DENON AVR/AVC control protocol
Ver. 3.7
Application model : AVR-4802R
Application terminal : RS-232C
Connector specification
Connector type : DB-9pin female type, slave straight connection (DCE type)
( 1pin : GND , 2pin : TxD , 3pin : RxD , 5pin : Common(GND) , 4,6,7,8,9pin : NC )
Communication format :
Synchronous system: Tone step synchronization
communication system : Ahalf duplex
Communication speed : 9600bps
Character length : 8 bits
Parity control : None
Start bit : 1 bit
Stop bit : 1 bit
Communication procedure : Non procedural
Communication data length : 135 bytes (maximum)

-2-
Protocol specification
The following three data formsis defined.
COMMAND : The message sent to a system(AVR/AVC) from a controller(Touch Panel etc.)
A command to a system is given from a controller.
EVENT : The message sent to a controller(Touch Panel etc.) from a system(AVR/AVC)
The result is sent, when a system is operated directly and a state changes.
*The form of EVENT presupposes that it is the same as that of COMMAND.
**Refer to the following table for the contents of COMMAND and EVENT.
RESPONSE : The message sent to a controller(Touch Panel etc.) from a system(AVR/AVC)
if the ‘request command’ (COMMAND+?+CR(0x0D)) has came from a controller.
The RESPONSE should be sent within 200ms of receiving the COMMAND.
*The form of RESPONSE presupposes that it is the same as that of EVENT.
Basic specification : The command by ASCII CODE, parameter expression
*ASCII CODE which can be used is from 0x20 to 0x7F : the alphabet and the number of 0-9 , and space (0x20) , Some signs ,
AND carriage return(0x0D)--- It is used only as a pause sign.
Command structure : COMMAND + PARAMETER + CR(0x0D)
COMMAND : ASCII CODE of 2 characters
ex. SI : Select Input source
MS : surround Mode Setting
MV : Master Volume setting
PW : system PoWer setting
PARAMETER : ASCII CODE ( up to 25 characters)
ex. DVD : function name
CDR/TAPE-1 : function name
THX SURROUND EX : surround mode name
SUPER STADIUM : surround mode name
*Special Parameter--- ? : for request command

-3-
The example of a command * <CR> is the meaning of 0x0D.
SIDVD<CR> : Select Input source DVD
MSTHX SURROUND EX<CR> : surround Mode Set to THX SURROUND EX
MVUP<CR> : Master Volume UP
PWON<CR> : system PoWer ON
PWSTANDBY<CR> : system PoWer STANDBY
SI?<CR> : Request command for now playing input source >> Return RESPONSE ‘SI***<CR>’
Others
A) COMMAND is receivable also during transmission of EVENT.
B) Since CHANNEL VOLUME changes simultaneously when the SURROUND MODE changes, the value of the channel volume of all channels
returns as EVENT.
C) CHANNEL VOLUME returns the data of ALL channels by the present SURROUND MODE also including an intact channel. In this case,
the data of an intact channel is set to "50".
D) Since SURROUND MODE changes simultaneously when the INPUT source changes, the SURROUND MODE (and also the value of the channel
volume of all channels , It described in B) ) returns as EVENT.
E) When SURROUND MODE is the same in between INPUT source change before and after, EVENT of SURROUND MODE and CHANNEL VOLUME
does NOT return.
F) Although EVENT of SURROUND MODE returns when the present SURROUND MODE is set up again, CHANNEL VOLUME does NOT return.
G) When SURROUND MODE is changed, before returning SURROUND MODE after change as EVENT, the present SURROUND MODE is returned.
H) The RESPONSE should be sent as opposed to the request command by all the commands with which an EVENT exists , not need to
the another request commands(ex. SV command).
I) The PARAMETER (with COMMAND and RESPONSE, EVENT) of minimum level of MASTER VOLUME and MULTI ZONE defines “99”.

