User's Manual - 1
Rev. 1.6.1.11
Rev. 1.0
User’s Manual
RX9502 H.265 Video Receiver
H.265/H.264 • 32 CH • HDMI • ONVIF
Rev. 1.0

VIVOTEK - Built with Reliability
2 - User's Manual
Table of Contents
Chapter One Hardware Installation and Initial Conguration ...................................................................................... 7
Introducing the Network Video Recorder ............................................................................................................... 7
Special Features ............................................................................................................................................. 8
Safety .............................................................................................................................................................. 8
Chassis Dimensions .................................................................................................................................... 9
Physical Description ........................................................................................................................................... 10
Topology ............................................................................................................................................................... 11
Hardware Installation .......................................................................................................................................... 12
Interface Connections ......................................................................................................................................... 13
Initial Conguration - via a Local Console ............................................................................................................ 14
Initial Conguration - via a Web Console (Optional) ............................................................................................ 17
LED Indicators...................................................................................................................................................... 19
Power Up and Power Down ................................................................................................................................. 20
Section One Management over a Local Console...................................................................................................... 21
Chapter Two Introduction to the Local Console Interface.......................................................................................... 21
2-1. How to Begin................................................................................................................................................. 23
2-2. Operation on a Camera View Cell................................................................................................................. 27
2-2-1. PTZ Panel........................................................................................................................................... 27
2-2-2. Digital Zoom Panel ............................................................................................................................. 31
2-2-3. Others ................................................................................................................................................. 32
2-2-4. Right-click Commands........................................................................................................................ 33
Chapter Three Conguation Using the Local Console .............................................................................................. 34
The Main Control Portal ....................................................................................................................................... 34
3-1. Layout .................................................................................................................................................... 34
3-2. Settings .................................................................................................................................................. 35
3-2-1. Settings - Overview...................................................................................................................... 35
3-2-2. Settings - Camera - Management................................................................................................ 36
3-3-1. Settings–Camera–Media ............................................................................................................. 44
3-3-2. Settings - System - Information ................................................................................................... 51
3-3-2. Settings - System - Maintenance................................................................................................. 52
3-3-3. Settings - System - Display.......................................................................................................... 53
3-4. Settings - User ................................................................................................................................ 54
3-4-1. Login / Logout.............................................................................................................................. 55
3-5. Settings - Network........................................................................................................................... 56
Settings - Network - IP ........................................................................................................................... 56
Settings - DDNS..................................................................................................................................... 57
Settings - Service................................................................................................................................... 58
3-6. HTTPS certicate .................................................................................................................................. 62
3-7. User ....................................................................................................................................................... 63
Settings–User-Login / Logout................................................................................................................. 65
3-8. Information ............................................................................................................................................. 66
Section Two Management over a Web Console ....................................................................................................... 67

VIVOTEK - Built with Reliability
User's Manual - 3
Safety and Compatibility............................................................................................................................................ 70

VIVOTEK - Built with Reliability
4 - User's Manual
Revision History
* Rev. 1.0: Initial release.
Some low quality Ethernet cables with smaller core diameter can seriously reduce the
transmission rate. Use CAT5e or CAT6 cables with a wire gauge of 24AWG for Receiver’s uplink
port. A thicker core 24 AWG network cable can o󰀨er less resistance than a 26 AWG or 28 AWG
network cable.
Use shielded cables in high noise environments where cross talk and EMI can occur.
IMPORTANT:
The product name tag and MAC address is here.

VIVOTEK - Built with Reliability
User's Manual - 5
Technology License Notice
Notices from HEVC Advance:
THIS PRODUCT IS SOLD WITH A LIMITED LICENSE AND IS AUTHORIZED TO BE USED ONLY
IN CONNECTION WITH HEVC CONTENT THAT MEETS EACH OF THE THREE FOLLOWING
QUALIFICATIONS: (1) HEVC CONTENT ONLY FOR PERSONAL USE; (2) HEVC CONTENT THAT
IS NOT OFFERED FOR SALE; AND (3) HEVC CONTENT THAT IS CREATED BY THE OWNER OF
THE PRODUCT. THIS PRODUCT MAY NOT BE USED IN CONNECTION WITH HEVC ENCODED
CONTENT CREATED BY A THIRD PARTY, WHICH THE USER HAS ORDERED OR PURCHASED
FROM A THIRD PARTY, UNLESS THE USER IS SEPARATELY GRANTED RIGHTS TO USE THE
PRODUCT WITH SUCH CONTENT BY A LICENSED SELLER OF THE CONTENT. YOUR USE OF
THIS PRODUCT IN CONNECTION WITH HEVC ENCODED CONTENT IS DEEMED ACCEPTANCE OF
THE LIMITED AUTHORITY TO USE AS NOTED ABOVE.
H.264
THIS PRODUCT IS LICENSED UNDER THE AVC PATENT PORTFOLIO LICENSE FOR THE
PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER TO (i) ENCODE VIDEO IN
COMPLIANCE WITH THE AVC STANDARD ("AVC VIDEO") AND/OR (ii) DECODE AVC VIDEO
THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL
ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO PROVIDER LICENSED TO PROVIDE AVC
VIDEO. NO LICENSE IS GRANTED OR SHALL BE IMPLIED FOR ANY OTHER USE. ADDITIONAL
INFORMATION MAY BE OBTAINED FROM MPEG LA, L.L.C. SEE HTTP://WWW.MPEGLA.COM

