Detection Systems DS9447 User manual

General Information
The DS9447 is a 4-wire Alpha-Numeric LCD keypad. It may
be surface mounted, mounted to standard single or double
gang boxes, or to 4 inch square boxes.
The following is a chart of general wiring guidelines:
Keypad Addresses
Important: Each keypad must have its address set with its
address pins. The keypads must also be
programmed at the control panel.
•Select the keypad address (1-15).
Place the shorting jumpers over the address pins as
shown at the top of the next column.
Remember: Each keypad must have its own address, and
each address can only support one device.
Mounting
The keypad should be mounted no higher than shoulder
height of the shortest person using the system.
•Remove the keypad’s cover.
Insert a small flat-head screwdriver in each slot at the
bottom of the base. Press up, and pull the cover off.
•Surface Mounting:
Use the base as a template and mark the location of the
mounting holes (use any holes).
Provide an opening in the mounting surface for the wiring.
Pre-start the mounting screws.
Do not secure the base at this point.
•Electrical Box Mounting:
See the diagram on page 2 to select the mounting holes.
Do not secure the base at this point.
Installation Instructions
for the
DS9447 Control Station / Keypad
Wire Gage 22 AWG (0.8 mm) minimum.
18 AWG (1 mm) is required for
NEC-NFPA-72.
Wire Type non-shielded, 4-wire
Max number of
keypads allowed
per system
4
Max distance
allowed between
the control and
the keypad
1,000 feet (304.8 m)
Max distance of
keypad wiring
per system
4,000 feet (1219.2 m)
1 2 4 8
1 2 4 8
1 2 4 8
1 2 4 8
1 2 4 8
address 1
address 4
address 7
address 10
address 13
1 2 4 8
1 2 4 8
1 2 4 8
1 2 4 8
1 2 4 8
address 2
address 5
address 8
address 11
address 14
1 2 4 8
1 2 4 8
1 2 4 8
1 2 4 8
1 2 4 8
address 3
address 6
address 9
address 12
address 15
DS9447
Alarm
Silenced
Power
Trouble
1 2 3
4 5 6
7 8 9
0
Program*#
Command
Silence
Disable
History
Test
Drill
Reset
Clear

Wiring
Caution: Be sure all wiring is unpowered before routing.
Keypad wiring can not be shared with multi-
plex, options bus, telephone, or siren wiring.
•Route wiring from the control panel to the keypads.
Important: Up to 2 keypads may be placed along any
single 1,000 foot run of 22 AWG (.8 mm) wire.
Three keypads may be used on any single
1,000 foot run of 18 AWG (1 mm) wire.
•Bring the wiring through the Wire Entrance in the keypad’s
base.
•Secure the base.
•Connect the wiring to the keypad’s terminal strip.
•Place the keypad cover onto the base.
While feeding the excess wiring out of the rear of the
base, press the cover straight in until it latches on.
Instruction Label and Slide
An instruction label is provided and needs to be placed onto
the pull-out slide. The slide may be installed to pull from the
left or right (slide it into rear of base). Be careful when
installing the label; place it as close to the pull-tab as
possible.
In Case of Trouble
See the following chart:
Keypad Notification Possible Cause
Continuous keypad
sounder PLUS “System
Fault”display
• The yellow and green wires have been
disconnected.
• The keypad has not been programmed
properly at the control panel.
• The control panel has malfunctioned.
Replace the control panel.
Control panel does not
respond to keypad input. • A keypad’s address has not been set with
its address pins.
Three beep error tone on
all keypads. • Invalid keypad input.
Copyright © 2001 Detection Systems, Inc.
DS9447 Installation Instructions
P/N 31124D Page 2 of 2
Wire
entrance
Singlegang
mounting slots
(2)
Doublegang
mounting slots
(4)
Donotuseasa
wireentrance
4"squarebox
mounting holes
(4)
K
eypa
d B
ase
R
B
G
Y
1 2 4 8
Address Pins
TerminalStrip
R
ear
Vi
ewo
f PCB
Donotuse
thispin
R
B
G
Y
Option BusAorB
+12
Com
DataIn
DataOut
R
B
G
Y
Keypad
LabelLabel
Label
Slide ineitherside
(writing on otherside)
