Desa VTGF33NRA Quick start guide

UNVENTED (VENT-FREE)
GAS FIREPLACE
OWNER’S OPERATION AND INSTALLATION MANUAL
Save this manual for future reference.
Save this manual for future reference.
For more information, visit www.desatech.com
For more information, visit www.desatech.com
Shown with optional cabinet
mantel, hearth base, and
trim accessories.
WARNING: If the information in this manual is not fol-
lowed exactly, a fire or explosion may result causing
property damage, personal injury, or loss of life.
— Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
— WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor’s phone. Follow the gas supplier’s
instructions.
• If you cannot reach your gas supplier, call the
fire department.
— Installationandservicemustbeperformedbyaquali-
fied installer, service agency, or the gas supplier.
WARNING: Improper installation,
adjustment, alteration, service, or
maintenance can cause injury or
property damage. Refer to this
manual for correct installation and
operationalprocedures. Forassis-
tanceoradditionalinformationcon-
sult a qualified installer, service
agency, or the gas supplier.
WARNING:Thisisanunventedgas-
fired heater. It uses air (oxygen)
from the room in which it is in-
stalled. Provisions for adequate
combustionandventilationairmust
be provided. Refer to Air for Com-
bustion and Ventilation section on
page 5 of this manual.
VTGF33NRA and VTGF33PRA
Gas Fireplace with Total Control System (TCS)
This appliance may be installed in an aftermarket,* permanently located, manufactured
(mobile) home, where not prohibited by local codes.
Thisapplianceisonlyforuse with the type ofgasindicatedonthe rating plate. This appliance
is not convertible for use with other gases.
* Aftermarket: Completion of sale, not for purpose of resale, from the manufacturer

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
2
TABLE OF CONTENTS
SAFETY INFORMATION
SAFETY INFORMATION
DANGER: Carbon monoxide poisoning may lead
to death!
Carbon Monoxide Poisoning: Early signs of carbon monoxide
poisoningresemblethe flu,with headaches, dizziness,or nausea.If
you have these signs, the fireplace may not be working properly.
Get fresh air at once! Have fireplace serviced. Some people are
more affected by carbon monoxide than others. These include
pregnantwomen,peoplewithheartorlungdiseaseoranemia,those
under the influence of alcohol, and those at high altitudes.
Natural and Propane/LP Gas: Natural and propane/LP gases are
odorless. An odor-making agent is added to these gases. The odor
helps you detect a gas leak. However, the odor added to the gas can
fade. Gas may be present even though no odor exists.
Make certain you read and understand all warnings. Keep this
manual for reference. It is your guide to safe and proper operation
of this fireplace.
WARNINGS
IMPORTANT: Read this owner’s manual carefully and
completelybeforetryingtoassemble,operate,orservice
this fireplace. Improper use of this fireplace can cause
serious injury or death from burns, fire, explosion, elec-
trical shock, and carbon monoxide poisoning.
WARNING: Any change to this heater or its
controls can be dangerous.
WARNING:Donotallowfanstoblowdirectlyintothe
fireplace. Avoid any drafts that alter burner flame pat-
terns.Ceilingfanscancreatedraftsthatalterburnerflame
patterns. Altered burner patterns can cause sooting.
WARNING: Do not use a blower insert, heat
exchanger insert, or other accessory not approved
for use with this fireplace.
Due to high temperatures, the appliance should be
located out of traffic and away from furniture and
draperies.
Donotplaceclothingorotherflammablematerialon
or near the appliance. Never place any objects on
the heater.
Fireplace front and screen become very hot when
running fireplace. Keep children and adults away
fromhotsurfaces toavoidburnsor clothingignition.
Fireplace will remain hot for a time after shutdown.
Allow surfaces to cool before touching.
Carefullysuperviseyoungchildrenwhentheyareinthe
roomwith fireplace. When using the hand-held remote
accessory, keep selector switch in the OFF position to
prevent children from turning on burners with remote.
You must operate this fireplace with the fireplace
screenandhoodinplace.Makesurefireplacescreen
and hood are in place before running fireplace.
Keeptheapplianceareaclearand free from combus-
tiblematerials,gasoline,andotherflammablevapors
and liquids.
TABLE OF CONTENTS
SAFETY INFORMATION ............................................................ 2
PRODUCT IDENTIFICATION ..................................................... 3
LOCAL CODES........................................................................... 4
UNPACKING ............................................................................... 4
PRODUCT FEATURES .............................................................. 4
AIR FOR COMBUSTION AND VENTILATION ........................... 5
INSTALLATION ........................................................................... 7
OPERATING FIREPLACE ........................................................ 18
INSPECTING BURNERS.......................................................... 20
CLEANING AND MAINTENANCE ............................................ 21
SPECIFICATIONS .................................................................... 22
TROUBLESHOOTING .............................................................. 23
ILLUSTRATED PARTS BREAKDOWNAND PARTS LIST ....... 26
ACCESSORIES ........................................................................ 30
REPLACEMENT PARTS .......................................................... 32
WIRING DIAGRAM ................................................................... 32
SERVICE HINTS....................................................................... 32
TECHNICAL SERVICE ............................................................. 32
TEMPLATES ............................................................................. 33
OWNER’S REGISTRATION FORM.......................................... 39
WARRANTY INFORMATION...................................... Back Cover
WARNING:Thisproductcontainsand/orgenerates
chemicals known to the State of California to cause
cancer or birth defects, or other reproductive harm.

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
3
3
SAFETY INFORMATION
PRODUCT IDENTIFICATION
1. This appliance is only for use with the type of gas indicated on
the rating plate. This appliance is not convertible for use with
other gases.
2. Do not place propane/LP supply tank(s) inside any structure. Lo-
catepropane/LPsupplytank(s)outdoors(propane/LP unitsonly).
3. If you smell gas
• shut off gas supply
• do not try to light any appliance
•
do not touch any electrical switch; do not use any phone in
your building
• immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions
• if you cannot reach your gas supplier, call the fire department
4. This fireplace shall not be installed in a bedroom or bathroom.
5. Do not use this fireplace as a wood-burning fireplace. Use only
the logs provided with the fireplace.
6. Do not add extra logs or ornaments such as pine cones, ver-
miculite,orrock wool.Usingthese addeditems can causesoot-
ing. Do not add lava rock around base. Rock and debris could
fall into the control area of fireplace.
7. To preventthe creationof soot,followthe instructionsin Clean-
ing and Maintenance, pages 21 and 22.
8. Before using furniture polish, wax, carpet cleaner, or similar
products, turn heater off. If heated, the vapors from these prod-
ucts may create a white powder residue within burner box or
on adjacent walls or furniture.
9. This fireplace needs fresh air ventilation to run properly. This
fireplace has an Oxygen Depletion Sensing (ODS) safety
shutoffsystem.The ODSshuts downthe fireplaceif notenough
fresh air is available. See Air for Combustion and Ventilation,
pages 5 through 7. If fireplace keeps shutting off, see Trouble-
shooting, pages 23 through 25.
10. Do not run fireplace
• where flammable liquids or vapors are used or stored
• under dusty conditions
11. Do not use this fireplace to cook food or burn paper or other
objects.
12. Do not use fireplace if any part has been exposed to or under
water. Immediately call a qualified service technician to in-
spect the fireplace and to replace any part of the control sys-
tem and any gas control which has been under water.
13. Do not operate fireplace if any log is broken. Do not operate
fireplace if a log is chipped (dime-sized or larger).
14. Turn fireplace off and let cool before servicing. Only a quali-
fied service person should service and repair fireplace.
15. Operating fireplace above elevations of 4,500 feet could cause
pilot outage.
16. To prevent performance problems with propane/LP units, do
not use propane/LP fuel tanks of less than 100 lb. capacity.
17. Provide adequate clearances around air openings.
SAFETY INFORMATION
Continued
PRODUCT IDENTIFICATION
Figure 2 - Fireplace
Top Louver
Assembly
Bottom Louver
Assembly
Screen
Assembly
Top Outer
Casing
Blower
Assembly
Figure 1 - Log Set and Base
Log Set
Base
Assembly
Piezo Ignitor
Fan Switch

