Detection Systems DS7080iP-32 User manual

For additional information on system commands, see the DS7080iP-32 User’s Guide P/N 39425
Reference Guide
for the
DS7080iP-32 Two Partition
Control/Communicator
Turning Off (Disarming) your System
[PIN] + [Off]
Commands for other System Features
Chime Mode [PIN] + [#] [7]
Zone Test [PIN] + [#] [8] [1]
Event History Readback [PIN] + [#] [8] [9]
Battery Test [PIN] + [System Reset]
Communicator Test [PIN] + [#] [8] [2]
Fire Reset [PIN] + [System Reset]
Fire Trouble [PIN] + [Off] to silence, [PIN] + [System Reset] to clear
Remote Program Dial-out [PIN] + [#] [8] [3]
Remote Program Answer [PIN] + [#] [8] [6]
Local Battery/Sounder Test [PIN] + [#] [8] [5]
Error Display [PIN] + [#] [8] [7]
Error Display Reset [PIN] + [System Reset]
Clear Zone Bypass [PIN] + [Bypass] [*] to clear
Access Control
[Access Control PIN] + [Off]
Keypad Quick Reference Guide
Turning On (Arming) your System
[PIN] + [On]
[PIN] + [No Entry] [Perimeter Only]
[PIN] + [Perimeter Only]
[PIN] + [No Entry] [On]
[PIN] + [#] [4]
[PIN] + [Arming Sequence] + [Bypass]
[PIN] + [Bypass] + [2-digit Zone number]
[PIN] + [#] [9] [9]
[PIN] + [OFF]
Normal Arming
Perimeter Arming, no entry delay
Perimeter Arming, with entry delay
Maximum Security Arming
Custom Arming
Force Arming
Zone Bypass
Set Delayed Arming
Delay Auto Arm by 15 Minutes
Change Partitions [PIN] + [#] [#]
Armed
Status
Power
Fire
123
456
789
0
*#
On
No
Entry
System
Reset
Bypass
Only
Perimeter
Off
Armed
Status
Power
Fire
123
456
789
0
*#
On
No
Entry
System
Reset
Bypass
Only
Perimeter
Off
Perimeter
Supervisory
Bell Silenced
Trouble
12345678
Ready To Arm
DS7447 DS7445
Downloaded from: http://www.guardianalarms.net

Page 2 P/N 39818D Copyright © 2001 Detection Systems, Inc. DS7080iP-32 Reference Guide
Table of Contents
1.0 Specifications ............................................................ 4
1.1 EnclosureHousing ............................................................. 4
1.2 Temperature ....................................................................... 4
1.3 Power ................................................................................. 4
1.3.1 Accessory Power ......................................................4
1.4 Outputs .............................................................................. 4
1.5 Zones ................................................................................. 4
1.6 Keypads ............................................................................. 4
1.6.1 DS7443 Keypad ........................................................4
1.6.2 DS7445/DS7447 Keypads ........................................4
1.7 Communicator .................................................................... 4
1.8 Users ................................................................................. 4
1.9 LightningProtection............................................................. 4
1.10 Burglar/FireZoneInputs ..................................................... 4
1.11 FireSignalInitiatingCircuit(2-wiremode)............................ 4
1.12 StandbyCurrentLoad......................................................... 5
2.0 Enclosure Installation ............................................... 5
2.1 Install theEnclosure............................................................ 5
2.2 InstalltheControl/Communicator ........................................ 5
3.0 Control Terminal Wiring ............................................ 6
4.0 SystemWorksheet ..................................................... 7
5.0 SystemOverview....................................................... 9
6.0 Glossary ................................................................... 10
6.1 ZoneProgramming ........................................................... 10
6.2 OutputProgramming......................................................... 11
6.3 GeneralControlProgramming........................................... 11
6.4 KeypadAssignment Programming .................................... 12
6.5 EX8Expansion Module Programming ............................... 12
6.6 EmergencyKeyProgramming .......................................... 12
6.7 CustomArming Programming ........................................... 12
6.8 ReportControlProgramming ............................................ 12
6.9 Day MonitorReportControl .............................................. 12
6.10 PhoneNumberGeneralControlProgramming .................. 13
6.11 PhoneAnsweringProgramming ........................................ 13
6.12 SystemTimers.................................................................. 13
6.13 ForceArmingProgramming .............................................. 13
6.14 ReportProgramming......................................................... 13
