D&M Holdings Inc.
SERVICE MANUAL
e
e
Copyright 2011 D&M Holdings Inc. All rights reserved.
WARNING: Violators will be prosecuted to the maximum extent possible.
Ver. 4
S0396-0V04DM/DG1111
• Some illustrations using in this service manual are slightly different from the actual set.
• Please use this service manual with referring to the operating instructions without fail.
• For purposes of improvement, specications and design are subject to change without notice.
MODEL JP E3 E2 EK EA E1 E1K E1C
AVR-1312
P P P P
AV SURROUND RECEIVER
MODEL JP E3 E2 EK EA E1 E1K E1C
DHT-1312XP
sP P
5.1CH HOME THEATER SYSTEM
Please refer to the
MODIFICATION NOTICE.

2
CONTENTS
SAFETY PRECAUTIONS ..........................................................3
NOTE FOR SCHEMATIC DIAGRAM.........................................4
TECHNICAL SPECIFICATIONS................................................5
DIMENSION ...............................................................................5
CAUTIONS IN SERVICING .......................................................6
Initializing AV SURROUND RECEIVER....................................6
Service Jig ................................................................................6
DISASSEMBLY ..........................................................................7
1. FRONT PANEL ASSY ...........................................................8
2. HDMI UNIT............................................................................9
3. INPUT UNIT ........................................................................10
4. RADIATOR ASSY................................................................11
5. POWER UNIT......................................................................12
6. POWER TRANS..................................................................12
SPECIAL MODE ......................................................................13
Special mode setting button....................................................13
1. µcom/DSP Version display mode ........................................14
WHEN THE MICROPROCESSOR IS REPLACED
WITH A NEW ONE...................................................................15
PROCEDURE FOR UPGRADING
THE VERSION OF THE FIRMWARE ......................................15
1. Preparations ........................................................................15
2. UPDATE FIRMWARE..........................................................16
3. Notice: .................................................................................27
Conrming the rmware’s number after upgraded..................27
ADJUSTMENT.........................................................................28
Audio Section ..........................................................................28
SURROUND MODES AND PARAMETERS ............................29
TROUBLE SHOOTING............................................................33
1. POWER...............................................................................33
2. Analog video........................................................................34
3. HDMI/DVI ............................................................................35
4. AUDIO .................................................................................40
CLOCK FLOW & WAVE FORM IN DIGITAL BLOCK .............42
BLOCK DIAGRAM...................................................................43
LAEVEL DIAGRAM .................................................................47
PRINTED WIRING BOARDS...................................................49
FRONT (COMPONENT SIDE)................................................49
POWER (COMPONENT SIDE)...............................................49
HEADPHONE (COMPONENT SIDE) .....................................49
PORTABLE IN (COMPONENT SIDE).....................................49
REGULATOR (COMPONENT SIDE) ......................................49
VOLUME (COMPONENT SIDE).............................................49
VOLUME (FOIL SIDE) ............................................................50
REGULATOR (FOIL SIDE)......................................................50
FRONT (FOIL SIDE) ...............................................................50
PORTABLE IN (FOIL SIDE) ....................................................50
HEADPHONE (FOIL SIDE).....................................................50
POWER (FOIL SIDE) ..............................................................50
MAIN (COMPONENT SIDE) ...................................................51
INPUT (COMPONENT SIDE) .................................................52
INPUT (FOIL SIDE).................................................................53
HDMI (COMPONENT SIDE)...................................................54
HDMI (FOIL SIDE) ..................................................................54
SCHEMATIC DIAGRAMS (1/7) ...............................................55
FRONT UNIT...........................................................................55
POWER UNIT .........................................................................55
HEADPHONE UNIT ................................................................55
PORTABLE UNIT ....................................................................55
PORTABLE UNIT(AVR-1312 ONLY).......................................55
PORTABLE UNIT(AVR-1312 ONLY).......................................55
iPOD/USB UNIT(AVR-1612 ONLY).........................................55
SCHEMATIC DIAGRAMS (2/7) ...............................................56
FRONT PART..........................................................................56
SCHEMATIC DIAGRAMS (3/7) ...............................................57
INPUT & VOLUME UNIT.........................................................57
SCHEMATIC DIAGRAMS (4/7) ...............................................58
VIDEO UNIT............................................................................58
SCHEMATIC DIAGRAMS (5/7) ...............................................59
DSP UNIT................................................................................59
SCHEMATIC DIAGRAMS (6/7) ...............................................60
MCU UNIT...............................................................................60
SCHEMATIC DIAGRAMS (7/7) ...............................................61
MAIN UNIT..............................................................................61
WIRING DIAGRAM..................................................................62
EXPLODED VIEW....................................................................63
PARTS LIST OF EXPLODED VIEW........................................64
PACKING VIEW (for AVR-1312) .............................................67
PARTS LIST OF PACKING & ACCESSORIES
(for AVR-1312) .........................................................................68
PACKING VIEW (for DHT-1312XP) ........................................69
PARTS LIST OF PACKING & ACCESSORIES
(for DHT-1312XP) ...................................................................69
SEMICONDUCTORS ...............................................................70
1. IC's ......................................................................................70
2. FL DISPLAY.........................................................................88
PARTS LIST OF P.W.B. UNIT..................................................90
FRONT P.W.B. UNIT ASS'Y ....................................................90
MAIN P.W.B. UNIT ASS'Y .......................................................93
INPUT P.W.B. UNIT ASS'Y......................................................97
HDMI P.W.B. UNIT ASS'Y .....................................................101
SPEAKER SYSTEM PACK ...................................................103
TECHNICAL SPECIFICATIONS............................................103
DIMENSION ...........................................................................103
SC-C1312 EXPLODED VIEW................................................104
SC-C1312 PARTS LIST OF EXPLODED VIEW ....................104
SC-F1312 EXPLODED VIEW ................................................105
SC-F1312(F) PARTS LIST OF EXPLODED VIEW................105
SC-F1312(R) PARTS LIST OF EXPLODED VIEW ...............105
DSW-1312 EXPLODED VIEW ...............................................106
DSW-1312 PARTS LIST OF EXPLODED VIEW ...................106
SYS-1312 PACKING VIEW....................................................107
SYS-1312 PARTS LIST OF PACKING VIEW........................108
SCHEMATIC DIAGRAMS (1/1) .............................................110