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
4
LOCAL CODES
Install and use fireplace with care. Follow all local codes. In the
absenceoflocalcodes,usethelatesteditionofTheNationalFuelGas
Code, ANSI Z223.1/NFPA 54*.
*Available from:
American National Standards Institute, Inc.
1430 Broadway
New York, NY 10018
National Fire Protection Association, Inc.
Batterymarch Park
Quincy, MA 02269
UNPACKING
1. With utility knife, cut the carton all the way around above the
staples on the bottom tray. Lift the carton off the heater. Re-
move packing. Note: The hood is located in the packing on
the right hand side of the heater front. Lift the heater off the
bottom tray.
2. Locate two screws above top corners of the fireplace screen.
Remove and discard these screws. Lift fireplace screen up and
pull out to remove.
3. Remove protective packaging applied to logs, log base assem-
bly, and fireplace.
4. Remove fireplace hood from carton insert.
5. Check allitems forany shipping damage.If damaged,promptly
inform dealer where you bought fireplace.
CAUTION:Donotremovethedataplatesattached
to the heater base assembly. The data plates contain
important warranty and safety information.
PRODUCT FEATURES
OPERATION
This vent-free fireplace is clean burning. It requires no outside
venting. There is no heat loss out a vent or up a chimney. Heat is
generated by both realistic flames and glowing embers. When used
without the optional blower, the fireplace requires no electricity
making it ideal for emergency backup heat.
SAFETY DEVICE
Thisfireplace hasa pilotwith anOxygen DepletionSensing(ODS)
safety shutoff system. The ODS/pilot is a required feature for vent-
free room heaters. The ODS/pilot system shuts off the fireplace if
there is not enough fresh air.
PIEZO IGNITION SYSTEM
This fireplace has a piezo ignitor. This system requires no matches,
batteries, or other sources to light fireplace.
WIRELESS REMOTE CONTROL
This fireplace features an infrared wireless remote control. This
controlsystemcanbeusedtoautomaticallylightthepilotandadjust
the burner flame height at the push of a button.
WIRED WALL-MOUNTED REMOTE CONTROL
This fireplace features a two-button wall switch assembly with
glowingLED’s.Thewallswitchperformsthesamefunctionsasthe
wireless hand-held remote control with the added feature of LED’s
for visual feedback of operation and status.
BLOWER ASSEMBLY
This fireplace includes a blower assembly. The blower operates
thermostatically.Theblowercirculatesheatedairfromthefireplace
into the room.
LOCAL CODES
UNPACKING
PRODUCT FEATURES

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
5
5
AIR FOR COMBUSTION AND
VENTILATION
Today’s homes are built more energy efficient than ever. New
materials,increased insulation,and newconstructionmethods help
reduce heat loss in homes. Home owners weather strip and caulk
aroundwindows anddoors tokeepthe coldair outand thewarm air
in. During heating months, home owners want their homes as
airtight as possible.
While it is good to make your home energy efficient, your home
needs to breathe. Fresh air must enter your home. All fuel-burning
appliances need fresh air for proper combustion and ventilation.
Exhaustfans,fireplaces,clothesdryers,andfuelburningappliances
drawairfromthehousetooperate.Youmustprovideadequatefresh
air for these appliances. This will insure proper venting of vented
fuel-burning appliances.
PROVIDING ADEQUATE VENTILATION
The following are excerpts from National Fuel Gas Code, ANSI
Z223.1/NFPA 54, Section 5.3, Air for Combustion and Ventilation.
All spaces in homes fall into one of the three following ventilation
classifications:
1. Unusually Tight Construction
2. Unconfined Space
3. Confined Space
The information on pages 5 through 7 will help you classify your
space and provide adequate ventilation.
Unusually Tight Construction
The air that leaks around doors and windows may provide enough
fresh air for combustion and ventilation. However, in buildings of
unusually tight construction, you must provide additional fresh air.
WARNING: This heater shall not be installed in a
confined space or unusually tight construction un-
less provisions are provided for adequate combus-
tion and ventilation air. Read the following instruc-
tionstoinsureproperfreshairforthisandotherfuel-
burning appliances in your home.
Unusually tight construction is defined as construction
where:
a. walls and ceilings exposedtotheoutsideatmosphere
have a continuous water vapor retarder with a rating
of one perm (6 x 10-11 kg per pa-sec-m2) or less with
openings gasketed or sealed and
b. weather stripping has been added on openable win-
dows and doors and
c. caulking or sealants are applied to areas such as
joints around window and door frames,between sole
platesandfloors,between wall-ceiling joints,between
wall panels, at penetrations for plumbing, electrical,
and gas lines, and at other openings.
If your home meets all of the three criteria above, you
must provide additional fresh air. See
Ventilation Air
From Outdoors , page 7 .
If your home does not meet all of the three criteria above,
proceed to Determining Fresh-Air Flow for Fireplace Lo-
cation on page 6.
Confined Space and Unconfined Space
The National Fuel Gas Code, ANSI Z223.1/NFPA 54 defines a
confined space as a space whose volume is less than 50 cubic feet
per 1,000 Btu per hour (4.8 m3per kw) of the aggregate input rating
of all appliances installed in that space and an unconfined space as
aspacewhosevolumeisnotlessthan50cubicfeetper1,000Btuper
hour (4.8 m3per kw) of the aggregate input rating of all appliances
installed in that space. Rooms communicating directly with the
space in which the appliances are installed*, through openings not
furnishedwith doors,areconsidered apartof theunconfinedspace.
* Adjoining rooms are communicating only if there are doorless
passageways or ventilation grills between them.
AIR FOR COMBUSTION AND VENTILATION
Providing Adequate Ventilation

