Denon RCD-CX1 User manual

SUPER AUDIO CD RECEIVER
RCD-CX1
Owner’s Manual
Bedienungsanleitung
Manuel de l’Utilisateur
Manuale delle istruzioni
Manual del usuario
Gebruiksaanwijzing
Bruksanvisning
1.RCD-CX1_ENG.indd 1 2008/05/30 11:19:54

I
ITALIANO ESPAÑOL NEDERLANDS SVENSKADEUTSCH FRANCAISENGLISH
nSAFETY PRECAUTIONS
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCETHE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICINGTO QUALIFIED SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of
uninsulated “dangerous voltage” within the product’s enclosure
that may be of sufficient magnitude to constitute a risk of electric
shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSETHIS APPLIANCETO RAIN OR MOISTURE.
nLaser Class
(IEC 60825-1:2001)
CLASS 1 LASER PRODUCT
LUOKAN 1 LASERLAITE
KLASS 1 LASERAPPARAT

$-"44
-"4&3 130%6$5 

ADVARSEL: USYNLIG LASERSTRÅLING VED ÅBNING, NÅR
SIKKERHEDSAFBRYDERE ER UDE AF FUNKTION.
UNDGÅ UDSAETTELSE FOR STRÅLING.
VAROITUS! LAITTEEN KÄYTTÄMINEN MUULLA KUIN TÄSSÄ
KÄYTTÖOHJEESSA MAINITULLA TAVALLA SAATTAA
ALTISTAA KÄYTTÄJÄNTURVALLISUUSLUOKAN 1
YLITTÄVÄLLE NÄKYMÄMTTÖMÄLLE LASERSÄTEILYLLE.
VARNING: OM APPARATEN ANVÄNDS PÅ ANNAT SÄTT ÄN I DENNA
BRUKSANVISNING SPECIFICERATS, KAN ANVÄNDAREN
UTSÄTTAS FÖR OSYNLIG LASERSTRÅLNING SOM
ÖVERSKRIDER GRÄNSEN FÖR LASERKLASS 1.
ATTENZIONE: QUESTO APPARECCHIO E’ DOTATO DI
DISPOSITIVO OTTICO CON RAGGIO LASER.
L’USO IMPROPRIO DELL’APPARECCHIO PUO’ CAUSARE
PERICOLOSE ESPOSIZIONI A RADIAZIONI! CAUTION:
USE OF CONTROLS OR ADJUSTMENTS OR PERFORMANCE OF
PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
THIS PRODUCT SHOULD NOT BE ADJUSTED OR REPAIRED BY ANYONE
EXCEPT PROPERLY QUALIFIED SERVICE PERSONNEL.
• DECLARATION OF CONFORMITY
We declare under our sole responsibility that this product, to which this
declaration relates, is in conformity with the following standards:
EN60065, EN55013, EN55020, EN61000-3-2 and EN61000-3-3.
Following the provisions of 2006/95/EC and 2004/108/EC Directive.
• ÜBEREINSTIMMUNGSERKLÄRUNG
Wir erklären unter unserer Verantwortung, daß dieses Produkt, auf das
sich diese Erklärung bezieht, den folgenden Standards entspricht:
EN60065, EN55013, EN55020, EN61000-3-2 und EN61000-3-3.
Entspricht den Verordnungen der Direktive 2006/95/EC und 2004/108/EC.
• DECLARATION DE CONFORMITE
Nous déclarons sous notre seule responsabilité que l’appareil, auquel se
réfère cette déclaration, est conforme aux standards suivants:
EN60065, EN55013, EN55020, EN61000-3-2 et EN61000-3-3.
D’après les dispositions de la Directive 2006/95/EC et 2004/108/EC.
• DICHIARAZIONE DI CONFORMITÀ
Dichiariamo con piena responsabilità che questo prodotto, al quale la
nostra dichiarazione si riferisce, è conforme alle seguenti normative:
EN60065, EN55013, EN55020, EN61000-3-2 e EN61000-3-3.
In conformità con le condizioni delle direttive 2006/95/EC e 2004/108/EC.
QUESTO PRODOTTO E’ CONFORME
AL D.M. 28/08/95 N. 548
• DECLARACIÓN DE CONFORMIDAD
Declaramos bajo nuestra exclusiva responsabilidad que este producto al
que hace referencia esta declaración, está conforme con los siguientes
estándares:
EN60065, EN55013, EN55020, EN61000-3-2 y EN61000-3-3.
Siguiendo las provisiones de las Directivas 2006/95/EC y 2004/108/EC.
• EENVORMIGHEIDSVERKLARING
Wij verklaren uitsluitend op onze verantwoordelijkheid dat dit produkt,
waarop deze verklaring betrekking heeft, in overeenstemming is met de
volgende normen:
EN60065, EN55013, EN55020, EN61000-3-2 en EN61000-3-3.
Volgens de bepalingen van de Richtlijnen 2006/95/EC en 2004/108/EC.
• ÖVERENSSTÄMMELSESINTYG
Härmed intygas helt på eget ansvar att denna produkt, vilken detta intyg
avser, uppfyller följande standarder:
EN60065, EN55013, EN55020, EN61000-3-2 och EN61000-3-3.
Enligt stadgarna i direktiv 2006/95/EC och 2004/108/EC.
DENON EUROPE
Division of D&M Germany GmbH
An der Landwehr 19, Nettetal,
D-41334 Germany
1.RCD-CX1_ENG.indd 2 2008/05/30 11:19:55