3
SAFETY PRECAUTIONS
The following items should be checked for continued protection of the customer and the service technician.
LEAKAGE CURRENT CHECK
Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the set is defective.
Be sure to test for leakage current with the AC plug in both polarities, in addition, when the set's power is in each state (on,
off and standby mode), if applicable.
CAUTION Please heed the following cautions and instructions during servicing and
inspection.
◎Heed the cautions!
Cautions which are delicate in particular for servicing
are labeled on the cabinets, the parts and the chassis,
etc. Be sure to heed these cautions and the cautions
described in the handling instructions.
◎Cautions concerning electric shock!
(1) An AC voltage is impressed on this set, so if
you touch internal metal parts when the set is
energized, you may get an electric shock. Avoid
getting an electric shock, by using an isolating
transformer and wearing gloves when servicing
while the set is energized, or by unplugging the
power cord when replacing parts, for example.
(2) There are high voltage parts inside. Handle with
extra care when the set is energized.
◎Caution concerning disassembly and
assembly!
Through great care is taken when parts were
manufactured from sheet metal, there may be burrs
on the edges of parts. The burrs could cause injury if
ngers are moved across them in some rare cases.
Wear gloves to protect your hands.
◎Use only designated parts!
The set's parts have specic safety properties (re
resistance, voltage resistance, etc.). Be sure to use
parts which have the same properties for replacement.
The burrs have the same properties. In particular, for
the important safety parts that are indicated by the z
mark on schematic diagrams and parts lists, be sure to
use the designated parts.
◎Be sure to mount parts and arrange the wires
as they were originally placed!
For safety seasons, some parts use tapes, tubes or
other insulating materials, and some parts are mounted
away from the surface of printed circuit boards.
Care is also taken with the positions of the wires by
arranging them and using clamps to keep them away
from heating and high voltage parts, so be sure to set
everything back as it was originally placed.
◎Make a safety check after servicing!
Check that all screws, parts and wires removed or
disconnected when servicing have been put back in
their original positions, check that no serviced parts
have deteriorate the area around. Then make an
insulation check on the external metal connectors and
between the blades of the power plug, and otherwise
check that safety is ensured.
(Insulation check procedure)
Unplug the power cord from the power outlet,
disconnect the antenna, plugs, etc., and on the power.
Using a 500V insulation resistance tester, check that
the insulation resistance value between the inplug and
the externally exposed metal parts (antenna terminal,
headphones terminal, input terminal, etc.) is 1MΩ or
greater. If it is less, the set must be inspected and
repaired.
Many of the electric and the structural parts used in
the set have special safety properties. In most cases
these properties are difcult to distinguish by sight, and
the use of replacement parts with higher ratings (rated
power and withstand voltage) does not necessarily
guarantee that safety performance will be preserved.
Parts with safety properties are indicated as shown
below on the wiring diagrams and the parts list in this
service manual. Be sure to replace them with the parts
which have the designated part number.
(1) Schematic diagrams.......Indicated by the z mark.
(2) Parts lists.......Indicated by the z mark.
The use of parts other than the
designated parts could cause electric
shocks, res or other dangerous
situations.
CAUTION Concerning important safety
parts