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
6
AIR FOR COMBUSTION AND
VENTILATION
Continued
DETERMINING FRESH-AIR FLOW FOR
HEATER LOCATION
Determining if You Have a Confined or
Unconfined Space
Usethisworksheettodetermineifyouhaveaconfined or unconfined space.
Space:Includestheroominwhichyouwillinstallheaterplusanyadjoining
rooms with doorless passageways or ventilation grills between the rooms.
1. Determine the volume of the space (length x width x height).
Length x Width x Height = ___________ cu. ft. (volume of space)
Example: Space size 20 ft. (length) x 18 ft. (width) x 8 ft. (ceiling
height) = 2880 cu. ft. (volume of space)
Ifadditionalventilationtoadjoiningroomissuppliedwith grills or open-
ings, add the volume of these rooms to the total volume of the space.
2. Multiply the space volume by 20 to determine the maximum Btu/Hr
the space can support.
__________ (volume of space) x 20 = (Maximum Btu/Hr the space
can support)
Example: 2880 cu. ft. (volume of space) x 20 = 57,600 (maximum
Btu/Hr the space can support)
3. Add the Btu/Hr of all fuel burning appliances in the space.
Vent-free heater _____________ Btu/Hr
Gas water heater* _____________ Btu/Hr
Gas furnace _____________ Btu/Hr
Vented gas heater _____________ Btu/Hr
Gas fireplace logs _____________ Btu/Hr
Other gas appliances* + _____________ Btu/Hr
Total = _____________ Btu/Hr
* Do not include direct-vent gas appliances. Direct-vent draws com-
bustion air from the outdoors and vents to the outdoors.
Example:
Gas water heater _____________ Btu/Hr
Vent-free heater + _____________ Btu/Hr
Total = _____________ Btu/Hr
4. Compare the maximum Btu/Hr the space can support with the actual
amount of Btu/Hr used.
__________________ Btu/Hr (maximum the space can support)
__________________ Btu/Hr (actual amount of Btu/Hr used)
Example: 57,600 Btu/Hr (maximum the space can support)
73,000 Btu/Hr (actual amount of Btu/Hr used)
The space in the above example is a confined space because the actual Btu/Hr
used is more than the maximum Btu/Hr the space can support. You must
provide additional fresh air. Your options are as follows:
WARNING: If the area in which the heater may be
operated is smaller than that defined as an uncon-
fined space or if the building is of unusually tight
construction,provideadequatecombustionandven-
tilation air by one of the methods described in the
National Fuel Gas Code, ANSI Z223.1/NFPA 54 Sec-
tion 5.3 or applicable local codes .
A. Rework worksheet, adding the space of an adjoining room. If the
extra space provides an unconfined space, remove door to adjoining
roomor add ventilation grillsbetweenrooms.SeeVentilationAir From
Inside Building.
B. Vent room directly to the outdoors. See Ventilation Air From Out-
doors, page 7.
C. Installa lower Btu/Hrheater, if lowerBtu/Hrsize makes room unconfined.
If the actual Btu/Hr used is less than the maximum Btu/Hr the space can
support, the space is an unconfined space. You will need no additional fresh
air ventilation.
40,000
33,000
73,000
AIR FOR COMBUSTION AND VENTILATION
Determining Fresh-Air Flow For Heater Location
Ventilation Air
VENTILATION AIR
Ventilation Air From Inside Building
This fresh air would come from an adjoining unconfined space.
When ventilating to an adjoining unconfined space, you must
provide two permanent openings: one within 12" of the ceiling and
one within 12" of the floor on the wall connecting the two spaces
(see options 1 and 2, Figure 3). You can also remove door into
adjoining room (see option 3, Figure 3). Follow the National Fuel
Gas Code, ANSI Z223.1/NFPA 54, Section 5.3, Air for Combustion
and Ventilation for required size of ventilation grills or ducts.
Figure 3 - Ventilation Air from Inside Building
Or
Remove
Door into
Adjoining
Room,
Option
3
Ventilation Grills
Into Adjoining Room,
Option 2
Ventilation
Grills
Into Adjoining
Room,
Option 1
12"
12"

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
7
7
AIR FOR COMBUSTION AND VENTILATION
Ventilation Air (Cont.)
INSTALLATION
Check Gas Type
AIR FOR COMBUSTION AND
VENTILATION
Continued
Figure 4 - Ventilation Air from Outdoors
Outlet
Air Ventilated
Attic
Outlet
Air
Inlet
Air
Inlet Air Ventilated
Crawl Space
To
Crawl
Space
To Attic
Ventilation Air From Outdoors
Provideextrafreshairby usingventilationgrillsorducts.Youmust
provide two permanent openings: one within 12" of the ceiling and
one within 12" of the floor. Connect these items directly to the
outdoorsorspacesopento theoutdoors.Thesespacesincludeattics
and crawl spaces. Follow the National Fuel Gas Code, ANSI
Z223.1/NFPA 54, Section 5.3, Air for Combustion and Ventilation
for required size of ventilation grills or ducts.
IMPORTANT: Donotprovideopeningsforinletoroutletairintoattic
if attic has a thermostat-controlled power vent. Heated air entering the
attic will activate the power vent.
INSTALLATION
CAUTION: This fireplace creates warm air cur-
rents. These currents move heat to wall surfaces next
to fireplace. Installing fireplace next to vinyl or cloth
wallcoveringsoroperatingfireplacewhereimpurities
(such as, but not limited to, tobacco smoke, aromatic
candles,cleaningfluids,oilorkerosenelamps,etc.)in
the air exist, may discolor walls or cause odors.
WARNING: A qualified service person must in-
stall fireplace. Follow all local codes.
WARNING: Never install the fireplace
•in a bedroom or bathroom
•in a recreational vehicle
•where curtains, furniture, clothing, or other flam-
mable objects are less than 42 inches from the
front, top, or sides of the fireplace
•in high traffic areas
•in windy or drafty areas
NOTICE: This heater is intended for use as supple-
mental heat. Use this heater along with your primary
heating system. Do not install this heater as your
primary heat source. If you have a central heating
system, you may run system’s circulating blower
while using heater. This will help circulate the heat
throughoutthehouse.Intheeventofapoweroutage,
you can use this heater as your primary heat source.
Note: Your fireplace is designed to be used in zero clearance
installations.Wallorframingmaterialcanbeplaceddirectlyagainst
any exterior surface on the rear, sides, or top of your fireplace,
except where standoff spacers are integrally attached. If standoff
spacers are attached to your fireplace, these spacers can be placed
directly against wall or framing materials.
Use the dimensions shown for rough openings to create the easiest
installation (see Built-In Fireplace Installation, page 15).
IMPORTANT: Vent-freeheaters addmoisture tothe air. Although
this is beneficial, installing fireplace in rooms without enough
ventilation air may cause mildew to form from too much moisture.
See Air for Combustion and Ventilation, pages 5 through 7.
IMPORTANT: Make sure the fireplace is level. If fireplace is not
level, log set will not work properly.
CHECK GAS TYPE
Use the correct gas type (natural or propane/LP) for your unit. If
your gas supply is not correct, do not install fireplace. Call dealer
where you bought fireplace for proper type fireplace.

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
8
ELECTRICAL HOOKUP
This fireplace normally operates under 120 VAC/60 Hz line volt-
age. The electrical cord supplied with your fireplace is five feet in
length. You must locate fireplace within reach of a 120 volt
groundedelectricaloutlet.Ifnot,youmustinstallanelectricaloutlet
within reach of the fireplace power cord. The GA3555 outlet
accessory may be used for built-in applications.
INSTALLATION CLEARANCES
WARNING: Maintain the minimum clearances. If
you can, provide greater clearances from floor, ceil-
ing, and adjoining wall.
Carefully follow the instructions below. This will ensure safe
installation.
Minimum Clearances For Side Combustible
Material, Side Wall, and Ceiling
A. Clearances from the side of the fireplace cabinet to any com-
bustible material and wall should follow diagram in Figure 5.
Example: The face of a mantel, bookshelf, etc. is made of
combustible material and protrudes 3 1/2" from the wall. This
combustible material must be 4" from the side of the fireplace
cabinet (see Figure 5).
B. Clearances from the top of the fireplace opening to the ceiling
should not be less than 42 inches.
Figure 5 - Minimum Clearance for Combustible to Wall
*Minimum 16 inches from Side Wall
*
Example
INSTALLATION
Continued
INSTALLATION
Electrical Hookup
Installation Clearances
Installation Sequence
Removing Fireplace Screen And Floor Assembly
INSTALLATION SEQUENCE
Afterunpackingfireplace (seeUnpacking, page4), we suggestthat
you install your fireplace system in the following sequence:
1. Removal of fireplace floor assembly (required)
2. Electrical connections for power cord (required)
3. Relocating wall switch (optional)
4. Installing blower accessory (optional)
5. Connecting fireplace to gas supply (required)
6. Checking gas connections (required)
7. Firebox installation, conventional or built-in (required)
8. Installing brass perimeter trim (optional)
9. Installing fireplace hood (required)
10. Installing logs (required)
11. Installing fireplace screen (required)
Use the following instructions to complete each step.
REMOVING FIREPLACE SCREEN AND
FLOOR ASSEMBLY
NOTICE: Shutoff gas supply and disconnect heater
from gas supply if installing blower into previously
installedfireplace.Contactaqualifiedserviceperson
to do this.
1. To remove fireplace screen, remove two screws that hold fire-
place screen in place for shipping. These screws are located
near top of screen. Discard screws. Lift fireplace screen up
and pull out to remove.
2. If logs are installed, carefully remove the logs and set aside,
noting the properly mounted location of each.
3. Remove screws that attach fireplace floor assembly to fire-
place. Open lower louver door. Carefully lift up fireplace floor
assembly and remove from fireplace, taking care to pull flex-
ible gas line through the access holes (see Figure 6, page 9).
Note: Be careful of all wires on underside of log base.
CAUTION:Donotpickupfireplacefloorassembly
byburners.Thiscoulddamageburners.Onlyhandle
base by grates.
MINIMUM CLEARANCE TO
COMBUSTIBLE MATERIALS
Top Left and Bottom
Right Sides and Rear
0" 16" 0"

