Denon Avr 1508 - av receiver Administrator guide

CONFIDENTIAL

AVR-1508

12-6-1 FORMAT：SHARP

DATA CONSTRUCTION 15bits C14 0 C15 0=NOT INVERTED,1=INVERTED

Genre

System Address(C1～C5):０１０００, Extension Bit(C12,C13):１１

Genre

System Address(C1～C5):０１０００, Extension Bit(C12,C13):１１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０ FUNC.CDR/TAPE

3 １１００００ FUNC.PHONO 19 １１００１０

4 ００１０００ FUNC.CD 20 ００１０１０

5 １０１０００ FUNC.TUNER 21 １０１０１０

6 ０１１０００ FUNC.AUX 22 ０１１０１０

7 １１１０００ 23 １１１０１０

8 ０００１００ FUNC.DBS/SAT 24 ０００１１０ VIDEO SELECT

9 １００１００ FUNC.TV 25 １００１１０

10 ０１０１００ FUNC.HDP 26 ０１０１１０

11 １１０１００ 27 １１０１１０

12 ００１１００ FUNC.V.AUX, 28 ００１１１０

13 １０１１００ FUNC.VCR-1(VCR) 29 １０１１１０ CURSOR RIGHT

14 ０１１１００ FUNC.VCR-2(DVR) 30 ０１１１１０ STATUS

15 １１１１００ 31 １１１１１０ ON SCREEN

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ ENTER 48 ００００１１ MUTING

33 １００００１ POWER ON 49 １０００１１ MASTER VOLUME UP

34 ０１０００１ POWER OFF 50 ０１００１１ MASTER VOLUME DOWN

35 １１０００１ FUNC.DVD 51 １１００１１

36 ００１００１ DOLBY/DTS SURROUND 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ DSP SIMULATION 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ TEST TONE 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ SPEAKER 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

AV AMP

CONFIDENTIAL

Genre

System Address(C1～C5):００１１０, Extension Bit(C12,C13):０１

Genre

System Address(C1～C5):００１１０, Extension Bit(C12,C13):０１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０ FUNC.CD( MULTI )

1 １０００００ 17 １０００１０ FUNC.TUNER( MULTI )

2 ０１００００ 18 ０１００１０ FUNC.HDP( MULTI )

3 １１００００ 19 １１００１０ FUNC.V.AUX( MULTI )

4 ００１０００ 20 ００１０１０ FUNC.VCR-1(VCR)( MULTI )

5 １０１０００ 21 １０１０１０

6 ０１１０００ 22 ０１１０１０

7 １１１０００ 23 １１１０１０

8 ０００１００ 24 ０００１１０ FUNC.AUX( MULTI )

9 １００１００ 25 １００１１０ FUNC.VCR-2( MULTI )

10 ０１０１００ FUNC.SAT( MULTI ) 26 ０１０１１０

11 １１０１００ 27 １１０１１０ FUNC.TV( MULTI )

12 ００１１００ 28 ００１１１０ FUNC.CDR/TAPE( MULTI )

13 １０１１００ MULTI VOLUME UP 29 １０１１１０

14 ０１１１００ MULTI VOLUME DOWN 30 ０１１１１０

15 １１１１００ FUNC.PHONO( MULTI ) 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ SYSTEM SET UP 48 ００００１１

33 １００００１ SURROUND PARAMETER 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ CURSOR UP 51 １１００１１

36 ００１００１ CURSOR DOWN 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１ INPUT MODE

39 １１１００１ 55 １１１０１１

40 ０００１０１ 5CH/7CH STEREO 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１ FUNC.DVD( MULTI )

47 １１１１０１ 63 １１１１１１

AVP

CONFIDENTIAL

Genre

System Address(C1～C5):０１０００, Extension Bit(C12,C13):１０

Genre

System Address(C1～C5):０１０００, Extension Bit(C12,C13):１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０