VIVOTEK - Built with Reliability
6 - User's Manual
Symbols and Statements in this Document
i
INFORMATION: provides important messages or advices that might help prevent inconvenient
or problem situations.
NOTE: Notices provide guidance or advices that are related to the functional integrity of the
machine.
Tips: Tips are useful information that helps enhance or facilitate an installation, function, or
process.
WARNING! or IMPORTANT: These statements indicate situations that can be dangerous or
hazardous to the machine or you.
Electrical Hazard: This statement appears when high voltage electrical hazards might occur
to an operator.
Read Before Use
The use of surveillance devices may be prohibited by law in your country. The Network Video
Receiver is not only a high-performance web-ready camera but can also be part of a flexible
surveillance system. It is the user’s responsibility to ensure that the operation of such devices is
legal before installing this unit for its intended use.
It is important to first verify that all contents received are complete according to the Package
Contents listed below. Take note of the warnings in the Quick Installation Guide before the
Network Video Receiver is installed; then carefully read and follow the instructions in the
Installation chapter to avoid damage due to faulty assembly and installation. This also ensures
the product is used properly as intended.
The Network Video Receiver is a network device and its use should be straightforward for those
who have basic networking knowledge. It is designed for various applications including video
sharing, general security/surveillance, etc. The Configuration chapter suggests ways to best
utilize the Network Video Receiver and ensure proper operations. For creative and professional
developers, the URL Commands of the Network Video Receiver section serves as a helpful
reference to customizing existing homepages or integrating with the current web server.
Package Contents
■ RX9502
■ Power adapter
■ Mouse
■ Quick Installation Guide
The operating system and management software are installed on a ash memory mounted
on the main board. Except for the plug-ins for the onscreen control, there is no need to install
software.
NOTE:

VIVOTEK - Built with Reliability
User's Manual - 7
Chapter One Hardware Installation and
Initial Conguration
Introducing the Network Video Recorder
VIVOTEK’s RX9502 is an H.265 Single-Channel Ultra-HD Video Receiver. Delivering high-
quality and detailed images, it is equipped for up to 32-CH network cameras and a maximum
network camera resolution of 8-Megapixels. The machine can drive an HD monitor directly via
HDMI, and supports decode options of 4K 30 fps, four H.265 1080p 120 fps, nine H.265 720p
270 fps, or sixteen H.265 D1 480 fps. The machine offers a more cost-effective and PC alterna-
tive solution with no costly VMS client fee, no HDD noise and no failure issues. It is suitable for
standalone viewers through local viewing. Secured and simplified IT management reduce the
requirement for end user training, further reducing long-term costs.
Space-saving, Flexible Installation
Compact size with fanless design for any small scale video surveillance installation, the model
is perfect for a single display application that requires space-saving solutions. For more fexible
installation, it supports, wall or desktop mount options.
Various Split-window Layout & Fisheye Dewarp Support
The machine provides various split modes for layout display (1x1, 2x2, 3x3, 1P+3, 2P+3, 1M+5,
1P+6, 3V, 1M+12, 1M+31, 4x4) and supports VIVOTEK’s fisheye camera Fisheye Dewarp func-
tion, which provides multiple de-warping modes to ensure the correct angle of video view and
detailed information for fexible usage.

VIVOTEK - Built with Reliability
8 - User's Manual
Safety
 Connect the system to an earthed main power outlet.
 Never open the housing of the power supply unit.
 Install and operate the system only in a dry, weather-proof location.
Observe the following safety factors:
• Is there visible damage to the system or power cord?
• Is the system operating correctly?
• Has the system been exposed to rain or moisture?
• Has the system been in a long storage under harsh conditions or exposed to
unconforming stress?
The relevant electrical engineering regulations must be complied with at all times during the
installation.
Ensure that all maintenance and repair work is handled by qualified personnel such as
electrical engineers or network specialists.
 Read this manual before installing or operating the system. The documentation contains
important safety instructions about permitted uses.
The rated AC input is: 100-240V~ 1A, 60-50Hz; the max. consumption: 11W (DC12V, 0.9A)
If a fault occurs, disconnect the power cord from the power supply.
Do not install the system close to heaters or other heat sources. Avoid locations with direct
sunlight.
All ventilation openings must not be blocked.
Use only the cables shipped with system or use appropriate cables that can withstand elec-
tromagnetic interference.
Special Features
● Runs on embedded Linux ● Fisheye Dewarp
● 1 x HDMI for local display up to 4K resolution ● Supports cameras of up to 20MP resolution
● Up to 32 Channel IP Camera Input ● ONVIF Compliance (Project Support Func-
tion)
● 1 x Gigabit RJ45 uplink Ethernet port; ● Supports Various Split-window Layout Dis-
play Modes
● 2 x USB Port (1 in Front / 1 USB 3.0 in Back) ● Snapshot / Export Media
● Size: 198 mm (W) x 200 mm (D) x 47 mm (H) ● PiP Video Control
● One Button Auto Setup ● Configuration Backup / Restore
● Compatible with VIVOTEK VSS Central Management Software*

VIVOTEK - Built with Reliability
User's Manual - 9
Chassis Dimensions
198
200
47
M4x10 for wall-mounting

VIVOTEK - Built with Reliability
10 - User's Manual
Physical Description
Front View
Rear View
1
2
1
2 3 4 5
3.0
1Activity LED: Please refer to page 19 for LED denitions.
2USB 2.0 port
1Power socket (DC12V, 1A) 4USB 3.0 port
210/100/1000Mbps uplink port 5Reset button
3HDMI
1