ENGLISH
II
DEUTSCHFRANCAISITALIANOESPAÑOLNEDERLANDSSVENSKA ENGLISH
CAUTION:
• The ventilation should not be impeded by covering the ventilation openings with items,
such as newspapers, tablecloths, curtains, etc.
• No naked flame sources, such as lighted candles, should be placed on the unit.
• Observe and follow local regulations regarding battery disposal.
• Do not expose the unit to dripping or splashing fluids.
• Do not place objects filled with liquids, such as vases, on the unit.
ACHTUNG:
• Die Belüftung sollte auf keinen Fall durch das Abdecken der Belüftungsöffnungen durch
Gegenstände wie beispielsweise Zeitungen, Tischtücher, Vorhänge o. Ä. behindert
werden.
• Auf dem Gerät sollten keinerlei direkte Feuerquellen wie beispielsweise angezündete
Kerzen aufgestellt werden.
• Bitte beachten Sie bei der Entsorgung der Batterien die örtlich geltenden
Umweltbestimmungen.
• Das Gerät sollte keiner tropfenden oder spritzenden Flüssigkeit ausgesetzt werden.
• Auf dem Gerät sollten keine mit Flüssigkeit gefüllten Behälter wie beispielsweise Vasen
aufgestellt werden.
ATTENTION:
• La ventilation ne doit pas être gênée en recouvrant les ouvertures de la ventilation avec des
objets tels que journaux, rideaux, tissus, etc.
• Aucune flamme nue, par exemple une bougie, ne doit être placée sur l’appareil.
• Veillez à respecter les lois en vigueur lorsque vous jetez les piles usagées.
• L’appareil ne doit pas être exposé à l’eau ou à l’humidité.
• Ne pas poser d’objet contenant du liquide, par exemple un vase, sur l’appareil.
ATTENZIONE:
• Le aperture di ventilazione non devono essere ostruite coprendole con oggetti, quali
giornali, tovaglie, tende e così via.
• Non posizionate sull’unità fiamme libere, come ad esempio candele accese.
• Prestate attenzione agli aspetti legati alla tutela dell’ambiente nello smaltimento delle
batterie.
• L’apparecchiatura non deve essere esposta a gocciolii o spruzzi.
• Non posizionate sull’unità alcun oggetto contenente liquidi, come ad esempio i vasi.
PRECAUCIÓN:
• La ventilación no debe quedar obstruida por haberse cubierto las aperturas con objetos
como periódicos, manteles, cortinas, etc.
• No debe colocarse sobre el aparato ninguna fuente inflamable sin protección, como velas
encendidas.
• A la hora de deshacerse de las pilas, respete la normativa para el cuidado del medio
ambiente.
• No exponer el aparato al goteo o salpicaduras cuando se utilice.
• No colocar sobre el aparato objetos llenos de líquido, como jarros.
WAARSCHUWING:
• De ventilatie mag niet worden belemmerd door de ventilatieopeningen af te dekken met
bijvoorbeeld kranten, een tafelkleed, gordijnen, enz.
• Plaats geen open vlammen, bijvoorbeeld een brandende kaars, op het apparaat.
• Houd u steeds aan de milieuvoorschriften wanneer u gebruikte batterijen wegdoet.
• Stel het apparaat niet bloot aan druppels of spatten.
• Plaats geen voorwerpen gevuld met water, bijvoorbeeld een vaas, op het apparaat.
OBSERVERA:
• Ventilationen bör inte förhindras genom att täcka för ventilationsöppningarna med föremål
såsom tidningar, bordsdukar, gardiner osv.
• Inga blottade brandkällor, såsom tända ljus, får placeras på apparaten.
• Tänk på miljöaspekterna när du bortskaffar batterier.
• Apparaten får inte utsättas för vätska.
• Placera inte föremål fyllda med vätska, t.ex. vaser, på apparaten.
• Avoid high temperatures.
Allow for sufficient heat dispersion when installed in a rack.
• Vermeiden Sie hohe Temperaturen.
Beachten Sie, dass eine ausreichende Belüftung gewährleistet
wird, wenn das Gerät auf ein Regal gestellt wird.
• Eviter des températures élevées.
Tenir compte d’une dispersion de chaleur suffisante lors de
l’installation sur une étagère.
• Evitate di esporre l’unità a temperature elevate.
Assicuratevi che vi sia un’adeguata dispersione del calore
quando installate l’unità in un mobile per componenti audio.
• Evite altas temperaturas.
Permite la suficiente dispersión del calor cuando está
instalado en la consola.
• Vermijd hoge temperaturen.
Zorg er bij installatie in een audiorack voor, dat de door
het toestel geproduceerde warmte goed kan worden
afgevoerd.
• Undvik höga temperaturer.
Se till att det finns möjlighet till god värmeavledning vid
montering i ett rack.
• Handle the power cord carefully.
Hold the plug when unplugging the cord.
• Gehen Sie vorsichtig mit dem Netzkabel um.
Halten Sie das Kabel am Stecker, wenn Sie den Stecker
herausziehen.
• Manipuler le cordon d’alimentation avec précaution.
Tenir la prise lors du débranchement du cordon.
• Manneggiate il cavo di alimentazione con attenzione.
Tenete ferma la spina quando scollegate il cavo dalla presa.
• Maneje el cordón de energía con cuidado.
Sostenga el enchufe cuando desconecte el cordón de
energía.
• Hanteer het netsnoer voorzichtig.
Houd het snoer bij de stekker vast wanneer deze moet
worden aan- of losgekoppeld.
• Hantera nätkabeln varsamt.
Håll i kabeln när den kopplas från el-uttaget.
• Keep the unit free from moisture, water, and dust.
• Halten Sie das Gerät von Feuchtigkeit, Wasser und Staub
fern.
• Protéger l’appareil contre l’humidité, l’eau et la poussière.
• Tenete l’unità lontana dall’umidità, dall’acqua e dalla
polvere.
• Mantenga el equipo libre de humedad, agua y polvo.
• Laat geen vochtigheid, water of stof in het apparaat
binnendringen.
• Utsätt inte apparaten för fukt, vatten och damm.
• Unplug the power cord when not using the unit for long
periods of time.
• Wenn das Gerät längere Zeit nicht verwendet werden soll,
trennen Sie das Netzkabel vom Netzstecker.
• Débrancher le cordon d’alimentation lorsque l’appareil n’est
pas utilisé pendant de longues périodes.
• Scollegate il cavo di alimentazione quando prevedete di non
utilizzare l’unità per un lungo periodo di tempo.
• Desconecte el cordón de energía cuando no utilice el equipo
por mucho tiempo.
•
Neem altijd het netsnoer uit het stopkontakt wanneer het
apparaat gedurende een lange periode niet wordt gebruikt.
• Koppla loss nätkabeln om apparaten inte kommer att
användas i lång tid.
* (For apparatuses with ventilation holes)
• Do not obstruct the ventilation holes.
• Decken Sie den Lüftungsbereich nicht ab.
• Ne pas obstruer les trous d’aération.
• Non coprite i fori di ventilazione.
• No obstruya los orificios de ventilación.
• De ventilatieopeningen mogen niet worden beblokkeerd.
• Täpp inte till ventilationsöppningarna.
• Do not let foreign objects into the unit.
•
Lassen Sie keine fremden Gegenstände in das Gerät kommen.
• Ne pas laisser des objets étrangers dans l’appareil.
• Non inserite corpi estranei all’interno dell’unità.
• No deje objetos extraños dentro del equipo.
• Laat geen vreemde voorwerpen in dit apparaat vallen.
• Se till att främmande föremål inte tränger in i apparaten.
• Do not let insecticides, benzene, and thinner come in
contact with the unit.
• Lassen Sie das Gerät nicht mit Insektiziden, Benzin oder
Verdünnungsmitteln in Berührung kommen.
• Ne pas mettre en contact des insecticides, du benzène et
un diluant avec l’appareil.
• Assicuratevi che l’unità non entri in contatto con insetticidi,
benzolo o solventi.
• No permita el contacto de insecticidas, gasolina y diluyentes
con el equipo.
• Voorkom dat insecticiden, benzeen of verfverdunner met dit
toestel in contact komen.
• Se till att inte insektsmedel på spraybruk, bensen och
thinner kommer i kontakt med apparatens hölje.
• Never disassemble or modify the unit in any way.
• Versuchen Sie niemals das Gerät auseinander zu nehmen
oder zu verändern.
• Ne jamais démonter ou modifier l’appareil d’une manière ou
d’une autre.
• Non smontate né modificate l’unità in alcun modo.
• Nunca desarme o modifique el equipo de ninguna manera.
• Dit toestel mag niet gedemonteerd of aangepast worden.
• Ta inte isär apparaten och försök inte bygga om den.
nNOTE ON USE / HINWEISE ZUM GEBRAUCH / OBSERVATIONS RELATIVES A L’UTILISATION / NOTE SULL’USO /
NOTAS SOBRE EL USO / ALVORENS TE GEBRUIKEN / OBSERVERA ANGÅENDE ANVÄNDNINGEN
1.RCD-CX1_ENG.indd 3 2008/05/30 11:19:58