-4-
COMMAND and PARAMETER list
COMMAND PARAMETER function example
PW ON POWER ON/STANDBY change PWON<CR>
STANDBY PWSTANDBY<CR>
MV UP MASTER VOLUME UP/DOWN , direct change to ***dB MVUP<CR>
DOWN **:00 to 99 by ASCII MVDOWN<CR>
** 98=+18dB(MAX),80=0dB,99=---(MIN) MV80<CR>
CV FL UP CHANNEL VOLUME UP/DOWN , direct change to ***dB CVFL UP<CR>
FL DOWN ---FRONT Lch CVFL DOWN<CR>
FL ** **:38 to 62 by ASCII , 50=0dB CVFL 50<CR>
FR UP CVFR UP<CR>
FR DOWN ---FRONT Rch CVFR DOWN<CR>
FR ** **:38 to 62 by ASCII , 50=0dB CVFR 50<CR>
C UP CVC UP<CR>
C DOWN ---CENTERch CVC DOWN<CR>
C ** **:38 to 62 by ASCII , 50=0dB CVC 50<CR>
SW UP CVSW UP<CR>
SW DOWN ---SUBWOOFERch CVSW DOWN<CR>
SW ** **:38 to 62 by ASCII , 50=0dB CVSW 50<CR>
SL UP CVSL UP<CR>
SL DOWN ---SURROUND Lch CVSL DOWN<CR>
SL ** **:38 to 62 by ASCII , 50=0dB CVSL 50<CR>
SR UP CVSR UP<CR>
SR DOWN ---SURROUND Rch CVSR DOWN<CR>
SR ** **:38 to 62 by ASCII , 50=0dB CVSR 50<CR>
SBL UP ---SURROUND BACK Lch (SBch 2SP) CVSBL UP<CR>
SBL DOWN CVSBL DOWN<CR>
SBL ** **:38 to 62 by ASCII , 50=0dB CVSBL 50<CR>
SBR UP ---SURROUND BACK Rch (SBch 2SP) CVSBR UP<CR>
SBR DOWN CVSBR DOWN<CR>
SBR ** **:38 to 62 by ASCII , 50=0dB CVSBR 50<CR>

-5-
COMMAND PARAMETER function example
CV SB UP ---SURROUND BACKch (SBch 1SP) CVSB UP<CR>
SB DOWN CVSB DOWN<CR>
SB ** **:38 to 62 by ASCII , 50=0dB CVSB 50<CR>
MU ON OUTPUT MUTE ON/OFF change MUON<CR>
OFF MUOFF<CR>
SI PHONO Select INPUT source SIPHONO<CR>
CD SICD<CR>
TUNER SITUNER<CR>
DVD SIDVD<CR>
VDP SIVDP<CR>
TV SITV<CR>
DBS/SAT SIDBS/SAT<CR>
VCR-1 SIVCR-1<CR>
VCR-2 SIVCR-2<CR>
VCR-3 SIVCR-3<CR>
V.AUX SIV.AUX<CR>
CDR/TAPE1 ---Select CDR/TAPE function at AVR-4802R SICDR/TAPE1<CR>
MD/TAPE2 ---Invalid at AVR-4802R SIMD/TAPE2<CR>
ZM ON MAIN-ZONE ON/OFF change ZMON<CR>
OFF ZMOFF<CR>
Z1 PHONO MULTI ZONE-1 mode set , and select source Z1PHONO<CR>
| ---The name of PARAMETER is |
MD/TAPE2 the same as that of the time of SI COMMAND. Z1MD/TAPE2<CR>
SOURCE MULTI ZONE-1 mode cancel Z1SOURCE<CR>
UP MULTI ZONE-1 VOLUME UP/DOWN , direct change to ***dB Z1UP<CR>
DOWN Z1DOWN<CR>
** **:00 to 99 by ASCII , 80=0dB, 99=---(MIN) Z180<CR>
ON MULTI ZONE-1 ON/OFF change Z1ON<CR>
OFF Z1OFF<CR>
---Set MULTI ZONE functions at AVR-4802R