6.15 EventHistory ReadbackControl....................................... 14
6.16 FCCComplianceNotice ................................................... 15
6.17 FCCPhone ConnectionNoticeToUsers .......................... 15
6.18 CanadianDept.ofCommunications................................... 15
6.19 ForInstallationsinNewZealand ....................................... 15
7.0 Operating Guide ...................................................... 16
7.1 Fire Safety ........................................................................ 16
7.1.1 If Installed in Family Residences ............................16
7.1.2 Having and Practicing an Escape Plan ..................16
7.1.3 Installation Considerations ......................................16
7.2 Setting theDate ................................................................ 17
7.3 SettingtheTime ................................................................ 17
7.4 Personal Identification Numbers ........................................ 18
7.4.1 General Information.................................................18
7.4.3 PIN Authority Levels................................................18
7.4.2 Removing a PIN ......................................................18
7.5 Automatic Arming ....................................................19
7.6 Delayed Automatic Arming......................................19
7.7 Error Displays .................................................................. 20
7.8 Remote Program Dial-out andAnswer .............................. 20
7.9 Zone Test.......................................................................... 21
7.10 Battery/SounderTest ...................................................... 21
7.11 CommunicatorTest ........................................................... 22
7.12 Event History Readback ................................................... 22
8.0 How to Program the DS7080iP-32 .......................... 23
9.0 Programming the DS7080iP-32 .............................. 23
9.1 Address 001 -EX8ZoneExpansionModuleControl ......... 24
9.2 Address 002 - General Control ......................................... 24
9.3 Address 003 - User Controls ............................................ 25
9.4 Address 004 - Programmer and Master Codes ................. 25
9.5 Address 005 - Cross-Zoning ............................................ 25
9.6 Address 006 -Trip window ................................................ 25
9.7 Address007 - KeypadAssignment ................................... 26
9.8 Address 008 - LanguageandArmingControls .................. 26
9.9 Address 009 -OutputProgramming.................................. 26
9.10 Address 010 -Time Delays............................................... 27
9.11 Address 011 - Report Controls ......................................... 27
9.12 Address012 -Phone Controls .......................................... 28
9.13 Address 013 - Partition 1 Account Codes.......................... 28
9.14 Address 014 - Partition 2 Account Codes.......................... 28
9.15 Address 015 - Phone # 1 Format ...................................... 29
9.16 Address 016 - Phone # 2 Format ...................................... 29
9.17 Address 017 - 022 - Phone Numbers................................ 30
9.18 Address023- Dial Attempts ............................................. 30
9.19 Address 024 - AutoTest / Remote Programmer Call-Out Day
30
9.20 Address025 - AutoTest / RemoteProgrammerCall-OutTime
31
9.21 Address 026 - AC Report Delay........................................ 31
9.22 Address 027 - History Controls......................................... 31
9.23 Address 028 - Special Keys.............................................. 31
9.24 Addess 029 - Keypad Reports .......................................... 32
9.25 Address 030, 031, 032, 033 - ZoneType........................... 32
9.26 Address034, 035, 036,037 - ZoneAction ........................ 34
9.27 Address 038, 039, 040, 041 - OutputType ........................ 34
9.28 Address 042, 043, 044, 045 - Zone Bypass ...................... 35
9.29 Address046, 047, 048,049 -CustomArming ................... 35
9.30 Address050,051, 052, 053 -ZonePartitionAssignment .. 35
9.31 Addresses 054, 055, 056, 057 - Zone Alarm Reports ........ 36
9.32 Addresses 058, 059, 060, 061 - Zone Restoral Reports.... 36
9.33 Addresses 062, 063, 064, 065 - ZoneTrouble Reports...... 37
9.34 Addresses 066, 067, 068, 069 -Trouble
Restoral Reports.............................................................. 37
9.35 Addresses 070, 071, 072, 073 - Zone Bypass Reports .. 37
9.36 Addresses 074, 075, 076, 077 - Bypass
Restoral Reports.............................................................. 37
9.37 Address 078 - Open/Close Reports ................................ 38