ENGLISH
A NOTE ABOUT RECYCLING:
This product’s packaging materials are recyclable and can be reused. Please dispose of any materials
in accordance with the local recycling regulations.
When discarding the unit, comply with local rules or regulations.
Batteries should never be thrown away or incinerated but disposed of in accordance with the local
regulations concerning battery disposal.
This product and the supplied accessories, excluding the batteries, constitute the applicable product
according to the WEEE directive.
HINWEIS ZUM RECYCLING:
Das Verpackungsmaterial dieses Produktes ist zum Recyceln geeignet und kann wieder verwendet werden. Bitte
entsorgen Sie alle Materialien entsprechend der örtlichen Recycling-Vorschriften.
Beachten Sie bei der Entsorgung des Gerätes die örtlichen Vorschriften und Bestimmungen.
Die Batterien dürfen nicht in den Hausmüll geworfen oder verbrannt werden; bitte entsorgen Sie die Batterien gemäß
der örtlichen Vorschriften.
Dieses Produkt und das im Lieferumfang enthaltene Zubehör (mit Ausnahme der Batterien!) entsprechen der WEEE-
Direktive.
UNE REMARQUE CONCERNANT LE RECYCLAGE:
Les matériaux d’emballage de ce produit sont recyclables et peuvent être réutilisés. Veuillez disposer des matériaux
conformément aux lois sur le recyclage en vigueur.
Lorsque vous mettez cet appareil au rebut, respectez les lois ou réglementations en vigueur.
Les piles ne doivent jamais être jetées ou incinérées, mais mises au rebut conformément aux lois en vigueur sur la
mise au rebut des piles.
Ce produit et les accessoires inclus, à l’exception des piles, sont des produits conformes à la directive DEEE.
NOTA RELATIVA AL RICICLAGGIO:
I materiali di imballaggio di questo prodotto sono riutilizzabili e riciclabili. Smaltire i materiali conformemente alle
normative locali sul riciclaggio.
Per lo smaltimento dell’unità, osservare le normative o le leggi locali in vigore.
Non gettare le batterie, né incenerirle, ma smaltirle conformemente alla normativa locale sui rifiuti chimici.
Questo prodotto e gli accessori inclusi nell’imballaggio sono applicabili alla direttiva RAEE, ad eccezione delle batterie.
ACERCA DEL RECICLAJE:
Los materiales de embalaje de este producto son reciclables y se pueden volver a utilizar. Disponga de estos materiales
siguiendo los reglamentos de reciclaje de su localidad.
Cuando se deshaga de la unidad, cumpla con las reglas o reglamentos locales.
Las pilas nunca deberán tirarse ni incinerarse. Deberá disponer de ellas siguiendo los reglamentos de su localidad
relacionados con los desperdicios químicos.
Este producto junto con los accesorios empaquetados es el producto aplicable a la directiva RAEE excepto pilas.
EEN AANTEKENING MET BETREKKINGTOT DE RECYCLING:
Het inpakmateriaal van dit product is recycleerbaar en kan opnieuw gebruikt worden. Er wordt verzocht om zich van
elk afvalmateriaal te ontdoen volgens de plaatselijke voorschriften.
Volg voor het wegdoen van de speler de voorschriften voor de verwijdering van wit- en bruingoed op.
Batterijen mogen nooit worden weggegooid of verbrand, maar moeten volgens de plaatselijke voorschriften
betreffende chemisch afval worden verwijderd.
Op dit product en de meegeleverde accessoires, m.u.v. de batterijen is de richtlijn voor afgedankte elektrische en
elektronische apparaten (WEEE) van toepassing.
OBSERVERA ANGÅENDE ÅTERVINNING:
Produktens emballage är återvinningsbart och kan återanvändas. Kassera det enligt lokala återvinningsbestämmelser.
När du kasserar enheten ska du göra det i överensstämmelse med lokala regler och bestämmelser.
Batterier får absolut inte kastas i soporna eller brännas. Kassera dem enligt lokala bestämmelser för kemiskt avfall.
Denna apparat och de tillbehör som levereras med den uppfyller gällande WEEE-direktiv, med undantag av
batterierna.
ITALIANO ESPAÑOL NEDERLANDS SVENSKADEUTSCH FRANCAISENGLISH
III
CAUTION:
To completely disconnect this product from the mains, disconnect
the plug from the wall socket outlet.
The mains plug is used to completely interrupt the power supply to
the unit and must be within easy access by the user.
VORSICHT:
Um dieses Gerät vollständig von der Stromversorgung abzutrennen,
ziehen Sie bitte den Stecker aus der Wandsteckdose.
Der Netzstecker wird verwendet, um die Stromversorgung zum
Gerät völlig zu unterbrechen; er muss für den Benutzer gut und
einfach zu erreichen sein.
PRECAUTION:
Pour déconnecter complètement ce produit du courant secteur,
débranchez la prise de la prise murale.
La prise secteur est utilisée pour couper complètement
l’alimentation de l’appareil et l’utilisateur doit pouvoir y accéder
facilement.
ATTENZIONE:
Per scollegare completamente questo prodotto dalla rete di
alimentazione elettrica, scollegare la spina dalla relativa presa a muro.
La spina di rete viene utilizzata per interrompere completamente
l’alimentazione all’unità e deve essere facilmente accessibile
all’utente.
PRECAUCIÓN:
Para desconectar completamente este producto de la alimentación
eléctrica, desconecte el enchufe del enchufe de la pared.
El enchufe de la alimentación eléctrica se utiliza para interrumpir por
completo el suministro de alimentación eléctrica a la unidad y debe
de encontrarse en un lugar al que el usuario tenga fácil acceso.
WAARSCHUWING:
Om de voeding van dit product volledig te onderbreken moet de
stekker uit het stopcontact worden getrokken.
De netstekker wordt gebruikt om de stroomtoevoer naar het toestel
volledig te onderbreken en moet voor de gebruiker gemakkelijk
bereikbaar zijn.
FÖRSIKTIHETSMÅTT:
Koppla loss stickproppen från eluttaget för att helt skilja produkten
från nätet.
Stickproppen används för att helt bryta strömförsörjningen till
apparaten, och den måste vara lättillgänglig för användaren.
1.RCD-CX1_ENG.indd 4 2008/05/30 12:05:20