-6-
COMMAND PARAMETER function example
Z2 PHONO MULTI ZONE-2 mode set , and select source Z2PHONO<CR>
| ---The name of PARAMETER is |
MD/TAPE2 the same as that of the time of SI COMMAND. Z2MD/TAPE2<CR>
SOURCE MULTI ZONE-2 mode cancel Z2SOURCE<CR>
UP MULTI ZONE-2 VOLUME UP/DOWN , direct change to ***dB Z2UP<CR>
DOWN Z2DOWN<CR>
** **:00 to 99 by ASCII , 80=0dB Z280<CR>
ON MULTI ZONE-2 ON/OFF change Z2ON<CR>
OFF Z2OFF<CR>
---Invalid at AVR-4802R
SR PHONO REC SELECT mode set , and select source SRPHONO<CR>
| ---The name of PARAMETER is |
MD/TAPE2 the same as that of the time of SI COMMAND. SRMD/TAPE2<CR>
SOURCE REC SELECT mode cancel SRSOURCE<CR>
SV DVD VIDEO SELECT mode set , and select source SVDVD<CR>
VDP SVVDP<CR>
TV SVTV<CR>
DBS/SAT SVDBS/SAT<CR>
VCR-1 SVVCR-1<CR>
VCR-2 SVVCR-2<CR>
VCR-3 SVVCR-3<CR>
V.AUX SVV.AUX<CR>
SOURCE VIDEO SELECT mode cancel SVSOURCE<CR>
SD AUTO set DIGITAL INPUT AUTO mode SDAUTO<CR>
PCM set DIGITAL INPUT force PCM mode SDPCM<CR>
DTS set DIGITAL INPUT force DTS mode SDDTS<CR>
RF set DIGITAL INPUT force RF mode SDRF<CR>
ANALOG set force ANALOG INPUT mode SDANALOG<CR>
EXT.IN-1 set EXT.IN-1 mode ---Set EXT.IN mode at AVR-4802R SDEXT.IN-1<CR>
EXT.IN-2 set EXT.IN-2 mode ---Invalid at AVR-4802R SDEXT.IN-2<CR>

-7-
EVENT PARAMETER function example
MS DIRECT SURROUND mode set MSDIRECT<CR>
PURE DIRECT MSPURE DIRECT<CR>
STEREO MSSTEREO<CR>
MULTI CH IN MSMULTI CH IN<CR>
MULTI CH DIRECT MSMULTI CH DIRECT<CR>
MULTI CH PURE D MSMULTI CH PURE D<CR>
DOLBY PRO LOGIC All are received as "DOLBY SURROUND" ,MSDOLBY PRO LOGIC<CR>
DOLBY PL2 the surround mode which changed return as EVENT. MSDOLBY PL2<CR>
DOLBY DIGITAL MSDOLBY DIGITAL<CR>
DOLBY D EX MSDOLBY D EX<CR>
6.1 SURROUND Same as "DOLBY D EX"MS6.1 SURROUND<CR>
DTS NEO:6 All are received as "DTS SURROUND" ,MSDTS NEO:6<CR>
DTS SURROUND the surround mode which changed return as EVENT. MSDTS SURROUND<CR>
DTS ES DSCRT6.1 MSDTS ES DSCRT6.1<CR>
DTS ES MTRX6.1 MSDTS ES MTRX6.1<CR>
HOME THX CINEMA All are received as "THX SURROUND" ,MSHOME THX CINEMA<CR>
THX5.1 the surround mode which changed return as EVENT. MSTHX5.1<CR>
THX U2 CINEMA MSTHX U2 CINEMA<CR>
THX MUSIC MODE MSTHX MUSIC MODE<CR>
THX6.1 ---Operate as Matrix6.1 or Discrete6.1 MSTHX6.1<CR>
THX SURROUND EX MSTHX SURROUND EX<CR>
WIDE SCREEN MSWIDE SCREEN<CR>
5CH STEREO Both are received as "5CH/7CH STEREO" , MS5CH STEREO<CR>
7CH STEREO the surround mode which changed return as EVENT. MS7CH STEREO<CR>
SUPER STADIUM MSSUPER STADIUM<CR>
ROCK ARENA MSROCK ARENA<CR>
JAZZ CLUB MSJAZZ CLUB<CR>
CLASSIC CONCERT MSCLASSIC CONCERT<CR>
MONO MOVIE MSMONO MOVIE<CR>
MATRIX MSMATRIX<CR>