9.38 Address 079 - AC/Battery Reports .................................. 38
9.39 Address 080 - Remote/Local Programming Reports ...... 38
9.40 Address 081 - Exit Error, Recent Closing, System Trouble,
System Trouble Restoral Reports ..................................... 38
9.41 Address 082 - Test Reports ............................................. 38
9.42 Address 083 - 116 - Alpha Labels ................................... 39
9.43 Address 117 - Point Expansion Module Missing Report . 39
9.44 Address 118 - Point Expansion Module Missing Restoral
Report ............................................................................... 39
9.45 Address 119 - Point Expansion Module Tamper Report.. 40
9.46 Address 120 - Point Expansion Module Tamper Restoral
Report ............................................................................... 40

DS7080iP-32 Reference Guide Copyright © 2001 Detection Systems, Inc. P/N 39818D Page 3
9.47 Address121-Point Expansion Module FaultReport ......... 40
9.48 Address122-PointExpansion Module FaultRestoralReport
40
9.49 Address 123 - Octal Relay Control and Reports ............... 40
9.50 Address124-DefaultProgramming ................................. 41
10.0 Installation Guide for UL Listed Systems ............. 42
10.1 DS7080iP-32ULListings: ................................................. 42
10.2 InstallationConsiderations ................................................ 42
10.2.1 Special Requirements for Partitioned Systems......43
10.3 ProgrammingtheDS7080iP-32 ......................................... 43
10.3.1 Household Fire Alarm..............................................43
10.3.2 Grade A Household Burglary Alarm .......................43
10.3.3 Local Burglary Alarm ...............................................43
10.3.4 Police Station Connection........................................44
10.3.5 Central Station Burglary Alarm................................45
10.4 UsingtheAdemcoAB-12Bell/Housing.............................. 46
11.0 Report Programming Suggested Values ............... 47
11.1 Personal Dialing and PagerFormat ................................... 47
11.2 PagerFormat ................................................................... 47
11.3 SuggestedValues forBFSK and other Pulse Formats ....... 49
12.0 Report Programming Values Sent ......................... 50
12.1 SIAFormat ....................................................................... 50
12.2 ContactIDFormatValues Sent ......................................... 51
12.3 HighSpeed4/9Format ..................................................... 52
13.0 ProgrammingAddresses........................................ 54
14.0 Troubleshooting Guide ........................................... 55
Index ................................................................................. 58

Page 4 P/N 39818D Copyright © 2001 Detection Systems, Inc. DS7080iP-32 Reference Guide
1.0 Specifications
1.1 Enclosure Housing
The standard enclosure is manufactured from 20 Ga., cold-rolled
steel, and measures 12.5 in. Wide, by 14.5 in. High, by 3 in. Deep
(31.8 cm W x 36.8 cm H x 7.6 cm D). A keyed lock is included, and
thisenclosure hasa provisionforanoptional tamperswitch(required
for Commercial Burglary applications) for monitoring the door.
1.2 Temperature
• StorageandOperatingTemperature: +32°to +120°F (0°to +49°C)
1.3 Power
• Input power: 16.5 VAC, 40 VA, 60 Hz.
• Auxiliary regulated power: 11.8 -12.5VDC, 1.0 A.
(200mA
for UL Listed Systems. 1.0 A
not investigated by UL.)
• Optional Standby battery (P334): 12 V, 7.0 AH
• Control panel current draw: 150 mA
1.3.1 Accessory Power
• DS7443 keypad current draw: 45 mA, Standby & Alarm
• DS7445 keypad current draw: 75 mA, Standby & Alarm
• DS7447 keypad current draw: 100 mA, Standby & Alarm
• DS7488 Octal Relay 10 mA for the module plus 40
mA for each energized relay
• EX8 Expansion Module: 35 mA, Standby & Alarm
The total current for all auxiliary devices, including keypads
and smoke detectors = 1.2 A standby and alarm.
1.4 Outputs
• Alarm Output: Normally Closed, 1.0 Amp contact connected
to auxiliary power. Can be programmed for
steady or pulsed output.
• Programmable Output 1*: Solid state current sink (1 A max.).
(200mA for UL Listed Systems.1 A
not investigated by UL.) Can be
used for alarm, arming state, or ac-
cess control.** This output is gen-
erally programmable.
• Programmable Output 2*: Solid state voltage source (500 mA
max.). (200mA for UL Listed
Systems. 500mA not investigated
by UL.) This is the smoke power
reset for Zone 1 when it is used as
afire zone for 2-wire smoke
detectors. Can be used for alarm,
armingstate, or access control.**
* = Current draw should be subtracted from either maximum
auxiliary or maximum alarm current draw.