ENGLISH

Accessories······················································································2
Cautions on Handling·····································································2
Cautions on Installation·································································2
About Discs·····················································································2
Discs Usable on the RCD-CX1·······················································2
Holding Discs·················································································3
Loading Discs·················································································3
Cautions on Loading Discs·····························································3
Cautions on Handling·····································································3
Cautions on Storing Discs······························································3
Cleaning Discs ···············································································4
About the Remote Control Unit····················································4
Inserting the Batteries····································································4
Operating Range of the Remote Control Unit································4
Part Names and Functions·····························································5
Front Panel ·····················································································5
Display ···························································································5
Rear Panel ······················································································5
Remote Control Unit······································································6
Setting the CurrentTime (24-Hour Display) ······························· 13
Convenient Functions ··································································27
Auto Power On·············································································27
Auto Function Selector Function ··················································27
Last Function Memory·································································27
Resetting the Microprocessor······················································27
Timer Playback··············································································24
Setting the Timer··········································································24
Set the Timer ON/OFF ·································································26
Setting the Sleep Timer································································26
Getting Started
nContents Setup Setting the Timer
Other Functions
Troubleshooting····························································· 28
Specifications·································································· 30
Preparations····················································································8
Cables Used for Connections ························································8
Using the AM Loop Antenna··························································8
Assembling the AM Loop Antenna ················································8
Speaker Connections ·····································································9
Connecting the Speaker Cables·····················································9
Connecting the Playback Components ······································ 10
Record Player··············································································· 10
iPod®···························································································· 10
Connecting a Power Amp and Subwoofer ································ 10
Connecting the Recording Components···································· 11
CD Recorder / MD Recorder / Tape Deck····································· 11
Connections to Other Devices····················································· 12
Antenna terminals ······································································· 12
Connecting the Power Cord························································· 12
Once Connections are Completed ·············································· 12
Connections
Preparations·················································································· 14
Turning the Power On ·································································· 14
Setting the layer to be played with priority··································· 14
Loading Discs··············································································· 14
Operations During Playback ························································ 15
Adjusting the Master Volume·······················································15
Input Source Switching ································································ 15
Listening with Headphones ························································· 15
Adjusting the Tone········································································ 15
Turning the Sound OffTemporarily (Muting)································· 15
Switching the Brightness of the Display ······································ 15
CD Playback ·················································································· 16
Playing CDs·················································································· 16
Switching the Display··································································· 16
Repeat Play or Random Play ························································ 17
PlayingTracks in the Desired Order <Program> ·························· 17
Playback of MP3 and WMA Files ·················································18
About the MP3 and WMA FormatsThat Can be Played ··············18
Playing MP3 and WMA Files························································ 19
Repeat Play or Random Play ························································ 19
TUNER Playback ··········································································· 19
Tuning in Broadcast Stations························································ 19
Automatically Presetting FM Stations (Auto Preset)····················20
Presetting FM/AM Stations Manually ··········································20
Listening to Preset Stations·························································20
Naming the Currently Tuned in Broadcast Station························20
RDS (Radio Data System) ····························································21
RDS Search ··················································································21
PTY Search···················································································21
TP Search ·····················································································21
RT (Radio Text)··············································································22
iPod®Playback ·············································································22
Preparations ·················································································22
Listening to Audio ········································································23
Disconnecting the iPod ································································23
Recording ······················································································23
Recording on an External Device ·················································23
Playback
1.RCD-CX1_ENG.indd 1 2008/05/30 11:19:59


ENGLISH
Connections Setup Playback Setting theTimer Other Functions Troubleshooting Specifications
Check that the following parts are supplied with the product.
qRemote control (RC-1109)........................................................ 1
wR03/AAA batteries ................................................................... 2
ePower cord (Cord length: Approx. 1.6 m).................................1
rAM loop antenna ..................................................................... 1
tFM indoor antenna .................................................................. 1
yOwner’s manual ...................................................................... 1
uService station list ................................................................... 1
Thank you for purchasing this DENON product. To ensure proper
operation, please read this owner’s manual carefully before using the
product.
After reading them, be sure to keep them for future reference. • Before turning the power switch on
Check once again that all connections are correct and that there are
no problems with the connection cables.
• Power is supplied to some of the circuitry even when the unit is
set to the standby mode. When traveling or leaving home for long
periods of time, be sure to unplug the power cord from the power
outlet.
• Sufficiently ventilate the place of installation
If the unit is left in a room full of the smoke from cigarettes, etc., for
long periods of time, the surface of the optical pickup could get dirty,
in which case it will not be able to read the signals properly.
• About condensation
If there is a major difference in temperature between the inside of
the unit and the surroundings, condensation (dew) may form on
the operating parts inside the unit, causing the unit not to operate
properly.
If this happens, let the unit sit for an hour or two with the power
turned off and wait until there is little difference in temperature
before using the unit.
• Cautions on using mobile phones
Using a mobile phone near this unit may result in noise. If so, move
the mobile phone away from this unit when it is in use.
• Moving the unit
Turn off the power and unplug the power cord from the power
outlet.
Next, disconnect the connection cables to other system units before
moving the unit.
• Note that the illustrations in these instructions may differ from the
actual unit for explanation purposes.
Note:
For proper heat dispersal, do not install this unit in a confined
space, such as a bookcase or similar enclosure.
bNote
bWall b
b
e
r t
q
Discs Usable on the RCD-CX1
qSuper Audio CDs
Super Audio CDs marked with the logotypes indicated below can
be played on this unit.
There are three types of Super Audio CDs:
q Single layer disc
Single layer Super Audio CD with only an HD layer.
w Dual layer disc
Super Audio CD with a double HD layer, offering extended playing
time and high sound quality.
e Hybrid disc
Two-layer Super Audio CD with an HD layer and a CD layer.
The signals on the CD layer can be played on a regular CD player.
Getting Started
Accessories
Getting Started
Cautions on Handling
About Discs
Cautions on Installation
1.RCD-CX1_ENG.indd 2 2008/05/30 11:20:00