4
NOTE FOR SCHEMATIC DIAGRAM
WARNING:
Parts indicated by the z mark have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.
CAUTION:
Before returning the set to the customer, be sure to carry out either (1) a leakage current check or (2) a line to chassis resistance check. If
the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the power cord is less than 460 kohms, the set
is defective.
WARNING:
DO NOT return the set to the customer unless the problem is identied and remedied.
NOTICE:
ALL RESISTANCE VALUES IN OHM. k=1,000 OHM / M=1,000,000 OHM
ALL CAPACITANCE VALUES ARE EXPRESSED IN MICRO FARAD, UNLESS OTHERWISE INDICATED. P INDICATES MICRO-MICRO
FARAD. EACH VOLTAGE AND CURRENT ARE MEASURED AT NO SIGNAL INPUT CONDITION. CIRCUIT AND PARTS ARE SUBJECT
TO CHANGE WITHOUT PRIOR NOTICE.
NOTE FOR PARTS LIST
Parts indicated by "nsp" on this table cannot be supplied.
When ordering a part, make a clear distinction between "1" and "I" (i) to avoid mis-supplying.
A part ordered without specifying its part number can not be supplied.
General-purpose Carbon Chip Resistors are not included are not included in the P.W.Board parts list.
(Refer to the Schematic Diagram for those parts.)
Parts indicated by the zmark have critical characteristics. Use ONLY replacement parts recommended by the manufacturer.
General-purpose Carbon Film Resistor in the P.W.Board parts list. (Refer to the Schematic Diagram for those parts.)
Part indicated by "★" mark is not illustrated in the exploded view.
WARNING:
1.
2.
3.
4.
5.
6.
●Resistors
RD : Carbon
RC : Composition
RS : Metal oxide film
RW: winding
RN : Metal film
RK : Metal mixture
P : Pulse-resistant type
NL : Low noise type
NB : Non-burning type
FR : Fuse-resistor
F : Lead wire forming
2B : 1/8 W
2E : 1/4 W
2H : 1/2 W
3A : 1 W
3D : 2 W
3F : 3 W
3H : 5 W
F : ±1%
G:±2%
J : ±5%
K : ±10%
M : ±20%
Ex.: RN
Type
14K
Shape
and per-
formance
2E
Power
182
Resist-
ance
G
Allowable
error
FR
Others
*Resistance
1800ohm=1.8kohm1 8 2
Indicates number of zeros after effective number.
2-digit effective number.
1.2ohm1 R 2
2-digit effective number, decimal point indicated by R.
1-digit effective number.
: Units: ohm
●Capacitors
CE : Aluminum foil
electrolytic
CA : Aluminium solid
electrolytic
CS : Tantalum electrolytic
CQ : Film
CK : Ceramic
CC : Ceramic
CP : Oil
CM: Mica
CF : Metallized
CH : Metallized
HS : High stability type
BP : Non-polar type
HR : Ripple-resistant type
DL : For change and discharge
HF : For assuring high frequency
U : UL part
C : CSA part
W : UL-CSA part
F : Lead wire forming
0J : 6.3 V
1A : 10 V
1C : 16 V
1E : 25 V
1V : 35 V
1H : 50 V
2A : 100 V
2B : 125 V
2C : 160 V
2D : 200 V
2E : 250 V
2H : 500 V
2J : 630 V
F : ±1%
G:±2%
J : ±5%
K : ±10%
M : ±20%
Z : ±80%
: - 20%
P : +100%
C : ±0.25pF
D : ±0.5pF
= : Others
Ex.: CE
Type
04W
Shape
and per-
formance
1H
Dielectric
strength
3R2
Capacity
M
Allowable
error
BP
Others
･Units:μF.
2200μF2 2 2
Indicates number of zeros after effective number.
2-digit effective number. ･Units:μF.
2.2μF2 R 2
2-digit effective number, decimal point indicated by R
1-digit effective number.
*Capacity (electrolyte only)
･When the dielectric strength is indicated in AC,"AC" is included after the dielectric strength value.
*Capacity (except electrolyte)
･Units:pF
2200pF=0.0022μF2 2 2
Indicates number of zeros after effective number. (More than 2)
2-digit effective number. ･Units:pF
220pF2 2 1
2-digit effective number.
Indicates number of zeros after effective number. (0 or 1)
NOTE FOR PARTS LIST

