Denon AVR-S570BT User manual

•
DENON ®
AVR-S570BT
AV SURROUND RECEIVER

1
Welcome
Thank you for choosing a Denon AVR.
Use the SetupAssistantfunction to help configure the settings for this unit when you first set it up.
Follow the guidance displayed on the TV screen connected to this unit to configure the settings.
This manual describes the procedure up until starting the SetupAssistant.
Scan the QR code orvisitsupport.denon.com/
Please do not return this product to the
store. If you need help... l) forsetup help, technical support, warranty assistance, or
customer supportcontact information. •

Before Y.OU begin
Required for setup
TV Speaker cables
Speakers
H DMI® cable
Subwoofer cable
• When connectingthis unit to adevice that iscompatible with the Deep Color, 4K, ARC and eARCfunctions, use a "High Speed HDMI cable with Ethernet" that
displays the HDMI logo.
• When connectingthis unit to adevice that iscompatible with the 8K and 4K 120Hzvideo, use a certified "Ultra High Speed HDMI cable". If you useadifferent
HDMI cable, the video may not bedisplayed or other prob lems may occur.
FR
ES
PT
2

3
What's in the box
Quickstartguide
Safety instructions
Notes on radio
Warranty
(forNorth America
model only)
Cable labels
AVR
FM indoor antenna
AM loop antenna
Sound calibration
microphone
Remote control
(RC-1254)
2x R03/ AAA batteries
• Using yourown tripod enables settings to be automaticallyconfigured to the optimum listening environment, providing exceptionally high
performance.
•

How to attach the cable labels
The supplied cable labels includelabels for the speaker and
HDMI cables.
Attach acable label to each cable that matches the speakers
and HDMI devices being connected, as shown below.
This makes iteasy to identifyand properlyconnect the cables
between your components .
Setup
0 Connect the power cord
Place the AVR near your TV and connect the power cord.
Power cord
u \l
TV
O ~~ 0
0
000 0
0 0
00 00
e,
AVR
FR
ES
PT
4

5
8 Connect the AVR to your TV
HDMIOUT
MONITOR
(ARC/eARC)
~<>
HDMI IN
(ARC/eARC)
L_ = )
HDMI cable
AVR (Rear panel)
Using a high quality HDMI cable*, connect one end to the HDMI
port labeled "eARC" or "ARC" on your TV. Connect the other
end to the HDMI OUT MONITOR port on your AVR.
WhdisARCandeARC?
Audio Return Channel or "ARC" sends audio back to the AVR
using the same HDMI cable that sends video from your AVR
to your TV .This allows your AVR to process the sound from
your TV
1s built-in
tuner and apps. TVs with an Enhanced Audio
Return Channel or "eARC" port will provide additional support
for high bitrate multichannel audio (DolbyTrueHD and DTS-
HD MasterAudio). Please refer to your TV owner
1s manual
for
details about eARC support for your particular model.
* For 4K TVs, we recommend using an HDMI cable labeled
"High Speed" and "with Ethernet" .
* For BK TVs, we recommend using an HDMI cable labeled
"Ultra High Speed".
•

•
8 Turn on the TV
TV remote control
Select the appropriate HDMI
input on your TV
HDMI
TV remote control
FR
ES
PT
6

7
Install batteries in the AVR
remote control
• Batteries can be taken out in reversed order.
C, Turn on the AVR
• Press <!> on the remote control.
I
0
0
0
0000
0 0
I
oo
000
000
000
0
ooo
ooo
:@°
0 0
000
000
0000
0000
0000
e
•
0
I I

•
8 Verify the connection
• Verify that you can seethisscreen on your TV.
If this screen is not displayed, please go backand retry the
stepsagain in the recommended sequence.
C9 Follow the on-screen Setup
Assistant
The TV is now connected to the AVR.
The Setup Assistant will walk you through connecting and
configuring your speakers and components to your Denon
AVR. Use the remote control and follow the instructions
on the TV screen to complete the AVR settings using the
SetupAssistant.
8
FR
ES
PT

9
Playing music -Bluetooth
1 Press and hold the Bluetooth button on the
remote control for at least 3 seconds to go into
pairing mode.
00
DOD
DOD
DOD
D
:@ o
0 0
000
000
ODDO
0000
2 Activate the Bluetooth settings on your mobile
device.
3 Select "Denon AVR-S570BT" from the Bluetooth
device liston your mobile device.
4 When a number appears on the display
of this
unit, check that it is the same number as that
shown on the screen of the Bluetooth device
and then select"Pair" for both the Bluetooth
device and the unit.
S Play music using any appon your device.
To reconnecta previously paired Bluetooth
device, Start at step 2.