Connections Setup Playback Setting theTimer Other Functions Troubleshooting
ENGLISH
Specifications

wMusic CDs
Discs marked with the logotype below can be played in this unit.
eCD-R/CD-RW
• Some discs and some recording formats may not be playable.
• Non-finalized discs cannot be played.
bWhat is finalization?
Finalization is the process that makes recorded CD-R/CD-RW discs
playable on compatible players.
NOTE
Discs with special shapes (heart-
shaped discs, octagonal discs,
etc.) cannot be played. Do not
attempt to play them, as doing so
can damage the product.
Holding Discs
Do not touch the signal surface.
Loading Discs
• Set the disc with the labeled side facing up.
• Make sure the disc tray is fully open when inserting the disc.
• Place the discs flatly, 12 cm discs in the outer tray guide (Figure 1), 8
cm discs in the inner tray guide (Figure 2).
Figure 1 Figure 2
Outer tray
guide 12 cm disc 8 cm disc
Inner tray
guide
• Place 8 cm discs in the inner tray guide without using an adapter.
• “00:00” is displayed if a disc that cannot be played is loaded.
• “NO DISC” is displayed if the disc is loaded upside-down or if no disc
is loaded.
Cautions on Loading Discs
• Only load one disc at a time. Loading two or more discs can damage
the unit or scratch the discs.
• Do not use cracked or warped discs or discs that have been repaired
with adhesive, etc.
• Do not use discs on which the sticky part of cellophane tape or labels
is exposed or on which there are traces of where labels have been
removed. Such discs can get caught inside the player and damage
it.
Cautions on Handling
• Do not get fingerprints, oil or dirt on discs.
• Take special care not to scratch discs when removing them from
their cases.
• Do not bend or heat discs.
• Do not enlarge the hole at the center.
• Do not write on the labeled (printed) surface with ball-point pens,
pencils, etc., or stick new labels on discs.
• Water droplets may form on discs if they are moved suddenly from a
cold place (outdoors for example) to a warm place, but do not try to
dry them off using a hairdryer, etc.
Cautions on Storing Discs
• Be sure to remove discs after using them.
• Be sure to store discs in their cases to protect them from dust,
scratches, warping, etc.
• Do not store discs in the following places:
1. Places exposed to direct sunlight for long periods of time
2. Dusty or humid places
3. Places exposed to heat from heating appliances, etc.
Getting Started
bWhat is the HD layer?
The HD layer is a layer of high density signals for Super Audio
CDs.
bWhat is the CD layer?
The CD layer is the layer of signals that can be read on a regular CD
player.
Hybrid discDual layer discSingle layer disc
HD layer
Types of Super Audio CDs
HD layer CD layer HD layer
This unit is not compatible with multi-channel playback.
1.RCD-CX1_ENG.indd 3 2008/05/30 11:20:02


ENGLISH
Connections Setup Playback Setting theTimer Other Functions Troubleshooting Specifications
Cleaning Discs
• If there are fingerprints or dirt on discs, wipe them off before using
the disc. Fingerprints and dirt can impair sound quality and cause
interruptions in playback.
• Use a commercially available disc cleaning set or a soft cloth to clean
discs.
Gently wipe the disc from the
inside towards the outside.
Do not wipe with a circular
motion.
NOTE
Do not use record spray, antistatic agents, or benzene, thinner or other
solvents.
Inserting the Batteries
qRemove the remote control
unit’s rear cover.
wSet two R03/AAA batteries in
the battery compartment in the
indicated direction.
ePut the rear cover back on.
NOTE
• Replace the batteries with new ones if the set does not operate even
when the remote control unit is operated close to the unit.
• The supplied batteries are only for verifying operation.
• When inserting the batteries, be sure to do so in the proper direction,
following the “q” and “w” marks in the battery compartment.
• To prevent damage or leakage of battery fluid:
• Do not use a new battery together with an old one.
• Do not use two different types of batteries.
• Do not attempt to charge dry batteries.
• Do not short-circuit, disassemble, heat or dispose of batteries in
flames.
• If the battery fluid should leak, carefully wipe the fluid off the inside
of the battery compartment and insert new batteries.
• Remove the batteries from the remote control unit if it will not be in
use for long periods.
30°
30°
Approx. 7 m
Operating Range of the Remote Control
Unit
Point the remote control unit at the remote sensor when operating it.
NOTE
The set may function improperly or the remote control unit may not
operate if the remote control sensor is exposed to direct sunlight,
strong artificial light from an inverter type fluorescent lamp or infrared
light.
Getting Started
About the Remote Control Unit
1.RCD-CX1_ENG.indd 4 2008/05/30 11:20:03

Connections Setup Playback Setting theTimer Other Functions Troubleshooting
ENGLISH
Specifications

For buttons not explained here, see the page indicated in parentheses ( ).
qRemote control sensor································· (4)
wPower indicator··········································· (14)
ePower operation button
(ON/STANDBY) ····································· (13, 14)
rHeadphones jack (PHONES)······················ (15)
tDisplay
y Master volume control knob (VOLUME) ····· (15)
qInformation display
Various information is displayed here, depending
on the operation mode.
Front Panel
Display
wTuner reception mode indicators ······(19 ~ 22)
eMode indicators···························· (16 ~ 19, 23)
Rear Panel
qCARTRIDGE selection switch ···················· (10)
wAnalog audio input connectors············(10, 11)
eAnalog audio output connectors ········(10, 11)
rDigital audio output connector
(OPTICAL OUT) ············································(11)
tDOCK CONTROL jack ································· (10)
yAC inlet (AC IN)··········································· (12)
uSpeaker terminals (SPEAKER SYSTEM) ····· (9)
iFM/AM antenna terminals························· (12)
oSIGNAL GND terminal ······························· (10)
uSOURCE button ·········································· (15)
iReverse-skip/Forward-skip buttons
(8/–, +/9)······································· (16, 19)
oPlay/Pause button (1/3)··························· (16)
Q0 Stop / Disc tray open/close button
(2/5)···························································· (14)
Q1 Disc tray························································· (3)
q w e r t
yuioQ0Q1
q
e
w
q
o i u y
w e r t
Getting Started
Part Names and Functions
1.RCD-CX1_ENG.indd 5 2008/05/30 11:20:04