-8-
EVENT PARAMETER function example
PS TONE DEFEAT ON PARAMETER setting PSTONE DEFEAT ON<CR>
TONE DEFEAT OFF TONE DEFEAT ON/OFF PSTONE DEFEAT OFF<CR>
SB:MTRX ON SURROUND BACK SP MODE set PSSB:MTRX ON<CR>
SB:NON MTRX---MTRX ON = SURR.EX ON = DSCRT ON = NRML PSSB:NON MTRX<CR>
SB:OFF (@THX) (@ES DSCRT) (PL2, NEO6) PSSB:OFF<CR>
CINEMA EQ.ON CINEMA EQ. ON/OFF PSCINEMA EQ.ON<CR>
CINEMA EQ.OFF PSCINEMA EQ.OFF<CR>
MODE : MUSIC CINEMA / MUSIC /PL mode change PSMODE : MUSIC<CR>
MODE : CINEMA (This parameter can change DOLBY PL2,NEO:6 mode.) PSMODE : CINEMA<CR>
MODE : EMULATION ---Invalid at AVR-4802R PSMODE : EMULATION<CR>
MODE : PRO LOGIC --- EMU. & PL can change ONLY DOLBY PL2 mode. PSMODE : PRO LOGIC<CR>
TF UP TUNER Frequency UP/DOWN , direct change TFUP<CR> *
DOWN TFDOWN<CR> *
****** (6 digits) --- ****.** kHz at AM band (>050000 is AM.)
****.** MHz at FM band (<050000 is FM.) TF105000<CR> (1050.00kHz at AM)
TP UP TUNER PRESET CH UP/DOWN , direct change to No.** TPUP<CR>
DOWN TPDOWN<CR>
**(PRESET No.) TPA1<CR>
(PRESET No.”A1”)
TM TUNER BAND , MODE Select
AM ---Band set to AM TMAM<CR>
FM ---Band set to FM TMFM<CR>
AUTO ---Tuning mode set to AUTO mode TMAUTO<CR> *
MANUAL ---Tuning mode set to MANUAL mode TMMANUAL<CR> *
TF, TP, TM COMMAND : '*' parameters can NOT operate when INPUT source isn’t TUNER.

-9-
EVENT(or RESPONSE) and PARAMETER list
EVENT PARAMETER function example *RES.
PW ON POWER ON/STANDBY change PWON<CR>
STANDBY PWSTANDBY<CR>
MV ** MASTER VOLUME change , **:00 to 98 by ASCII MV80<CR>
98 = +18dB(MAX)
80 = 0dB
10 = -70dB
99 = ---dB(MIN)
CV FL ** CHANNEL VOLUME change , **:38 to 62 by ASCII CVFL 50<CR>
FR ** 62 = +12dB(MAX) CVFR 50<CR>
C ** 50 = 0dB CVC 50<CR>
SW ** 38 = -12dB(MIN) CVSW 50<CR>
SL ** 00 = OFF (define ONLY SWch in DIRECT mode.) CVSL 50<CR>
SR ** CVSR 50<CR>
SBL ** (at SBch 2SP) CVSBL 50<CR>
SBR ** (at SBch 2SP) CVSBR 50<CR>
SB ** (at SBch 1SP) CVSB 50<CR>
MU ON OUTPUT MUTE ON/OFF change MUON<CR>
OFF MUOFF<CR>
SI PHONO INPUT source change SIPHONO<CR>
CD SICD<CR>
TUNER SITUNER<CR>
DVD SIDVD<CR>
VDP SIVDP<CR>
TV SITV<CR>
DBS/SAT SIDBS/SAT<CR>
VCR-1 SIVCR-1<CR>
VCR-2 SIVCR-2<CR>
VCR-3 SIVCR-3<CR>
V.AUX SIV.AUX<CR>
CDR/TAPE1 ---means CDR/TAPE function at AVR-4802R SICDR/TAPE1<CR>
MD/TAPE2 ---Invalid at AVR-4802R SIMD/TAPE2<CR>
*RES. : NOT returns '*' parameters as RESPONSE.