** = Not investigated to the requirements of UL294.
1.5 Zones
• 1 or 2 Partitions.Zones may be assigned to one or both partitions.
Zones assigned to both partitions become common zones.
• 8zones,plus 1troublezone onthe maincontrol board.Thetrouble
zone cannot be assigned to a partition.
• 24 Expansion zones using EX8 Zone Expansion Module. Each
EX8 adds 8 additional zones. Up to three EX8 modules can be
added to the system.
• On Board Zone Response Time: 300 milliseconds.
1.6 Keypads
1.6.1 DS7443 Keypad
• Total number of keypads: 4 Keypads
• Maximum wire length each run: 400 feet (122m)
• Maximum wire length total: 1600 feet (488m) in system
• Wire type: 4 conductor, unshielded, #22 AWG (0.8mm) or 18
AWG (1.0mm) "Telephone quad".
Onlyone DS7443 is allowedpercable.EachDS7443must
have a “home run” back to the DS7080iP-32.Do not “daisy
chain” or place two DS7443 keypads on any cable run.
1.6.2 DS7445/DS7447 Keypads
• Total number of keypads: 4 Keypads
• Maximum wire length each run: 1000 feet (305m)
• Maximum wire length total: 4000 feet (1220m) in system
• Wire type: 4 conductor, unshielded, #22 AWG (0.8mm) or 18
AWG (1.0mm) "Telephone quad".
If using #22 AWG (0.8mm) wiring, there can be no more
than twokeypads allowed on any 1000 foot (305m) run.
Three keypads are allowed on any 1000 foot (305m) run if
#18 AWG (1.0mm) wire is used. Keypad wiring can be
“daisy-chained” or “home-run,” but the cables can NOT be
shared with other devices (e.g. telephone or siren wiring).
The DS7488 and EX-8 can only be “home-run.”
1.7 Communicator
Will report to two phone numbers with full single, double and back-
up reporting. Communicates in SIA, 3/1, 3/1 Ext., 4/1, 4/2, BFSK,
Contact ID, High Speed 4/9, and Pager formats.
The ringer equivalence is 0.1B
1.8 Users
The system allows up to 24 individual users.Each user will have his
own PIN number (the 4- or 6-digit code entered at the keypads) and
his own authority level (to determine which functions he may
perform).
1.9 Lightning Protection
MOVs and spark gaps provide protection from lightning surges and
static discharges.
1.10 Burglar/Fire Zone Inputs
• Number of circuits 8 Circuits
• End-of-line resistor 2.21k ohms
1.11 Fire Signal Initiating Circuit (2-wire mode)
The Fire circuit (zone 1) will work with 2- or 4-wire detectors. It has
an optional alarm verification.
• Number of 2-wire circuits: 1 circuit, compatibility identifier A
• Type of circuit: Class B, latching
• End-of-Line resistor: 2.21k ohms
• Supervisory current: 5 mA
• Maximum current for alarm: 13 mA
• Maximum short circuit current: 25 mA
• Maximum line resistance: 65 ohms
• Circuit voltage range: 8.5 to 14.0 VDC
• Maximum detectors per zone: 20 detectors (2-wire)
• Total detector standby current: 2.5 mA

DS7080iP-32 Reference Guide Copyright © 2001 Detection Systems, Inc. P/N 39818D Page 5
2.2 Install the Control/Communicator
The control is static sensitive. Make sure you touch
earth ground before handling the control. This will
discharge any static electricity in your body. Example:
Run the ground wire to the enclosure before handling
the control. Then keep holding the ground wire while
installing the control.
• Insert the three support posts into the control retainer holes as
shown in the diagram.
• Slide the top of the control into the retainer tabs (the slots under
the top frame).
• Once in the retainer tabs, the control will rest on the three support
posts.
• Secure the bottom of the enclosure by screwing the bottom three
holesthrough thesupportposts andthrough tothe controlretainer
holes.
Once the control is installed, be sure to connect its
ground wire to the top hinge of the enclosure (the
unpainted tab).
