Denon AVR-X2200W User manual

Model Information
INTEGRATED NETWORK AV RECEIVER
I/R Codes
Product Specifications
Upgrades/Updates
FAQ’s
Accessories
Reset Procedure
Warranty
Remote Control
Rear Panel
Front Panel
MODEL: AVR-X2200W
MI070115E3-1
NOTE:
This edition is missing the FAQ’s content (pages 16 and 17) ………………………………………………………..7/1/2015
This edition is missing the link to the IR Codes………………………………………………………………………....7/1/2015
Model Information
Index

Power operation button ( )
Used to turn the power of the MAIN ZONE (room where this unit is located)
on/off (standby).
Power indicator
This is lit as follows according to the power status:
White: Power on
Off: Normal standby
Red:
oWhen “HDMI Control” is set to “On”
oWhen “HDMI Pass Through” is set to “On”
oWhen “Network Control” is set to “Always On”
SOURCE SELECT knob
This selects the input source.
Remote control sensor
This receives signals from the remote control unit.
Display
This displays various pieces of information.
MASTER VOLUME knob
This adjusts the volume level.
Tuner preset channel buttons
(TUNER PRESET CH +, –)
These select preset broadcast stations.
ZONE2 ON/OFF button
This turns the power of ZONE2 (separate room) on/off.
ZONE2 SOURCE button
This selects the input source for ZONE2.
DIMMER button
Each press of this switches the brightness of the display.
STATUS button
Each press of this switches the status information that is shown on the
display.
Front Panel (1 of 2)
HOME FRONT PANEL 2DISPLAY 1 2

QUICK SELECT buttons
With a single press of any of these buttons, you can call up various
settings you’ve registered to each button such as the input source,
volume level and sound mode settings.
Headphones jack (PHONES)
This is used to connect headphones.
When the headphones are plugged into this jack, audio will no longer
be output from the connected speakers or from the PRE OUT
connectors.
NOTE:
To prevent hearing loss, do not raise the volume level excessively when
using headphones.
AUX1-HDMI connector
This is used to connect HDMI output compatible devices such as video
camcorders and game consoles.
USB port
This is used to connect USB storages (such as USB memory devices)
and the USB cable supplied with iPod.
SETUP MIC jack
This is used to connect the supplied Sound calibration microphone.
Front Panel (2 of 2)
HOME DISPLAY 1FRONT PANEL 1 3

Input mode indicators
These light according to the audio input mode settings of each input
source.
Surround back indicator
This lights when audio signals are being output from the surround back
speakers.
Decoder indicators
These light when Dolby or DTS signals are input or when the Dolby or
DTS decoder is running.
Audyssey® indicator
This lights when “MultEQ® XT”, “Dynamic EQ” or “Dynamic Volume”
has been set up.
Tuner reception mode indicators
These light up according to the reception conditions when the input
source is set to “Tuner”.
TUNED: Lights up when the broadcast is properly tuned in.
STEREO: Lights up when receiving FM stereo broadcasts.
Sleep timer indicator
This lights when the sleep mode is selected.
Circle indicator
This is displayed when the input source is “Online Music” or “iPod/USB”
when you are playing back music.
Display (1 of 2)
HOME DISPLAY 2FRONT PANEL 2 4

HOME REAR PANEL 1DISPLAY 1
Display (2 of 2)
Volume indicator
MUTE indicator
This blinks while the sound is muted.
Information display
The input source name, sound mode, setting values and other
information are displayed here.
Input signal indicators
The respective indicator will light corresponding to the input signal.
ZONE2 indicator
This lights up when ZONE2 (separate room) power is turned on.
5

Rod antennas for Bluetooth/wireless LAN
Stand this antenna upright when connecting to a network via wireless
LAN, or when connecting to a handheld device via Bluetooth.
Analog audio connectors (AUDIO)
Used to connect devices equipped with analog audio connectors.
•“Connecting a set-top box (Satellite tuner/cable TV)”
•“Connecting a DVD player or Blu-ray Disc player”
NETWORK connector
Used to connect to a LAN cable when connecting to a wired LAN network.
Video connectors (VIDEO)
Used to connect devices equipped with video connectors.
•“Connecting a set-top box (Satellite tuner/cable TV)”
•“Connecting a DVD player or Blu-ray Disc player”
HOME
DISPLAY 2 REAR PANEL 2
Rear Panel (1 of 3)
The antenna clip can be removed from the rear panel.
A Rotate the antenna clip 90 degrees to the left.
B Pull the antenna clip out towards yourself.
•The antenna clip is needed when transporting this unit.
Keep it in a safe place.
•Attach the antenna clip by following the steps for
removing it in reverse.