-10 -
EVENT PARAMETER function example *RES.
ZM ON MAIN-ZONE ON/OFF change ZMON<CR>
OFF ZMOFF<CR>
Z1 PHONO MULTI ZONE-1 source change Z1PHONO<CR>
| ---The name of PARAMETER is |
MD/TAPE2 the same as that of the time of SI COMMAND. Z1MD/TAPE2<CR>
SOURCE MULTI ZONE-1 mode cancel Z1SOURCE<CR>
** MULTI ZONE-1 VOLUME change , **:00 to 99 by ASCII Z180<CR>
98 = +18dB(MAX)
80 = 0dB
10 = -70dB
99 = ---(MIN)
ON MULTI ZONE-1 ON/OFF change Z1ON<CR>
OFF Z1OFF<CR>
---means MULTI ZONE functions at AVR-4802
Z2 PHONO MULTI ZONE-2 source change Z2PHONO<CR>
| ---The name of PARAMETER is |
MD/TAPE2 the same as that of the time of SI COMMAND. Z2MD/TAPE2<CR>
SOURCE MULTI ZONE-2 mode cancel Z2SOURCE<CR>
** MULTI ZONE-2 VOLUME change , **:00 to 99 by ASCII Z180<CR>
98= +18dB(MAX)
80 = 0dB
10 = -70dB
99 = ---(MIN)
ON MULTI ZONE-2 ON/OFF change Z2ON<CR>
OFF Z2OFF<CR>
---Invalid at AVR-4802R
SR PHONO REC SELECT source change SRPHONO<CR>
| ---The name of PARAMETER is |
MD/TAPE2 the same as that of the time of SI COMMAND. SRMD/TAPE2<CR>
SOURCE REC SELECT mode cancel SRSOURCE<CR>

-11 -
EVENT PARAMETER function example *RES.
TF ****** (6 digits) TUNER Frequency change TF105000<CR>
--- ****.** kHz at AM band (1050.00kHz at AM)
****.** MHz at FM band
TP **(PRESET No.) TUNER PRESET change to No.** TPA1<CR>
(PRESET No.”A1”)
TM TUNER BAND , MODE change
AM ---Band set to AM TMAM<CR>
FM ---Band set to FM TMFM<CR>
AUTO ---Tuning mode set to AUTO mode TMAUTO<CR>
MANUAL ---Tuning mode set to MANUAL mode TMMANUAL<CR>

-12 -
EVENT PARAMETER function example *RES.
MS DIRECT SURROUND mode change MSDIRECT<CR>
PURE DIRECT MSPURE DIRECT<CR>
STEREO MSSTEREO<CR>
MULTI CH IN MSMULTI CH IN<CR>
MULTI CH DIRECT MSMULTI CH DIRECT<CR>
MULTI CH PURE D MSMULTI CH PURE D<CR>
DOLBY PRO LOGIC MSDOLBY PRO LOGIC<CR>
DOLBY PL2 MSDOLBY PL2<CR>
DOLBY DIGITAL MSDOLBY DIGITAL<CR>
DOLBY D EX MSDOLBY D EX<CR>
6.1 SURROUND MS6.1 SURROUND<CR>
DTS NEO:6 MSDTS NEO:6<CR>
DTS SURROUND MSDTS SURROUND<CR>
DTS ES DSCRT6.1 MSDTS ES DSCRT6.1<CR>
DTS ES MTRX6.1 MSDTS ES MTRX6.1<CR>
HOME THX CINEMA MSHOME THX CINEMA<CR>
THX5.1 MSTHX5.1<CR>
THX U2 CINEMA MSTHX U2 CINEMA<CR>
THX MUSIC MODE MSTHX MUSIC MODE<CR>
THX6.1 MSTHX6.1<CR>
THX SURROUND EX MSTHX SURROUND EX<CR>
WIDE SCREEN MSWIDE SCREEN<CR>
5CH STEREO MS5CH STEREO<CR>
7CH STEREO MS7CH STEREO<CR>
SUPER STADIUM MSSUPER STADIUM<CR>
ROCK ARENA MSROCK ARENA<CR>
JAZZ CLUB MSJAZZ CLUB<CR>
CLASSIC CONCERT MSCLASSIC CONCERT<CR>
MONO MOVIE MSMONO MOVIE<CR>
MATRIX MSMATRIX<CR>