1.12 Standby Current Load
Rechargeable
Battery Size
4 AH
7 AH
8 AH
14 AH
15 AH
17.2 AH
Derated
2.825 AH
5.225 AH
6.025 AH
10.825 AH
11.625 AH
13.385 AH
Max. Standby
for 4 hours
590 mA
1.0 A
1.0 A
1.0 A
1.0 A
1.0 A
Max. Standby
for 8 hours
230 mA
530 mA
640 mA
1.0 A
1.0 A
1.0 A
Max. Standby
for 24 hours
X
100 mA
130 mA
330 mA
360 mA
440 mA
Max. Standby
for 48 hours
X
X
X
X
120 mA
160 mA
Max. Standby
for 60 hours
X
X
X
X
X
100 mA
Battery AH - (20% Storage + 0.375 AH’s Alarm)
The following table is the derated battery divided by hours minus the control standby (150 mA):
2.0 Enclosure Installation
The DS7080iP-32 control/communicator and the enclosure are
shipped together. The control, however, still needs to be installed
into the enclosure. Hardware for mounting the enclosure to a wall,
and the control to the enclosure is located in its own hardware pack.
2.1 Install the Enclosure
• Use the enclosure as a template and mark the top mounting holes
on the mounting surface.
• Pre-start the mounting screws for these two holes. Slide the
enclosure onto these mounting screws so that the screws move
up into the thinner section of the holes.Tighten the screws.
• Screwinthe remainingtwoscrews ineither setofbottom mounting
holes.
• Knock out the desired wire entrances on the enclosure.
• Use knock out bushings if conduit is not used.

Page 6 P/N 39818D Copyright © 2001 Detection Systems, Inc. DS7080iP-32 Reference Guide
3.0 Control Terminal Wiring
ZONES 1-8: Zones 1-8 are for connection of NO or
NC alarm contacts. These zones require a 2.21K ohm
resistor (P/N 25899) at the end of the loop. Power is
momentarily removed after a [PIN] [System Reset]
during a fire verification. Only zone 1 may be used for
compatible 2-wire smoke detectors (up to 20). Zone
programming is done in address 034 for zones 1-8.
18 19 20 21 22 23 24 25 26
KEYPAD*:
Up to 4 keypads may be
used.
910 11 12
RBGY
Keypad(s)*
DS7488
Octal
Relay
13 14 15 16 17
TRBL PO2 1 2 3 4 5 6 7 8
TRBL:Trouble Input. For
the connection of any
accessory that provides a dry
contact trouble output.
PO2: PO2 supplies 12-12.5 v
and up to 500 mA when
activated. PO2 function
programmed in address 009.
*= Maximum Wire length each.
DS7443: 400 ft. (122m) maximum wire length.
Total in system: 1600 ft. (488M). Each keypad must be
a “home run”. Do not “daisy chain” keypads.
Trouble input is
non-supervised.
Do not use an
EOL resistor.
DS7488 Octal Relay
and EX8 Expansion
Modules. 1000 ft.
(305m) maximum
wire length. Must be
"Home Run". Do not
"Daisy Chain" with
keypads. The
DS7488 and EX-8
can only be “Home
Run.”
Shared cable is not
allowed for keypad
expansion modules,
telephone, or siren
wiring.
Do not use shielded
or twisted pair cable.
IMPORTANT
EX8
Expansion
Modules
DS7445/DS7447: 1000ft. (305m) maximum wire length.
Total in system: 4000ft. (1220m). Keypads may be
“home run” or “daisy chained”. Maximum of 2 keypads
per run for #22 AWG (.8mm) or 3 keypads for 18 AWG (1.0mm).
Option Bus
Quick Connect
TYPICAL BURGLAR AND FIRE WIRING
Typical 2-wire
smoke detector
wiring
(for a list of
compatible 2-wire
smoke detectors,
see Technical Service
Note P/N 41150)
EOL
Resistor
Smoke
Detector
Zone 1 Only
14 15
Typical 4-wire smoke
detector wiring.
For example:
Detection System's DS250
in an MB4W base.
EOL
Resistor
EOLRelay
Smoke
Detector
EOL
Resistor
EOLRelay
Smoke
Detector
Zone 1 Only
Zones 2-8 Only
14
14 15 16
Danger of explosion if battery
is incorrectly replaced.
Replace only with the same or
equivalent type recommended
by the manufacturer. Dispose of
used batteries according to the
manufacturer's instructions.
