AVR-4311CI
AV Surround Receiver
New model information
Features
New Features
• Featuring 3D pass-through technology
• Supports HDMI 1.4a with 3D, Audio Return Channel, Deep Color,“x.v.Color”, Auto
Lipsync and HDMI control function
• Audyssey MultEQ XT 32 room acoustic correction system and Auto Setup
• Audyssey Sub EQ HT multiple subwoofer calibration
• Direct play for iPod and iPhone via USB
• Audyssey DSX Processing (up to 11.2 ch including front height and width channels)
• Enhanced network capability
-Internet Radio and network audio/photo streaming via Ethernet
-Pandora, ickr, Napster and Rhapsody online support
-‘Party Mode Plus’(*1)
-FLAC HD, High-resolution audio format
-Compatible with Windows®7
-Web control
• Newly developed pre-memory remote control handset with LCD display
• iPod and iPhone playback for Zone 2 / Zone 3; iPod/iPhone Remote App compatible
• iTunes streaming via AirPlayTM; feature upgrade Fall 2010
• Dual subwoofer pre-outs
• Dolby Volume leveling to prevent annoying volume jumps due to TV commercials
Immerse yourself in rich 3D video and 3D sound with up to 11.2 channels
Featuring a full suite of high resolution audio decoders including Dolby TrueHD and DTS-HD Master Audio, the advanced AVR-4311CI is also equipped
with Audyssey DSX processing which delivers an incredible 11.2 channel experience with derived front width and height channels for a dramatically
expanded front soundstage. For the utmost delity, the AVR-4311CI is also equipped with Audyssey's advanced MultEQ XT 32 room acoustic measur-
ing and correction system, which provides superlative tonal quality, matching the speaker system to the room with automatic ease and speed (mea-
suring microphone included). There's a whole world of internet connectivity via RJ-45 LAN connection, including music
and photo streaming from your DLNA-compliant multi-media PC.

Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey 07430 USA
TEL: [phone]
usa.denon.com
Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: [phone]
ca.denon.com
18050810 A
*Design and specications are subject to change without notice.
*“Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories.
*DTS is a registered trademark and the DTS logos, Symbol, DTS-HD and DTS-HD
Master Audio are trademarks of DTS, Inc.
*HDMI, the HDMI logo and High-Denition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
*HD Radio™ Technology Manufactured Under License From iBiquity Digital Corp.
U.S. and Foreign Patents. HD Radio™ and the HD Radio logo are proprietary
trademarks of iBiquity Digital Corp.
*SIRIUS, XM and all related marks and logos are trademarks of Sirius XM Radio Inc.
and its subsidiaries. All rights reserved. Service not available in Alaska and Hawaii.
*Audyssey MultEQ® is a registered trademark of Audyssey Laboratories.
Audyssey Dynamic EQ® is a trademark of Audyssey Laboratories.
Audyssey Dynamic Volume® is a trademark of Audyssey Laboratories.
*“Made for iPod,” and “Made for iPhone,” mean that an electronic accessory has
been designed to connect specifically to iPod, or iPhone, respectively, and has
been certified by the developer to meet Apple performance standards. Apple is
not responsible for the operation of this device or its compliance with safety and
regulatory standards. iPhone, iPod, iPod classic, iPod nano, iPod shue, and iPod
touch are trademarks of Apple Inc., registered in the U.S. and other countries.
*Windows Media and the Windows logo are trademarks or registered trademarks of
Microsoft Corporation in the United States and/or other countries.
*Microsoft, HDCD, and the HDCD logo are trademarks or registered
trademarks of Microsoft Corporation in the United States and/or other countries.