5
TECHNICAL SPECIFICATIONS
nAudio Section
• Poweramplier
Rated output :
Front :
75 W + 75 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
110 W + 110 W (6 Ω, 1 kHz with 0.7 % T.H.D.)
Center :
75 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
110 W (6 Ω, 1 kHz with 0.7 % T.H.D.)
Surround :
75 W + 75 W (8 Ω, 20 Hz – 20 kHz with 0.08 % T.H.D.)
110 W + 110 W (6 Ω, 1 kHz with 0.7 % T.H.D.)
Output connectors : 6 – 16 Ω
• Analog
Input sensitivity/Input impedance : 200 mV/47 kΩ
Frequency response: 10 Hz – 100 kHz — 0, –3 dB (DIRECT mode)
S/N : 98 dB (IHF–A weighted, DIRECT mode)
nTuner section
[FM](Note: μV at 75 Ω, 0 dBf = 1 x 10–15 W)
Receiving Range (for E3) :
[FM] 87.5 MHz – 107.9 MHz [AM]520 kHz – 1710 kHz
Receiving Range (for E2, EA, E1C) :
[FM] 57.5 MHz – 108.0 MHz [AM]522 kHz – 1611 kHz
Usable Sensitivity :
[FM]1.2 μV (12.8 dBf) [AM]18 μV
50 dB Quieting Sensitivity :
[FM]MONO 2.8 μV (20.2 dBf)
S/N (IHF-A) :
[FM]MONO 70 dB
STEREO 67 dB
Total harmonic Distortion (at 1 kHz) :
[FM]MONO 0.7 %
STEREO 1.0 %
nGeneral
Power supply (for E3) : AC 120 V, 60 Hz
(for E2, EA) : AC 230 V, 50 Hz / 60Hz
(for E1C) : AC 220 V, 50 Hz
Power consumption :
330 W
0.5 W (Standby)
Maximum external dimensions :
435 (W) x 162 (H) x 382 (D) mm
Weight : 9.2 kg
nRemote Control Unit (RC-1158)
Batteries : R03/AAA Type (two batteries)
Maximum external dimensions : 50 (W) x 211 (H) x 22 (D) mm
Weight : 110 g (including batteries)
DIMENSION
245.0
43.5
30.5
340.0
435.0
15.0 147.0
162.0
21.5 54.7 236.8
338.5
382.0
22.0
86.0 30.5