CAUTION
NO
Typical burglar
alarm loop wiring
Ground
Zone
Input
NC
CAUTION: Incorrect connections may
result in damageto the unit.
This System is Power Limited except for the
Battery terminals. All wiring entering this
enclosure must be Power Limited.
Before servicing this
equipment, remove all
power including the
transformer and battery.
Also remove the phone
line connection.
WARNING
CAUTION:
An appropriate two pole
disconnect device must be
installed by qualified service
personnel, as part of the
building installation.
AC INPUT: Use a listed Class 2,16.5 VAC
40 VA transformer Model D1640
requires 60 Hz unswitched
dedicated outlet - do not share.
ALARM OUTPUT: Provides 12 VDC, special
application, up to 1 Afor powering bells, siren
drivers, etc. Function programmed in address
009.
1
2
3
4
5
6
7
8
AC
–
+
–
+
AC
AUX
PO1 PO1: Shorts to Auxiliary (-) when activated. Can sink
up to 1 A. Programmed in Address 009.
EARTH GROUND: Connected to a good earth
ground and to the cabinet cover.
AUXILIARY POWER: Provides 12 VDC, special
application, up to 1 A for powering detectors.
30
29
28
27
R
RH
TH
T

DS7080iP-32 Reference Guide Copyright © 2001 Detection Systems, Inc. P/N 39818D Page 7
4.0 System Worksheet

Page 8 P/N 39818D Copyright © 2001 Detection Systems, Inc. DS7080iP-32 Reference Guide
4.0 System Worksheet (continued)

DS7080iP-32 Reference Guide Copyright © 2001 Detection Systems, Inc. P/N 39818D Page 9
5.0 System Overview
•Description: The DS7080iP-32 Control/Communicator is a fully
integrated hard-wire security and residential fire alarm system.
- It can support up to 8 input zones, two partitions, 24 individual
users, and multiple output options.
- Up to 4 keypads may be used to provide user interface with the
system, as well as programming access for the installer.
•Zone: A zone is an input to the DS7080iP-32 Control/
Communicator. There are 8 hard-wired zones on the main circuit
board.
•Zone 1: This zone can be programmed as a Fire or Burglar zone.
It is the only zone capable of supplying power to 2-wire smoke
detectors.
- When programmed as a Burglar zone, an alarm results on an
open or short when the control panel is armed.
- If trouble is programmed, a trouble report is generated, and the
zoneisconsidered“Not Ready”only whenthezone isdisarmed.
- For Fire zone operation, see the Fire zone description in the
Glossary.
•Zones 2 - 32: These zonescan beprogrammed asFire orBurglar
zones.
- When programmed as a Burglar zone, an alarm results on an
open or short when the control panel is armed.
- If trouble is programmed, a trouble report is generated, and the
zoneisconsidered“Not Ready”only whenthezone isdisarmed.
- For Fire zone operation, see the Fire zone description in the
Glossary.
•Cross-Zoning: Each on-board zone (zones 1-8) may be cross-
zoned with any or all of the other on-board zones. You cannot
cross-zone with the expansion module (EX8) zones.
When a pair of zones (A and B OR B and A) are cross-zoned, an
alarm condition is not generated unless:
1) Both A and B are in alarm simultaneously, or
2) B is in alarm within N seconds of the clearing of A or A is in
alarm within N seconds of the clearing of B, where N is the time
programmed in address 006. This allows for a one-way trip
pattern.
If two zones are cross-zoned to each other (A with B AND B with A)
analarmcondition isnot onlygeneratedbyconditions 1and 2above,
but also if:
3) A is in alarm within N seconds of the clearing of B. This allows
for a two-way trip pattern.
An alarm condition will be generated any time the above
criteria is met.
- Zone overlap required. Each zone shall have the ability to
individually protect the intended area (i.e. motion detector
patterns overlap).
- The following zone types can be cross-zoned:
• Perimeter Instant (1)
• 24 Hour (2)
• Interior Home/Away (6)
• Interior Instant (7)
• Day Monitor (8)
• Interior Delay (D)
• Perimeter Homeguard (E)
- The following zone types cannot be cross-zoned:
• Disabled (0)
• Entry/Exit Delay #1 (3)
• Entry/Exit Delay #2 (4)
• Interior Entry/Exit Follower (5)
• Keyswitch Toggle (9)
• Keyswitch On/Off(A)
• Fire Zone with Verification (B)
• Fire Zone without verification (C)
• Perimeter Follower Homeguard (F)
4) Cross-zoning across partitions is not supported.