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
9
9
Figure 6 - Removing Fireplace Floor Assembly
Screw
Fireplace Floor
Assembly
Flexible
Gas Line
INSTALLATION
Continued
ELECTRICAL CONNECTIONS FOR POWER
CORD
This fireplace operates on 120 VAC, 60 Hz power. An electrical
power cord is supplied with this unit.
For Mantel Installation
1. Determine from which side of the fireplace the power cord will
exit. Locate the 1.5" diameter hole near the center of floor sup-
port bracket on appropriate side of lower cavity (see Figure 7).
2. Locate power cord. Remove wire tie or tape holding plug end
of power cord.
3. Power cord has 2 plastic hole bushings threaded onto it. Route
cord's 3-prong plug through the 1.5" diameter hole in appro-
priate floor support bracket.
4. Push first plastic bushing completely through hole. Squeeze
bushing as needed to do this.
5. Install the second plastic bushing into the hole in the floor sup-
port bracket by snapping into place.
6. Route the 3-prong plug through the 1.5" hole in fireplace
outer casing.
7. Installthefirstplasticbushingintothisholebysnappingintoplace.
8. After you have connected to gas supply and checked your gas
connections (see pages 15 and 16), plug power cord into any
convenient 3-prong grounded wall receptacle near fireplace.
For Recessed Installation
If an outlet is not installed in fireplace, install model GA3555 -
Outlet Kit with Cover. This kit will supply a convenient 3-prong
grounded electrical outlet for power. Refer to installation manual
provided with this optional accessory for instructions on wiring.
Note: A qualified installer must make all electrical connections.
Figure 7 - Routing Power Cord
Power Cord
Bushings
Hole in Floor
Support Bracket Hole in Outer
Casing
RELOCATING WALL SWITCH ASSEMBLY
Note: The decorative wall switch plate supplied is white. The wall
switch plate may be painted to match your decor.
The push-button switch and decorative wall plate assembly sup-
plied with your fireplace is pre-mounted at the factory in the lower
cavity of the fireplace. You may relocate this wall switch assembly
to a more convenient location such as the side of your mantel or
directly onto the wall near the fireplace. To mount the wall switch
assembly, you must first cut openings in the mantel or wall where
the switch will be located.
Note: If you choose to relocate the wall switch assembly, do so
beforefinalinstallationintoamantelorrecessingintoawall. Ifyou
areinstallinganoptionalbloweraccessory,installitatthesametime
you relocate the wall switch assembly.
For Recessed Installation
If fireplace is to be recessed into a wall (see Built-In Fireplace
Installation, page 15), we recommend mounting wall switch
assemblytoleftsideoffireplace.Thewallswitchassemblyshould
bemountedapproximately12"fromleftedgeoffireplace,andless
than 60" from the floor. IMPORTANT: Do not locate wall switch
assemblydirectlyin frontofwallstud -theremustbe roombehind
wall board for wires from switch. If you choose to locate wall
switch assembly to right side of fireplace, the length of the cord
restricts you to less than 6" from right edge of fireplace and less
than 48" from floor.
CAUTION: The wall switch assembly must never
be mounted directly above the fireplace where heat
may damage it. If you relocate wall switch assembly
fromlowerfireplacecavity,itmustbemountedeither
on side wall of mantel or on wall to side of fireplace.
INSTALLATION
Removing Fireplace Screen And Floor Assembly (Cont.)
Electrical Connections for Power Cord
Relocating Wall Switch Assembly
Screw

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
10
INSTALLATION
Relocating Wall Switch Assembly (Cont.)
CAUTION:Becarefulofgaslinesandwiringwhen
moving floor.
For Mantel Installation
If fireplace is to be installed into a mantel, (see Conventional
Fireplace Installation, page 15) the wall switch assembly may be
mountedon eithersideof themantel,facing totheside. Donotlocate
wall switch assembly anywhere on the front face of the mantel.
1. Determine the new location for the wall switch assembly. The
wires attached to switch are six feet long.
2. Remove 2 screws securing plastic wall switch assembly to
bracket in fireplace lower cavity. Save screws.
3. Remove wire tie holding coiled wire attached to wall switch
assembly (see Figure 8).
4. Remove wall switch assembly from bracket.
5. Carefully pass wall switch assembly and cord through large
elongatedhole inrear ofeither leftorrightfloorsupportbracket,
depending on desired location of switch. Pass wall switch as-
sembly and cord through 1.5" diameter hole in side of fire-
place outer casing (see Figure 9).
6. Pull wall switch assembly and cord from fireplace making sure
wall switch assembly will reach desired mounting location
without straining cord assembly.
If you are mounting wall switch assembly to a wall, continue
reading. If you are mounting your wall switch assembly to the side
of the mantel, see page 11.
INSTALLATION
Continued
Figure 8 - Relocating Wall Switch Assembly
CAUTION: Do not apply excessive pull on cord.
Figure9 -Routing WallSwitch AssemblyThrough Fireplacefor
Relocation
Wall Switch
Assembly
Wire Tie
Burner
Outlet
Tube
Gas Control Valve
Firebox
Bottom
Wall Switch Assembly
Hole in Outer
Casing Hole in
Floor
Support
Bracket
MountingWallSwitchAssemblytoWallforRecessedFireplace
7. Create three openings on wall according to Template 1, page
33. This is best done by making a pattern to work with on your
wall. Carefully cut page 33/34 from manual and tape paper
template vertically onto wall at preferred location. Pierce the
paper at the centers of the 2 holes with a nail or sharp pencil,
leaving a mark on the wall. Do the same at centers of the four
circles near the corners of the rectangle.
8. Remove paper template from wall.
9. Drill 3/8" holes at each mark.
10. Using a straight edge and pencil, connect the outer edges of
the 4 holes for the rectangle (see Figure 10). This will give you
cutting lines for the rectangle you will cut in the wall.
11. Using a keyhole saw, hack saw blade, drill, file, or other suit-
able tool, carefully cut out the rectangular opening. Note: The
corners of the rectangle may be round. IMPORTANT: Do not
exceed the size of the rectangle on template.
12. From inside the recessed opening for the fireplace, carefully
pass wall switch assembly through the rectangular opening to
the outside of the wall.
13. Using wall anchors supplied in hardware package, fold wall
anchor as shown in Figure 11.
14. Insertwallanchor,wingsfirst, intohole.Tap anchor flushto wall.
15. For thin walls (1/2" or less), insert red key into wall anchor.
Push red key to “pop” open anchor wings. See Figure 12.
IMPORTANT: Do not hammer key! For thick walls (over 1/2"
thick), do not pop open wings.
Figure 11 - Folding Anchor Figure12-PoppingOpenAnchor
Wings for Thin Walls
Figure10-UsingTemplateforWallSwitchAssemblyInstallation
4
3
/ 4 "
3
3
/ 4 "
3/8"
3/16"
3/4"
3/8" Diameter
2 Holes
Template
from This
Manual
Cutting
Lines
Make Marks
at Centers
of Holes
Tape

