Model DP-2617 DP-3617 DP-3622
Projection System Texas Instruments DLPTM Technolgoy
Panel
Data Processor DDR DLPTM with DDP2000
Native Resolution SVGA 800x600 XGA 1024x768 XGA 1024x768
Maximum Supported Resolution Up to SXGA+ 1440x1050@60Hz , UXGA@60Hz half sampling
Brightness (Typical)
Boost mode 2300 ANSI Lumens 2300 ANSI Lumens 2800 ANSI Lumens
Standard mode 1900 ANSI Lumens 1900 ANSI Lumens 2350 ANSI Lumens
ECO mode 1700 ANSI Lumens 1700 ANSI Lumens 2000 ANSI Lumens
Contrast Ratio 1850:1 1800:1 2100:1
Brightness Uniformity (Typical) 85% 85% 80%
Color Reproduction 24 bit, 16.7million True Color
Projection Lens Manual Zoom, Manual Focus
Zoom Ratio Digital Zoom , 1.15:1
Focal Length 21.3 ~ 24.5mm; 2m@50" 21.3 ~ 24.5mm; 2m@50" 26.9 ~ 29.84mm; 2m@54"
Projection Distance 1~10m
Projection Screen Size 22.57" - 260" 22.57" - 260" 23.4"- 273.4"
Projection Method Front/Rear, Desktop/Ceiling
Throw Ratio (D/W) 1.89~2.18 1.8~2.1
Image Distortion +/- 1 % max
Optical Offset 130% 130% 124%
Aspect Ratio 4:3 (native) & 16:9(supported)
Keystone Correction Vertical
Frequency H-Sync 15, 31~90KHz
V-Sync 50 - 85 Hz
Data Compatibility VGA, SVGA, XGA, SXGA, Macintosh
Video Compatibility NTSC/NTSC 4.43, PAL B/G/H/I/M/N 60, SECAM, 480i/480p/720p/1080i
Lamp Mode 230W (boost) / 200W (standard) / 180W (eco)
Lamp Life 2000hr (boost) / 3000hr (standard) / 4000hr (eco)
Acoustic Noise (typical) 36dB (boost) / 33dB (standard) / 31dB (eco)
Power Supply AC input 110~240 Voltage (auto ranging)
Power Consumption 290W (boost) / 255W (standard) / 230W (eco), Standby <5W
Dimensions (WxDxH) 300mm x 244mm x 88mm
Weight (typical) 7.3 lbs
Safety & Regulatory Compliance FCC-B, UL/Cul, TUV, CB, CE, CCC
Led Indicator Power, Lamp Standby
IO Panel
Input Terminals
RGB x1, RGB x1, DVI-Dx1, RGB x1,
S-Video x1, Video x1, S-Video x1, Video x1, S-Video x1, Video x1,
Audio (RCA L&R)x1, Audio (Mini Jack) x 1 Audio (RCA L&R)x1, Audio (Mini Jack) x 1 Audio (RCA L&R)x1, Audio (Mini Jack) x 1
Output Terminals RGB x 1, Audio x 1
Control Terminals USBx1
Build-in Speaker 3 w mono speaker (SPL <= 5W)
1. All Features, specifications, model numbers are subject to change without notice.
2. Digital Light Processing and DLP are registered trademarks of Texas Instruments.