5) Cross-zoning with different zone types is not supported.
6) If the trip window is 000, the cross-zone time will be the duration
ofthe armcycle ofthe crossednon-24hour zones.24 hourzones
will have a 24 hour duration.
• Trouble Zone (TRBL): This non-supervised (requires no End Of
Lineresistor) zoneisintended for theuseof simpletamperdevices.
If tripped, this zone will generate a Control Trouble/System Fault.
This trouble will clear when the Trouble Zone loop is un-faulted.
- Trouble Zone is disabled by default.
- Trouble Zone has two modes of operation: Normally Open and
Normally Closed.
•EX8 Expansion Module: Up to three (3) EX8 Expansion Modules
(24 additional zones) may be added to the system. They must be
set for Option Bus Addresses 101, 102 and 103 respectively (see
the EX8 Installation Guide P/N 39565 for module addresses).It is
important that each module be set with a different address.Failure
to do so will result in improper communications with the EX8
modules and the zones associated with them.
•DS7488 Octal Relay:Ifinstalled, theoptionalDS7488 OctalRelay
will provide fixed outputs for predetermined panel conditions.The
DS7488 Octal Relay attaches to the keypad bus and must be set
for Option Bus Address 9.
Octal relay outputs will not operate during the first two
minutes after powering up the control panel.
The fixed outputs are:
-Output 1 - Zone Alarm: Follows any zone alarm (except Silent
and Invisible zones). Remains On until the zone restores, the
bell cutoff time expires or [PIN] + [Off] is entered.
-Output 2 - Zone Trouble: Follows any zone trouble. Latches
ON when any zone is in an abnormal condition.
-Output 3 - System Reset: Activates for 8 seconds when the
[PIN] + [System Reset] command is entered at any keypad.
-Output 4 - Panic/Duress: Latches ON when the Panic (C) key
is pressed for 2 seconds on any keypad or when a Duress
Code is entered into any keypad. The relay is released when
the command [PIN] + [Off] is entered at any keypad.
-Output 5 - System Trouble: This relay is ON when a system
trouble has occurred. Releases when the system trouble is
cleared.
-Output 6 - Low Battery:The relay is ON during a Low Battery
condition.
-Output 7 - Partial Arm: In a non-partitioned system the relay
isON when thesystem ispartially armed (ForceArm,Perimeter
Arm or zones bypassed). In a partitioned system, the relay is
ON when any partition is partially armed. The relay is reset
when the system (or partition) is disarmed or is fully armed.
-Output 8 - Armed: In a non-partitioned system the relay is ON
when the system is armed to any level. In a partitioned system,
the relay is ON when both partitions are armed to any level.
The relay is reset when the system or any partition is disarmed.

Page 10 P/N 39818D Copyright © 2001 Detection Systems, Inc. DS7080iP-32 Reference Guide
6.0 Glossary
6.1 Zone Programming
• Invisible Alarms: This is a zone programmed not to have an
alarm output or an alarm display (except when arming) at any
keypad when activated. Invisible Alarm zones are recommended
for holdup alarms. An alarm signal will be sent, but the keypad
display will not indicate an alarm while this zone is violated.
•Silent Alarms: This is a zone programmed to activate the visual
display at the keypad, but not audible signals.
- If this zone is also an entry zone, an entry tone will sound when
this zone is activated.
•Bypassing Allowed: This zone can be bypassed (shunted).This
is done using the bypass command ([PIN] + [Bypass] + [2-Digit
Zone Number]) or the force arming sequence ([PIN] + [Arming
Sequence] + [Bypass]).
•Alarm on Short: This zone will activate an alarm when its loop is
shorted.
•Alarm on Open: This zone will activate an alarm when its loop is
opened.
•Trouble on Open: Thisisa zoneprogrammedtoactivateatrouble
when its loop is opened and the system is disarmed.
- If the system is armed, this zone will activate an alarm if shorted
or opened.
- For 24-hour zones, regardless of the arming state of the panel,
this always remains as a Trouble on Open.
•Trouble on Short: Works like Trouble on Open, but activates a
trouble when shorted and disarmed.
•Perimeter Instant: This is a zone programmed to activate an
alarm even during the entry/exit delay period.