6
CAUTIONS IN SERVICING
Initializing AV SURROUND RECEIVER
AV SURROUND RECEIVER initialization should be performed when the μcom, peripheral parts of μcom, and Digital
P.W.B. were replaced.
1. Turn off the power pressing ON/STANDBY button.
2. Press ON/STANDBY button while simultaneously while pressing DOCK CONTROL 8 and DOCK CONTROL 9
buttons.
3. Check that the entire display is ashing at intervals of about 1 second, and then release the 2 buttons.
The microprocessor will be initialized.
Service Jig
When you update the rmware, you can use the following
JIG (RS232C to internal connector conversion adapter).
Please order it from Denon Ofcial Service Distributor in your region if necessary.
8U-210100S : WRITING KIT : 1 Set
606050028012P : 7P FFC(1.0) L-240 : 1 Set
(Refer to "PROCEDURE FOR UPGRADING THE VERSION OF THE FIRMWARE".)
Note: • If step 3 fails, start over from step 1.
• All user settings will be lost and the factory setting will be recovered after the set is initialized.
So make sure to note down your setting beforehand for restoring after the initialization.
ON/STANDBY
DOCK CONTROL 8
DOCK CONTROL 9

7
DISASSEMBLY
• Disassemble in order of the arrow in the following gure.
• In the case of the re-assembling, assemble it in order of the reverse of the following ow.
• In the case of the re-assembling, observe "attention of assembling".
• If wire bundles are untied or moved to perform adjustment or replace parts etc., be sure to rearrange them neatly as
they were originally bundled or placed afterward.
Otherwise, incorrect arrangement can be a cause of noise generation.
About the photos used for "descriptions of the DISASSEMBLY" section
• The shooting direction of each photograph used herein is indicated on the left side of the respective photograph as
"Shooting direction: ***".
• Refer to the diagram below about the shooting direction of each photograph.
• Photographs with no shooting direction indicated were taken from the top of the set.
The viewpoint of each photograph
(Shooting direction)
［View from the top］
Front side
Shooting direction : B
Shooting direction: D
Shooting direction: C
Shooting direction: A
FRONT PANEL ASSY
Refer to "DISASSEMBLY
1. FRONT PANEL ASSY"
and "EXPLODED VIEW"
PORTABLE IN UNIT
(Ref. No. of EXPLODED VIEW : C1)
VOLUME UNIT
(Ref. No. of EXPLODED VIEW : C2)
FRONT UNIT
(Ref. No. of EXPLODED VIEW : C3)
HEADPHONE UNIT
(Ref. No. of EXPLODED VIEW : C4)
POWER UNIT
(Ref. No. of EXPLODED VIEW : C5)
HDMI UNIT
Refer to "DISASSEMBLY
2. HDMI UNIT"
and "EXPLODED VIEW"
HDMI UNIT
(Ref. No. of EXPLODED VIEW : C11)
INPUT UNIT
Refer to "DISASSEMBLY
3. INPUT UNIT"
and "EXPLODED VIEW"
INPUT UNIT
(Ref. No. of EXPLODED VIEW : C10)
RADIATOR ASSY
Refer to "DISASSEMBLY
4. RADIATOR ASSY"
and "EXPLODED VIEW"
MAIN UNIT
(Ref. No. of EXPLODED VIEW : C6)
TOP COVER
POWER UNIT
Refer to "DISASSEMBLY
5. POWER UNIT"
and "EXPLODED VIEW"
REGULATOT UNIT
(Ref. No. of EXPLODED VIEW : C7)
POWER TRANS
Refer to "DISASSEMBLY
6. POWER TRANS "
and "EXPLODED VIEW"
POWER TRANS
(Ref. No. of EXPLODED VIEW : C14)

8
1. FRONT PANEL ASSY
(1) Remove the screws.
(2) Cut the wire clamp band, then disconnect the connector wires and FFC cable. Remove the screws.
(3) Remove the screws.
TOP COVER FRONT PANEL ASSY
→
Proceeding :
View from the bottom
CN610
CN71FFC cable
CN603 cut
FRONT PANEL ASSY
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in FRONT PANEL ASSY.