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
11
11
INSTALLATION
Relocating Wall Switch Assembly (Cont.)
Installing Gas Piping to Fireplace Location
INSTALLATION
Continued
16. Position wall switch assembly vertically over wall openings
with decal lettering upright (see Figure 13).
17. Insert mounting screws, removed in step 2 of Relocating Wall
Switch Assembly on pages 9 and 10, through holes in wall plate
and into wall anchors.
18. Tighten screws until wall plate is firmly attached to wall. Do
not overtighten.
Mounting Wall Switch Assembly to Side of Mantel
7. Create three openings in the mantel wall according to Tem-
plate 2, page 33. This is best done by making a pattern to work
with on the mantel. Carefully cut page 33/34 from manual and
tape paper template vertically onto mantel wall at preferred
location. Pierce the paper at the centers of the 2 holes with a
nail or sharp pencil, leaving a mark on the wall. Do the same
at centers of the four circles near the corners of the rectangle.
8. Remove paper template from mantel wall.
9. Drill 1/8" pilot holes at each mark for top and bottom screw
holes. Drill 3/8" holes at each mark for centers of four circles
near corners of rectangle.
10. Using a straight edge and pencil, connect the outer edges of the 4
holes for the rectangle (see Figure 10, page 10). This will give
you cutting lines for the rectangle you will cut in the mantel wall.
11. Using a keyhole saw, hack saw blade, drill, file, or other suit-
able tool, carefully cut out the rectangular opening. Note: The
corners of the rectangle may be round. IMPORTANT: Do not
exceed the size of the rectangle on template.
12. Carefully pass wall switch assembly through rectangular open-
ing from inside mantel (see Figure 13).
13. Position wall switch assembly vertically over opening with
decal lettering upright. Make sure wires freely pass through
wall without binding.Align holes in wall plate with 1/8" pilot
holes in mantel wall.
14. Drive mounting screws, removed in step 2 of Relocating Wall
Switch Assembly on pages 9 and 10, through wall plate holes
and into pilot holes in mantel wall.
15. Tighten screws until wall switch assembly is firmly attached
to mantel. Do not overtighten.
Figure 13 - Securing Wall Switch Assembly
Screws
Wall Switch Assembly
Opening in
Wall or
Mantel Wall WARNING: A qualified service person must con-
nect fireplace to gas supply. Follow all local codes.
WARNING: For natural gas units, never connect
fireplace to private (non-utility) gas wells. This gas is
commonly known as wellhead gas.
INSTALLING GAS PIPING TO FIREPLACE
LOCATION
WARNING: For propane/LP units, never connect
fireplace directly to propane/LP supply. This fire-
place requires an external regulator (not supplied).
Install the external regulator between the heater and
propane/LP supply.
Installation Items Needed
Beforeinstallingfireplace,makesureyouhavetheitemslistedbelow.
• externalregulator (suppliedbyinstaller,for propane/LPunits only)
• piping (check local codes)
• sealant (resistant to propane/LP gas)
• equipment shutoff valve *
• test gauge connection *
• sediment trap
• tee joint
• pipe wrench
• approved flexible gas line with gas connector (if allowed by lo-
cal codes) (not provided)
* A CSA design-certified equipment shutoff valve with 1/8" NPT
tap is an acceptable alternative to test gauge connection. Purchase
the optional CSA design-certified equipment shutoff valve from
your dealer. See Accessories, pages 30 and 31.
For propane/LP units, the installer must supply an external regula-
tor. The external regulator will reduce incoming gas pressure. You
must reduce incoming gas pressure to between 11 and 14 inches of
water. If you do not reduce incoming gas pressure, heater regulator
damage could occur. Install external regulator with the vent point-
ing down as shown in Figure 14, page 12. Pointing the vent down
protects it from freezing rain or sleet.

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
12
INSTALLATION
Installing Gas Piping to Fireplace Location (Cont.)
Connecting Fireplace To Gas Supply
INSTALLATION
Continued
WARNING:Usepipejoint sealant that isresistant
to liquid petroleum (LP) gas.
We recommend that you install a sediment trap in supply line as
showninFigure15.Locatesedimenttrapwhereitiswithinreachfor
cleaning.Installinpipingsystembetweenfuelsupplyandfireplace.
Locatesedimenttrap wheretrapped matter isnot likely tofreeze. A
sediment trap traps moisture and contaminants. This keeps them
from going into fireplace gas controls. If sediment trap is not
installed or is installed wrong, fireplace may not run properly.
Installation must include an equipment shutoff valve, union, and
plugged 1/8" NPT tap. Locate NPT tap within reach for test gauge
hook up. NPT tap must be upstream from fireplace (see Figure 14).
IMPORTANT: Install equipment shutoff valve in an accessible
location. The equipment shutoff valve is for turning on or shutting
off the gas to the appliance.
Checkyourbuildingcodesforanyspecialrequirementsforlocating
equipment shutoff valve to fireplaces.
ApplypipejointsealantlightlytomaleNPTthreads.Thiswillprevent
excess sealant from going into pipe. Excess sealant in pipe could
result in clogged fireplace valves. Never use sealant on flare threads.
CAUTION: Use only new, black iron or steel pipe.
Internally-tinned copper tubing may be used in cer-
tain areas. Check your local codes. Use pipe of 1/2"
diameter or greater to allow proper gas volume to
fireplace. If pipe is too small, undue loss of volume
will occur.
Figure 14 - External Regulator with Vent Pointing Down
(Propane/LP Gas)
Propane/LP
Supply Tank
External
Regulator
Vent
Pointing
Down
Figure 15 - Gas Connection
* Purchase the optional CSA design-certified equipment shutoff
valve from your dealer. See Accessories, pages 30 and 31.
Natural
From Gas Meter
(5" W.C. to 10.5"
W.C. Pressure)
Propane/LP
From External
Regulator (11" W.C.
to 14 " W.C.
Pressure
CSA Design-Certified
Equipment Shutoff Valve
With 1/8" NPT Tap*
3" Minimum
Installation Items Needed
• 5/16" hex socket wrench or nut-driver
• Phillips screwdriver
• sealant (resistant to propane/LP gas, not provided)
1. If fireplace screen and floor are still installed, see Removing
Fireplace Screen and Floor Assembly, pages 8 and 9.
2. Route gas line (provided by installer) from equipment shutoff
valve to fireplace. Route flexible gas supply line through one
of the access holes.
CONNECTING FIREPLACE TO GAS SUPPLY
3. Attach theflexible gaslineto gassupply (see Figure16). Check
tightness of flexible gas line attached to gas regulator of fire-
place (see Figure 16).
4. Check all gas connections for leaks. See Checking Gas Con-
nections, page 13.
5. Replace fireplace floor assembly. Feed flexible gas line into
fireplace base area while replacing fireplace floor assembly.
Make sure the entire flexible gas line is in fireplace base area.
Note: Be careful of wires and components on underside of
fireplace floor. Reattach fireplace floor assembly with screws
removed in step 3 of Removing Fireplace Screen and Floor
Assembly, pages 8 and 9.
NOTICE: Most building codes do not permit con-
cealed gas connections. A flexible gas line is pro-
vided to allow accessibility from the fireplace (see
Figure16).Theflexiblegassupply line connection to
the equipment shutoff valve should be accessible.
Sediment Trap
Pipe Cap Tee
Nipple Joint

