Denon AVR-391 Dimensions

AVR-391
AV Surround Receiver
New model information
Features
A/V Home Theater Receiver with 3D Video Connectivity
The AVR-391 sets new standards for performance and aordability, and is packed with great features that assures a superb
surround sound experience. The latest audio decoders, including Dolby TrueHD and DTS-HD Master Audio are included,
and there's even Dolby Pro Logic IIz, which for the first time provides front channel height effects, for a dramatically
expanded front soundstage. It's also equipped with the latest HDMI 1.4a technology, which for the rst time provides for
3D pass-through (Broadcast and Blu-ray) capability, delivering thrilling 3D high denition viewing with 3D-compatible
HDTVs. With 4 HDMI inputs, the AVR-391 can easily accommodate a wide variety of HD sources, including cable or satellite
set-top box, HD game console, Blu-ray disc player, even an HD camcorder. The remote features discrete input selector
buttons for quick source selection and includes dedicated buttons for iPod control with an optional Denon iPod dock.
New Features
• Featuring 3D pass-through technology
• Supports HDMI 1.4a with 3D, Deep Color, “x.v.Color”
• 4 x HDMI in / 1 x HDMI out (Repeater)
• Stereo Mini Jack on front panel lets you connect any portable audio player
State-of-the-art Denon Solutions for Maximizing Content Quality
• Fully discrete, identical quality and power for all 5 channels (110 W x 5 ch)
• Stable power supply for high-quality sound and picture playback
• High denition audio support, Dolby TrueHD and DTS-HD Master Audio
• Minimum Signal Path for clear audio and video signal
• Direct Mechanical Ground Construction, embodying concepts for thorough
vibration resistance
• Compressed Audio Restorer to enhance digital music les
Connectivity & Future-ready Expandability
•Dock connectivity for iPod®and network streaming
Ease-of-Use
• Comes with simple, easy-to-use remote control handset
• Three Quick Select buttons
• Sleep timer function
• Auto surround mode
• Audio level memory, capable of correcting different signal levels for each
input device
Others
• Audio Delay function (max. 6 frames or 200 mSec)
• Muting level settings (Full/-40dB/-20dB)
• Variable subwoofer crossover switching
• Lower power consumption at stand-by 0.5 W (Standby)

Denon Brand Company
D&M Building, 2-1 Nisshin-cho, Kawasaki-ku, Kawasaki-shi,
Kanagawa, 210-8569, Japan
www.denon.com
Denon Electronics (USA), LLC.
100 Corporate Drive, Mahwah, New Jersey 07430 USA
TEL: [phone]
usa.denon.com
Denon Canada Inc.
505 Apple Creek Blvd, Unit 5, Markham, Ontario, Canada L3R 5B1
TEL: [phone]
ca.denon.com
17880610 A
*Design and specications are subject to change without notice.
*“Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby
Laboratories.
*DTS is a registered trademark and the DTS logos, Symbol, DTS-HD
and DTS-HD Master Audio are trademarks of DTS, Inc.
*HDMI, the HDMI logo and High-Denition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
*iPod is a trademark of Apple Inc., registered in the U.S. and other
countries.
Main Specications
Power amplier section Preamplier section
Rated output
*THD gures are power amp stage values. Input sensitivity/impedance 200 mV / 47 kΩ/kohms
Front L/R 75 W + 75 W Frequency response
10 Hz ~ 100 kHz — +1, –3 dB (DIRECT mode)
(8 ohms, 20 Hz - 20 kHz, THD 0.08 %) S/N Ratio 98 dB (IHF-A weighted, DIRECT mode)
110 W + 110 W
(6 ohms, 1 kHz, THD 0.7%) FM section
Center 75 W Tuning frequency range 87.5 - 107.9 MHz
(8 ohms, 20 Hz - 20 kHz, THD 0.08 %) Usable sensitivity 1.2 µV (12.8 dBf)
110 W
(6 ohms, 1 kHz, THD 0.7%) AM section
Surround L/R 75 W + 75 W Tuning frequency range 520 - 1710 kHz
(8 ohms, 20 Hz - 20 kHz, THD 0.08 %) Usable sensitivity 18 µV
110 W + 110 W
(6 ohms, 1 kHz, THD 0.7%) General
Power supply AC 120 V , 60 Hz
Power consumption 330 W (Standby 0.5 W)
Dimensions (W x H x D) 17-3/16” x 6-1/2” x 15”
434 x 166 x 381 mm
Weight 20 lbs 4.5 oz, 9.2 kg
Ports
In HDMI x 4
S-Video x 1
Composite (Video) x 3
Analog Audio (Tuner included) x 6
Digital Optical x 1
Digital Coaxial x 1
Out HDMI Monitor x 1
Composite Monitor x 1
Audio Preout
(Surround Back L/R, SW) x 2
Phones x 1
Other Dock Control Port x 1
FM Tuner Antenna x 1
AM Tuner Antenna x 1
State-of-the-art Denon Solutions for
Maximizing Content Quality
• Fully discrete, identical quality and power for all
5 channels (75 W x 5 ch)
To faithfully reproduce the original surround sound, each of
the AVR-391’s 5 channels is equipped with the same power
amp of equal power. Since these power amps also use
discrete circuits congured with parts strictly selected for their
contribution to high sound quality, rather than with low-cost
integrated circuits (ICs), the surround sound playback is of
impeccably high quality.
• Featuring 3D pass-through technology
By connecting a 3D-compliant Blue-ray disc player and
3D-compliant TV to the AVR-391, you will have a 3D home
theater where you can enjoy high-denition sound and video
on a level you’ve never experienced before.
• Supports HDMI 1.4a with 3D, Deep Color,
“x.v.Color”
• High-denition audio support
The AVR-391 has a decoder that supports Dolby TrueHD and
DTS-HD Master Audio, the high resolution audio formats
found on many Blu-ray titles.
• Minimum Signal Path for clear audio and video
signal
The “simple and straight” design concept has been
thoroug hly implemented in the signal paths to contribute to
immaculately clean audio and video playback. Signal paths
are as short as possible to keep signal degradation in the
audio and video circuitry to an absolute minimum.
• Direct Mechanical Ground Construction, embody-
ing concepts for thorough vibration resistance
Vibration-resistant construction has been reviewed to thor-
oughly suppress the adverse inuences of vibration on sound
quality. The power transformers, a source of vibration, have
been securely mounted on the highly rigid bottom chassis.
Direct mounting of cast-iron feet to the radiator in near
proximity to each other serves to suppress mutual vibration
with the power transformers and other sources of vibration.
• Compressed Audio Restorer to enhance digital
music les
Connectivity & Future-ready Expandability
• 4 x HDMI in / 1 x HDMI out (Repeater)
The AVR-391 provides 4 HDMI inputs that let you simultaneously
connect a variety of HDMI-equipped devices such as a game
console and HD video camera as well as Blu-ray disc player.
• Stereo Mini Jack on front panel lets you connect
any portable audio player
Compressed Audio Restorer is a Denon technology that restores
compressed music sources to their original pre-compressed
quality to give you a lively sonic ambience with greater detail
and depth.
• Dock connectivity for iPod and network streaming
Network music can be enjoyed via the Denon Networked Con-
trol Dock. (Requires optional ASD-51W or ASD-51N dock)
Sounds Better
Portable in to
Compressed Audio Restorer