4 ００１０００ 20 ００１０１０

5 １０１０００ 21 １０１０１０

6 ０１１０００ 22 ０１１０１０

7 １１１０００ 23 １１１０１０

8 ０００１００ 24 ０００１１０

9 １００１００ 25 １００１１０

10 ０１０１００ 26 ０１０１１０

11 １１０１００ 27 １１０１１０

12 ００１１００ 28 ００１１１０

13 １０１１００ 29 １０１１１０

14 ０１１１００ 30 ０１１１１０

15 １１１１００ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１ MAIN ZONE ON

42 ０１０１０１ PURE DIRECT 58 ０１０１１１ MAIN ZONE OFF

43 １１０１０１ 59 １１０１１１ MULTI ZONE ON

44 ００１１０１ 60 ００１１１１ MULTI ZONE OFF

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

PRE AMP

CONFIDENTIAL

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):０１ＤＶＤ：ＤＥＮＯＮＡ

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):０１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 0 17 １０００１０ MENU

2 ０１００００ 1 18 ０１００１０ RETURN

3 １１００００ 2 19 １１００１０

4 ００１０００ 3 20 ００１０１０

5 １０１０００ 4 21 １０１０１０

6 ０１１０００ 5 22 ０１１０１０

7 １１１０００ 6 23 １１１０１０

8 ０００１００ 7 24 ０００１１０ DVD ＞＞｜

9 １００１００ 8 25 １００１１０ DVD ｜＜＜

10 ０１０１００ 9 26 ０１０１１０ DVD ＞＞

11 １１０１００ 27 １１０１１０ DVD ＜＜

12 ００１１００ +10 28 ００１１１０

13 １０１１００ SUBTITLE 29 １０１１１０ DVD ｜｜

14 ０１１１００ AUDIO 30 ０１１１１０

15 １１１１００ 31 １１１１１０

No. Data(C6～C11) ｷｰ名称 No. Data(C6～C11) ｷｰ名称

32 ０００００１ DVD ＞ 48 ００００１１

33 １００００１ DVD STOP 49 １０００１１ DVD POWER

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ DISPLAY 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ DVD DISC SKIP 59 １１０１１１ DVD ENTER

44 ００１１０１ DVD CURSOR UP 60 ００１１１１ DVD SET UP

45 １０１１０１ DVD CURSOR DOWN 61 １０１１１１

46 ０１１１０１ DVD CURSOR →62 ０１１１１１

47 １１１１０１ DVD CURSOR ←63 １１１１１１

VIDEO CD

CONFIDENTIAL

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):１０

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０

4 ００１０００ 20 ００１０１０

5 １０１０００ 21 １０１０１０

6 ０１１０００ 22 ０１１０１０

7 １１１０００ 23 １１１０１０

8 ０００１００ 24 ０００１１０ CD ＞＞｜

9 １００１００ 25 １００１１０ CD ｜＜＜

10 ０１０１００ 26 ０１０１１０ CD ＞＞

11 １１０１００ 27 １１０１１０ CD ＜＜

12 ００１１００ 28 ００１１１０ CD ＞

13 １０１１００ 29 １０１１１０ CD ｜｜

14 ０１１１００ 30 ０１１１１０ CD STOP

15 １１１１００ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ CD DISC SKIP+ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

CONFIDENTIAL

Genre

System Address(C1～C5):００１００, Extension Bit(C12,C13):１０

Genre

System Address(C1～C5):００１００, Extension Bit(C12,C13):１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０ TAPE A / B

4 ００１０００ 20 ００１０１０

5 １０１０００ 21 １０１０１０

6 ０１１０００ 22 ０１１０１０

7 １１１０００ 23 １１１０１０ TAPE ＜

8 ０００１００ 24 ０００１１０

9 １００１００ 25 １００１１０

10 ０１０１００ 26 ０１０１１０ TAPE ＞＞

11 １１０１００ 27 １１０１１０ TAPE ＜＜

12 ００１１００ 28 ００１１１０ TAPE ＞

13 １０１１００ 29 １０１１１０

14 ０１１１００ 30 ０１１１１０ TAPE STOP

15 １１１１００ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

TAPE

CONFIDENTIAL

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):１１ＣＤＲ：ＤＥＮＯＮＡ

Genre

System Address(C1～C5):０００１０, Extension Bit(C12,C13):１１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０ CDR STOP