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
13
13
➞
➞
INSTALLATION
Connecting Fireplace To Gas Supply (Cont.)
Checking Gas Connections
INSTALLATION
Continued
Figure 16 - Attaching Gas Lines Together
From Gas Meter (Natural)
From External Regulator (Propane/LP)
Flexible Gas Line from
Fireplace Gas Regulator
To Fireplace
Gas Regulator
Equipment Shutoff Valve
Provided by Installer
Pressure Testing Gas Supply Piping System
Test Pressures In Excess Of 1/2 PSIG (3.5 kPa)
1. Disconnect appliance with its appliance main gas valve (control
valve)andequipmentshutoffvalvefromgas supplypipingsystem.
Pressures in excess of 1/2 psig will damage fireplace gas regulator.
2. Cap off open end of gas pipe where equipment shutoff valve
was connected.
3. Pressurizesupplypipingsystembyeitheropeningpropane/LPsup-
ply tank valve for propane/LP gas or opening main gas valve lo-
cated on or near gas meter for natural gas, or using compressed air.
4. Check all joints of gas supply piping system.Apply noncorrosive
leak detection fluid to all joints. Bubbles forming show a leak.
5. Correct all leaks at once.
6. Reconnect fireplace and equipment shutoff valve to gas sup-
ply. Check reconnected fittings for leaks.
Test Pressures Equal To or Less Than 1/2 PSIG (3.5 kPa)
1. Close equipment shutoff valve (see Figure 17).
2. Pressurize supply piping system by either opening propane/LP
supplytank valve forpropane/LP gasor openingmain gasvalve
located on or near gas meter for natural gas, or using com-
pressed air.
CHECKING GAS CONNECTIONS
WARNING: Test all gas piping and connections,
internal and external to unit, for leaks after installing
or servicing. Correct all leaks at once.
WARNING: Never use an open flame to check for
aleak.Applyanoncorrosiveleakdetectionfluidtoall
joints.Bubblesformingshowaleak.Correctallleaks
at once.
WARNING:Forpropane/LPunits,makesureexter-
nal regulator has been installed between propane/LP
supply and heater. See guidelines under Installing
Gas Piping to Fireplace Location , pages 11 and 12.
Figure 18 - Checking Gas Joints for Natural Gas Fireplace
Figure 19 - Checking Gas Joints for Propane/LP Gas Fireplace
Figure 17 - Equipment Shutoff Valve
3. Check all joints from gas meter for natural gas or propane/LP
supply to equipment shutoff valve for propane/LPgas (see Fig-
ures 18 or 19). Apply noncorrosive leak detection fluid to all
joints. Bubbles forming show a leak.
4. Correct all leaks at once.
Pressure Testing Fireplace Gas Connections
1. Open equipment shutoff valve (see Figure 17).
2. Open main gas valve located on or near gas meter for natural
gas or open propane/LP supply tank valve.
3. Place manual ignition switch in the OFF position.
4. Check all joints from equipment shutoff valve to gas valve
(see Figure 18 or 19).Apply noncorrosive leak detection fluid
to all joints. Bubbles forming show a leak.
5. Correct all leaks at once.
6. Light fireplace (see Operating Fireplace, pages 18 through
20). Check all other internal joints for leaks.
7. Turn off fireplace (see To Turn Off Gas to Appliance, pages
19 or 20).
ON
POSITION
OFF
POSITION
Open
Closed
Equipment
Shutoff
Valve
Equipment
Shutoff Valve
Manual
Gas Valve Gas Meter
Equipment
Shutoff
Valve
Manual Gas Valve
Propane/LP
Supply
Tank

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
14
INSTALLATION
Conventional Fireplace Installation
INSTALLATION
Continued
CONVENTIONAL FIREPLACE INSTALLATION
Conventional installation of fireplace involves installing fireplace
alongwith corner,face,or cabinetmantelwith hearthbaseaccesso-
riesagainstawallinyourhome.Followinstructionsbelowtoinstall
fireplace in this manner.
Note: The instructions below show installation using the cabinet
mantel and hearth base accessories (see Accessories, pages 30 and
31). The hearth base accessory shown is optional for this installa-
tion. You can install fireplace and cabinet mantel directly on the
floor. The corner mantel accessory cannot be installed with the
hearth bases. You must install corner mantel directly on the floor.
1. Assemble cabinet mantel, hearth base, and trim accessories.
Assembly instructions are included with each accessory.
2. When installing blower, install a properly grounded, 120 volt
three-prong electrical outlet at fireplace location if an outlet is
not there. If possible, locate outlet so cabinet mantel will cover
it when installed (see Figure 20).
3. If not already completed, install gas piping to fireplace loca-
tion. This installation includes an approved flexible gas line
(if allowed by local codes) after the equipment shutoff valve.
The flexible gas line must be the last item installed on the gas
piping. See Installing Gas Piping to Fireplace Location, pages
11 and 12.
4. Place hearth base accessory against wall at installation loca-
tion. Cut an access hole in hearth top to run flexible gas line to
fireplace (see Figure 20). Make sure to locate access hole so
cabinet mantel will cover it when installed. Note: You can
secure base to floor using wood screws. Countersink screw
heads and putty over.
5. Route flexible gas line through access hole in hearth base.
6. Center cabinet mantel on hearth base (see Figure 21). Make
sure mantel is flush against wall.
7. Break off nailing flanges (see Figure 22) with hammer or pliers.
8. Place cardboard or other protective material on top of hearth
base. Carefully set fireplace on protective material, with back
of fireplace inside mantel opening.
9. Attach flexible gas line to fireplace gas regulator. See Con-
necting Fireplace to Gas Supply, pages 12 and 13.
Figure 20 - Placing Hearth Base Accessory Against Wall
Electrical
Outlet
Hearth
Base
Rigid Pipe and
Gas Shutoff Valve
Gas Line
Access
Hole
10. Routeelectrical cord(s)throughaccessholesin eitherside offire-
place with bushing. Plug electrical cord(s) into electrical outlet.
11. Carefully insert fireplace into cabinet mantel (see Figure 23).
Be careful not to scratch or damage hearth base, cabinet man-
tel, or any laminate trim on hearth base. Remove protective
material from top of hearth base and from front of fireplace (if
any).
Note: You can secure fireplace to hearth or floor. Open
lower louver. Locate screw holes in bottom of base. Tighten
wood screws through these holes and into hearth or floor.
12. Check all gas connections for leaks. See Checking Gas Con-
nections, page 13.
Figure 21 - Installing Cabinet Mantel
Cabinet
Mantel
Figure 23 - Inserting Fireplace Into Cabinet Mantel
Figure 22 - Location of Nailing Flanges
Nailing Flanges

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
15
15
INSTALLATION
Built-In Fireplace Installation
INSTALLATION
Continued
BUILT-IN FIREPLACE INSTALLATION
Built-in installation of this fireplace involves installing fireplace
into a framed-in enclosure. This makes the front of fireplace flush
withwall.Ifinstallingamantelabovethefireplace,youmustfollow
theclearances showninFigure 27.Follow theinstructionsbelow to
install the fireplace in this manner.
Actual Framing
Height 32 3/8" 33"
Front Width 34 5/16" 35 1/2"
Depth 16 11/16" 17 3/4"
1. Frame in rough opening. Use dimensions shown in Figure 24
for the rough opening. If installing in a corner, use dimensions
shown in Figure 25 for the rough opening. The height is 33"
which is the same as the wall opening above.
2. Install and properly ground GA3555, three-prong 120 volt elec-
tricaloutlet, infireplace.Follow instructionsincluded inkit (see
Accessories, pages 30 and 31).
3. If not already completed, install gas piping to fireplace loca-
tion. This installation includes an approved flexible gas line
(if allowed by local codes) after the equipment shutoff valve.
The flexible gas line must be the last item installed on the gas
piping. See Installing Gas Piping to Fireplace Location, pages
11 and 12.
4. Carefully set fireplace in front of rough opening with back of
fireplace inside wall opening.
5. Attach flexible gas line to gas supply. See Connecting Fire-
place to Gas Supply, pages 12 and 13.
6. Plug electrical cord(s) into electrical outlet installed in step 2.
7. Carefully insert fireplace into rough opening.
8. Attach fireplace to wall studs using nails or wood screws
through holes in nailing flange (see Figure 26).
9. Check all gas connections for leaks. See Checking Gas Con-
nections, pages 13.
10. Install brass trim. See Assembling and Attaching Optional
Brass Trim, page 16.
35
1
/ 2 "
17
3
/ 4 "
33"
39 3/8"27 7/8"
55 5/8"
35 1/2"
Figure 24 - Rough Opening for
Installing in Wall Figure 25 - Rough Opening
for Installing in Corner
Figure 26 - Attaching Fireplace to Wall Studs
Nailing
Flanges
Nails or
Wood
Screws
Mantel Clearances for Built-In Installation
Ifplacing mantelabovebuilt-in fireplace,you mustmeet minimum
clearance between mantel shelf and top of fireplace opening.
NOTICE:Surfacetemperaturesofadjacent walls and
mantels become hot during operation. Walls and
mantels above the firebox may become hot to the
touch. If installed properly, these temperatures meet
the requirement of the national product standard.
Followallminimumclearancesshowninthismanual.
NOTICE: If your installation does not meet the mini-
mum clearances shown, you must do one of the
following:
•raise the mantel shelf to an acceptable height
•remove the mantel shelf
Figure 27 - Minimum Mantel Clearances for Built-In Installation
Supplied Firebox
Hood Must Be
Used at All Times
Wire-mesh
Screen
Firebox
Noncombustible
Material May
Project Off this
Surface above
the Firebox Hood
Mantel Shelf
13" 16" 19" 21"
2 1/2"
6"
8"
10"
Note: All vertical
measurements are
from top of fireplace
hood opening to bottom
of mantel shelf.
These minimum
clearances replace any
other recommended
clearances supplied with
your ANSI Z21.11.2
approved gas logs.
Wall board or facing
material (above
firebox) may be of
combustible material,
including decorative
mantel ornaments or
other similar projec-
tions off of the facing
material.
Framing
Material