Connections Setup Playback Setting theTimer Other Functions Troubleshooting
ENGLISH
Specifications
Remote Control Unit
qRemote control signal transmitter·············· (4)
wON/STANDBY button································· (13)
eMENU/SET button ····································· (13)
rCursor buttons
(2/u, 8/i, 4/o, 6/p)·································· (13)
tFunction buttons
(LINE1/LINE2,TUNER, PHONO)················· (15)
yTIME/DISPLAY button································ (13)
uMaster volume control buttons
(VOLUME) ··················································· (15)
iDIMMER button·········································· (15)
oENTER button (5/ENTER) ·························· (13)
Q0 SLEEP/TIMER button ································· (26)
Q1 PURE DIRECT/TONE button ······················ (15)
Q2 MUTE button ·············································· (15)
qNumber buttons ········································· (16)
wREPEAT/RANDOM button ························· (17)
ePlay/Pause button (1/3)··························· (16)
rFast-reversing/Fast-forwarding buttons
(TU–/6,TU+/7)···································· (16)
tMODE button·············································· (19)
yCLEAR button ············································· (17)
uPROGRAM DIRECT button························· (17)
iReverse-skip/Forward-skip buttons
(CH–/8, CH+/9)································· (16)
oStop button (2)··········································· (16)
w
q
t
e
r
u
Q1
Q0
o
Q2
i
y
q
y
u
i
o
r
e
w
t
Buttons Operable for All Functions (CD, PHONO,TUNER, LINE1, LINE2 and iPod) Buttons Operable When the Function is Set to “CD”
The buttons listed at “Buttons Operable for All Functions” can also be used.
Getting Started
1.RCD-CX1_ENG.indd 6 2008/05/30 11:20:05

Connections Setup Playback Setting theTimer Other Functions Troubleshooting
ENGLISH
Specifications

q
w
r
t
e
r
e
q
w
qNumber buttons ········································· (20)
wChannel +, – buttons
(CH–/8, CH+/9)································· (20)
eTuning +, – buttons
(TU–/6,TU+/7)···································· (19)
rCLEAR button ············································· (20)
tPROGRAM/DIRECT button ························ (20)
qiPod 1/3button ········································· (23)
wREPEAT/RANDOM button ························· (23)
eMODE button·············································· (22)
rReverse-skip/Forward-skip /
Fast-reversing/Fast-forwarding buttons
(CH–/8, CH+/9)································· (23)
Buttons Operable When the Function is Set to “TUNER”
The buttons listed at “Buttons Operable for All Functions” can also be used.
Buttons Operable When the Function is Set to “iPod”
The buttons listed at “Buttons Operable for All Functions” can also be used.
Getting Started
1.RCD-CX1_ENG.indd 7 2008/05/30 11:20:06


ENGLISH
Getting Started Setup Playback Setting theTimer Other Functions Troubleshooting Specifications
Audio cables
Optical digital connections
Optical cable
Analog connections (stereo)
(White)
(Red)
R
L
R
L
Stereo pin-plug cable
Speaker connections
Speaker cables
Signal direction
Audio signal:
Output
Input
Input
Output
Cables Used for Connections
Select the cables according to the equipment being connected.
NOTE
• Do not plug in the power cord until all connections have been
completed.
• When making connections, also refer to the operating instructions of
the other components.
• Be sure to connect the left and right channels properly (left with left,
right with right).
• Do not bundle power cords together with connection cables. Doing
so can result in humming or noise.
Connections for all compatible audio signal format is described in
this operating instructions. Please select the types of connections
suited for the equipment you are connecting.
With some types of connections, certain settings must be made
on the RCD-CX1. For details, refer to the instructions for the
respective connection items below.
Using the AM Loop Antenna
nTo use suspended on a wall
Suspend directly on the wall without assembling.
Nail, tack, etc.
nTo use standing alone
Use the procedure below to assemble.
1Bend in the direction of the arrow.
2Insert into the hole.
Assembling the AM Loop Antenna
Connections
Connections
Preparations
1.RCD-CX1_ENG.indd 8 2008/05/30 11:20:09

Getting Started Setup Playback Setting theTimer Other Functions Troubleshooting
ENGLISH
Specifications

w qw q
(R)(L)
Speakers
Carefully check the left (L) and right (R) channels and + (red) and –
(black) polarities on the speakers being connected to the RCD-CX1,
and be sure to interconnect the channels and polarities correctly.
1Peel off about 10 mm of sheathing from the tip of the speaker cable, then either
twist the core wire tightly or terminate
it.
2Turn the speaker terminal counterclockwise to loosen it.
3Insert the speaker cable’s core wire to the hilt into the speaker terminal.
4Turn the speaker terminal clockwise to tighten it.
NOTE
• Use speakers with an impedance of 4 to 16 Ω/ohms. The protection
circuit may be activated if speakers with an impedance other than
specified are used.
• Connect the speaker cables in such a way that they do not stick out
of the speaker terminals. The protection circuit may be activated if
the core wires touch the rear panel or if the + and – sides touch each
other (v“Protection circuit”).
• Never touch the speaker terminals while the power supply is
connected. Doing so could result in electric shock.
Protection circuit
The protection circuit will be activated in thefollowing cases:
• When the speaker cable’s core wires are touching the rear
panel or screws or when the speaker cable’s + and – sides are
touching
• When the surrounding temperature is extremely high
• When the internal temperature rises due to extended use with a
high output
If this happens, unplug the power cord, then check the connections
of the speaker cables and input cables. If the set’s temperature
is extremely high, wait for it to cool off and improve surrounding
ventilation. After doing this, plug the power cord back in.
If the protection circuit is activated though there are no problems
in ventilation around the set or in connections, the set could be
damaged. Turn off the power, then contact a DENON servicing and
inquiry outlet.
Connecting the Speaker Cables
Connections
Speaker Connections
1.RCD-CX1_ENG.indd 9 2008/05/30 11:20:11