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０

4 ００１０００ 20 ００１０１０ CDR ｜＜＜

5 １０１０００ 21 １０１０１０ CDR ＞＞｜

6 ０１１０００ 22 ０１１０１０ CDR ＜＜

7 １１１０００ 23 １１１０１０ CDR ＞＞

8 ０００１００ 24 ０００１１０

9 １００１００ 25 １００１１０

10 ０１０１００ 26 ０１０１１０

11 １１０１００ 27 １１０１１０

12 ００１１００ 28 ００１１１０

13 １０１１００ 29 １０１１１０

14 ０１１１００ CDR ＞ 30 ０１１１１０

15 １１１１００ CDR ｜｜ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

CDR

CONFIDENTIAL

Genre

System Address(C1～C5):００１００, Extension Bit(C12,C13):０１

Genre

System Address(C1～C5):００１００, Extension Bit(C12,C13):０１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０

4 ００１０００ 20 ００１０１０

5 １０１０００ 21 １０１０１０ CINEMA MODE

6 ０１１０００ 22 ０１１０１０ MUSIC MODE

7 １１１０００ 23 １１１０１０

8 ０００１００ 24 ０００１１０ NIGHT MODE

9 １００１００ 25 １００１１０

10 ０１０１００ 26 ０１０１１０

11 １１０１００ 27 １１０１１０

12 ００１１００ 28 ００１１１０

13 １０１１００ 29 １０１１１０ ROOM EQ

14 ０１１１００ 30 ０１１１１０

15 １１１１００ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ DVD PICTURE ADJUST 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

CAR

CONFIDENTIAL

Genre

System Address(C1～C5):００１１０, Extension Bit(C12,C13):１０

Genre

System Address(C1～C5):００１１０, Extension Bit(C12,C13):１１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１ 48 ００００１１