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
16
INSTALLATION
Assembling And Attaching Optional Brass Trim
Installing Hood
Installing Logs
INSTALLATION
Continued
ASSEMBLING AND ATTACHING OPTIONAL
BRASS TRIM
(Included with Mantel Accessory)
Note: Theinstructions belowshowassembling andattaching brass
trim to fireplace.
1. Remove packaging from three pieces of brass trim.
2. Locate four brass screws, two adjusting plates with set screws,
and two shims in the hardware packet.
3. Align shim under adjusting plate as shown in Figure 28.
4. Slide one end of adjusting plate/shim in slot on mitered edge
of top brass trim (see Figure 28).
5. Slide other end of adjusting plate/shim in slot on mitered edge
of side brass trim (see Figure 28).
6. While firmly holding edges of brass trim together, tighten both
set screws on the adjusting plate with slotted screwdriver.
7. Repeat steps 1 through 6 for other side.
8. Tighten trim hanging screws (#10 x 6.25 shoulder) into holes
in cabinets. Place the assembled trim onto fireplace cabinet.
Align hanging notches on trim with hanging screws on side of
fireplace (see Figure 29). Push trim firmly into place, sliding
hanging notches over hanging screws.
Figure 29 - Attaching Brass Trim to Fireplace
Trim
Hanging
Screws
Assembled
Brass Trim
Hanging
Notches
on Trim
Figure 28 - Assembling Brass Trim
Slot
Mitered Edge
Slot Shim
Set Screws
Adjusting
Plate
Side Brass
Trim
Figure 30 - Installing Hood to Firebox
INSTALLING HOOD
Install hood to top of firebox as shown in Figure 30. Use 3 Phillips
screws provided.
Top Brass
Trim
INSTALLING LOGS
WARNING: Failure to position the parts in accor-
dance with these diagrams or failure to use only parts
specifically approved with this heater may result in
property damage or personal injury.
CAUTION: After installation and periodically there-
after, check to ensure that no yellow flame comes in
contact with any log. With the heater set to HI, check to
see if flames contact any log. If so, reposition logs
according to the log installation instructions in this
manual.Yellowflamescontactinglogswillcreatesoot.
It is very important to install the logs exactly as instructed. Do not
modify logs. Only use logs supplied with heater. Before installing
logs, make sure log alignment screws are in place and straight.
1. Place log #1 (ember bed) onto base over log alignment screws
to the left of front burner and behind middle burner. Log #1
will sit on top of front and middle burners (see Figure 31).
Figure 31 - Installing Log #1 (Ember Bed)

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
17
17
INSTALLATION
Installing Logs (Cont.)
Installing Battery Into Remote
INSTALLATION
Continued
INSTALLING BATTERY INTO REMOTE
1. Locate slot at bottom of remote control (see Figure 35). Firmly
insert tool such as a small screwdriver, butter knife, or dime
into the slot and lift up to remove cover.
2. Insert supplied battery into remote control. Positive and nega-
tive are marked inside remote control casing. Note: Remote
will not function if battery is not installed correctly.
3. Slide tab on cover into remote housing and snap cover back
into place.
IMPORTANT: Use only A23 12 volt battery in remote. DO NOT
use AAA battery.
Positive
Figure 35 - Installing Battery
Negative
Tab
Cover
Remote
Control
Slot
A23 12
Volt
Battery
Figure 32 - Installing Log #2 (Right) and Log #3 (Left)
Figure 33 - Installing Log #4
Figure 34 - Installing Log #5 and Log #6
Log #6
Log #5
Log #2
Log #4
Log #3
Log #1
Log #2
Log #3
Log #1
Log #4
Log #2
Log #3
Log #1
2. Place log #2 to right of log #1 and onto log alignment screw
as shown in Figure 32. Log #2 will wrap around right end of
rear burner.
3. Place log #3 on left side of base and onto alignment screw to
right of rear burner (see Figure 32). Log #3 will wrap around
left end of rear burner.
4. Place log #4 onto two alignment screws to rear of base (see
Figure 33).
5. Locate hole on bottom of log #5 and place over pin on log #2.
Log #5 will rest on back of log #1 (ember bed). See Figure 34.
6. Place log #6 onto two pins on log #1 (ember bed) and rest
back of log #6 on back log #4 (see Figure 34).

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
18
INSTALLATION
Installing Screen
OPERATING FIREPLACE
For Your Safety Read Before Lighting
Normal Lighting Instructions
INSTALLATION
Continued
Figure 36 - Installing Fireplace Screen
INSTALLING SCREEN
Install fireplace screen by slipping notches of fireplace screen over
screws on front of fireplace (see Figure 36).
Notches
Screws for
Mounting Screen
OPERATING FIREPLACE
FOR YOUR SAFETY
READ BEFORE LIGHTING
WARNING: Ifyoudonotfollowtheseinstructions
exactly, a fire or explosion may result causing prop-
erty damage, personal injury or loss of life.
A. This appliance has a pilot which lights automatically when
using the supplied wall switch or remote control. If you
have a power outage, the pilot may be lighted by hand with
push-button piezo ignitor. When lighting the pilot, the fol-
lowing warnings must be followed.
B. BEFORE LIGHTING smell all around the appliance area
for gas. Be sure to smell next to the floor because some gas
is heavier than air and will settle on the floor.
WHATTO DO IFYOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone in
your building.
• Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
• If you cannot reach your gas supplier, call the fire de-
partment.
C. Electric Power Outage Only: Use only your hand to turn
the manual override handle on the gas control knob. Never
use tools. If the knob will not turn by hand, don’t try to
repair it, call a qualified service technician or gas supplier.
Force or attempted repair may result in a fire or explosion.
D. Do not use this appliance if any part has been under water.
Immediately call a qualified service technician to inspect
the appliance and to replace any part of the control system
and any gas control which has been under water.
NORMAL LIGHTING
INSTRUCTIONS
WARNING: You must operate this heater with the
fireplacescreeninplace.Makesurefireplacescreenis
in place before running heater.
NOTICE:Duringinitialoperationofnewheater,burning
logswillgiveoffapaper-burningsmell.Opendamperor
window to vent smell. This will only last a few hours.
1. STOP! Read the safety information, column 1.
2. Make sure equipment shutoff valve is fully open.
3. Wait five (5) minutes to clear out any gas. Smell for gas
around heater and near floor. If you smell gas, STOP! Fol-
low “B” in the safety information on warnings plate. If you
don’t smell gas, go to the next step.
A. Using Supplied Wall Switch Assembly
1. Set manual ignition bypass switch on the control panel to
the OFF position (automatic ignition position).
2. Press ON/OFF button. Hold for 6 seconds. Gas valve will
open and electronic ignition will begin sparking to light
pilot.LEDwill light. Note: You mayberunning this heater
for the first time after connecting to gas supply or at the
startofyourheatingseason. If so,theON/OFFbuttonmay
need to be pressed again. This will allow air to bleed from
gas system. If several attempts to light pilot fail, contact a
qualified service person or gas supplier for repairs. Until
repairs are made, light and operate manually (see Manual
Lighting Instructions for Electric Power Outage, pages 19
and 20).
3. When pilot flame is lit, the thermocouple is heated by the
flame. When thermocouple becomes hot (5 to 15 seconds),
main burner will automatically light on high flame.