Digital audio connectors (DIGITAL AUDIO)
Used to connect devices equipped with digital audio connectors.
•“Connection 2 : TV equipped with an HDMI connector and
incompatible with the ARC (Audio Return Channel)”
•“Connection 3 : TV equipped without an HDMI connector”.
REMOTE CONTROL jacks
Used to connect infrared receivers/transmitters in order to operate this
unit and external devices from a different room.
HOME REAR PANEL 3REAR PANEL 1
Rear Panel (2 of 3)
HDMI connectors
Used to connect devices equipped with HDMI connectors.
•“Connection 1 : TV equipped with an HDMI connector and compatible with the
RC (Audio Return Channel)”
•“Connection 2 : TV equipped with an HDMI connector and incompatible with
the ARC (Audio Return Channel)”
•“Connecting a set-top box (Satellite tuner/cable TV)”
•“Connecting a DVD player or Blu-ray Disc player”
AC inlet (AC IN)
Used to connect the power cord.
RS-232C connector
Used to connect home automation controller devices fitted with RS-232C
connectors. Consult the owner’s manual of the home automation controller for
more information about serial control of this unit.
Perform the operation below beforehand.
ATurn on the power of this unit.
BTurn off the power of this unit from the external controller.
CCheck that the unit is in the standby mode.

FM/AM antenna terminals (ANTENNA)
Used to connect FM antennas and AM loop antennas.
Speaker terminals (SPEAKERS)
Used to connect speakers.
PRE OUT connectors
Used to connect a subwoofer with built-in amplifier or an external power
amplifier.
•“Connecting the subwoofer”
•“Connection 3 : Connection using an external amplifier”
Component video connectors (COMPONENT VIDEO)
Used to connect devices equipped with component video connectors.
•“Connection 3 : TV equipped without an HDMI connector”
•“Connecting a set-top box (Satellite tuner/cable TV)”
•“Connecting a DVD player or Blu-ray Disc player”
NOTE
Do not touch the inner pins of the connectors on the rear panel. Electrostatic
discharge may cause permanent damage to the unit.
HOME REMOTE CONTROL 1REAR PANEL 2
Rear Panel (3 of 3)

ZONE SELECT buttons
These switch the zone (MAIN ZONE, ZONE2) that is operated through
the remote control unit.
•“Playback in ZONE2”
•“Menu operations”
Input source select buttons
These selects the input source.
•“Selecting the input source”
•“Playback in ZONE2”
Channel/page search buttons (CH/PAGE )
These select radio stations registered to presets or switch pages.
MUTE button ()
This mutes the output audio.
•“Turning off the sound temporarily (Muting)”
•“Turning off the sound temporarily (Muting) (ZONE2)”
Information button (INFO)
This displays the status information on the TV screen.
Cursor buttons ()
These select items.
HOME REMOTE CONTROL 2REAR PANEL 3
Remote Control (1 of 3)
9

BACK button
This returns to the previous screen.
System buttons
These perform playback related operations.
Tuning up / Tuning down buttons (TUNE +, –)
These select either FM broadcast or AM broadcast.
QUICK SELECT buttons (1 –4)
These call up settings registered to each button, such as input source,
volume level and sound mode settings.
SOUND MODE buttons
These select the sound mode.
Remote control signal transmitter
This transmits signals from the remote control unit.
SLEEP button
This sets the sleep timer.
HOME REMOTE CONTROL 3REMOTE CONTROL 1
Remote Control (2 of 3)
10