9
2. HDMI UNIT
(1) Remove the screws.
(2) Disconnect the connector wire and FFC cable.
TOP COVER HDMI UNIT
→
Proceeding :
Shooting direction: A
CN12FFC cable
HDMI UNIT

10
3. INPUT UNIT
(1) Remove the screws.
(2) Disconnect the connector wires and FFC cables, then remove the screws.
TOP COVER HDMI UNIT
→INPUT UNIT →
Proceeding :
Shooting direction: A
CN42
CN71
FFC cable
FFC cableCN43
INPUT UNIT
cut

11
4. RADIATOR ASSY
(1) Remove the screws.
(2) Disconnect the connector wires, then remove the screws.
(3) Disconnect the connector wire, then remove the screws. Remove the RADIATOR ASSY from the main unit.
TOP COVER HDMI UNIT
→INPUT UNIT →RADIATOR ASSY →
Proceeding :
Shooting direction: A
RADIATOR ASSY
CN45
CN47 CN48
CN46
cut
cut
Shooting direction: C
CN41
RADIATOR ASSY
Please refer to "EXPLODED VIEW" for the disassembly method of each P.W.B included in RADIATOR ASSY.

12
5. POWER UNIT
6. POWER TRANS
TOP COVER POWER UNIT
→
Proceeding :
Please refer to "EXPLODED VIEW" for the disassembly method of POWER UNIT.
CABINET TOP TRANS MAIN
→
Proceeding :
Please refer to "EXPLODED VIEW" for the disassembly method of POWER TRANS.

13
SPECIAL MODE
Special mode setting button
b Press the ON/STANDBY button to turn on the power while pressing both the button A and the button B at the same
time.
Mode Button A Button B Contents
µcom/DSP Version display mode STATUS DIMMER
Firmware versions such as Main or DSP are displayed in the
FL display. Errors are displayed or when they occur.
(Refer to page 14 .)
Initialization mode DOCK
CONTROL 8
DOCK
CONTROL 9Backup data initialization is carried out. (Refer to page 6 .)
Mode for switching tuner frequency
step DIMMER PRESET CH +
---E2 model only---
Change tuner frequency step to AM9k/FM50kHz STEP or
AM:10k/FM:200kHz.
Mode for preventing remote control
acceptance RESTORER SOURCE f
Operations using the remote control are rejected.
"REMOTE LOCK:ON" is displayed in FL display.
(Mode the cancellation: Turn off the power and execute the
same button operations as when performing setup.)
b When power is turned on, pressing both buttons A and B at the same time for 3 seconds or more.
Mode Button A Button B Contents
Select the video signal format STATUS DIMMER Select with the "+", "-" and iPod play button change video
format NTSC or PAL
ON/STANDBY
RESTORER
DIMMERSOURCE f
STATUS
DOCK CONTROL 8
DOCK CONTROL 9

14
1. µcom/DSP Version display mode
1.1. Operationspecications
µcom/DSP version display mode:
When the set is started up in this mode, the version information is displayed.
Starting up:
Press the "ON/STANDBY" button to turn on the power while pressing the "RETURN" and "STATUS" buttons.
Now, press the "STATUS" button to the display the 2nd item information on the FL Display.
1.2. Display Order
q Model destination information → w Main-µcom version → e DSP version → rOSD version
→ t iPod Dock version (Connecting iPod Dock)
Display State
qModel destination information
AVR-1312 E3 model AVR1312 E3
AVR-1312 E2 model AVR1312 E2
AVR-1312 E1C model AVR1312 E1C
wMain-µcom version Main :**.**
eDSP version DSP.*.*.*
rOSD version OSD :**.**
t iPod Dock version (Connecting iPod Dock)
(ASD-1R/11R)
Dock Ver :**.**
(ASD-3/51) Dock :I********
Cleared of mode:
Press the "ON/STANDBY" button to turn the power off.
1.3. Error display
See the following table for each "Error information" display and its contents (status).
Condition - State
DSP NG When DSP boot, executing DSP reset makes to becomes error. DSP ERROR 01
DSP OK (No error display, version display only)