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
19
19
MANUAL LIGHTING INSTRUCTIONS
FOR ELECTRICAL POWER OUTAGE
WARNING: You must operate this heater with the
fireplace screen in place. Make sure fireplace screen
is in place before running heater.
NOTICE:Duringinitialoperationofnewheater,burning
logswillgiveoffapaper-burningsmell.Opendamperor
window to vent smell. This will only last a few hours.
Because this fireplace has an electronic ignition system, in the
event there is a loss of power, it will be necessary to manually
light the pilot with the piezo ignitor. After the pilot is lit, the
main burner will light automatically.
1. Follow steps 1 through 3 under Normal Lighting Instructions,
pages 18 and 19.
2. Set manual ignition bypass switch on control panel to ON
position (manual ignition position). See Figure 39.
3. The pilot is attached to the rear of the front burner. You
will be able to see the pilot and spark electrode without
removing the screen or logs.
Figure 39 - Control Locations
Manual Ignition
Bypass Switch
(Down is ON)
ON/OFF
Button
HI/LO
Button
Piezo
Ignitor
Wall
Switch
LED LED
OPERATING FIREPLACE
Normal Lighting Instructions
To Turn Off Gas To Appliance
Manual Lighting Instructions for Electrical Power Outage
OPERATING FIREPLACE
Continued
B. Using Hand-Held Wireless Remote Control
1. Set manual ignition bypass switch on control panel to OFF
position (automatic ignition position).
2. Wait five (5) minutes to clear out any gas. Smell for gas
around heater and near floor. If you smell gas, STOP! Fol-
low “B” in the safety information on warnings plate. If you
don’t smell gas, go to the next step.
3. Point remote control toward the lower front of fireplace
and push both buttons at the same time. Hold for 6 sec-
onds. The gas valve will open and electronic ignition will
begin sparking to light the pilot. Note: You will be able to
hear a clicking sound during this process. LED on wall
switch will light.
Note: You may be running this heater for the first time
after connecting to gas supply or at the start of your heat-
ing season. If so, the ON button may need to be pressed
again. This will allow air to bleed from gas system. If sev-
eral attempts to light pilot fail, contact a qualified service
person or gas supplier for repairs. Until repairs are made,
light and operate manually (see Manual Lighting Instruc-
tions for Electrical Power Outage).
4. When pilot flame is lit, the thermocouple is heated by the
flame. When thermocouple becomes hot (5 to 15 seconds),
main burner will automatically light on high flame.
Automatic
Ignitor
Electrode Pilot
Burner
Figure 38 - Pilot (Propane/LP Gas Shown)
Manual
Ignitor
Electrode
TO TURN OFF GAS
TO APPLIANCE
Shutting Off Heater - Wall Switch
Push ON/OFF button on wall switch once.
Shutting Off Heater - Wireless Remote Control
Point remote control toward lower front of fireplace and push
both buttons at the same time.
4. To lower flame, push HI/LO button on wall switch once.
Note: This fireplace does not have a pilot-only mode.
Manual Ignition Bypass
Switch (Up is for
Remote Control)
ON/OFF Button
HI/LO
Button Wall Switch
Assembly
CAUTION: Do not try to adjust heating levels by
using the equipment shutoff valve.
Figure 37 - Control Locations
LED
5. To lower flame, point remote control toward lower front of
fireplace and push HI/LO button once.
Note: This fireplace does not have a pilot-only mode.
Thermocouple
Magnetic Manual
Override Handle
Gas
Valve

110112-01A
For more information, visit www.desatech.com
For more information, visit www.desatech.com
20
OPERATING FIREPLACE
Manual Lighting Instructions for Electrical Power Outage (Cont.)
To Turn Off Gas To Appliance
Optional Blower Operation
INSPECTING BURNERS
Pilot Flame Pattern
OPERATING FIREPLACE
Continued
Locate the blower switch by opening lower louver on fireplace.
Blower switch is located at lower left inside louver door.
Note: It is safe to operate fireplace with blower turned off.
However,theblowerhelpsdistributeheatedairfromthefireplace.
Follow installation instructions included with the blower
accessory.
OPTIONAL BLOWER
OPERATION
TO TURN OFF GAS
TO APPLIANCE
Shutting Off Heater When Manually Lit
Set manual ignition bypass switch on control panel to OFF
(automaticignitionposition).Thiswillcausethecontrolstoshut
down the fireplace.
4. Placethemagneticmanualoverride handle, providedwith
this unit, on the end of the gas valve stem (see Figure 39,
page 19).
5. Turn the override handle fully counterclockwise to
thePILOT position.The handle willnotstopbutwill begin
to slip when you have fully turned to the PILOT position.
6. Whileholdingthe valvehandleinthe PILOTposition,press
and release piezo ignitor button (see Figure 39, page 19).
This will light the pilot. If needed, keep pressing ignitor
button until pilot lights.
7. When pilot flame is lit, hold manual override handle until
thermocouple heats (approximately 5 to 15 seconds). If pi-
lot goes out, repeat process. If several attempts to light the
pilot fail, contact a qualified service person or gas supplier
for repairs.
8. Whenthermocoupleis heated,releaseoverridehandle.The
main burner will immediately light on high flame. Adjust
flame size by turning override handle.
INSPECTING BURNERS
Check pilot flame pattern and burner flame patterns often.
PILOT FLAME PATTERN
Figure41 onpage 21showsacorrectpilot flamepattern. Figure42,
page 21, shows an incorrect pilot flame pattern. The incorrect pilot
flameisnot touchingthethermocouple.Thiswillcausethe thermo-
couple to cool. When the thermocouple cools, the heater will shut
down.
If pilot flame pattern is incorrect, as shown in Figure 42, page 21
• turn heater off (see To Turn Off Gas to Appliance, page 19 or col-
umn 1)
• see Troubleshooting, pages 23 through 25
Note: The pilot flame on natural gas units will have a slight curve,
but the flame should be blue and have no yellow or orange color.
Figure 40 - AUTO/OFF/ON Switch
AUTO/OFF/ON
Switch
OPERATING
FAN
Thisblowerhasthreesettings:ON,OFF,andAUTO.IntheON
position, the blower will operate constantly. In the OFF posi-
tion, the blower will not operate. In the AUTO position, the
blower will start when the thermostat senses a sufficient in-
crease in firebox temperature.
Note: Your fireplace and thermostat blower will not turn on
and off at the same time. The fireplace may run for several
minutesbefore theblowerturnson.After theheater modulates
tothepilotposition,theblowerwillcontinuetorun.Theblower
will shut off after the firebox temperature decreases.
Note: It is safe to operate fireplace with blower turned off.
However,theblowerhelpsdistributeheatedairfromthefireplace.
Piezo Ignitor
Fan Switch