Main Specications
Power amplier section Preamplier section
Rated output *THD gures are power amp stage values. Input sensitivity/impedance 200 mV / 47 kΩ/kohms
Front L/R 140 W + 140 W Frequency response 10 Hz ~ 100 kHz — +1, –3 dB (DIRECT mode)
(8 ohms, 20 Hz - 20 kHz, THD 0.05 %) S/N Ratio 102 dB
(IHF-A weighted, DIRECT mode)
170 W + 170 W
(6 ohms, 1 kHz, THD 0.7%) FM section
Center 140 W Tuning frequency range 87.5 - 107.9 MHz
(8 ohms, 20 Hz - 20 kHz, THD 0.05 %) Usable sensitivity 1.5 μV (14.8 dBf)
170 W
(6 ohms, 1 kHz, THD 0.7%) AM section
Surround L/R 140 W + 140 W Tuning frequency range 530 - 1710 kHz
(8 ohms, 20 Hz - 20 kHz, THD 0.05 %) Usable sensitivity 20 µV
170 W + 170 W
(6 ohms, 1 kHz, THD 0.7%) General
Surround Back L/R 140 W + 140 W Power supply AC 120 V, 60 Hz
(8 ohms, 20 Hz - 20 kHz, THD 0.05 %) Power consumption 780 W (Standby 0.1 W)
170 W + 170 W Dimensions (W x H x D) 17-3/32” x 6-47/64” x 16-19/64”
(6 ohms, 1 kHz, THD 0.7%) 434 x 171 x 414 mm
Front Height/Front Wide 140 W + 140 W Weight 38 lbs 2.2 oz, 17.3 kg
(8 ohms, 20 Hz - 20 kHz, THD 0.05 %)
170 W + 170 W
(6 ohms, 1 kHz, THD 0.7%)
One-cable HD solution
• Supports HDMI 1.4a with Audio Return Channel
• All sources are up-scaled to 1080P
• 7 x HDMI in / 2 x HDMI out with GUI (Graphical
User Interface)
State-of-the-art Denon Solutions for
Maximizing Content Quality
• Fully discrete, identical quality and power for all 9
channels (140 W x 9 channels)
• 9 channels Discrete Mono Amp Construction
• 4 ohms speaker drive capability
• Stable power supply for high-quality sound and picture
playback
• HDMI Clock Control via DENON LINK 4th
• Dynamic Discrete Surround Circuit, D.D.S.C.-HD
• High definition audio support, Dolby TrueHD
and DTS-HD Master Audio
• Supports Dolby Pro Logic IIz processing
• High-bit I/P Converter and Scaler up to 1080p
• Minimum Signal Path for clear audio and video signal
• Direct Mechanical Ground Construction, embody-
ing concepts for thorough vibration resistance
Connectivity & Future-ready Expandability
• Simultaneous playback on two HDMI channels
• HD Radio
• Sirius satellite radio ready
• Power Amp Assign function, provides a broad range
of amp/speaker congurations
• 3 source / 3 zone capability
Ease-of-Use
• On-Board GUI (Graphical User Interface) via
HDMI output (up to 1080p)
• Audyssey Dynamic Volume, for real-time volume
adjustment
• 2-line uorescent display on front panel
• Sleep timer function
• Audio Delay function
(max. 6 frames or 200 mSec)
• Muting level settings (Full/-40dB/-20dB)
• Audio level memory, capable of correcting
dierent signal levels for each input device
• Variable subwoofer crossover switching
Custom Integration
• AMX, Crestron third party control support
• PC and iPhone setup via Ethernet (web control)
• Remote Access & Maintenance
• IP Control
• Audyssey installer Program Ready
Others
• Lower power consumption at stand-by 0.1 W
(Standby)
Notes:
*1 Update distribution via network connection is slated to start around
autumn, 2010.
Ports
In HDMI x 7
Component x 3
S-Video x 2
Composite (Video) x 5
Analog Audio (Tuner included) x 9
Analog EXT. Input 7.1ch
Digital Optical x 2
Digital Coaxial x 2
DENON LINK(4th) x 1
Out HDMI Monitor x 2
Component Monitor x 1
Composite Monitor x 1
Composite (DVR/ Zone2) x 2
Audio Preout 11 ch
(FL/ FR/ C/ SL/ SR/ SBL/ SBR/ FHL/ FHR/ FWL/ FWR)
Audio Preout (SW) x 2
Audio Preout (Zone2 L/R, Zone3 L/R) x 2
Audio REC out x 1
Phones x 1
Digital Optical x 1
Other USB port x 2 (selectable)
Ethernet x 1
Microphone Port x 1
Dock Control Port x 1
FM Tuner Antenna x 1
AM Tuner Antenna x 1
Sirius connector x 1
Remote Control In/Out In 1 / Out 1
RS-232C x 1
DC12V 150mA MAX. trigger out x 2