0
ENGLISH
Getting Started Setup Playback Setting theTimer Other Functions Troubleshooting Specifications
Record Player
(/%
"6%*0
065
R
L
• With some record players, noise may be generated when the ground
wire is connected. If so, disconnect the ground wire.
• Set the CARTRIDGE selection switch to “jMM” or “hMC”
according to the cartridge being used.
NOTE
The RCD-CX1’s SIGNAL GND terminal is meant to reduce noise when
a record player is connected. This is not a safety ground terminal.
iPod®
• When using a control dock for iPod, the Control Dock for iPod must
be set. For details, refer to the operating instructions of the Control
Dock for iPod.
• When the control dock for iPod is connected, the function indicator
switches from “LINE1” to “iPod”.
• To use an iPod, see “iPod®Playback” (vpage 22).
Use a DENON control dock for iPod (ASD-1R or ASD-3N/3W, sold
separately) to connect the iPod to the RCD-CX1.
"4%/8
RL
RL
iPod
Connections
R
L
R
L
3-
*/
Connecting the Playback
Components
Turntable
Connecting a Power Amp and
Subwoofer
Use when adding a power amp, subwoofer, etc.
Power amp /
Subwoofer
NOTE
DO NOT insert a short pin plug for recording output (REC) and pre-out
terminals, as this may result in damage.
1.RCD-CX1_ENG.indd 10 2008/05/30 11:20:12

Getting Started Setup Playback Setting theTimer Other Functions Troubleshooting
ENGLISH
Specifications

"6%*0
*/
015*$"-
Digital connections
No digital signals are output for Super Audio CDs.
nWhen connecting the optical digital output connector
with an optical transmission cable (sold separately)
Protective cap Match the shapes
Remove the protective cap, match the shapes, then insert firmly all
the way in.
Store the protective cap in a safe place so as not to lose it, and use it
when not using the terminal.
CD recorder /
MD recorder
Connections
CD Recorder / MD Recorder / Tape Deck
R
L
R
L
R
L
R
L
3- 3-
065 */
"6%*0
"6%*0
CD recorder /
MD recorder /
Tape deck
Analog connections
Connecting the Recording
Components
1.RCD-CX1_ENG.indd 11 2008/05/30 11:20:13


ENGLISH
Getting Started Setup Playback Setting theTimer Other Functions Troubleshooting Specifications
NOTE
• Insert the AC plugs securely. Incomplete connections could cause noise.
• When the power cord is plugged into the power outlet, the power indicator flashes orange for about 10 seconds.
Do not unplug the power cord before the power indicator turns off and the RCD-CX1 enters Standby mode.
• Only use the supplied power cord.
• Be sure the power cord is unplugged from the power outlet before connecting or disconnecting it to the AC IN.
Wait until all connections have been completed before connecting the power cord.
To household
power outlet
(AC 230 V, 50 Hz)
Power cord
(supplied)
Turning the Power On (vpage 14)
NOTE
• Make sure the AM loop antenna lead terminals do not touch metal
parts of the panel.
• Do not connect two FM antennas simultaneously.
nConnecting the AM loop antenna
1Push the lever.
2Insert the conductor.
3Return the lever.
Connections
AM / FM
The AM and FM reception sensitivity depends on the place the antenna
is set and the direction in which it is set. Set it so that reception is
best.
Antenna terminals
AM loop
antenna
(supplied)
FM indoor antenna
(supplied)
Connections to Other Devices Connecting the Power Cord
Once Connections are Completed
1.RCD-CX1_ENG.indd 12 2008/05/30 11:20:15

Getting Started Setting theTimer Other Functions Troubleshooting
ENGLISH
Specifications

[MENU/SET]
[2/u]
[5/ENTER]
[8/i]
[TIME/DISPLAY]
ON/STANDBY
ON/STANDBY
Button located on both the main unit and the remote control
unit BUTTON
Button only on the main unit <BUTTON>
Button only on the remote control unit [BUTTON]
Symbols used to indicate buttons in this manual
GExampleH Setting the current time to 10:15 am
1Press ON/STANDBY to turn the power on.
2Press and hold in [TIME/DISPLAY].
The time is displayed.
3Press and hold in [MENU/SET] to enter time setting mode.
“TIME Adj” is displayed for about 2 seconds.
4Use [2/u]or [8/i]to set the “hours”.
5Press [MENU/SET] or [5/ENTER]. The “minutes” display flashes.
6
Use [2/u]or [8/i]to set the “minutes”.
7Press [MENU/SET] or [5/ENTER].
The current time is set, and the normal display reappears.
TIME AdjTIME Adj
10:0010:00
10:0010:00
10:1510:15
nChecking the current time when the power is on
Press and hold in [TIME/DISPLAY].
Press once more and the display returns to its original condition.
nChecking the current time when the power is set
to standby
Press [TIME/DISPLAY].
Press once more, and the standby display is resumed.
Displaying the time when the power is set to standby consumes
electricity. To reduce electric consumption, turn the time display off.
NOTE
The time cannot be set when in the standby mode.Turn on the power
first.
Connections Setup Playback
Setup
Setting the CurrentTime
(24-Hour Display)
1.RCD-CX1_ENG.indd 13 2008/05/30 11:20:18


ENGLISH
Getting Started Connections Setup Setting theTimer Other Functions Troubleshooting Specifications
Setting the layer to be played with
priority
• The layer that is played with priority when the disc is loaded can be
set.
• Upon purchase, the priority layer is set to the “SA-CD”.
[Selectable items]
SA-CD : The SA-CD layer mode for Super Audio CDs.
CD : The CD layer mode for Super Audio CDs.
This setting is stored in the RCD-CX1’s memory and is not canceled
even when the disc tray is opened or closed or the power is turned on
or off. To change the setting, perform the above procedure again.
Loading Discs
In the stop mode, press <2/5>to open the disc tray.
b“Loading Discs” (vpage 3).
nTo close the disc tray
Press <2/5>again.
bThe disc tray also closes when 1/3is pressed.
NOTE
• The power must be on when opening and closing the disc tray.
• Do not push the disc tray in by hand when the power is off. Doing so
can damage it.
• Do not insert foreign objects into the disc tray. Doing so will damage it.
Playback
[MENU/SET]
[VOLUME df]
SOURCE
[PURE DIRECT/
TONE]
[MUTE]
[DIMMER]
[4/o][6/p]
1/3
ON/STANDBY
ON/STANDBY
SOURCE
<PHONES>
< 2 / 5 > 1 / 3
<VOLUME>
Button located on both the main unit and the remote control
unit BUTTON
Button only on the main unit <BUTTON>
Button only on the remote control unit [BUTTON]
Symbols used to indicate buttons in this manual
Playback
Turning the Power On
NOTE
• Power continues to be supplied to some of the circuitry even when
the power is in the standby mode. When leaving home for long
periods of time or when traveling, either press ON/STANDBY to turn
off the power, or unplug the power cord from the power outlet.
• Be sure to stop playback before turning the power off.
Press ON/STANDBY.
• The power turns on. Press again to set the power to standby.
• When the power is turned on, the function that was being used
when the power was last turned off is selected (vpage 27 “Last
function memory”).
GWhen the last function was CDH
When no disc is loaded, “NO DISC” is displayed.
nCompletely turning off the power
Unplug the power cord from the wall outlet.
bNote that the time setting is cleared when the power cord is
unplugged from the outlet.
bThe settings made for the various functions may be cleared if the
power cord is left unplugged from a power outlet for an extended
period of time.
Power indicator
Standby∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ Off
Power on ∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙ Red
When the timer is set∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙∙Orange
Preparations
1When “NO DISC” is displayed, press and hold [MENU/SET].
The current priority layer is displayed.
2Press [MENU/SET] again and select the layer to be played with priority.
SA-CD CD
1.RCD-CX1_ENG.indd 14 2008/05/30 11:20:21