15
WHEN THE MICROPROCESSOR IS REPLACED WITH A NEW ONE
When the U-PRO (Microprocessor) or the Flash ROM is replaced, conrm the following.
PWB Name Ref. No. Description After
replaced Remark
INPUT IC91 T5CN5 BSOFTWARE: Main
INPUT IC82 ST25VF080B-50-4C-S2AF BSOFTWARE: DSP ROM
After replacing
A : Mask ROM (With software). No need for write-in of software to the microprocessor.
B : Flash ROM (With software). Usually, no need for write-in of software. But, when the software was updated, you should
write the new software on the microprocessor or ash ROM. Please check the software version.
C : Empty Flash ROM (Without software). You should write the software on the microprocessor or ash ROM.
Refer to "Update procedure" or "writing procedure", when you write the software.
PROCEDURE FOR UPGRADING THE VERSION OF THE FIRMWARE
1. Preparations
1.1. Before starting the operation
(1) Personal Computer (Installed “BootTool_M330(Writing program).exe”).
(2) RS-232 cable (9P (Male), Straight).
(3) 8U-210100S Writing Kit.
(4) 606050028012P / 7P FFC(1.0) L=240.
1.2. Connection of the AV receiver
(1) Conrm the power on/off switch of the AV receiver is turning off.
(2) Connect the update terminal of AV receiver with the “Writing Kit”.
(Refer to gure below for the connection of the 7P FFC cable.)
(3) Connect the RS-232C cable from PC with the “Writing Kit”.
PC
Writing Kit
RS-232C Cable
This side is contacts of
7P FFC Cable.
S709
S708
S707 S706 S702
S706-709 : HIGE S702 : 3.3V
7P FFC Cable
7P FFC Cable
1 pin

16
2. UPDATE FIRMWARE
(1) Connect the update terminal of AV receiver with the “Writing Kit”.
(2) Set the switch of “Writing Kit" (Refer to the table below).
DSPBOOT CE EPM CNVSS
H H H H
(3) Press the "ON/STANDBY" button to turn the power on of AV receiver.
(4) Set the switch of “Writing Kit" (Refer to the table below).
DSPBOOT CE EPM CNVSS
H H LH
(5) Press the "RESET" switch of “Writing Kit".
(6) Run the “BootTool_M330(Writing program).exe” on desktop of PC.
(7)-1 Click the “Connect” button.
"Connected" is displayed, it is OK.

17
[ If you can't get a "Connected" message. ]
(7-a) Click the “Connect” button. If connection is not good, then you can see the “Don't Connect” message.
Please conrm the following
(i) Check the connection of the AV receiver and PC. (Refer to "1.2. Connection of the AV receiver" )
(ii) Check the selection of the RS-232C port number of PC.
(ii) Refer to "3. Notice: ". (page 27 )
(7-b) If Ram/Flash le selection screen is active, after you Click "Resend" button.
Connection is good, go to next step.

18
SP SF1
(8) Choose Ram File(OnBoard_M330.s32).
XXXX
Choose Ram File(OnBoard_M330.s32).

19
(9) Choose Flash File(DSP : SF1).
XXXX
XXXX
XXXX
Choose "AVRXXXX_SF1_*_*_*_01.s32".
Choose "Hex File (*.S32)".

20
(10) Click the “Start” button.
XXXX
XXXX
XXXX
XXXX
The Setup Status bar appears.