33 １００００１ 49 １０００１１

34 ０１０００１ 50 ０１００１１

35 １１０００１ 51 １１００１１

36 ００１００１ 52 ００１０１１

37 １０１００１ 53 １０１０１１

38 ０１１００１ 54 ０１１０１１

39 １１１００１ 55 １１１０１１

40 ０００１０１ 56 ０００１１１

41 １００１０１ 57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１ CURSOR LEFT

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ 19 １１００１０

4 ００１０００ 20 ００１０１０

5 １０１０００ 21 １０１０１０ TUNER CHANNNEL-

6 ０１１０００ 22 ０１１０１０ TUNER CHANNNEL+

7 １１１０００ 23 １１１０１０ TUNER BAND

8 ０００１００ 24 ０００１１０ TUNER MODE

9 １００１００ 25 １００１１０ TUNER TUNING UP

10 ０１０１００ 26 ０１０１１０ TUNER TUNING DOWN

11 １１０１００ 27 １１０１１０

12 ００１１００ TUNER MEMORY 28 ００１１１０

13 １０１１００ TUNER SHIFT 29 １０１１１０

14 ０１１１００ 30 ０１１１１０

15 １１１１００ 31 １１１１１０ DIMMER

RCVR

TUNER

CONFIDENTIAL

Genre

System Address(C1～C5):０１１００, Extension Bit(C12,C13):０１

Genre

System Address(C1～C5):０１１００, Extension Bit(C12,C13):０１

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

64 ００００００ 16 ００００１０

1 １０００００ VDP POWER 17 １０００１０

2 ０１００００ 18 ０１００１０

3 １１００００ VDP STOP 19 １１００１０

4 ００１０００ VDP ＞ 20 ００１０１０

5 １０１０００ VDP ｜｜ 21 １０１０１０

6 ０１１０００ VDP ＞＞｜ 22 ０１１０１０

7 １１１０００ VDP ｜＜＜ 23 １１１０１０

8 ０００１００ VDP ＞＞ 24 ０００１１０

9 １００１００ VDP ＜＜ 25 １００１１０

10 ０１０１００ 26 ０１０１１０

11 １１０１００ 27 １１０１１０

12 ００１１００ 28 ００１１１０

13 １０１１００ 29 １０１１１０

14 ０１１１００ 30 ０１１１１０

15 １１１１００ 31 １１１１１０

CH Data(C6～C11) FUNCTION CH Data(C6～C11) FUNCTION

32 ０００００１０48 ００００１１＋１０

33 １００００１１49 １０００１１

34 ０１０００１２50 ０１００１１

35 １１０００１３51 １１００１１

36 ００１００１４52 ００１０１１

37 １０１００１５53 １０１０１１

38 ０１１００１６54 ０１１０１１

39 １１１００１７55 １１１０１１

40 ０００１０１８56 ０００１１１

41 １００１０１９57 １００１１１

42 ０１０１０１ 58 ０１０１１１

43 １１０１０１ 59 １１０１１１

44 ００１１０１ 60 ００１１１１

45 １０１１０１ 61 １０１１１１

46 ０１１１０１ 62 ０１１１１１

47 １１１１０１ 63 １１１１１１

Other manuals for AVR 1508 - AV Receiver

This manual suits for next models

Table of contents

Other Denon Receiver manuals

Denon

Denon AVR 4308CI - AV Network Receiver User manual

Denon

Denon AVR-X3000 User manual

Denon

Denon AVC-A1D User manual

Denon

Denon DRA-365R User manual

Denon

Denon AVR-790 User manual

Denon

Denon AVR-1602 User manual

Denon

Denon AVR-S900W User manual

Denon

Denon MULTEQXT AVR-4306 User manual

Denon

Denon AVR-1610 Administrator guide

Denon

Denon HEOS User manual

Denon

Denon AVR-X500 User manual

Denon

Denon AVR 1508 - AV Receiver User guide

Denon

Denon AVR2310CI - Multi-Zone Home Theater Receiver Dimensions

Denon

Denon AVR-E400 User manual

Denon

Denon AVR-3806 User manual

Denon

Denon AVR-1507 User guide

Denon

Denon AVR-87 User manual

Denon

Denon RC-7001RCI - Remote Control RF/IR Base... User manual

Denon

Denon AVR 788 - AV Receiver User manual

Denon

Denon AVR-4208 User manual

Denon

Denon AVR-1507 User manual

Denon

Denon AVR 1909 - AV Receiver User manual

Denon

Denon AVR-2105 User manual

Denon

Denon AVR-5805-UPGRADE User manual

Popular Receiver manuals by other brands

Televes

Televes ZAS HD SAT user manual

Realistic

Realistic DX-75 Operating and service instructions

Saris

Saris 4620 Assembly instructions

Mini

Mini DTR 206C PVR user manual

RF Elements

RF Elements TwistPort manual

Yamaha

Yamaha RX-V467 owner's manual

Russound

Russound SaphIR 858 instruction manual

Quasonix

Quasonix RDMS Firmware update procedure

Pioneer

Pioneer XV-HTD1 Service manual

ATZ

ATZ HDMI-V2-44HE150 manual

Sony

Sony XNV-770BT MyTomTom Specifications

Grundig

Grundig STR 7122 TWIN Service manual

Creative

Creative Blaster Modem user guide

Panduit

Panduit ATLONA AT-OME-RX11 installation guide

VOLTCRAFT

VOLTCRAFT UTPS-40 operating instructions

JVC

JVC KW-ADV794 instructions

Litelink

Litelink VT-1001 operating instructions

Sangean

Sangean WR-11 Service manual

Denon AVR 1508 - AV Receiver Administrator guide

Popular Receiver manuals by other brands
