specification as defined on Page 3 under “Protections”. In such
occurrence, the output voltage (VO) will start to droop and once the
power supply has reached its maximum power limit, the protection
is activated and the power supply will go into “Hiccup mode” (Auto-
Recovery). The power supply will recover once the fault condition
of the OLP and OCP is removed and IOis back within the
specifications.
It is not recommended to prolong the duration of IOwhen it is less
than OLP/OCP point, but greater than 100%, since it may cause
damage to the PSU.
Short Circuit Protection (Auto-Recovery)
The power supply’s output OLP/OCP function also provides
protection against short circuits. When a short circuit is applied, the
output current will operate in “Hiccup mode”, as shown in the
illustration in the OLP/OCP section on this page. The power supply
will return to normal operation after the short circuit is removed.
Overvoltage Protection (Auto-Recovery)
The power supply’s overvoltage circuit will be activated when its
internal feedback circuit fails. The output voltage shall not exceed
its specifications defined on Page 3 under “Protections”. The power
supply does not shut down but goes in 2nd level regulation at 30-
32 Vdc and continue to deliver the power. According to high output
voltage which will be operating > 100% of rated load (32 V × rated
output current), if this condition persists, the power supply will
sense OTP (Over Temperature Protection) and will go under
hiccup mode. The power will return to normal operation once the
fault condition is removed.
Over Temperature Protection (Auto-Recovery)
As mentioned above, the power supply also has Over Temperature
Protection (OTP). In the event of a higher operating temperature at
100% load, the power supply will run into OTP when the operating
temperature is beyond what is recommended in the de-rating
graph. When activated, the output voltage will go into bouncing
mode until the temperature drops to its normal operating
temperature as recommended in the de-rating graph.

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
13
Operating Mode
Redundant Operation
In order to ensure proper redundant operation for the power
supply unit (PSU), the output voltage difference between the
two units must be kept at 0.45~0.50 V for 24 V supplies. Follow
simple steps given below to set them up for the redundant
operation:
Step 1.
Measure output voltage of PSU 1 and PSU 2. If PSU 1 is the
master unit, then VOof PSU 1 must be higher than PSU 2. In
order to set the output voltage, individually connect the power
supply to 50% of rated load at any line voltage from 85-264Vac,
and set the PSU 1 and PSU 2 output voltage.
Step 2.
Connect the power supply units PSU 1 and PSU 2 to Vin 1 &
Vin 2, respectively, of the DRR-20N (or 20A) module shown on
the diagram on the right.
Step 3.
Connect the system load from Vout. Please note that output
voltage Vout from DRR module will be = VO(output voltage of
power supply) – Vdrop* (in DRR module).
*Vdrop will vary from 0.60V to 0.90V (Typical 0.65V) depending on the load current
and surrounding air temperature.
**The Signal GND in the DRR module is for the built-in LED and DC OK signals. The Output
GND terminals from the two PSU’s do not need to be connected to the Signal GND
terminal.
Fig. 4 Redundant Operation Connection Diagram
Parallel Operation
The power supply units (PSUs) can also be used for parallel
operation in order to increase the output power. The difference
in output voltage between the two units must be kept to within
25mV of each other. This difference must be verified with the
same output load connected independently to each unit.
Parameters such as EMI, inrush current, leakage current,
PARD, start up time will be different from those on the
datasheet, when two units are connected in parallel. The user
will need to verify that any differences will still allow the two
power supplies connected in parallel will work properly in their
product/application.
Fig. 5 Parallel Operation Connection Diagram

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
14
Fig. 6DC Input Operation Connection Diagram
DC Input Operation
Step 1.
Use a battery or similar DC source.
Step 2.
Connect +pole to L and -pole to N.
Step 3.
Connect the PE terminal to an earth wire or to the machine ground.
Fig. 72 of 3 Phase System Input Operation Connection Diagram
2 of 3 Phase System Input Operation
Delta's CliQ can use on 2 of 3 phase system. Please refer to the following step.
Step 1.
The input voltage applied from Line to Neutral is below the maximum rated input. The input voltage shall be below 240Vac +10%.
Step 2.
The external protector is needed on N (Neutral) input line to secure a safety. N line does not have internal fuse protection. An appropriate
fuse or circuit breaker should be connected in series with N input line connection like the following.

TECHNICAL DATASHEET
CliQ DIN Rail Power Supply
24 V 60 W 1 Phase / DRP024V060W1AZ
All parameters are specified at 25°C ambient and AC input unless otherwise indicated.
www.DeltaPSU.com (September 2021, Rev. 10)
15
Others
Attention
Delta provides all information in the datasheets on an “AS IS” basis and does not offer any kind of warranty through the information for
using the product. In the event of any discrepancy between the information in the catalog and datasheets, the datasheets shall prevail
(please refer to www.DeltaPSU.com for the latest datasheets information). Delta shall have no liability of indemnification for any claim
or action arising from any error for the provided information in the datasheets. Customer shall take its responsibility for evaluation of using
the product before placing an order with Delta.
Delta reserves the right to make changes to the information described in the datasheets without notice.
Manufacturer and Authorized Representatives Information
Manufacturer
Thailand
Delta Electronics (Thailand) PCL.
909 Pattana 1 Rd., Muang, Samutprakarn, 10280 Thailand
Taiwan
Delta Electronics, Inc.
3 Tungyuan Road, Chungli Industrial Zone, Taoyuan County
32063, Taiwan
Authorized Representatives
The Netherlands
Delta Greentech (Netherlands) B.V.
Zandsteen 15, 2132 MZ Hoofddorp, The Netherlands
United Kingdom
Delta Electronics Europe Limited
1 Redwood Court, Peel Park Campus,
East Kilbride, Glasgow, G74 5PF, United Kingdom