•24-Hour Zone: This is a zone programmed to activate when its
loop is faulted, even if the system is disarmed.
•Entry/Exit Delay #1: This zone is ignored during the entry/exit
delay period.
- If it is violated while the system is armed, it will activate a delay
for the amount of time programmed in Entry Delay Time #1.
The keypad pre-alert sounders will activate and the system
may be disarmed during this delay period.
- If the system is not disarmed during the entry period, this zone
will activate an alarm.
- If, at the end of an Exit delay, an entry/exit delay zone is faulted,
an exit error condition will activate.
- The Entry delay will begin as above and any outputs
programmed to follow burglar alarms will activate.
- Ifthe systemis notdisarmedduring thisdelayperiod, thecontrol
panel will send an alarm report and an exit error report.
- If the system is disarmed during this delay period, the alarm
outputs will deactivate and no alarm report will be sent.
• Entry/Exit Delay #2: Works in the same manner as the Entry/
Exit Delay #1 zone, except that it uses Entry Delay Time #2.
If both Entry/Exit delays have been activated, the control
will use the shorter delay.
• Interior Entry/Exit Follower: This is a zone programmed to be
ignored during an entry/exit delay and then become an interior
instant zone.
- If this zone is violated while the system is armed and no entry/
exit zones have been violated, it will activate an instant alarm.
- If this zone is violated after an entry/exit delay zone is violated,
it will follow that entry/exit delay time.
- This zone is bypassed when arming only the perimeter.
• Interior Home/Away: This zonebecomes anactiveinterior entry/
exit follower when the system is armed and an entry/exit delay
zone is violated during the exit delay time.
- If the system is armed and an entry/exit delay zone is not
violated, this zone will be bypassed.
- This zone is bypassed when arming only the perimeter.
• Interior Instant: This is an instant zone that does not use entry
delays. This zone is bypassed when arming only the perimeter.
• Day Monitor: This isa perimeter instantzonethat activatesalarm
outputs when the system is armed, but only activates the keypad
sounders when the system is disarmed.
- When the system is disarmed, any violation of this zone will
activate the keypad sounders which will sound continuously
until a disarming command is entered. The alarm outputs will
not operate.A trouble report (if programmed) will be sent to the
central station.
- A day monitor violation will be recorded in the alarm history.
• Keyswitch Input: This zone allows the system to be armed or
disarmed using a Normally Open momentary keyswitch (toggle
mode) or an on/off switch wired across the keyswitch zone.
- In toggle mode, each time the keyswitch input is shorted, the
arming state of the control panel will toggle.
- In the on/off mode, the control panel will arm when the zone is
shorted and will disarm when the zone is supervised.
- May be programmed to allow force arming.
- In the on/off mode, may be bypassed for keypad arming.
- Keyswitch zones should be programmed for trouble on open.
- If the keyswitch zone circuit is cut, a zone trouble and an alarm
(if armed) will be generated on this zone. Alarm output for this
zone is fixed at on steady.
- An output should be used for an LED to indicate armed/
disarmed status and for a sounder to indicate entry/exit delays.
• Fire Zone: This zonecauses afire alarm whenactivated,whether
the system is armed or disarmed.
- It can be silenced (but not reset) by entering a valid [PIN with
disarming privileges] + [Off].
- A fire alarm will be displayed on all keypads.
- A fire reset command [PIN] + [System Reset] must be entered
after silencing the alarm to re-enable this zone. It is important
to not use the panel during the 8 second reset period.
- If a fire alarm is not reset within 24 hours of the alarm being
silenced, “Fire Alarm…Not Reset” will appear on the display
with the keypad beeping every 10 seconds.
- If this zone is programmed for trouble and the loop opens, the
keypads willindicatea“FireTrouble”forthiszone andthe keypad
sounders will beep once every ten seconds.
- If the system is a combination fire and burglar alarm, the fire
alarm has priority over the burglar alarm.
• Fire Zone with Verification: This zone is identical to a fire zone
except that after the first alarm, it will perform a fire reset and
then wait up to two minutes for a second alarm.
- If a second alarm occurs within this two minute period, the
system will instantly signal a fire alarm.
- If there is no second alarm within this two minute period, the
control panel will reset back to its normal condition.
Use of this control’s alarm verification feature may not be
permitted in your area. Check local codes.