Getting Started Connections Setup Setting theTimer Other Functions Troubleshooting
ENGLISH
Specifications

1Press [PURE DIRECT/TONE] and select the mode you want to adjust.
BASS
TREBLE
Pure D
(PURE DIRECT)
BALANCE
2Adjust the volume with [4/o,6/p].
bThereafter, to adjust another mode, press [PURE DIRECT/TONE].
bIf no operation is performed for 3 seconds, the adjustment is
retained and the normal display reappears.
Adjusting theTone
[Selectable modes]
Pure D
(PURE
DIRECT)
: This is the mode that recreates the original sound most
faithfully, providing extremely high quality sound.
[Selectable items] on off
BASS : Adjusts the bass sound.
[Variable range] –8dB ~+8dB
TREBLE : Adjusts the treble sound.
[Variable range] –8dB ~+8dB
BALANCE : Adjusts the left/right volume balance.
[Variable range] +L10 ~CENTER ~+R10
Press [4/o]when you want to adjust the left channel,
and [6/p]when you want to adjust the right channel.
Settings made upon purchase:
• Pure D (PURE DIRECT) ·············off
• BASS ·······································0dB
• TREBLE···································0dB
• BALANCE························ CENTER
When “Pure D” is set to “on”, digital output is switched off. What is
shown on the display also goes off. (When not playing or when no disc
is loaded, only part of the display is shown.)
NOTE
• When “Pure D” is set to “on”, you cannot set “BASS”, “TREBLE” or
“BALANCE”.
• When “Pure D” is set to “on”, you cannot use [DIMMER].
Switching the Brightness of the Display
Press [DIMMER].
100% 40%
OFF
bThe display’s brightness switches each time the button is
pressed.
Turning the Sound OffTemporarily
(Muting)
Press [MUTE].
The “Mute on” is displayed.
To cancel, press [MUTE] again.
(The mute mode is also canceled when the <VOLUME> is turned or a
[VOLUME df]is pressed.)
Playback
Adjusting the Master Volume
Either turn <VOLUME> or press [VOLUME df].
The volume level is displayed.
[Variable range] –90.0dB ~0.0dB
bWhen lowering the volume from –90.0 dB, the display shows
“– –.– dB”.
Input Source Switching
Press SOURCE to select input source.
CD TUNER PHONO
LINE1 (iPod)LINE2 b
bThe “iPod” indicator is displayed when a Control Dock for iPod is
connected. (“NO iPod” is displayed if no iPod is connected to the
Control Dock for iPod.)
Listening with Headphones
Plug the headphones (sold separately) into the <PHONES>.
bThe sound from the speakers is automatically cut off.
NOTE
Be careful not to set the volume too high when using headphones.
Operations During Playback
1.RCD-CX1_ENG.indd 15 2008/05/30 11:20:22


ENGLISH
Getting Started Connections Setup Setting theTimer Other Functions Troubleshooting Specifications
Switching the Display
Press [TIME/DISPLAY].
[During Play or Pause]
z
[During Stop]
z z
zDisplayed only when Super Audio CD is in use.
bThe display switches each time the button is pressed.
When a Super Audio CD with no recorded text information is loaded,
“NO TEXT” is displayed when you select “Title name”, “Album title” or
“Artist name”.
Currently playing
track number
Elapsed time
of currently
playing track
Remaining time
of currently
playing track
Remaining time of
all remaining tracks
Total number of
tracks Total time
Album titleArtist name
Title name
[2]
[CLEAR]
[TU–/6,TU+/7]
[CH–/8, CH+/9]
1/3
[NUMBER]
[PROGRAM/
DIRECT]
[REPEAT/
RANDOM]
[TIME/DISPLAY]
< 2 / 5 >
< 8 /–, +/ 9 >
1 / 3
Button located on both the main unit and the remote control
unit BUTTON
Button only on the main unit <BUTTON>
Button only on the remote control unit [BUTTON]
Symbols used to indicate buttons in this manual n
To play the desired track (remote control unit only)
Press [NUMBER] (0~ 9, +10) to select the track.
GExampleH: Track 4 : [4]
GExampleH: Track 12 : [+10] [2]
GExampleH: Track 20 : [+10] [+10] [0]
Playback
Playing CDs
Press 1/3.
The “1” indicator lights and playback begins.
• If the function is set to something other than “CD”, press 1/3to
switch the function to “CD” and start playback (vpage 27 “Auto
Function Selector Function”).
• The function can also be switched to “CD” using <SOURCE>.
NOTE
It is not possible to switch to a layer not recorded on the disc.
nStopping playback
Press <2/5>or [2].
nStopping playback temporarily
Press 1/3.
The “3” indicator lights.
bTo resume playback, press 1/3.
nFast-forwarding and fast-reversing (searching)
During playback, press and hold in [TU –/6 , TU +/7].
The “1” indicator flashes.
bNormal playback resumes when the button is released.
The sound may be interrupted for a brief moment when resuming
normal playback after searching.
nMoving to the beginning of tracks (skipping)
During playback, press <8/–, +/9>or [CH –/8, CH +/9].
bThe disc is skipped the number of tracks equal to the number of
times the button is pressed.
bWhen pressed once in the return direction, playback returns to the
beginning of the currently playing track.
CD Playback
z
z
1.RCD-CX1_ENG.indd 16 2008/05/30 11:20:24
